This document describes a theming system for React components that allows: - Defining themes with styles categorized into types - Components to connect to themes and receive styles as props - Themes to be changed dynamically at runtime - Component styles to be customized through props and overrides - A plugin-based engine to compile styles for different component outputs

1. BuildingaThemingSystemWithReact

2. MatteoRonchi
@cef62 -- github/cef62
Senior Software Engineer at WorkWave

3. Today's Web is all about
Component-basedArchitectures

4. WhyComponents?

5. -Modular
-Scalable
-Extensible
-Reusable
-Encapsulated

6. Componentizationenables
HigherOrderComponents

7. HoCsallowabstractionof
reusableaugmentations

8. Componentizationisaseductive
softwaredevelopmentpractice.
— Maarten Koning - Sep 29, 2006

9. ManyWaysto
StyleComponents

10. PLAINCSS

11. Web pages load Cascading Style Sheets
to learn how to render HTML elements
.red-button {
color: red;
}
<button class="red-button">Red</button>

12. CSS-Modules

13. Allow per-component css rules
greatly improving components portability
.redButton { color: red; }
import css from './styles.css'
const comp = () => <button className={css.redButton}>Red</button>
<!-- HTML output -->
<button class="red_button_7655465hgfhyoda4567">Red</button>

14. InlineStyles

15. Component styling without using CSS
Making it really easy to dynamically change the
visual output based on a component's state
const redButton { color: 'red' }
const comp = () => <button style={redButton}>Red</button>

16. RuntimeGeneratedCSS

17. InrecentyearsCSS-in-JScontinuedtogrowandevolve.
Thecurrentstateoftheartisexpressedbylibrariesas
· Styled Components
· Aphrodite
· Styletron
· Glamour

18. ThoselibrariesdynamicallydefineCSSrules
usingJavascript,JSONorCSSsyntaxes.
GeneratedCSSclassesareinjected
atruntimeintothewebpage.

19. ComponentsTheming

20. In UI development theming is the
definition of reusable sets of visual
styles, aiming to create consistency
across views

21. UI Theming can be done in
so many different ways mostly
depending
on per-project requirements

22. ColorPalettesthesimplestwaytokeepconsistencyacrossviewsandcomponents

23. @nice-blue: #5B83AD;
@light-blue: #98C7F9;
@small: 0.6rem;
@big: 1.3rem;
#header {
color: @light-blue;
font-size: @big;
}
#footer {
color: @nice-blue;
font-size: @small;
}

24. PropsDrivenStylesgreatercustomizationandeasetocreatedynamicstylesdefinition

25. const theme = {
niceBlue: '#5B83AD',
lightBlue: '#98C7F9',
small: '0.6rem',
normal: '1rem',
}
const bgStyle = (p) => p.isFooter ? p.theme.lightBlue : p.theme.niceBlue
const fontStyle = (p) => p.isFooter ? p.theme.small : p.theme.normal
// styled-components
const Button = styled.div`
backgroundColor: ${bgStyle};
border: 2px solid ${fontStyle};
`

26. ColorPalettesandPropsDriven
Stylesaregreat
but we - at WorkWave - looked for something different

27. · change the whole theme at runtime
· support WYSIWYG
· decouple component UI definition from UI
styling
· easy implementable theme variations

28. · support theme variations per-component
branches
· be agnostic on how to create the final output
· support component-based and atomic-css
approaches

29. WorkWaveTheme-Manager

30. TheThemeManagerisresponsibleforsharingthemes
It's possible to subscribe to be notified of theme
changes
enabling a set of components to update
consistently in a easy and transparent way

31. AThemedefinestwomainfields:
styles a map of categories. Each category is a
map of css classes in Javascript notation
presets a map of presets, each preset is used to
programmatically override the main theme
definition

