1. Active Learning
COMS 6998-4:
Learning and Empirical Inference
Irina Rish
IBM T.J. Watson Research Center

2. Outline
 Motivation
 Active learning approaches
 Membership queries
 Uncertainty Sampling
 Information-based loss functions
 Uncertainty-Region Sampling
 Query by committee
 Applications
 Active Collaborative Prediction
 Active Bayes net learning
2

3. Standard supervised learning model
Given m labeled points, want to learn a classifier with
misclassification rate <ε, chosen from a hypothesis class H with
VC dimension d < 1.
VC theory: need m to be roughly d/ε, in the realizable case.
3

4. Active learning
In many situations – like speech recognition and document
retrieval – unlabeled data is easy to come by, but there is a
charge for each label.
What is the minimum number of labels needed to achieve the
target error rate? 4

5. 5

6. What is Active Learning?
 Unlabeled data are readily available; labels are
expensive
 Want to use adaptive decisions to choose which
labels to acquire for a given dataset
 Goal is accurate classifier with minimal cost
6

7. Active learning warning
 Choice of data is only as good as the model itself
 Assume a linear model, then two data points are sufficient
 What happens when data are not linear?
7

8. Active Learning Flavors
Selective Sampling Membership Queries
Pool Sequential
Myopic Batch
8

9. Active Learning Approaches
 Membership queries
 Uncertainty Sampling
 Information-based loss functions
 Uncertainty-Region Sampling
 Query by committee
9

10. 10

11. 11

12. Problem
Many results in this framework, even for complicated
hypothesis classes.
[Baum and Lang, 1991] tried fitting a neural net to handwritten
characters.
Synthetic instances created were incomprehensible to humans!
[Lewis and Gale, 1992] tried training text classifiers.
“an artificial text created by a learning algorithm is unlikely to
be a legitimate natural language expression, and probably would
be uninterpretable by a human teacher.”
12

13. 13

14. 14

15. 15

16. Uncertainty Sampling
[Lewis & Gale, 1994]
 Query the event that the current classifier is most
uncertain about
If uncertainty is measured in Euclidean distance:
x x x x x x x x x x
 Used trivially in SVMs, graphical models, etc.
16

17. Information-based Loss Function
[MacKay, 1992]
 Maximize KL-divergence between posterior and prior
 Maximize reduction in model entropy between posterior
and prior
 Minimize cross-entropy between posterior and prior
 All of these are notions of information gain
17

18. Query by Committee
[Seung et al. 1992, Freund et al. 1997]
 Prior distribution over hypotheses
 Samples a set of classifiers from distribution
 Queries an example based on the degree of
disagreement between committee of classifiers
x x x x x x x x x x
A B C
18

19. Infogain-based Active
Learning

20. Notation
We Have:
• Dataset, D
• Model parameter space, W
• Query algorithm, q
20

21. Dataset (D) Example
t Sex Age Test A Test B Test C Disease
0 M 40-50 0 1 1 ?
1 F 50-60 0 1 0 ?
2 F 30-40 0 0 0 ?
3 F 60+ 1 1 1 ?
4 M 10-20 0 1 0 ?
5 M 40-50 0 0 1 ?
6 F 0-10 0 0 0 ?
7 M 30-40 1 1 0 ?
8 M 20-30 0 0 1 ? 21

22. Notation
We Have:
• Dataset, D
• Model parameter space, W
• Query algorithm, q
22

23. Model Example
St Ot
Probabilistic Classifier
Notation
T : Number of examples
Ot : Vector of features of example t
St : Class of example t
23

24. Model Example
Patient state (St)
St : DiseaseState
Patient Observations (Ot)
Ot1 : Gender
Ot2 : Age
Ot3 : TestA
Ot4 : TestB
Ot5 : TestC
24

25. Possible Model Structures
Gender
TestB
Age
Gender
S TestA S TestA
Age
TestB
TestC
TestC
25

26. Model Space
Model: St Ot
Model Parameters: P(St) P(Ot|St)
Generative Model:
Must be able to compute P(St=i, Ot=ot | w)
26

27. Model Parameter Space (W)
• W = space of possible
parameter values
• Prior on parameters: P(W )
• Posterior over models: P (W | D ) ∝ P ( D | W ) P (W )
T
∝ ∏ P ( St , Ot | W ) P(W )
t
27

