Sergiy Dudkovskyy, Product manager, Fujitsu Technology Solutions (Armenia, Azerbaijan, Belarus, Georgia, Moldova, Ukraine) – Building up cloud infrastructure? It is easy!

1. Building up cloud infrastructure?
It is easy!
Implementing private cloud infrastructures with
ServerView Resource Orchestrator Cloud Edition (ROR CE)
Minsk
April 2012
1 Copyright 2011 FUJITSU

2. Stuck in the IT Bermuda Triangle
I expect IT to
be a lever for
CEO driving our
We can’t deliver business
IT projects in
time, because
service levels
don’t meet our
expectations
Users IT I expect IT to
reduce cost
CFO
IT operations are desperately seeking ways to escape from restrictions
Time
2 Copyright 2011 FUJITSU

3. The Way Forward?
Evolution
Evolve towards more
business-centric IT !
Time
Business-centric IT means applying IT to maximize business value
Time
3 Copyright 2011 FUJITSU

4. ServerView Resource Orchestrator: At a glance
Benefit from improved
Create an on-premise operational efficiency
private cloud  Higher productivity
infrastructure  Reduced CAPEX & OPEX
 Higher agility
Evolve towards more
dynamic IT
environments
Efficiently manage a
consolidated server
environment
ROR VE
ROR CE
ServerView Resource Orchestrator (ROR) is the one tool to best help
manage your journey to business centric IT. Time
4 Copyright 2011 FUJITSU

5. ServerView Resource Orchestrator
Cloud Edition (ROR CE)
5 Copyright 2011 FUJITSU

6. ROR CE: Focus on IaaS
SaaS Applications
PaaS Application Oriented Middleware
IaaS ServerView Resource Orchestrator
Accounting/Billing
Cloud Self-service Portal Subscription Workflow Mgmt.
NEW Service
Management Service Catalog Dashboard Metering
Dynamic
Resource Orchestration Multi-Tenancy HA/DR
Management
Pool Server Mgmt. Storage Mgmt. Network Mgmt.
Management
Resource
Pools
Server Storage Network
6 Copyright 2011 FUJITSU

7. The Building Blocks of a Dynamic IT Environment
Infra- Automated User
 Organize resources into pools Resource
Pools
structure
Templates
Provisio-
ning
Logical
Platform
Multi-
tenancy
& role
mgmt.
 Logically describe resources
Global Resource Pools Tenant A L-Platform
 L-Server/L-Platform templates
Server Pool
 Automate provisioning of real VM Host
Pool
Hypervisor
L-Platform
Storage Pool
resources based on logical Template
Network Pool
descriptions Server
Pool
Automation
 Covers physical and virtual Image Pool
(multi-hypervisor) environments Storage
Pool
Address Pool
 Integrate security operations Tenant B L-Platform
 User and role management Network VM HostPool
Pool
 Multi-tenant support L-Platform
Storage Pool Template
 Provide multiple high-availability Image
Pool
OS
Automation
options Network Pool
 Server and storage failover Address
Pool
Virtual I/O
Addresses Image Pool
 Disaster recovery
Infrastructure Administration Service Administration
ROR CE provides dynamic resource management across servers,
storage and networks.
7 Copyright 2011 FUJITSU

8. ROR CE: Role-based Operations
Separation of service and infrastructure administrative roles
Service administration domain
Service Tiered application infrastructure
administrators L-Server L-Server
concentrate Web1 App1
on application L-Server Net1 L-Server Net1 L-Server
Web2 App2 DB1
management L-Server L-Server L-Server
(roll-out, Infrastructure Web3 App3 DB2
operation, administrators
maintenance) concentrate on
delivering
Template 1 L-Platform Template 2 L-Platform Template 3 L-Platform
resources
into pools
OS Image Network
Pool Pool
Virtual I/O Address
Server Pool Pool
Physical Storage
Server Pool Pool
Infrastructure administration domain
ROR CE allows each expert to focus on their core competences
8 Copyright 2011 FUJITSU

9. ROR CE: Multi-tenancy
Admin A Admin B
L-Platform L-Platform
A1 B1
L-Platform L-Platform
Operator A2 B2 Operator
A B
Resource Resource
pool A pool B
Tenant A Tenant B
User A1 User A2 User B1 User B2
ROR CE enables resource isolation for different user groups
9 Copyright 2011 FUJITSU

