An Approach for Object and Scene Detection for Blind Peoples Using Vocal Vision.

Shraddha A. Kamble Int. Journal of Engineering Research and Applications www.ijera.com
ISSN : 2248-9622, Vol. 4, Issue 12( Part 5), December 2014, pp.01-03
www.ijera.com 1 | P a g e
An Approach for Object and Scene Detection for Blind Peoples
Using Vocal Vision.
Shraddha A. Kamble
ABSTRACT
This system help the blind peoples for the navigation without the help of third person so blind person can perform its work
independently. This system implemented on android device in which object detection and scene detection implemented, so
after detection there will be text to speech conversion so user or blind person can get message from that android device with
the help of headphone connected to that device. Our project will help blind people to understand the images which will be
converted to sound with the help of webcam. We shall capture images in front of blind peoples .The captured image will be
processed through our algorithms which will enhances the image data. The hardware component will have its own database.
The processed image is compare with the database in the hardware component .The result after processing and comparing
will be converted into speech signals. The headphones guide the blind peoples.
I. Introduction:
Vocal Vision is an application made for visually
impaired people. From long years ago till the date it
is seen that blind people face many problems in doing
their activities. They are dependent on others for
doing everything. This motivated us to design the
system called “VOCAL VISION”. This is a small
approach to make the blind people independent. This
project is a vision substitute system designed to assist
blind people for autonomous navigation. Its working
concept is based on „image to sound‟ conversion. The
webcam captures the image in front of blind user then
object detection algorithm process this image and
enhances the image data that image compare with
image in database .If comparison successful then
message through android device deliver to user or
blind person with the help of headphone about object
name and for scene name of the sce A webcam is
used to capture the image of the object in the
surrounding. This captured image is processed
through algorithms. Algorithms includes blurring,
gray scaling, edge detection, threasholding, boundary
detection, cropping, RGB to HSV, histogram,
normalization. After this the object or scenes are
compare with the database images so if comparison is
successful then it inform blind person about that
object or scenes.
Previous System:
technologies and devices includes:
1. Electronic Travel Aids (ETA).
2. Augmented Reality (AR) technology.
3. Navigation Assistance for Visually Impaired
(NAVI)
II. ETA:
This technology propose a new system for blind
navigation using RFID tags to set up a location
tagging infrastructure within buildings such that the
blind can use an RFID equipped ETA (such as a cell
phone) to determine their location as well as software
that can utilize this localization data to generate vocal
directions to reach a destination. Electronic Travel
Aids (ETAs) are electronic devices designed to
improve autonomous navigation of blind people.
ETAs design varies from the sizes, the type of sensor
used in the system, the method of conveying
information and also the method of usage. Image of
the scene in front of blind user is captured using
video camera and it is transformed into sound pattern.
The intensity of the pixel of the image is transformed
into loudness .
III. AR Technology:
Augmented Reality (AR) technologies have the
potential to support some of the activities for the
blind people. This paper presents a design for how a
walking cane can be augmented with a camera to
detect Semacodes and a Braille device to deliver
information. Based on the design they have
developed a prototype and described its
characteristics, limitations, and lessons learned.
Augmented Reality (AR) technologies make the daily
life easier for people with disabilities. Smaller and
smaller computers enable these people to wear
powerful information devices that can help
navigating and recognizing objects. Otherwise
impossible tasks could be doable by introducing AR
concepts and special designed tools. This outlines
three strategies in the field of augmented reality: 1)
Augmenting the user, 2) Augmenting physical
objects and 3) Augmenting the environment.
IV. NAVI:
This technology proposes a new object
identification and color recognition module for blind
people. Image processing techniques are proposed to
RESEARCH ARTICLE OPEN ACCESS