28. Notation
We Have:
• Dataset, D
• Model parameter space, W
• Query algorithm, q
q(W,D) returns t*, the next sample to label
28

29. Game
while NotDone
• Learn P(W | D)
• q chooses next example to label
• Expert adds label to D
29

30. Simulation
O1 O2 O3 O4 O5 O6 O7
e
S2 fals e
S1 = S3 S4 S5 true
= S6 S7 fals
=
S2 S5 S7
?
?
hmm…
?
q
30

31. Active Learning Flavors
• Pool
(“random access” to patients)
• Sequential
(must decide as patients walk in the door)
31

32. q?
• Recall: q(W,D) returns the “most
interesting” unlabelled example.
• Well, what makes a doctor curious about a
patient?
32

33. 1994
33

34. Score Function
scoreuncert ( S t ) = uncertainty(P ( St | Ot ))
= H ( St )
= ∑ P ( St = i ) log P( St = i )
i
34

35. Uncertainty Sampling Example
t Sex Age Test Test Test St P(St) H(St)
A B C
1 M 20-
30
0 1 1 ? 0.02 0.043
2 F 20-
30
0 1 0 ? 0.01 0.024
3 F 30-
40
1 0 0 ? 0.05 0.086
4 F 60+ 1 1 0 ?
FALSE 0.12 0.159
5 M 10-
20
0 1 0 ? 0.01 0.024
6 M 20-
30
1 1 1 ? 0.96 0.073
35

36. Uncertainty Sampling Example
t Sex Age Test Test Test St P(St) H(St)
A B C
1 M 20-
30
0 1 1 ? 0.01 0.024
2 F 20-
30
0 1 0 ? 0.02 0.043
3 F 30-
40
1 0 0 ? 0.04 0.073
4 F 60+ 1 1 0 ?
FALSE 0.00 0.00
5 M 10-
20
0 1 0 ?
TRUE 0.06 0.112
6 M 20-
30
1 1 1 ? 0.97 0.059
36

37. Uncertainty Sampling
GOOD: couldn’t be easier
GOOD: often performs pretty well
BAD: H(St) measures information gain about the
samples, not the model
Sensitive to noisy samples
37

38. Can we do better than
uncertainty sampling?
38

39. 1992
Informative with
respect to what?
39

40. Model Entropy
P(W|D) P(W|D) P(W|D)
W W W
H(W) = high …better… H(W) = 0
40

41. Information-Gain
• Choose the example that is expected to
most reduce H(W)
• I.e., Maximize H(W) – H(W | St)
Current model Expected model space
space entropy entropy if we learn St
41

42. Score Function
score IG ( St ) = MI ( St ;W )
= H (W ) − H (W | St )
42

43. We usually can’t just sum over all models to
get H(St|W)
H (W ) = − ∫ P ( w) log P ( w) dw
w
…but we can sample from P(W | D)
H (W ) ∝ H (C )
= −∑ P (c) log P (c)
c∈C
43

44. Conditional Model Entropy
H (W ) = ∫ P ( w) log P ( w) dw
w
H (W | St = i ) = ∫ P ( w | St = i ) log P ( w | St = i ) dw
w
H (W | St ) = ∑ P ( St = i ) ∫ P( w | S t = i ) log P ( w | St = i ) dw
w
i
44

45. Score Function
score IG ( St ) = H (C ) − H (C | St )
45

46. t Sex Age Test Test Test St P(St) Score =
A B C H(C) - H(C|St)
1 M 20-3 0 1 1
0
? 0.02 0.53
2 F 20-3 0 1 0
0
? 0.01 0.58
3 F 30-4 1 0 0
0
? 0.05 0.40
4 F 60+ 1 1 1 ? 0.12 0.49
5 M 10-2 0 1 0
0
? 0.01 0.57
20-3
6 M
0
0 0 1 ? 0.02 0.52
46

47. Score Function
score IG ( St ) = H (C ) − H (C | St )
= H ( St ) − H ( St | C )
Familiar?
47

48. Uncertainty Sampling &
Information Gain
scoreUncertain ( St ) = H ( St )
score InfoGain ( St ) = H ( St ) − H ( St | C )
48

