1) Kubernetes operators can simplify deploying data warehouses like ClickHouse from a single specification and provide portability, fast deployment, and flexible resource management. 2) While the Kubernetes operator model reduces overhead, ensuring data safety remains a challenge as data warehouses are complex and losing data is problematic. 3) Future work includes developing data warehouses as a service on Kubernetes with multi-tenancy, high availability, security, and optimized resource utilization, as well as enhancing ClickHouse to better match Kubernetes' cloud-native execution model.

1. DATA WAREHOUSE AND
KUBERNETES:
LESSONS FROM THE
CLICKHOUSE
OPERATOR
Robert Hodges -- August 2019

2. Brief Intros
www.altinity.com
Leading software and services
provider for ClickHouse
Major committer and community
sponsor in US and Western Europe
Robert Hodges - Altinity CEO
30+ years on DBMS plus
virtualization and security.
ClickHouse is DBMS #20

3. Why run data warehouse on Kubernetes?
1. Same environment as other cloud native services
2. Portability
3. Fast deployment cycles
4. Flexible mapping to resources

4. ClickHouse
Data
Warehouse

5. Introduction to ClickHouse
Understands SQL
Runs on bare metal to cloud
Shared nothing architecture
Stores data in columns
Parallel and vectorized execution
Scales to many petabytes
Is Open source (Apache 2.0)
a b c d
a b c d
a b c d
a b c d
And it’s really fast!

6. ClickHouse structure is optimized for speed
Table
Part
Index Columns
Indexed
Sorted
Compressed
Part
Index Columns
Part

7. ClickHouse has built-in sharding & replication
ClickHouse
event_loc
ClickHouse
event
event_loc
ClickHouse
event_loc
ClickHouse
event_loc
ClickHouse
event_loc
ClickHouse
event_loc
SELECT ...
FROM event
GROUP BY ...
Result Set
Zookeeper
ZNodes
Zookeeper
ZNodes
Zookeeper
ZNodes

8. Kubernetes

9. “Kubernetes is the new Linux”
Actually it’s an open-source platform to:
● manage container-based systems
● build distributed applications declaratively
● allocate machine resources efficiently
● automate application deployment

10. A typical distributed service
Load
Balancer
Service
#1
Service
#3
Service
#2
Storage
Storage
Storage
Traffic

11. Defined using Kubernetes resources
Pod
“svc-1”
Persistent
Volume
Service
“svc”
Stateful
Set
Persistent
Volume
Claim
Persistent
Volume
Persistent
Volume
Pod
“svc-2”
Pod
“svc-2”
Persistent
Volume
Claim
Persistent
Volume
Claim
Config
Maps
SecretsConfig
Maps
Secrets

12. Kubernetes NodeKubernetes NodeKubernetes Node
Mapped to proxies, containers, and storage
Container
“svc-1”
NVMe
SSD
NGINX
“svc”
Container
“svc-2”
Container
“svc-3”
NVMe
SSD
NVMe
SSD

13. ClickHouse
Operator

14. ClickHouse on Kubernetes is complex!
Zookeeper
Services
Zookeeper-0
Zookeeper-2
Zookeeper-1Shard 1 Replica 1
Replica
Service
Load
Balancer
Service
Shard 1 Replica 2
Shard 2 Replica 1
Shard 2 Replica 2
Replica
Service
Replica
Service
Replica
Service
User Config Map Common Config Map
Stateful
Set
Pod
Persistent
Volume
Claim
Persistent
Volume
Per-replica Config Map

15. Operators encapsulate complex deployments
kube-system namespace
ClickHouse
Operator
your-favorite namespace
Apache 2.0 source,
distributed as Docker
imageSingle specification
Best practice deployment
ClickHouse
Resource
Definition

16. Basic data warehouse topology
apiVersion: "clickhouse.altinity.com/v1"
kind: "ClickHouseInstallation"
metadata:
name: "ch01"
spec:
configuration:
clusters:
- name: replicated
layout:
shardsCount: 2
replicasCount: 2
zookeeper:
nodes:
- host: zookeeper.zk
Name used to identify all resources
Definition of cluster
Location of service we depend on

