Media Service on a Cloud :: 콘텐츠연합플랫폼 :: AWS Media Day 2016

The document summarizes the evolution of the POOQ platform from 2012 to present. It began as a joint venture between MBC and SBS in 2012 and initially hosted on a traditional IDC. As user numbers grew, performance issues emerged. This led to a redesign with scalable cloud infrastructure using services like MongoDB, Cassandra, and auto-scaling. The new design successfully supported over 280,000 concurrent users for a major sports event in 2015. Lessons were learned about cloud benefits but also limitations. Future work includes migration to AWS and use of services like Lambda and GPU instances for machine learning.

Technology◦
Downloaded 62 times
Project Westworld POOQ Platform Evolution Story
Who Am I? • 조휘열 • 콘텐츠연합플랫폼 플랫폼운영실장 • 서비스 기획/서버&클라이언트개발/플랫폼&서비스 운영 담당 • 개발 경력 26년 • felix@captv.co.kr
In the beginning • May, 2012 - CAP(Contents Alliance Platform Co., Ltd.) Formed  Joint venture between MBC & SBS • July, 2012 – POOQ service open to public • September, 2012 – POOQ became paid subscription service
What is POOQ?
POOQ 1.0 • Most of platform comes from iMBC • Hosted at Nonhyun IDC (LG) • Typical Web App Structure ASP.Net (PC Web Service) MS SQL (Data Storage) Ingestion Engine MAPI (Mobile API Server) ASP.Net (Backoffice)
Houston, we have problem • With number of users grow fast, problem start rise • Occasional heavy load – could not stand over 80,000 concurrent users • Required server reset • Poor user experience
Evidence - 2013/10/19
Evidence - 2013/10/20
Evidence – 2013/11/8
Evidence - 2014/4/24
Why? • IDC  No rapid platform growth  Everything should planned month ahead • Old technology  RDBMS backed, real-time query design  Developed cache on ASP.net but it was complex and not efficient  Cannot increase number of servers (of RDBMS)  Everybody hates “Sharding”
New Game Plan • New type of service: “Emergency Platform”  RDBMS-less, Authentication-less  Operate when primary platform failed • From IDC to Cloud  Rapid Scalability is the name of game • New platform design  Unified API  Personalization  Scalable Performance
Emergency Platform • Preparation for Primary Platform Failure • Collect live & VOD information at booting • Does not rely on any regular platform servers • No authentication – When primary server failed, everybody can watch VOD! ASP.Net (PC Web Service+MAPI emulation) External Data Source (live & VOD info) Emergency Platform From IDC to Cloud New Platform Design
From IDC to Cloud • Immigration is decided, problem is to where? • Two options were considered  KT ucloud  AWS Tokyo • Regulatory issue makes a complication for AWS option  “One cannot move customer’s personal record outside of country without consent” • KT ucloud was cheaper, too • So, destination : KT ucloud • Problem was, we really did not know about KT ucloud  No good document or books exist as well  Though cloud is almost same  Big Mistake Emergency Platform From IDC to Cloud New Platform Design
New Platform Design • Unified API • Personalization • Scalable Performance Emergency Platform From IDC to Cloud New Platform Design Unified API Personalization Scalable
New Platform Design • Unified API model  Eliminate duplicated resource allocation  Same behavior on all client • Requirements  Restful API  JSON output  Specification & Documentation  Testing  Auto server generation from spec ASP.Net MAPI Unified API Emergency Platform From IDC to Cloud New Platform Design Unified API Personalization Scalable
Unified API • Swagger (http://swagger.io/)  Restful API definition with .yaml  Free documentation, testing tools available  Auto-generate client & server for several languages Emergency Platform From IDC to Cloud New Platform Design Unified API Personalization Scalable
Unified API - Swagger Emergency Platform From IDC to Cloud New Platform Design Unified API Personalization Scalable
