As the core SQL processing engine of the Greenplum Unified Analytics Platform, the Greenplum Database delivers Industry leading performance for Big Data Analytics while scaling linearly on massively parallel processing clusters of standard x86 servers. This session reviews the product's underlying architecture, identify key differentiation areas, go deep into the new features introduced in Greenplum Database Release 4.2, and discuss our plans for 2012.

1. Greenplum Database
Overview
Michael Crutcher
Greenplum Product Management
© Copyright 2012 EMC Corporation. All rights reserved. 1

2. © Copyright 2012 EMC Corporation. All rights reserved. 2

3. © Copyright 2012 EMC Corporation. All rights reserved. 3

4. © Copyright 2012 EMC Corporation. All rights reserved. 4

5. Greenplum Unified Analytic Platform
© Copyright 2012 EMC Corporation. All rights reserved. 5

6. GREENPLUM DATABASE
Industry Leading Database with
Massively Parallel Performance
To Empower your Analytics
© Copyright 2012 EMC Corporation. All rights reserved. 6

7. GREENPLUM DATABASE
Extreme Performance for Analytics
 Optimized for BI and analytics
– Deep integration with statistical packages
– High performance parallel implementations
• Simple and automatic
– Just load and query like any database
– Tables are automatically distributed
across nodes
• Extremely scalable
– MPP shared-nothing architecture
– All nodes can scan and process in parallel
– Linear scalability by adding nodes
© Copyright 2012 EMC Corporation. All rights reserved. 7

8. GREENPLUM DATABASE
Performance Through Parallelism
Master
Servers ... ...
Query planning &
dispatch
Network
Interconnect
Segment
Servers ... ...
Query processing
& data storage
External
Sources
Loading,
streaming, etc.
© Copyright 2012 EMC Corporation. All rights reserved. 8

9. GREENPLUM DATABASE
Greenplum Delivers Choice & Flexibility
Greenplum Data Greenplum
Computing Appliance Software Solutions
Choose Greenplum  Greenplum
Database and/or Database, Hadoop,
Hadoop modules in & Chorus on your
¼ rack increments x86 hardware
Scale up by adding  Flexibility for any
your choice of workload or
additional modules environment
Minimal time to value  Perpetual or
subscription licenses
© Copyright 2012 EMC Corporation. All rights reserved. 9

10. Core Functionality
GREENPLUM DATABASE
© Copyright 2012 EMC Corporation. All rights reserved. 10

11. GREENPLUM DATABASE
Component Overview
CLIENT ACCESS 3rd PARTY TOOLS ADMIN TOOLS
CLIENT ACCESS ODBC, JDBC, OLEDB, BI Tools, ETL Tools Greenplum Command Center
& TOOLS MapReduce, etc. Data Mining, etc Greenplum Package Manager
LOADING & EXT. ACCESS STORAGE & DATA ACCESS LANGUAGE SUPPORT
Petabyte-Scale Loading Hybrid Storage & Execution Comprehensive SQL
(Row- & Column-Oriented)
Trickle Micro-Batching Native MapReduce
PRODUCT Anywhere Data Access
In-Database Compression
SQL 2003 OLAP Extensions
FEATURES Multi-Level Partitioning
Programmable Analytics
Indexes – Btree, Bitmap, etc.
Analytics Extensions
External Table Support (GeoSpatial, PR/R, PL/Java,
PL/Python, PL/Perl)
GREENPLUM Multi-Level Fault Tolerance
DATABASE ADAPTIVE (RAID, Mirroring, DR with Online System Expansion Workload Management
SERVICES Data Domain Boost)
Shared-Nothing MPP Parallel Dataflow Engine
CORE MPP
Parallel Query Optimizer gNet™ Software Interconnect
ARCHITECTURE
Polymorphic Data Storage™ Scatter/Gather Streaming™ Data Loading
© Copyright 2012 EMC Corporation. All rights reserved. 11

12. GREENPLUM DATABASE
Most Powerful Data Loading Capabilities
SINGLE RACK COMPARISON
 Industry leading performance
at 10+TB per-hour per-rack
 Scatter-Gather Streaming™
provides true linear scaling
 Support for both large-batch and
continuous real-time loading
strategies Greenplum Oracle Netezza Teradata
Exadata
 Enable complex data
transformations ―in-flight‖ Greenplum load rates scale linearly with
the number of racks, others do not.
 Transparent interfaces to loading For example, two racks = >20TB/H
via support files, application, and
services
© Copyright 2012 EMC Corporation. All rights reserved. 12