49. But there is a problem…
49

50. If our objective is to reduce
the prediction error, then
“the expected information gain
of an unlabeled sample is NOT
a sufficient criterion for
constructing good queries”
50

51. Strategy #2:
Query by Committee
Temporary Assumptions:
Pool  Sequential
P(W | D)  Version Space
Probabilistic  Noiseless
 QBC attacks the size of the “Version space”
51

52. O1 O2 O3 O4 O5 O6 O7
S1 S2 S3 S4 S5 S6 S7
FALSE!
FALSE!
Model #1 Model #2
52

53. O1 O2 O3 O4 O5 O6 O7
S1 S2 S3 S4 S5 S6 S7
TRUE! TRUE!
Model #1 Model #2
53

54. O1 O2 O3 O4 O5 O6 O7
S1 S2 S3 S4 S5 S6 S7
FALSE!
TRUE! Ooh, now we’re going to learn
something for sure!
One of them is definitely wrong.
Model #1 Model #2
54

55. The Original QBC
Algorithm
As each example arrives…
• Choose a committee, C, (usually of size 2)
randomly from Version Space
• Have each member of C classify it
• If the committee disagrees, select it.
55

56. 1992
56

57. Infogain vs Query by Committee
[Seung, Opper, Sompolinsky, 1992; Freund, Seung, Shamir, Tishby 1997]
First idea: Try to rapidly reduce volume of version space?
Problem: doesn’t take data distribution into account.
H:
Which pair of hypotheses is closest? Depends on data distribution P.
Distance measure on H: d(h,h’) = P(h(x) ≠ h’(x)) 57

58. Query-by-committee
First idea: Try to rapidly reduce volume of version space?
Problem: doesn’t take data distribution into account.
To keep things simple, say d(h,h’) = Euclidean distance
H:
Error is likely to
remain large!
58

59. Query-by-committee
Elegant scheme which decreases volume in a manner which is
sensitive to the data distribution.
Bayesian setting: given a prior π on H
H1 = H
For t = 1, 2, …
receive an unlabeled point xt drawn from P
[informally: is there a lot of disagreement about xt in Ht?]
choose two hypotheses h,h’ randomly from (π, Ht)
if h(xt) ≠ h’(xt): ask for xt’s label
set Ht+1
59
Problem: how to implement it efficiently?

60. Query-by-committee
For t = 1, 2, …
receive an unlabeled point xt drawn from P
choose two hypotheses h,h’ randomly from (π, Ht)
if h(xt) ≠ h’(xt): ask for xt’s label
set Ht+1
Observation: the probability of getting pair (h,h’) in the inner
loop (when a query is made) is proportional to π(h) π(h’) d(h,h’).
vs.
60
Ht

61. 61

62. Query-by-committee
Label bound:
For H = {linear separators in Rd}, P = uniform distribution,
just d log 1/ε labels to reach a hypothesis with error < ε.
Implementation: need to randomly pick h according to (π, Ht).
e.g. H = {linear separators in Rd}, π = uniform distribution:
How do you pick a
Ht random point from a
convex body?
62

63. Sampling from convex bodies
By random walk!
2. Ball walk
3. Hit-and-run
[Gilad-Bachrach, Navot, Tishby 2005] Studies random walks and
also ways to kernelize QBC.
63

64. 64

65. Some challenges
[1] For linear separators, analyze the label complexity for
some distribution other than uniform!
[2] How to handle nonseparable data?
Need a robust base learner
+ true boundary
-
65

66. Active Collaborative Prediction

67. Approach: Collaborative Prediction (CP)
QoS measure (e.g. bandwidth) Movie Ratings
Server1 Server2 Server3 Matrix Geisha Shrek
Client1 3674 18 Alina ? 1 3
Client2 187 567 Gerry 4 2
Client3 1688 Irina 9 10
Client4 3009 703 ? Raja 4
Given previously observed ratings R(x,y), where X is a
“user” and Y is a “product”, predict unobserved ratings
- will Alina like “The Matrix”? (unlikely )
- will Client 86 have fast download from Server 39?
- will member X of funding committee approve our project Y? 
67

68. Collaborative Prediction = Matrix Approximation
100 servers
• Important assumption:
100 clients
matrix entries are NOT independent,
e.g. similar users have similar tastes
• Approaches:
mainly factorized models assuming
hidden ‘factors’ that affect ratings
(pLSA, MCVQ, SVD, NMF, MMMF, …)
68