identify objects in the captured image and then the
processed image is transformed into stereo sound
patterns. Color information from the interested object
is evaluated to determine the color of the
object.NAVI system consists of tiny vision sensor
attached on a sunglass, a stereo earphones and a
Single Board Processing System (SBPS)
interconnected. SPBS selected for this system is
PCM-9550F with Embedded Intel low power
PentiumMMX 266 MHz processor, 128 MB
SDRAM, 2.5” light weight hard disk, two Universal
serial bus and RTL 8139 sound device chipset
assembled in Micro box PC-300 chassis. The weight
of SBPS is 0.7 Kg. Constant 5V and 12 V supply for
SBPS is provided from the batteries. Vision sensor
selected for this application is a digital video camera,
Zion PN615CMOS. Figure shows the processing
equipment of NAVI system.
Drawbacks of system:
1) ETA system uses the ultrasonic sensors which is
expensive which contains few electronic components.
2) In AR technology walking cane can be augmented
with a camera to detect Semacodes and a Braille
device to deliver information.
3) NAVI system only useful for object detection but
we also included the scene detection technique in this
project.
Proposed System:
Definition:
Vocal Vision is an application made for visually
impaired people. From long years ago till the date it
is seen that blind people face many problems in doing
their activities. They are dependent on others for
doing everything. This motivated us to design the
system called “VOCAL VISION”. This is a small
approach to make the blind people independent. This
project is a vision substitute system designed to assist
blind people for autonomous navigation. Its working
concept is based on „image to sound‟ conversion. The
webcam captures the image in front of blind user then
object detection algorithm process this image and
enhances the image data that image compare with
image in database .If comparison successful then
message through android device deliver to user or
blind person with the help of headphone about object
name and for scene name of the scene.
Overall Description
Different blocks includes in this systems are
blurring, gray scaling, edge detection, threasholding,
boundary detection, cropping, RGB to HSV,
histogram, normalization. After this the object or
scenes are compare with the database images so if
comparison is successful then it inform blind person
about that object or scenes.

Blurring:
Using this image looks more sharp or more
detailed and it is use for the noise reduction from the
grabbed image. Blurring can be achieved using filters
such as:
1) Mean filter
2) Weighted average
3) Gaussian filter
Gray Scale:
In a (8-bit) grayscale image each picture element
has an assigned intensity that ranges from 0 to 255.A
grey scale image is different from black and white
image since a grayscale image also includes shades
of grey apart from pure black and pure white color.
Edge Detection:
Edge of the object detected from this technique.
Sobel operator or Sobel filter use within edge
detection algorithm.
Threasholding:
From a grayscale image, threshoulding can be
used to create binary images i.e. image with only
black or white colors. It is usually used for feature
extraction where required features of image are
converted to white and everything else to black. (or
vice-versa)
Boundry Detection:
Boundry which separate object from the
surrounding detected.
Cropping:
Only the required object cropped and other
eliminated from image.
RGB to HSV:
HSV separate color information from image
intensity .It is use for histogram equalization of color
image because it only require the intensity
information of image.
Histogram:
Graphical representation of number of pixels for
each color. On x-axis range of color(0-255) and on y-
axis number of pixel for each color.
Normalization:
It is the process that changes the range of pixel
intensity values or spreading out most frequently
intensity values. Stretches an image‟s pixel values to
cover the entire pixel value range(0-255)
Conclusion:
Blind person can perform different activities
without the help of third person using this system.
Using this system blind person can do its work
independently
References:
[1] Object Identification and Colour Recognition
for Human Blind by R. Nagarajan, G.
Sainarayanan, Sazali Yaacob and Rosalyn R
Porle
[2] Blind Navigation and Object Recognition by
(Augmented Reality)R. Gude, M. Østerby, S.
Soltveit University of Aarhus, Denmark
[3] Building a Color Recognizer System on the
Smart Mobile Device for the Visually Impaired
People by Hsiao Ping Lee
[4] Joseph Schlecht, Björn Ommer “Contour-based
Object Detection” Interdisciplinary Center for
Scientific Computing University of Heidelberg ,
Germany, 2011