13. GREENPLUM DATABASE
Polymorphic Table StorageTM
TABLE ‗CUSTOMER‘
Mar Apr May Jun Jul Aug Sept Oct Nov
‗11 ‗11 ‗11 ‗11 ‗11 ‗11 ‗11 ‗11 ‗11
Column-oriented for COLD DATA Row-oriented for HOT DATA
• Storage types can be mixed within a table or database
– Four table types: heap, row-oriented AO, column-oriented AO,
external
• Rich compression functionality, definable column by column
– Block compression: Gzip (levels 1-9), QuickLZ
– Stream compression: RLE (levels 1-4)
• Flexible indexing, partitioning, and more
© Copyright 2012 EMC Corporation. All rights reserved. 13

14. GREENPLUM DATABASE
gNet Software Interconnect
 A supercomputing-based ―soft-switch‖
responsible for
– Efficiently pumping streams of data between motion
nodes during query-plan execution
– Delivers messages, moves data, collects results, and
coordinates work among the segments in the system
gNet Software
Interconnect
© Copyright 2012 EMC Corporation. All rights reserved. 14

15. GREENPLUM DATABASE
Parallel Query Optimizer
PHYSICAL EXECUTION PLAN
 Cost-based optimization FROM SQL OR MAPREDUCE
looks for the most Gather Motion
efficient plan
4:1(Slice 3)
Sort
 Physical plan contains
scans, joins, sorts,
HashAggregate
aggregations, etc. HashJoin
 Global planning avoids Redistribute Motion
4:4(Slice 1) Hash
sub-optimal ‘SQL
HashJoin HashJoin
pushing’ to segments
Seq Scan on
 Directly inserts ‘motion’
Seq Scan on
lineitem Hash Hash
customer
nodes for inter-segment Seq Scan on
orders
Broadcast Motion
4:4(Slice 2)
communication Seq Scan on
motion
© Copyright 2012 EMC Corporation. All rights reserved. 15

16. Analytics Overview
GREENPLUM DATABASE
© Copyright 2012 EMC Corporation. All rights reserved. 16

17. GREENPLUM DATABASE
Analytical Capabilities Overview
Data Access & Query Layer ODBC JDBC
SQL
Stored SQL 2003 In-Database
MapReduce
Procedures OLAP Analytics
GREENPLUM
HD
Polymorphic Storage
GREENPLUM DATABASE
Greenplum gNet
© Copyright 2012 EMC Corporation. All rights reserved. 17

18. GREENPLUM DATABASE
In-Database Analytics: Categories
Data Access & Query Layer ODBC JDBC
SQL
In-Database Analytics
Embedded
SAS Scoring
Accelerator
Partner GPDB User-Written
Open Source
Embedded Analytical
Extensions
Analytics SAS/HPA Algorithms
Open-Source High Performance
Analytics
User-written
GREENPLUM DATABASE
© Copyright 2012 EMC Corporation. All rights reserved. 18

19. GREENPLUM DATABASE
Analytics Highlight: MADlib
 Scalable in-database
analytics
 Data-parallel
– Mathematical Algorithms
– Statistical Algorithms
– Machine learning Algorithms
– Supports structured and
unstructured data.
 Open-source software
– Source Accessibility
– Converge business,
academic, and open-source
communities
© Copyright 2012 EMC Corporation. All rights reserved. 19

20. Manageability, Extensions
GREENPLUM DATABASE
© Copyright 2012 EMC Corporation. All rights reserved. 20

21. GREENPLUM DATABASE
Easy Manageability for Big Data
 Single console for both Database and Hadoop
 Administration
– Start, Stop Database
– Recover, Rebalance Segments
 Interactive view of System Metrics
– Real-time
– Historic (Configurable by time period)
 In-depth view for System Health
– Hardware health
– Software (Database, Hadoop)
 Query Monitoring
– Search, Prioritize, Cancel Queries
– View Query‘s Execution Plan
 Workload Management
– Configure Resource Queues
– Prioritize Users
© Copyright 2012 EMC Corporation. All rights reserved. 21

22. GREENPLUM DATABASE
Easy Extension Installation
Greenplum Package Manager
Greenplum supports easy deployment
of numerous extensions like Madlib,
PL/Perl, PL/Java, PostGIS, etc.
Master
Servers
Segment ...
Servers ...
© Copyright 2012 EMC Corporation. All rights reserved. 22

