Debugging big data analytics in Data-Intensive Scalable Computing (DISC) systems is a time-consuming effort. Today’s DISC systems offer very little tooling for debugging and, as a result, programmers spend countless hours analyzing log files and performing trial and error debugging. To aid this effort, UCLA developed BigDebug, an interactive debugging tool and automated fault localization service to help Apache Spark developers in debugging big data analytics. To emulate interactive step-wise debugging without reducing throughput, BigDebug provides simulated breakpoints that enable a user to inspect a program without actually pausing the entire distributed computation. It also supports on-demand watchpoints that enable a user to retrieve intermediate data using a guard predicate and transfer the selected data on demand. To understand the flow of individual records within a pipeline of RDD transformations, BigDebug provides data provenance capability, which can help understand how errors propagate through data processing steps. To support efficient trial-and-error debugging, BigDebug enables users to change program logic in response to an error at runtime through a realtime code fix feature, and selectively replay the execution from that step. Finally, BigDebug proposes an automated fault localization service that leverages all the above features together to isolate failure-inducing inputs, diagnose the root cause of an error, and resume the workflow for only affected data and code. The BigDebug system should contribute to improving Spark developerproductivity and the correctness of their Big Data applications. This big data debugging effort is led by UCLA Professors Miryung Kim and Tyson Condie, and produced several research papers in top Software Engineering and Database conferences. The current version of BigDebug is publicly available at https://sites.google.com/site/sparkbigdebug/.

1. Debugging Big Data Analytics in
Apache Spark with BigDebug
MATTEO INTERLANDI - MUHAMMAD ALI GULZAR

2. Open Source Data-Intensive Scalable Computing (DISC)
Platforms: Hadoop MapReduce and Spark
◦ Severe lack of debugging support in these systems
◦ Programs (i.e., queries, jobs) are batch executed / black boxes
So what to do?
◦ Trial and error debugging on subsample
◦ Post-mortem analysis of error logs
◦ Analyze physical view of the execution (a job id, failed node, etc).
Debugging Cloud Computing Programs

3. BigDebug Project Overview
Titian: Data Provenance for Fine-
Grained Tracing
[PVLDB 2016]
Vega: Incremental Computation for
Interactive Debugging
[SoCC 2016]
Collaboration with Tyson Condie, Miryung Kim, and Todd Millstein
BigDebug: Debugging Primitives
for Interactive Big Data Processing
in Spark
[ICSE 2016]
Automated Debugging in Data
Intensive Scalable Computing
Systems
[Under Submission]

4. Simulated Breakpoint1
BigDebug: Interactive Debugger Features

5. Simulated Breakpoint1
Guarded Watchpoint2
BigDebug: Interactive Debugger Features

6. Simulated Breakpoint1
Guarded Watchpoint2
Crash Culprit Identification3
BigDebug: Interactive Debugger Features

7. Simulated Breakpoint1
Guarded Watchpoint2
Crash Culprit Identification3
Backward Tracing4
BigDebug: Interactive Debugger Features
$>Crash inducing input records:
9K23 Cruz TX 1440023645
2FSD Cruz KS 1440026456
9909 Cruz KS 1440023768

8. Simulated Breakpoint1
Guarded Watchpoint2
Crash Culprit Identification3
Backward Tracing4
Automated Fault Localization5
BigDebug: Interactive Debugger Features
Test Fails
Split
Test PassesTest Fails
…
..
.

9. Feature 1:
Simulated
Breakpoint
Stage 0 Stage 1
map
simulated
breakpoint
groupByKey
map
map

10. Feature 1:
Simulated
Breakpoint
Simulated breakpoint enables user to inspect intermediate
program state without pausing the computation

11. Feature 2: On Demand
Guarded Watchpoint map
simulated
breakpoint
map
map
groupBy
Key
Stage 0
Stage 1
watch
point

12. Feature 2: On Demand
Guarded Watchpoint
A user can inspect intermediate data using a guard
and also update it on the fly

13. Feature 3: Crash Culprit
Identification and
Remediation
map
simulated
breakpoint
map
Stage 0
Stage 1
watch
point
map
groupBy
Key

14. Feature 3: Crash Culprit
Identification and
Remediation
A user can use BigDebug to identify the crashing records
and remediate from the failure

15. Feature 4: Backward Tracing
Data Provenance enables users to identify crash inducing
inputs records

16. Feature 5: Automated Fault Localization
Goal: Given a test function and set of failing results
◦ Identify the minimum set of input records that can reproduce the failure
After all is said
and done more is
said than done
than done
done more is
said
After all is
said and
After
all
is
said
and
done
more
is
said
than
done
(After,1)
(all,1)
(is,1)
(said,1)
(and,1)
(done,1)
(more,1)
(is,1)
(said,1)
(than,1)
(done,1)
(After,1)
(all,1)
(is,2)
(and,1)
(more,1)
(said,2)
(than,1)
(done,2)
After,1
all, 1
is, 2
and, 1
more, 1
said, 2
done, 2
than, 1
FlatMap Map ReduceByKey CollectTextFile
Task 1
Task 3
Task 1
Task 3
Task 2Task 2
Stage 2Stage 1

17. Feature 5: Automated Fault Localization
Goal: Given a test function and set of failing results
◦ Identify the minimum set of input records that can reproduce the failure
◦ We apply data provenance and delta debugging in tandem
After all is said
and done more is
said than done
than done
done more is
said
After all is
said and
After
all
is
said
and
done
more
is
said
than
done
(After,1)
(all,1)
(is,1)
(said,1)
(and,1)
(done,1)
(more,1)
(is,1)
(said,1)
(than,1)
(done,1)
(After,1)
(all,1)
(is,2)
(and,1)
(more,1)
(said,2)
(than,1)
(done,2)
After,1
all, 1
is, 2
and, 1
more, 1
said, 2
done, 2
than, 1
FlatMap Map ReduceByKey CollectTextFile
Task 1
Task 3
Task 1
Task 3
Task 2Task 2
Stage 2Stage 1

18. We apply data provenance and delta debugging [Zeller et al. ] in tandem
Feature 5: Automated Fault Localization

19. We apply data provenance and delta debugging [Zeller et al. ] in tandem
Feature 5: Automated Fault Localization
Test

20. We apply data provenance and delta debugging [Zeller et al. ] in tandem
Feature 5: Automated Fault Localization
Test Split

21. We apply data provenance and delta debugging [Zeller et al. ] in tandem
Feature 5: Automated Fault Localization
Test Split
In average BigDebug is able to localize faults within 63% of
the original job running time

22. We apply data provenance and delta debugging [Zeller et al. ] in tandem
Feature 5: Automated Fault Localization
….
Test Split
In average BigDebug is able to localize faults within 63% of
the original job running time
In average BigDebug is able to localize faults within 63% of
the original job running time

23. Demo

24. Running Example
val log = "s3n://xcr:wJY@ws/logs/enroll.log"
val text_file = sc.textFile(log)
text_file
.map{line=>(line.split()[2],line.split()[3])}
.map{t => (t._1 , getYears(t._2))}
.groupByKey()
.map(v => (v._1 , average(v._2)))
.collect()
1 Michael Sophomore 03/12/1996
2 Justin Freshman 05/01/1998
.. .. ..