69. 2 4 5 1 4 2
User’s ‘weights’ Factors
associated with ‘factors’’
Assumptions:
- there is a number of (hidden) factors behind the user
preferences that relate to (hidden) movie properties
- movies have intrinsic values associated with such factors
- users have intrinsic weights with such factors;
user ratings a weighted (linear) combinations of movie’s values
69

70. 2 4 5 1 4 2
70

71. 2 4 5 1 4 2
71

72. rank k
2 4 5 1 4 2 7 2 5 4 5 3 1 4 2
3 1 2 2 5 3 1 2 4 2 2 7 5 6
4 2 4 1 3 1 4 3 2 2 4 1 4 3 1
=
3 3 4 2 3 1 2 3 4 3 2 4 5
2 3 1 4 3 2 2 3 2 1 3 4 3 5 2
2 2 1 4 8 2 2 9 1 8 3 4 5
1 3 1 1 4 1 2 3 5 1 1 5 6 4
Y X
Objective: find a factorizable X=UV’ that approximates Y
X = arg min Loss ( X ' , Y )
X'
and satisfies some “regularization” constraints (e.g. rank(X) < k)
Loss functions: depends on the nature of your problem
72

73. Matrix Factorization Approaches
 Singular value decomposition (SVD) – low-rank approximation
 Assumes fully observed Y and sum-squared loss
 In collaborative prediction, Y is only partially observed
Low-rank approximation becomes non-convex problem w/ many local minima
 Furthermore, we may not want sum-squared loss, but instead
 accurate predictions (0/1 loss, approximated by hinge loss)
 cost-sensitive predictions (missing a good server vs suggesting a bad one)
 ranking cost (e.g., suggest k ‘best’ movies for a user)
NON-CONVEX PROBLEMS!
 Use instead the state-of-art Max-Margin Matrix Factorization [Srebro 05]
 replaces bounded rank constraint by bounded norm of U, V’ vectors
 convex optimization problem! – can be solved exactly by semi-definite programming
 strongly relates to learning max-margin classifiers (SVMs)
 Exploit MMMF’s properties to augment it with active sampling! 73

74. Key Idea of MMMF
Rows – feature vectors, Columns – linear classifiers
Linear classifiersweight vectors
“margin” here =
Dist(sample, line)
v2
f1 -1
“ma
rgin
Feature vectors
”
Xij = signij x marginij
Predictorij = signij
If signij > 0, classify as +1,
Otherwise classify as -1 74

75. MMMF: Simultaneous Search for Low-norm
Feature Vectors and Max-margin Classifiers
75

76. Active Learning with MMMF
- We extend MMMF to Active-MMMF using margin-based active sampling
- We investigate exploitation vs exploration trade-offs imposed by different heuristics
-0.3 -0.5 0.3 0.4
0.6 0.1 -0.9 -0.6
-0.5 0.8 0.2
-0.9 0.3 -0.1
0.6 -0.7 -0.5 0.7
-0.9 -0.8 0.9
0.1 0.5 0.2 0.3
-0.5 0.6 0.6
0.5 0.2 -0.9 0.7 -0.8 -0.5
0.9 -0.6 -0.1 0.9
0.7 0.8 -0.4 0.3 Margin-based heuristics:
-0.5 -0.2 0.6
-0.5 -0.5 -0.5 -0.4
0.6 -0.5 0.4 0.5 min-margin (most-uncertain)
-0.2 -0.5 -0.5 0.1 0.9 0.3
min-margin positive (“good” uncertain)
0.8 -0.5 0.6 0.2
max-margin (‘safe choice’ but no76
info)

77. Active Max-Margin Matrix Factorization
A-MMMF(M,s)
1. Given s sparse matrix Y, learn approximation X = MMMF(Y)
2. Using current predictions, actively select “best s” samples and
request their labels (e.g., test client/server pair via ‘enforced’ download)
3. Add new samples to Y
4. Repeat 1-3
Issues:
 Beyond simple greedy margin-based heuristics?
 Theoretical guarantees? not so easy with non-trivial learning
methods and non-trivial data distributions
(any suggestions???  )
77

