High Performance JavaScript - WebDirections USA 2010

High Performance JavaScript Nicholas C. Zakas Yahoo!, Inc. The Web Industry Conference September 21–25, 2010 Midtown Atlanta

Greetings, program Principal Front End Contributor, Engineer Creator of YUI Test Author Lead Author Contributor Lead Author

I know what you're thinking

Is he really going to use a Tron theme throughout this presentation?

Yes, because it's awesome

Well, mostly awsome

Does JavaScript performance matter?

After all, all browsers now have optimizing JavaScript engines Tracemonkey/ V8 Squirrelfish Chakra Karakan JaegarMonkey (all) (4+) (9+) (10.5+) (3.5+)

So our scripts are getting really, really fast

Old computers ran slow applications Small amounts of CPU power and memory

New computers are generally faster but slow applications still exist More CPU + more memory = less disciplined application development

It's still possible to write slow JavaScript on the new, faster JavaScript engines

JavaScript performance directly affects user experience

"Know the enemy and know yourself; in a hundred battles you will never be in peril." -Sun Tzu, The Art of War

The UI Thread The brains of the operation

The browser UI thread is responsible for both UI updates and JavaScript execution Only one can happen at a time

Jobs for UI updates and JavaScript execution are added to a UI queue if the UI thread is busy Each job must wait in line for its turn to execute

<button id="btn" style="font-size: 30px; padding: 0.5em 1em">Click Me</button> <script type="text/javascript"> window.onload = function(){ document.getElementById("btn").onclick = function(){ //do something }; }; </script>

Before Click UI Thread time UI Queue

When Clicked UI Thread time UI Queue UI Update onclick UI Update

When Clicked UI Thread UI Update time UI Queue onclick Draw down state UI Update

When Clicked UI Thread UI Update onclick time UI Queue UI Update

When Clicked UI Thread UI Update onclick UI Update time UI Queue Draw up state

No UI updates while JavaScript is executing

JavaScript May Cause UI Update <button id="btn" style="font-size: 30px; padding: 0.5em 1em">Click Me</button> <script type="text/javascript"> window.onload = function(){ document.getElementById("btn").onclick = function(){ var div = document.createElement(“div”); div.className = “tip”; div.innerHTML = “You clicked me!”; document.body.appendChild(div); }; }; </script>

A UI update must use the latest info available

Long-running JavaScript = Unresponsive UI

Responsive UI UI Thread UI Update JavaScript UI Update time

Unresponsive UI UI Thread UI Update JavaScript UI Update time

The longer JavaScript runs, the worse the user experience

The browser vendors know this and put limits on JavaScript via the runaway script timer

Internet Explorer

Firefox

Safari

Chrome

Runaway Script Timer Limits • Internet Explorer: 5 million statements • Firefox: 10 seconds • Safari: 5 seconds • Chrome: Unknown, hooks into normal crash control mechanism • Opera: none

Does JIT compiling help?

Interpreted JavaScript UI Thread Interpret time

JITed JavaScript (1st Run) UI Thread Compile Execute time

JITed JavaScript (After 1st Run) UI Thread Execute time

How Long Is Too Long? “0.1 second [100ms] is about the limit for having the user feel that the system is reacting instantaneously, meaning that no special feedback is necessary except to display the result.” - Jakob Nielsen

Translation: No single JavaScript job should execute for more than 100ms to ensure a responsive UI

Recommendation: Limit JavaScript execution to no more than 50ms measured on IE6 :)

Techniques Ways to ensure JavaScript doesn't run away

function processArray(items, process, callback){ for (var i=0,len=items.length; i < len; i++){ process(items[i]); } callback(); }

Technique #1: Timers

//create a new timer and delay by 500ms setTimeout(function(){ //code to execute here }, 500) setTimeout() schedules a function to be added to the UI queue after a delay

When Clicked UI Thread UI Update time UI Queue onclick UI Update

When Clicked UI Thread UI Update onclick UI Update time UI Queue

After 25ms UI Thread UI Update onclick UI Update time UI Queue JavaScript

After 25ms UI Thread UI Update onclick UI Update JavaScript time UI Queue

After Another 25ms UI Thread UI Update onclick UI Update JavaScript time UI Queue JavaScript

After Another 25ms UI Thread UI Update onclick UI Update JavaScript JavaScript time UI Queue

Technique #2: Web Workers

Web Workers ● Asynchronous JavaScript execution ● Execution happens outside of UI thread ● Not on the UI thread = no UI delays ● Data-driven API ● Data is serialized when sending data into or out of Worker ● No access to DOM, BOM ● Completely separate execution environment

//in page var worker = new Worker("process.js"); worker.onmessage = function(event){ useData(event.data); }; worker.postMessage(values); //in process.js self.onmessage = function(event){ var items = event.data; for (var i=0,len=items.length; i < len; i++){ process(items[i]); } self.postMessage(items); };

When Clicked UI Thread UI Update time UI Queue onclick UI Update

When Clicked UI Thread UI Update onclick time Worker Thread UI Queue UI Update

When Clicked UI Thread UI Update onclick UI Update time Worker Thread UI Queue JavaScript

Worker Thread Complete UI Thread UI Update onclick UI Update time UI Queue onmessage

Worker Thread Complete UI Thread UI Update onclick UI Update onmessage time UI Queue

Web Workers Support 3.5 4.0 4.0 10.6

Repaint and Reflow Hidden performance costs of common operations

Long UI updates = Unresponsive UI

JavaScript can cause long UI updates by triggering repaint and reflow

A repaint occurs when a visual change doesn't require recalculation of layout Changes to visibility, colors (text/background), background images, etc.

