Chapter_1._Basics_of_Heat_Transfer.pdf
1. Department of Mechanical Engineering
Institute of Engineering
Central Campus, Pulchowk
Prepared by
Umesh Sharma
2. THERMODYNAMICS AND HEAT TRANSFER
• Heat: The form of energy that can be transferred from one system to another as a
result of temperature difference.
• Thermodynamics is concerned with the amount of heat transfer as a system
undergoes a process from one equilibrium state to another.
• Heat Transfer deals with the determination of the rates of such energy transfers as
well as variation of temperature.
2
• The transfer of energy as heat is always from the higher-temperature medium to the
lower-temperature one.
• Heat transfer stops when the two mediums reach the same temperature.
• Heat can be transferred in three different modes:
conduction, convection, radiation
3. Energy can exist in numerous forms such as:
thermal,
mechanical,
kinetic,
potential,
electrical,
HEAT AND OTHER FORMS OF ENERGY
3
electrical,
magnetic,
chemical,
nuclear.
Their sum constitutes the total energy E (or e on a unit mass basis) of
a system.
The sum of all microscopic forms of energy is called the internal
energy of a system.
4. Internal energy: May be viewed as the sum of the kinetic and potential energies
of the molecules.
Sensible heat: The kinetic energy of the molecules.
Latent heat: The internal energy associated with the phase of a system.
Chemical (bond) energy: The internal energy associated with the atomic bonds
in a molecule.
Nuclear energy: The internal energy associated with the bonds within the
nucleus of the atom itself.
4
nucleus of the atom itself.
What is thermal energy?
What is the difference between thermal energy
and heat?
5. Internal Energy and Enthalpy
In the analysis of systems that
involve fluid flow, we frequently
encounter the combination of
properties u and Pv.
The combination is defined as
enthalpy (h = u + Pv).
5
enthalpy (h = u + Pv).
The term Pv represents the flow
energy of the fluid (also called the
flow work).
6. Specific Heats of Gases, Liquids, and Solids
Specific heat: The energy required to raise the
temperature of a unit mass of a substance by one
degree.
Two kinds of specific heats:
specific heat at constant volume cv
specific heat at constant pressure c
6
specific heat at constant pressure cp
The specific heats of a substance, in general,
depend on two independent properties such as
temperature and pressure.
At low pressures all real gases approach ideal
gas behavior, and therefore their specific heats
depend on temperature only.
7. Incompressible substance: A substance
whose specific volume (or density) does
7
whose specific volume (or density) does
not change with temperature or pressure.
The constant-volume and constant-pressure
specific heats are identical for
incompressible substances.
The specific heats of incompressible
substances depend on temperature only.
8. Energy Transfer
Energy can be transferred to or from a given mass
by two mechanisms:
heat transfer and work.
Heat transfer rate: The amount of heat
transferred per unit time.
Heat flux: The rate of heat transfer per unit area
normal to the direction of heat transfer.
when is constant:
8
normal to the direction of heat transfer.
Power: The work
done per unit time.
9. THE FIRST LAW OF THERMODYNAMICS
The first law of thermodynamics (conservation of energy
principle) states that energy can neither be created nor destroyed during a
process; it can only change forms. The net change (increase or decrease)
in the total energy of the system during
a process is equal to the difference
between the total energy entering and
the total energy leaving the system
9
The energy balance for any system
undergoing any process in the rate
form
the total energy leaving the system
during that process.
10. In heat transfer problems it is convenient to
write a heat balance and to treat the conversion
of nuclear, chemical, mechanical, and electrical
energies into thermal energy as heat generation.
10
11. Energy Balance for Closed Systems (Fixed Mass)
A closed system consists of a fixed mass.
The total energy E for most systems
encountered in practice consists of the internal
energy U.
This is especially the case for stationary systems
since they don’t involve any changes in their
velocity or elevation during a process.
11
velocity or elevation during a process.
12. Energy Balance for Steady-Flow
Systems
A large number of engineering devices such as water
heaters and car radiators involve mass flow in and out of
a system, and are modeled as control volumes.
