<ul><li>DRINKING WATER SUPPLY SCHEMES  </li></ul><ul><li>FOR SOLAPUR TOWN </li></ul><ul><li>DEVELOPMENT, PROBLEMS & FUTURE...


Solapur District - Physiographic Map
Introduction  Solapur is an ancient historical place dating back to 90 BC. Solapur is one of the important town place in M...
Solapur City And Surrounding Area in SOI Toposheet 47 0
Solapur City And Surrounding Area in SOI Toposheet 47 0/14
Aerial View of Part of Solapur City
A View of Shri Siddheshwar Temple & Tank surrounding the Temple

Solapur Fort
<ul><li>History of Physical Growth   </li></ul><ul><li>Solapur Municipality was established an 1st August 1852  </li></ul>...
<ul><ul><li>On 1/5/1964 Municipal Corporation existed.  </li></ul></ul><ul><ul><li>Due to increase in revenue and populati...
Brief  Data of Water Sources tapped by Solapur Municipal Corporation Ekrukh tank is an earthen dam built in (1859-1869) in...
Kambar Tank
Kambar Tank
Ekrukh Tank
A View of Ujani Dam in the year 1998
M.B.R. at Kondi





Existing Land Use Analysis for Total Area
Groundwater as source Solapur Municipal Corporation is one of the main body in the Maharashtra State which has successfull...
Of these the shallow aquifer is found to get recharged during regular monsoon, while the other two at depths are normally ...
It is roughly estimated that probably there are total about 10,000 bore well drilled in the city area of which nearly 60% ...
In different part of the city where the water are low to moderately polluted, include areas around MIDC areas and small sc...
<ul><li>  </li></ul><ul><li>Filter/ treatment plants – </li></ul><ul><ul><li>Bhavani peth – Mainly for Ekrukh dam water (f...
Distribution of Reservoirs
<ul><ul><li>Development for Water Resources </li></ul></ul><ul><ul><li>In 12th century, centrally located beautiful tank w...
With increasing demand and acute problem of water scarcity to meet the needs in 1969 water from Bhima River 30 kms. South ...
Present Situation  Presently if all conditions are fulfilled with good storage at each source then the water availability ...
Demand rate of water supply per capita - estimated by technical committee forecasting population  of city given by Gokhale...
<ul><li>Future & Suggestions </li></ul><ul><ul><li>Additional pipeline similar to present one with double capacity is utmo...
Quarries must be started near Ekrukh tank in acquired areas of Government.  The excavated material must be used for constr...
Corporation can charge heavily for extra and excess use of water than the prescribed or standardized requirement for a fam...
IMAGERY OF PART OF SOLAPUR CITY