23. GREENPLUM DATABASE
High Performance gNet for Hadoop
Parallel Query Access
 Connect any data set in Hadoop to
GP DB‘s SQL Engine
 Process Hadoop data in place
 Parallelize import/export data
from/to Hadoop thanks to GP DB‘s
market leading data sharing
performance
gNet for Hadoop  Supported formats:
– Text (compressed and
uncompressed)
– binary
User-
Text Binary
Defined
– proprietary/user-defined
 GP HD 1.x, GP MR 1.x, CDH3u2
© Copyright 2012 EMC Corporation. All rights reserved. 23

24. High Availability,
Back up, Support
GREENPLUM DATABASE
© Copyright 2012 EMC Corporation. All rights reserved. 24

25. GREENPLUM DATABASE
High Availability
 GPDB cluster
– 2 Master servers
– Multiple Segment servers
 Segment servers support
multiple database
instances
– Primary instances that
actively process queries
– Standby mirror instances
 Block level mirroring
– Low resource
Set of Active
consumption Segment Instances
– Differential resynch
capable for fast recovery
© Copyright 2012 EMC Corporation. All rights reserved. 25

26. GREENPLUM DATABASE
Backup/Restore with EMC Data Domain
 Integration options
– NFS: Data Domain device mounted
Full
Appliance
as NFS storage
+
Data Domain
– DD Boost: Native, client-side
deduplication. Supported in GPDB
4.2 and higher
Boost or NFS
 Drastic reduction in backup storage
requirement
2 X 10GBit IP
 Backup all segment servers in
parallel directly to Data Domain
 Data Domain Integrates seamlessly
into standard Greenplum full
backup data export and data
restore procedures
© Copyright 2012 EMC Corporation. All rights reserved. 26

27. GREENPLUM DATABASE
Backup/Restore with EMC Data Domain
Backup and restore between remote and primary sites
Greenplum DCA Greenplum DCA
Data Domain Data Domain
LAN/WAN
Data Domain
Replication
 Ideal for configurations with RPO and RTO requirements that can be specified in hours
 Supports:
– Collection Replication for DD Boost backup
– Directory-level replication for NFS backup
– Encryption over the WAN
© Copyright 2012 EMC Corporation. All rights reserved. 27

28. GREENPLUM DATABASE
Customer Support Services
• Remote Technical Support
– 24x7 technical support and remote troubleshooting
– Customer-managed case severity level
– Four-hour response objective
• Onsite Support (DCA Only)
– Installation of replacement parts
– Replacement parts shipped for next business day arrival
– GP SW upgrade included
• Proactive Service
– Secure remote monitoring for hardware (DCA)
– Notification of engineering technical advisories
– Built-in tools maximize stability and performance
• Secure Self-Help
– 24x7 access to eService support tools including
knowledgebase, forums, and appropriately licensed
software updates
© Copyright 2012 EMC Corporation. All rights reserved. 28

29. GREENPLUM DATABASE
Other Relevant Greenplum Sessions
Session Presenter Times
Unified Analytics Platform Introduction Brian Wilson Tues 10:00-11:00 Thurs 1:00-2:00
Greenplum Hadoop Overview Susheel Kaushik Mon 10:00-11:00 Wed 4:15-5:15
Greenplum DCA Overview Hanxi Chen Mon 4:00-5:00 Thurs 10:00-11:00
Greenplum Analytics Workbench Apurva Desai Wed 8:30-9:30 Thurs 10:00-11:00
Analytics on Hadoop Don Miner Tues 11:30-12:30 Thurs 8:30-9:30
Big Data Driven Businesses in Action: Mike Maxey Wed 4:15-5:15 Thurs 11:30-12:30
Creating Real Business Value Using
Greenplum UAP (Panel w/4 Customers)
Analytics for Business Value: Collaboration Josh Klahr Mon 10:00-11:00 Wed 2:45-3:45
Disruptive Data Science — How Data Annika Jimenez Tues 4:15-5:15 Thurs 11:30-12:30
Science and Big Data are Transforming David Dietrich
Business, IT and People
© Copyright 2012 EMC Corporation. All rights reserved. 29

30. Thank You
© Copyright 2012 EMC Corporation. All rights reserved. 30