Repaint <button id="btn" style="font-size: 30px; padding: 0.5em 1em">Click Me</button> <script type="text/javascript"> window.onload = function(){ document.getElementById("btn").onclick = function(){ this.style.color = "#ff0"; }; }; </script> Repaint!

A reflow occurs when a visual change requires a change in layout Initial page load ▪ browser resize ▪ DOM structure change ▪ layout style change layout information retrieved

Reflow <button id="btn" style="font-size: 30px; padding: 0.5em 1em">Click Me</button> <script type="text/javascript"> window.onload = function(){ document.getElementById("btn").onclick = function(){ var div = document.createElement(“div”); div.className = “tip”; div.innerHTML = “You clicked me!”; document.body.appendChild(div); }; }; </script> Reflow!

Repaints and reflows are queued up as JavaScript executes and then executed in order

Reflow var list = document.getElementsByClassName("items")[0], i, item; for (i=0; i < 10; i++){ item = document.createElement("li"); item.innerHTML = "Item #" + i; list.appendChild(item); } Reflow x 10!

Limiting repaints/reflows improves overall performance

Technique #1 Perform DOM manipulations off-document

Off-Document Operations • Fast because there's no repaint/reflow • Techniques: – Remove element from the document, make changes, insert back into document – Set element's display to “none”, make changes, set display back to default – Build up DOM changes on a DocumentFragment then apply all at once

DocumentFragment • A document-like object • Not visually represented • Considered to be owned by the document from which it was created • When passed to appendChild(), appends all of its children rather than itself

DocumentFragment var list = document.getElementsByClassName("items")[0], fragment = document.createDocumentFragment(), i, item; for (i=0; i < 10; i++){ item = document.createElement("li"); item.innerHTML = "Item #" + i; fragment.appendChild(item); } list.appendChild(fragment); 1 Reflow

Technique #2 Group Style Changes

Repaint! Reflow! element.style.color = "red"; element.style.height = "100px"; Reflow! element.style.fontSize = "25px"; element.style.backgroundColor = "white"; Repaint!

Grouping Style Changes .active { color: red; height: 100px; fontSize: 25px; background-color: white; } element.className = "active"; Reflow!

Grouping Style Changes var item = document.getElementById("myItem"); item.style.cssText = "color:red;height:100px;" + "font-size:25px;background-color: white"); Reflow!

Technique #3 Avoid Accidental Reflow

Accidental Reflow element.width = "100px"; var width = element.offsetWidth; Reflow!

What to do? • Minimize access to layout information – offsetTop, offsetLeft, offsetWidth, offsetHeight – scrollTop, scrollLeft, scrollWidth, scrollHeight – clientTop, clientLeft, clientWidth, clientHeight – Most computed styles • If a value is used more than once, store in local variable

Does hardware acceleration help?

Traditional Rendering UI Thread Compositing Drawing time

Hardware Acceleration UI Thread Prep Wait time Rendering info Signal complete Compositing Drawing GPU

awesome!!

The browser UI thread is responsible for both UI updates and JavaScript execution Only one can happen at a time

Responsive UI UI Thread UI Update JavaScript UI Update time

Avoid Slow JavaScript • Don't allow JavaScript to execute for more than 50ms • Break up long JavaScript processes using: – Timers – Web Workers

Avoid Long UI Updates • Be careful of repaint and reflow • Perform complex DOM operations off- document – Remove elements and re-add them – Use DocumentFragment objects • Group style changes together • Avoid accidental reflow

Etcetera • My blog: www.nczonline.net • My email: nzakas@yahoo-inc.com • Twitter: @slicknet • These Slides: http://slideshare.net/nzakas/presentations/ • Rate Me: http://spkr8.com/t/4511

Questions?

See ya!

Creative Commons Images Used • http://www.flickr.com/photos/hippie/2406411610/ • http://www.flickr.com/photos/55733754@N00/3325000738/ • http://www.flickr.com/photos/eurleif/255241547/ • http://www.flickr.com/photos/off_the_wall/3444915939/ • http://www.flickr.com/photos/wwarby/3296379139/ • http://www.flickr.com/photos/derekgavey/4358797365/ • http://www.flickr.com/photos/mulad/286641998/ • http://www.flickr.com/photos/torley/2361164281/ • http://www.flickr.com/photos/ottoman42/455242/