Most control volumes are analyzed under steady
operating conditions.
The term steady means no change with time at a
specified location.
12
specified location.
Mass flow rate: The amount of mass flowing through a
cross section of a flow device per unit time.
Volume flow rate: The volume of a fluid flowing
through a pipe or duct per unit time.
13. HEAT TRANSFER MECHANISMS
Heat as the form of energy that can be transferred from one system to another as a
result of temperature difference.
A thermodynamic analysis is concerned with the amount of heat transfer as a
system undergoes a process from one equilibrium state to another.
The science that deals with the determination of the rates of such energy transfers
is the heat transfer.
13
The transfer of energy as heat is always from the higher-temperature medium to the
lower-temperature one, and heat transfer stops when the two mediums reach the
same temperature.
Heat can be transferred in three basic modes:
conduction
convection
radiation
All modes of heat transfer require the existence of a temperature difference.
14. CONDUCTION
Conduction: The transfer of energy from the more
energetic particles of a substance to the adjacent less
energetic ones as a result of interactions between the
particles.
In gases and liquids, conduction is due to the collisions and
diffusion of the molecules during their random motion.
In solids, it is due to the combination of vibrations of the
molecules in a lattice and the energy transport by free
14
Heat conduction through a large
plane wall of thickness x and
area A.
molecules in a lattice and the energy transport by free
electrons.
The rate of heat conduction through a plane layer is
proportional to the temperature difference across the layer
and the heat transfer area, but is inversely proportional to
the thickness of the layer.
15. When x → 0 Fourier’s law of heat conduction
Thermal conductivity, k: A measure of the ability of a
material to conduct heat.
Temperature gradient dT/dx: The slope of the
temperature curve on a T-x diagram.
Heat is conducted in the direction of decreasing
temperature, and the temperature gradient becomes
negative when temperature decreases with increasing x.
15
negative when temperature decreases with increasing x.
The negative sign in the equation ensures that heat
transfer in the positive x direction is a positive quantity.
The rate of heat conduction
through a solid is directly
proportional to its thermal
conductivity.
In heat conduction
analysis, A represents the
area normal to the
direction of heat transfer.
16. Thermal Conductivity
Thermal conductivity: The
rate of heat transfer through
a unit thickness of the
material per unit area per
unit temperature difference.
A high value for thermal
conductivity indicates that
16
conductivity indicates that
the material is a good heat
conductor, and a low value
indicates that the material is
a poor heat conductor or
insulator.
A simple experimental setup to
determine the thermal
conductivity of a material.
18. Thermal Diffusivity
cp Specific heat, J/kg · °C: Heat capacity per unit
mass
cp Heat capacity, J/m3·°C: Heat capacity per
unit volume
Thermal diffusivity, m2/s: Represents how fast
heat diffuses through a material
A material that has a high thermal conductivity or a low heat capacity will obviously have
18
A material that has a high thermal conductivity or a low heat capacity will obviously have
a large thermal diffusivity.
The larger the thermal diffusivity, the faster the propagation of heat into the medium.
A small value of thermal diffusivity means that heat is mostly absorbed by the material
and a small amount of heat is conducted further.
19. CONVECTION
Convection: The mode of energy
transfer between a solid surface
and the adjacent liquid or gas that
is in motion, and it involves the
combined effects of conduction
and fluid motion.
The faster the fluid motion, the
19
The faster the fluid motion, the
greater the convection heat
transfer.
In the absence of any bulk fluid
motion, heat transfer between a
solid surface and the adjacent fluid
is by pure conduction.
Heat transfer from a hot surface to air by
convection.
20. Forced convection: If the fluid
is forced to flow over the
surface by external means such
as a fan, pump, or the wind.
Natural (or free) convection:
If the fluid motion is caused by
buoyancy forces that are
induced by density differences
due to the variation of
20
due to the variation of
temperature in the fluid.
The cooling of a boiled egg by forced
and natural convection.