32. const source = {
// Main theme
styles: {
Button: {
button: {
backgroundColor: 'lightpink',
color: 'blue',
padding: '0.6em',
fontWeight: 800,
},
},
},
presets: {
// dark style variation
dark: {
Button: {
button: {
backgroundColor: 'violet',
color: 'white',
},
},
},
},
}
const appTheme = theme(source)

33. const source = {
// Main theme
styles: {
colors: {
normal: { color: 'blue' },
confirm: { color: 'red' },
},
backgrounds: {
normal: { backgroundColor: 'lightpink' },
confirm: { backgroundColor: 'lightgreen' },
},
},
presets: {
// dark style variation
dark: {
colors: {
confirm: { color: 'yellow' },
},
backgrounds: {
confirm: { backgroundColor: 'darkgreen' },
},
}.
},
}
const appTheme = theme(source)

34. A Themed Component expects to receive
a map of css classes as a prop
knowing how to apply those css classes
to its internal implementation

35. ReactBindings

36. <ThemeProvider />

37. Makes available a themeManager instance
to every descendant
A themeManager instance can also be passed
as a prop to every themed component

38. connectTheme()

39. A HoC connecting a React component to
a themeManager instance
connectTheme(config, mapThemeToProps, options)(DecoratedComponent)

40. A themed component declares which
theme categories it's interested in,
and a mapThemeToProps function
const config = { types: ['Header'] }
const mapThemeToProps = ({ Header: { wrapper, label } }) => ({ wrapper, label })
const ThemedHeader = connectTheme(config, mapThemeToProps)(Header)

41. The decorated component will receive
a css prop containing all generated css classes
const Header = ({ css, title }) =>
<div className={css.wrapper}>
<div className={css.label}>{title}</div>
</div>

42. mapThemeToProps is where you are in control
mapThemeToProps(theme, props) -> composed styles

43. const mapThemeToProps = (theme) => {
const { colors, backgrounds } = theme
return {
wrapper: { ...backgrounds.normal },
normalBtn: { ...colors.normal, ...backgrounds.normal },
confirmBtn: { ...colors.confirm, ...backgrounds.confirm },
}
}
const DecoratedComponent = ({ css }) =>
<div className={css.wrapper}>
<button className={css.normalBtn}>Do Something</button>
<button className={css.confirmBtn}>Are You Sure?</button>
</div>

44. const mapThemeToProps = (theme, props) => {
const { colors, backgrounds, disabled } = theme
const { canConfirm } = props
const normalDisabled = canConfirm ? disabled.normal : {}
const confirmDisabled = canConfirm ? disabled.normal : {}
return {
wrapper: { ...backgrounds.normal },
normalBtn: { ...colors.normal, ...backgrounds.normal, ...normalDisabled },
confirmBtn: { ...colors.confirm, ...backgrounds.confirm, ...confirmDisabled },
}
}
const DecoratedComponent = ({ css }) =>
<div className={css.wrapper}>
<button className={css.normalBtn}>Do Something</button>
<button className={css.confirmBtn}>Are You Sure?</button>
</div>

45. The decorated component's interaction with the
theme is customizable using the themeParams
property

46. preset: a theme preset to be applied to
the component branch
themeName: changes the active theme
for the component branch
overrides: a local overrides to the style object
passed to the mapThemeToProps function

47. const themeParams = {
preset: 'dark',
overrides: {
colors: {
normal: {
color: 'white',
fontWeight: 'bold',
},
},
backgrounds: {
normal: {
backgroundColor: 'black',
},
},
}
}
const Comp = () => <MyThemedComp themeParams={themeParams} />

48. PluginBased
OutputEngine

49. The map of styles returned by
mapThemeToProps is passed through a
pluggable compiler
The engine is configurable on per-component
basis

50. PerformancesMatters
Every themed component uses memoization
and strict equality checks to ensure
the compiler is invoked as little as possible

51. Roomforimprovements
The code boilerplate required to create reusable
variations of a themed component feels
excessive
Declaration of expected
theme categories could be more flexible

52. Thanks!
@cef62