Unified API-Swagger API Design (.yaml) Validate & Test (Swagger editor) Commit (To GitHub) Server Code Gen (Custom Tool) API Doc Site Publishing Emergency Platform From IDC to Cloud New Platform Design Unified API Personalization Scalable
Unified API-Swagger Emergency Platform From IDC to Cloud New Platform Design Unified API Personalization Scalable
Unified API-Auto Code Gen Emergency Platform From IDC to Cloud New Platform Design Unified API Personalization Scalable
New Platform Design • Personalization  Continues viewing – Across N-Screen  Popular content listing  Your program listing  All based on “Bookmark” concept  Client send streaming status to server  Every 10 second  UDP and HTTP based protocol support  Heavy load on server side Emergency Platform From IDC to Cloud New Platform Design Unified API Personalization Scalable
Continues Viewing Emergency Platform From IDC to Cloud New Platform Design Unified API Personalization Scalable
Bookmark Engine Bookmark Receiver Bookmark ReceiverBookmark Receiver Client ActiveMQ Bookmark Receiver Bookmark Cassandra Data Store API Server Apache SparkMongo DB Service About 17TB Per 2 Month Emergency Platform From IDC to Cloud New Platform Design Unified API Personalization Scalable
Scalable Design • All participant server must be able to increase performance by increasing number of VMs  Rules out MSSQL as online database  Active/Active is not enough  MongoDB is choice of database (as mostly read-cache)  Cassandra NoSQL as data logging server • Single VM failure should not affect whole platform’s functionality  Utilize lots of Load Balancer Emergency Platform From IDC to Cloud New Platform Design Unified API Personalization Scalable
Selection of NoSQL Emergency Platform From IDC to Cloud New Platform Design Unified API Personalization Scalable
Cassandra Performance Emergency Platform From IDC to Cloud New Platform Design Unified API Personalization Scalable
Scalable Design Client Cassandra API Server Apache SparkMongo DB Service MS SQL Pentaho Kettle Batch Update Emergency Platform From IDC to Cloud New Platform Design Unified API Personalization Scalable
MongoDB Scale Out Mongo DB (Master, WRITE) Mongo DB (Slave, READ) Mongo DB (Slave, READ) Mongo DB (Slave, READ) Mongo DB (Slave, READ) Mongo DB (Slave, READ) Up To 50 replica members Emergency Platform From IDC to Cloud New Platform Design Unified API Personalization Scalable
MongoDB (Slave) Scalable Design Emergency Platform From IDC to Cloud New Platform Design Unified API Personalization Scalable Web Servers (Static Page) LB Group Web Servers (Static Page) Web Servers (Static Page) Web Servers (Static Page) Web Servers (Static Page) LB Group Web Servers (Static Page) Web Servers (Static Page)API Servers MongoDB (Slave) MongoDB (Master) Cassandra Ring Node Node Node Node Node Node Web Servers (Static Page) LB Group Web Servers (Static Page) Web Servers (Static Page) Bookmark Collectors
The Result? • POOQ obtain exclusive Internet streaming rights on Premier12 Baseball Game • 19th November, 2015 - Premier12, Korea vs. Japan
The Result • 551G Network • 283,577 Users • Platform was stable  CPU Utilization was 20%
The Road So Far… • Built solid platform foundation • With collaboration of fantastic developer team • Confidence on handling large user interaction • Still far way to go, though
Lesson Learned (About Cloud) • Very efficient, Will recommend to almost any platform • Enjoying decent support in general • VMs are really slower than you think • Not all VMs are equal • Sometimes your bottleneck is not number of VMs • Long way from perfection/shit happen
Migration toward AWS • Project Halloween • Winter of 2016 ~ Spring of 2017
Auto-Scale • Metric Based & Schedule Based
GPU Instances Machine Learning & Deep Learning
Gadgets • Lambda • Cloud Watch & 3rd Party tools • RDS • Marketplace
Q&A