17. Simplicity requires defaults
defaults:
templates:
volumeClaimTemplate: persistent
podTemplate: clickhouse:19.6
serviceTemplate: minikube
templates:
volumeClaimTemplates:
- name: persistent
spec:
accessModes:
- ReadWriteOnce
resources:
requests:
storage: 10Gi
Name of template
Storage misconfigurations
lead to insidious errors

18. Templates can be simple, too
defaults:
templates:
volumeClaimTemplate: persistent
podTemplate: clickhouse:19.6
serviceTemplate: minikube
templates:
podTemplates:
- name: clickhouse:19.6
spec:
containers:
- name: clickhouse-pod
image: yandex/clickhouse-server:19.6.2.11
Name of template
Most values take
defaults

19. templates:
podTemplates:
- name: clickhouse-in-zone-us-east-1b
spec:
affinity:
nodeAffinity:
requiredDuringSchedulingIgnoredDuringExecution:
nodeSelectorTerms:
- matchExpressions:
- key: "failure-domain.beta.kubernetes.io/zone"
operator: In
values:
- "us-east-1b"
containers:
- name: clickhouse-pod
image: yandex/clickhouse-server:19.3.7
Or specify complex configuration
Set availability
zone affinity
More container
properties

20. Versatile mapping to different deployments
ClickHouse
Resource
Definition
Pod
Load
Balance
PodPod
Pod Pod
Load
BalanceLoad
Balance
Load
BalanceLoad
Balance
Pod Pod
Load
BalanceLoad
Balance
Pod Pod
Minikube Multi-AZ Deployment
(Differences mostly
in templates)

21. Changes are recognized automatically
defaults:
templates:
volumeClaimTemplate: persistent
podTemplate: clickhouse:19.11
serviceTemplate: minikube
templates:
podTemplates:
- name: clickhouse:19.11
spec:
containers:
- name: clickhouse-pod
image: yandex/clickhouse-server:19.11.3.11
Make new version
the default
Define template
for new version

22. Upgrade runs while service is online
Pod
chi-0-0
Update resource definition
ClickHouse
Operator
Apply Pod
chi-0-1
Pod
chi-1-1
Pod
chi-1-0
Compare resource
to actual state
Upgrade pods sequentially
ClickHouse
Resource
Definition

23. Grafana
ClickHouse monitoring with prometheus
ClickHouse
Operator
(ServiceMonitor)
ClickHouse Installations
Prometheus

24. Demo Time
Fast data warehouse
deployment on Kubernetes

25. Lessons from
Operator
Development

26. Pod
chi-0-1
Surprise! DNS is different in Kubernetes
Pod
chi-1-1 Pod
chi-0-1
Pod
chi-1-0
Pod
chi-0-0
DNS DNS
DNS
Restart
Pod restart invalidates
cluster DNS mappings
Core DNS
Server
Name resolution
deadlock at startup
Must resolve
host name
to start up
Won’t resolve
host until
pod starts

27. Kubernetes overhead is minimal (whew!)
Cluster deploy and load Query Comparison
Redshift dc2.large vs. Kubernetes EC2 r5.xlarge with EBS (st1)

28. No surprise: error handling is complicated
ClickHouse
Operator
ClickHouse
Resource
Definition
Complex
specification
Kubernetes
Storage
Provider
Asynchronous
execution
Local
semantics

29. Biggest challenge
Data warehouses are not cattle
Losing/compromising data is bad
Safety is paramount
Security, migration, availability require logic
above level of the operator

30. Biggest gain
Kubernetes democratizes data
warehouse access
Set up complex configurations in minutes
Map data warehouse flexibly to resources
Integrate easily with other services

31. Wrap-up

32. Conclusions
● Kubernetes operators set up DW from single specification
● ClickHouse experience validates Kubernetes value:
○ Every application can have a data warehouse!
○ Portable
○ Fast deployment
○ Flexible resource management
● Kubernetes operator alone is not enough for all use cases

33. Future Work
● Data warehouse as a service on Kubernetes
○ Multi-tenancy
○ Data availability
○ Security
○ Optimized resource utilization
● Extend ClickHouse to match cloud native execution model
○ Decouple storage and compute
○ Rebalance data on scale-up/down

34. Thank you!
We’re hiring!
Presenter:
rhodges@altinity.com
ClickHouse Operator:
https://github.com/Altinity/clickhouse-operator
ClickHouse:
https://github.com/yandex/ClickHouse
Altinity:
https://www.altinity.com