10. ROR CE: Resource Availability
Easy setup of physical Blade chassis and
or virtual server HA storage system failover Disaster recovery
Physical Blade Chassis Blade Chassis Blade Chassis Blade
and virtual OS OS VM VM
chassis
server … … failover
failover
SAN SAN
Storage Storage
Production site DR site
Blade Chassis Manager Manager
OS OS VM VM Blade Chassis Blade Chassis
… …
SAN SAN SAN
Storage
system Disaster
Storage Storage Storage Storage
failover recovery
ROR CE provides efficient high-availability options.
10 Copyright 2011 FUJITSU

11. ROR CE: Cloud Service Management
Create Services
Create template Publish in portal
Request Services
Select Approve Provision
Monitor Services
Dashboard Metering
11 Copyright 2011 FUJITSU

12. IT Infrastructure Provisioning Today and Tomorrow
ROR CE accelerates provisioning of IT infrastructures
12 Copyright 2011 FUJITSU

13. ROR CE Support Matrix – Extract*
Managed Servers1  PRIMERGY BX, RX, TX2 and CX2 Servers
 PRIMEQUEST 18002
 Selected 3rd-party x86 servers from HP, IBM, Dell2
Operating Systems  Microsoft Windows Server 2003 (SP2) (x86, x86-64)
(native)  Microsoft Windows Server 2008 (x86, x86-64)
 Novell SUSE SLES 102, 11 (x86, x86-64)
 Red Hat Enterprise Linux 5.x / 6.x (x86, x86-64)
 Oracle Enterprise Linux 5.x / 6.0 (x86, x86-64)2
Hypervisors  VMware Infrastructure 3, VMware vSphere 4, 5
 Microsoft Windows Server 2008 Hyper-V
 Red Hat KVM
 Oracle VM 2.2.1
Storage  ETERNUS, Netapp, EMC
Network (FC)  Internal FC switches supported in PRIMEGRY BX blade servers
 External FC switches: Brocade
Network (LAN)  Internal LAN switches supported in PRIMEGRY BX blade servers
 External LAN switches: Cisco Catalyst series
 Firewalls: Cisco ASA 5500 series
1) Partly supported only in virtualized environments *for further details, please see ROR CE data sheet
2) On special request
13 Copyright 2011 FUJITSU

14. DI Blocks
14 Copyright 2011 FUJITSU

15. The Next Evolution in IT?
I really like ROR CE and want to
setup a private cloud infrastructure
as fast as possible !
Standardization
Drive standardization in building and delivering IT infrastructure
Time
15 Copyright 2011 FUJITSU

16. DI Blocks: The IT Infrastructure Appliance
 Pre-defined, pre-tested DI Blocks
scalable building blocks
Orchestration
consisting of HW and SW
 Holistic management for
physical and virtual servers, Resource Management
storage and networks
 Quality assured IT Solutions Logical Server
 Services and support with
SolutionContract Virtual Physical
Server Server
 Life-cycle management for
the complete infrastructure
Server Network Storage
16 Copyright 2011 FUJITSU

17. DI Blocks: Benefits
 Reduced implementation risk for private cloud infrastructures
 Shorter time to production for new IT projects
 Improved availability and consistency of private cloud infrastructure
throughout the life time
DI Blocks – Taking several steps in one, towards the cloud
Time
17 Copyright 2011 FUJITSU

18. Roadmap
18 Copyright 2011 FUJITSU

19. Roadmap and vision towards the cloud*
2012+
2012
Hybrid Cloud
Q2/2012
 Enable integration
Public Cloud of private & public
Q1/2012 cloud services
 Enable setup of
DI Blocks public cloud  Integration with
Q3/2011 infrastructures Fujitsu Trusted
based on ROR
 Accounting/Billing Cloud or 3rd-party
Private Cloud  Enable improved
 SLA Management Public Cloud
 Enable setup of time to production
services
Dynamic Resource private cloud for cloud
Mgmt. infrastructures infrastructures
 Enable greater  Multi-tier system  Pre-integrated,
operational deployment pre-tested IT
efficiency and  Self-service portal infrastructure
agility for IaaS  Includes hardware,
 IT infrastructure  Dashboard – software, services
orchestration monitoring of and advanced life-
resource states cycle mgmt.
 Metering
ROR V2.3 ROR V3.0 ROR Vx.x + further SW
* Subject to change without notice!
19 Copyright 2011 FUJITSU

20. Global Cloud
20 Copyright 2011 FUJITSU

21. Global Cloud – Service Outline
Virtual private system environment within the large scale resources of Fujitsu DC
Resource pool
Fujitsu DC
Internet
Customers
Virtual system
 Create a scaling system
 Create systems with a load balancer and firewall
 Customers can login as an administrator of virtual machines OS
21 Copyright 2011 FUJITSU