78. Empirical Results
 Network latency prediction
 Bandwidth prediction (peer-to-peer)
 Movie Ranking Prediction
 Sensor net connectivity prediction
78

79. Empirical Results: Latency Prediction
P2Psim data NLANR-AMP data
Active sampling with most-uncertain (and most-uncertain positive)
heuristics provide consistent improvement over random and least-
uncertain-next sampling 79

80. Movie Rating Prediction (MovieLens)
80

81. Sensor Network Connectivity
81

82. Introducing Cost: Exploration vs Exploitation
DownloadGrid: PlanetLab:
bandwidth prediction latency prediction
Active sampling  lower prediction errors at lower costs (saves 100s of samples)
(better prediction  better server assignment decisions  faster downloads
Active sampling achieves a good exploration vs exploitation trade-off:
reduced decision cost AND information gain
82

83. Conclusions
 Common challenge in many applications:
need for cost-efficient sampling
 This talk: linear hidden factor models with active sampling
 Active sampling improves predictive accuracy while keeping
sampling complexity low in a wide variety of applications
 Future work:
 Better active sampling heuristics?
 Theoretical analysis of active sampling performance?
 Dynamic Matrix Factorizations: tracking time-varying matrices
 Incremental MMMF? (solving from scratch every time is too costly)
83

84. References
Some of the most influential papers
• Simon Tong, Daphne Koller.
Support Vector Machine Active Learning with Applications to Text Classification
. Journal of Machine Learning Research. Volume 2, pages 45-66. 2001.
• Y. Freund, H. S. Seung, E. Shamir, N. Tishby. 1997.
Selective sampling using the query by committee algorithm. Machine
Learning, 28:133—168
• David Cohn, Zoubin Ghahramani, and Michael Jordan.
Active learning with statistical models, Journal of Artificial Intelligence
Research, (4): 129-145, 1996.
• David Cohn, Les Atlas and Richard Ladner.
Improving generalization with active learning, Machine Learning
15(2):201-221, 1994.
• D. J. C. Mackay.
Information-Based Objective Functions for Active Data Selection. Neural
Comput., vol. 4, no. 4, pp. 590--604, 1992. 84

85. NIPS papers
• Francis Bach. Active learning for misspecified generalized linear models. NIPS-06
• Ran Gilad-Bachrach, Amir Navot, Naftali Tishby. Query by Committee Made Real. NIPS-05
• Brent Bryan, Jeff Schneider, Robert Nichol, Christopher Miller, Christopher Genovese, Larry Wasserman.
Active Learning For Identifying Function Threshold Boundaries . NIPS-05
• Rui Castro, Rebecca Willett, Robert Nowak. Faster Rates in Regression via Active Learning. NIPS-05
• Sanjoy Dasgupta. Coarse sample complexity bounds for active learning. NIPS-05
• Masashi Sugiyama. Active Learning for Misspecified Models. NIPS-05
• Brigham Anderson, Andrew Moore. Fast Information Value for Graphical Models. NIPS-05
• Dan Pelleg, Andrew W. Moore. Active Learning for Anomaly and Rare-Category Detection. NIPS-04
• Sanjoy Dasgupta. Analysis of a greedy active learning strategy. NIPS-04
• T. Jaakkola and H. Siegelmann. Active Information Retrieval. NIPS-01
• M. K. Warmuth et al. Active Learning in the Drug Discovery Process. NIPS-01
• Jonathan D. Nelson, Javier R. Movellan. Active Inference in Concept Learning. NIPS-00
• Simon Tong, Daphne Koller. Active Learning for Parameter Estimation in Bayesian Networks. NIPS-00
• Thomas Hofmann and Joachim M. Buhnmnn. Active Data Clustering. NIPS-97
• K. Fukumizu. Active Learning in Multilayer Perceptrons. NIPS-95
• Anders Krogh, Jesper Vedelsby.
NEURAL NETWORK ENSEMBLES, CROSS VALIDATION, AND ACTIVE LEARNING. NIPS-94
• Kah Kay Sung, Partha Niyogi. ACTIVE LEARNING FOR FUNCTION APPROXIMATION. NIPS-94
• David Cohn, Zoubin Ghahramani, Michael I. Jordan. ACTIVE LEARNING WITH STATISTICAL MODELS.
NIPS-94
• Sebastian B. Thrun and Knut Moller. Active Exploration in Dynamic Environments. NIPS-91 85