Heat transfer processes that involve change of phase of a fluid are also considered to be
convection because of the fluid motion induced during the process, such as the rise of
the vapor bubbles during boiling or the fall of the liquid droplets during condensation.
21. Newton’s law of cooling
h convection heat transfer coefficient, W/m2 · °C
As the surface area through which convection heat transfer takes place
Ts the surface temperature
T the temperature of the fluid sufficiently far from the surface.
The convection heat transfer
coefficient h is not a property of the
fluid.
It is an experimentally determined
21
It is an experimentally determined
parameter whose value depends on
all the variables influencing
convection such as
- the surface geometry
- the nature of fluid motion
- the properties of the fluid
- the bulk fluid velocity
22. RADIATION
• Radiation: The energy emitted by matter in the form of electromagnetic waves (or
photons) as a result of the changes in the electronic configurations of the atoms or
molecules.
• Unlike conduction and convection, the transfer of heat by radiation does not require the
presence of an intervening medium.
• In fact, heat transfer by radiation is fastest (at the speed of light) and it suffers no
attenuation in a vacuum. This is how the energy of the sun reaches the earth.
22
attenuation in a vacuum. This is how the energy of the sun reaches the earth.
• In heat transfer studies we are interested in thermal radiation, which is the form of
radiation emitted by bodies because of their temperature.
• All bodies at a temperature above absolute zero emit thermal radiation.
• Radiation is a volumetric phenomenon, and all solids, liquids, and gases emit, absorb, or
transmit radiation to varying degrees.
• However, radiation is usually considered to be a surface phenomenon for solids.
23. Stefan–Boltzmann law
= 5.670 108 W/m2 · K4 Stefan–Boltzmann constant
Blackbody: The idealized surface that emits radiation at the maximum rate.
Emissivity : A measure of how closely a
surface approximates a blackbody for which
= 1 of the surface. 0 1.
Radiation emitted by
real surfaces
23
Blackbody radiation represents the maximum amount of
radiation that can be emitted from a surface at a
specified temperature.
= 1 of the surface. .
24. Absorptivity : The fraction of the radiation energy incident on a surface that is
absorbed by the surface. 0 1
A blackbody absorbs the entire radiation incident on it ( = 1).
Kirchhoff’s law: The emissivity and the absorptivity of a surface at a given
temperature and wavelength are equal.
24
The absorption of radiation incident on an
opaque surface of absorptivity .
25. Net radiation heat transfer: The
difference between the rates of
radiation emitted by the surface and
the radiation absorbed.
The determination of the net rate of
heat transfer by radiation between
two surfaces is a complicated
matter since it depends on
• the properties of the surfaces
When a surface is completely enclosed by a much
larger (or black) surface at temperature Tsurr
separated by a gas (such as air) that does not
intervene with radiation, the net rate of radiation
heat transfer between these
two surfaces is given by
25
• the properties of the surfaces
• their orientation relative to each
other
• the interaction of the medium
between the surfaces with radiation
Radiation is usually significant relative to
conduction or natural convection, but
negligible relative to forced convection.
26. Combined heat transfer coefficient hcombined
Includes the effects of both convection and radiation
When radiation and convection occur simultaneously
between a surface and a gas:
26
27. SIMULTANEOUS HEAT TRANSFER MECHANISMS
Heat transfer is only by conduction in opaque solids, but by
conduction and radiation in semitransparent solids.
A solid may involve conduction and radiation but not
convection. A solid may involve convection and/or radiation
on its surfaces exposed to a fluid or other surfaces.
Heat transfer is by conduction and possibly by radiation in a
still fluid (no bulk fluid motion) and by convection and
27
Although there are three mechanisms
of heat transfer, a medium may
involve only two of them
simultaneously.
still fluid (no bulk fluid motion) and by convection and
radiation in a flowing fluid.
In the absence of radiation, heat transfer through a fluid is
either by conduction or convection, depending on the presence
of any bulk fluid motion.
Convection = Conduction + Fluid motion
Heat transfer through a vacuum is by radiation.