22. Four Key Features
Safety &
Simplified Design On-demand Service Portal Reliability
 Select system  Create / delete,  Create /  Data Protection
configuration and increase / customize by redundancy,
from the System decrease servers / performance
Template Library servers / storages on the warranty for VM
 Secure storages, at any Service Portal resources and
environment time when  Monitor status / VPN connection
which protects necessary trend, start /
against any  Hourly-based stop VMs and
threat coming charge system operate backup/
from Internet restore on the
Service Portal
22 Copyright 2011 FUJITSU

23. Global Cloud – Virtual Machine Offerings
Economy Standard
 CPU: 1.0 GHz  CPU: 1 x 2.0 GHz
 Memory: 1.7 GB  Memory: 3.4 GB
 System partition: 10 – 40 GB  System partition: 10 – 40 GB
 Data partition: extendable  Data partition: extendable
up to 1 TB / HDD up to 1 TB / HDD
Advanced High Performance
 CPU: 1 x 4.0 GHz  CPU: 2 x 4.0 GHz
 Memory: 7.5 GB  Memory: 15 GB
 System partition: 10 – 40 GB  System partition: 10 – 40 GB
 Data partition: extendable  Data partition: extendable
up to 1 TB / HDD up to 1 TB / HDD
23 Copyright 2011 FUJITSU

24. Three Network Topologies
Subnet Controllable traffic Conceptual diagram
1-Tier  Internet  DMZ Internet
Fire
DMZ
Wall
2-Tier  Internet  DMZ Internet
 DMZ  Internal netk1 DMZ
Fire
Wall Internal
net 1
3-Tier  Internet  DMZ Internet
 DMZ  Internal net1 DMZ
 DMZ  Internal net2 Fire Internal
 Internal net1  Internal net2 Wall net 1
Internal
net 2
24 Copyright 2011 FUJITSU

25. Global Cloud Offering Summary
Fujitsu Data Center
Resource pool
Provide s customer
dedicated virtual
platforms
Internet
Customers
Virtual platform Environment
Service Offering Key Features
 Virtual datacenter  99.95% availability
 2- or 3-tier system templates  Fujitsu Tier-3 data centers
 Self-service portal and cloud API  Fujitsu technology and IP assets
 Full redundancy  ISO9001:2000 (Quality Mgmt.)
 Hourly charge / pay-per-use  ISO 27001 (Information Security)
 ISO 20000 / ITIL (Service Mgmt.)
 A sustainable cloud (Green IT)
25 Copyright 2011 FUJITSU

26. Local Cloud Extensions – Server Options
Basis – Virtual Server
Hardware
 CPU: 1 × 2.0 GHz Dedicated Server
(extendable up to 4 CPUs)
Hardware (PRIMERGY)
 RAM: 2 GB
(extendable up to 24 GB)  CPU: 1 × Quad-Core /
 System partition: 40 GB 2 × Quad Core
 Data partition (extendable  RAM: 16 GB / 32 GB
up to  1.5 TB HDD)  System partition 2 × 73 GB
 Data partition
Additional Options  Virtualization layer
 Customer can upload
VM-Clone
Additional Options
 Selection of operating system
with OS-Management  Boot process from local hard disk
 Secure Web Server function  Customer can upload VM-Clone
 Backup Server function
26 Copyright 2011 FUJITSU

27. Local Cloud Extensions – Storage Options
Customer Benefits
 Minimal investment
 Cost efficiency
 Latest technology deployed
 Easy entry/low barriers
 SLAs ensuring highest quality
Economy Productivity High Performance
Typical usage Typical usage Typical usage
Backup data, File, web-services, Database, Logfiles
 Sequential read/write  medium size applications 
Technical parameters Technical parameters Technical parameters
SATA, RAID5 7+1 SAS, RAID5 4+1 SAS, RAID 10
  
High availability and secure operation via a virtual infrastructure
offering cost-efficiency and -transparency.
27 Copyright 2011 FUJITSU

28. Comparison Global Cloud – Local Extensions
Feature Global Cloud Local Exensions
Standardized virtual server configurations 
Custom virtual server configurations 
Dedicated server configurations 
Custom storage configurations 
Load-balancing service 
2- and 3-Tier DMZ topologies 
Pre-configured system templates 
API for service orchestration 
Hypervisor Open Source Xen VMware ESX
28 Copyright 2011 FUJITSU

29. Free trial Fujitsu Global Cloud
 http://www.global-cloud.ts.fujitsu.com/freetrial/
29 Copyright 2011 FUJITSU

30. 30 Copyright 2011 FUJITSU