86. ICML papers
• Maria-Florina Balcan, Alina Beygelzimer, John Langford. Agnostic Active Learning. ICML-06
• Steven C. H. Hoi, Rong Jin, Jianke Zhu, Michael R. Lyu.
Batch Mode Active Learning and Its Application to Medical Image Classification. ICML-06
• Sriharsha Veeramachaneni, Emanuele Olivetti, Paolo Avesani.
Active Sampling for Detecting Irrelevant Features. ICML-06
• Kai Yu, Jinbo Bi, Volker Tresp. Active Learning via Transductive Experimental Design. ICML-06
• Rohit Singh, Nathan Palmer, David Gifford, Bonnie Berger, Ziv Bar-Joseph. Active Learning for
Sampling in Time-Series Experiments With Application to Gene Expression Analysis. ICML-05
• Prem Melville, Raymond Mooney. Diverse Ensembles for Active Learning. ICML-04
• Klaus Brinker. Active Learning of Label Ranking Functions. ICML-04
• Hieu Nguyen, Arnold Smeulders. Active Learning Using Pre-clustering. ICML-04
• Greg Schohn and David Cohn. Less is More: Active Learning with Support Vector Machines, ICML-00
• Simon Tong, Daphne Koller.
Support Vector Machine Active Learning with Applications to Text Classification. ICML-00.
• COLT papers
• S. Dasgupta, A. Kalai, and C. Monteleoni. Analysis of perceptron-based active learning. COLT-05.
• H. S. Seung, M. Opper, and H. Sompolinski. 1992. Query by committee. COLT-92, pages 287--294.
86

87. Journal Papers
• Antoine Bordes, Seyda Ertekin, Jason Weston, Leon Bottou.
Fast Kernel Classifiers with Online and Active Learning. Journal of Machine Learning Research
(JMLR), vol. 6, pp. 1579-1619, 2005.
• Simon Tong, Daphne Koller.
Support Vector Machine Active Learning with Applications to Text Classification. Journal of
Machine Learning Research. Volume 2, pages 45-66. 2001.
• Y. Freund, H. S. Seung, E. Shamir, N. Tishby. 1997.
Selective sampling using the query by committee algorithm. Machine Learning, 28:133--168
• David Cohn, Zoubin Ghahramani, and Michael Jordan. Active learning with statistical models,
Journal of Artificial Intelligence Research, (4): 129-145, 1996.
• David Cohn, Les Atlas and Richard Ladner. Improving generalization with active learning,
Machine Learning 15(2):201-221, 1994.
• D. J. C. Mackay. Information-Based Objective Functions for Active Data Selection. Neural
Comput., vol. 4, no. 4, pp. 590--604, 1992.
• Haussler, D., Kearns, M., and Schapire, R. E. (1994).
Bounds on the sample complexity of Bayesian learning using information theory and the VC dimension
. Machine Learning, 14, 83--113
• Fedorov, V. V. 1972. Theory of optimal experiment. Academic Press.
• Saar-Tsechansky, M. and F. Provost.
Active Sampling for Class Probability Estimation and Ranking. Machine Learning 54:2 2004,
153-178.
87

88. Workshops
• http://domino.research.ibm.com/comm/researc
88

89. Appendix
89

90. Active Learning of Bayesian
Networks

91. Entropy Function
• A measure of information in
random event X with possible
outcomes {x1,…,xn}
H(x) = - Σi p(xi) log2 p(xi)
• Comments on entropy function:
– Entropy of an event is zero when
the outcome is known
– Entropy is maximal when all
outcomes are equally likely
• The average minimum yes/no
questions to answer some
question (connection to binary 91
search) [Shannon, 1948]

92. Kullback-Leibler divergence
• P is the true distribution; Q distribution is used to encode
data instead of P
• KL divergence is the expected extra message length per
datum that must be transmitted using Q
DKL(P || Q) = Σi P(xi) log (P(xi)/Q(xi))
= Σi P(xi) log Q(xi) – Σi P(xi) log P(xi)
= -H(P,Q) + H(P)
= -Cross-entropy + entropy
• Measure of how “wrong” Q is with respect to true
distribution P 92

