Development and operational control of two string maximum power point trackers in dc distribution systems
•Download as DOC, PDF•
0 likes•160 views
This paper develops an operational control system for two maximum power point trackers used with two photovoltaic string panels in a DC distribution system connected to the AC grid via a bidirectional inverter. The paper introduces a topology for the MPPTs that uses buck and boost converters to handle the wide output voltage range of the PV panels. It also presents methods for online checking of the PV string configuration, maximum power point tracking using perturbation and observation, and current balancing of the two parallel MPPT modules. Experimental results are provided to validate the configuration check and current balancing, as well as to demonstrate maximum power tracking performance and power conversion efficiency.