93. Learning Bayesian Networks
E B
Data
R A
+ Learner
Prior Knowledge C
E B P(A | E,B)
e b .9 .1
• Model Building
e b .7 .3
• Parameter estimation
• Causal structure discovery e b .8 .2
• Passive Learning vs Active Learning e b .99 .01
93

94. Active Learning
• Selective Active Learning
• Interventional Active Learning
• Obtain measure of quality of current model
• Choose query that most improves quality
• Update model
94

95. Active Learning: Parameter
Estimation
•
[Tong & Koller, NIPS-2000]
Given a BN structure G
• A prior distribution p(θ)
• Learner request a particular instantiation q (Query)
Updated
Initial Network
distribution
G, p(θ)
p´(θ)
E B
Query (q) E B
Active Learner
A
A
+
Response (x)
Training
data
How to update parameter density
How to select next query based on p
95

96. Updating parameter density
•Do not update A since we are fixing it
B
•If we select A then do not update B
•Sampling from P(B|A=a) ≠ P(B)
•If we force A then we can update B A
•Sampling from P(B|A:=a) = P(B)*
•Update all other nodes as usual
J M
•Obtain new density
p(θ | A = a, X = x )
96
*Pearl 2000

97. Bayesian point estimation
• Goal: a single estimate θ
– instead of a distribution p over θ
p(θ)
~
• If we choose θ and the true model is θ’
θ θ’
then we incur some loss, L(θ’ || θ)
97

98. Bayesian point estimation
• We do not know the true θ’
• Density p represents optimal beliefs over θ’
• Choose θ that minimizes the expected loss
~
θ = argminθ ∫p(θ’) L(θ’ || θ) dθ’
~
• Call θ the Bayesian point estimate
• Use the expected loss of the Bayesian point
estimate as a measure of quality of p(θ):
– Risk(p) = ∫p(θ’) L(θ’ || θ) dθ’
98

99. The Querying component
• Set the controllable variables so as to
minimize the expected posterior risk:
ExPRisk(p | Q=q)
~
= ∑ P( X = x | Q = q) ∫ p(θ | x ) KL(θ || θ ) dθ
x
• KL divergence will be used for loss
Conditional KL-divergence
– KL(θ || θ’)=∑KL(Pθ(Xi|Ui)|| Pθ’(Xi|Ui)) 99

100. Algorithm Summary
• For each potential query q
• Compute ∆Risk(X|q)
• Choose q for which ∆Risk(X|q) is greatest
– Cost of computing ∆Risk(X|q):
• Cost of Bayesian network inference
• Complexity: O (|Q|. Cost of inference)
100

101. Uncertainty sampling
Maintain a single hypothesis, based on labels seen so far.
Query the point about which this hypothesis is most “uncertain”.
Problem: confidence of a single hypothesis may not accurately
represent the true diversity of opinion in the hypothesis class.
X
-
- -
-
+ + -
-
+
+ + -
- - 101

102. 102

103. Region of uncertainty
Current version space: portion of H consistent with labels so far.
“Region of uncertainty” = part of data space about which there is
still some uncertainty (i.e. disagreement within version space)
current version space
Suppose data lies
on circle in R2; +
hypotheses are +
linear separators.
(spaces X, H
superimposed)
region of uncertainty
in data space 103

104. Region of uncertainty
Algorithm [CAL92]:
of the unlabeled points which lie in the region of uncertainty,
pick one at random to query.
Data and current version space
hypothesis spaces,
superimposed:
(both are the
surface of the unit
sphere in Rd)
region of uncertainty
in data space 104

105. Region of uncertainty
Number of labels needed depends on H and also on P.
Special case: H = {linear separators in Rd}, P = uniform
distribution over unit sphere.
Then: just d log 1/ε labels are needed to reach a hypothesis
with error rate < ε.
[1] Supervised learning: d/ε labels.
[2] Best we can hope for.
105

106. Region of uncertainty
Algorithm [CAL92]:
of the unlabeled points which lie in the region of uncertainty,
pick one at random to query.
For more general distributions: suboptimal…
Need to measure
quality of a query – or
alternatively, size of
version space.
106

107. Expected
Infogain
of sample Uncertainty sampling!
107

108. 108
