High Performance JavaScript (CapitolJS 2011)

  1. High Performance JavaScript<br />Nicholas C. Zakas| CapitolJS | September 18, 2011<br />
  2. Who's this guy?<br />Co-Creator csslint.net<br />Contributor,<br />Creator of YUI Test<br />Ex-tech lead<br />Yahoo!<br />Author<br />Lead Author<br />Contributor<br />Lead Author<br />
  3. @slicknet<br />(complaints: @voodootikigod)<br />
  4. Does JavaScript performance matter?<br />
  5. All browsers now haveoptimizing JavaScript engines<br />Tracemonkey/<br />JaegarMonkey<br />(3.5+)<br />V8<br />(all)<br />Nitro<br />(4+)<br />Chakra<br />(9+)<br />Karakan<br />(10.5+)<br />
  6. http://ie.microsoft.com/testdrive/benchmarks/sunspider/default.html<br />
  7. Old computers ran slow applications<br />Small amounts of CPU power and memory<br />
  8. New computers are generally faster but<br />slow applications still exist<br />More CPU + more memory = less disciplined application development<br />
  9. Oh yeah, one more thing<br />
  10. It's still possible to write slow JavaScript<br />
  11. JavaScript performancedirectlyaffects user experience<br />
  12. The UI Threadaka Browser Event Loop<br />
  13. The browser UI thread is responsible for<br />both UI updates and JavaScript execution<br />Only one can happen at a time<br />
  14. Jobs for UI updates and JavaScript execution<br />are added to a UI queue<br />Each job must wait in line for its turn to execute<br />
  15. <button id="btn" style="font-size: 30px; padding: 0.5em 1em">Click Me</button><br /><script type="text/javascript"><br />window.onload = function(){<br /> document.getElementById("btn").onclick = function(){<br />//do something<br /> };<br />};<br /></script><br />
  16. Before Click<br />UI Thread<br />time<br />UI Queue<br />
  17. When Clicked<br />UI Thread<br />time<br />UI Queue<br />UI Update<br />onclick<br />UI Update<br />
  18. When Clicked<br />UI Thread<br />UI Update<br />time<br />UI Queue<br />onclick<br />Draw down state<br />UI Update<br />
  19. When Clicked<br />UI Thread<br />onclick<br />UI Update<br />time<br />UI Queue<br />UI Update<br />
  20. When Clicked<br />UI Thread<br />onclick<br />UI Update<br />UI Update<br />time<br />UI Queue<br />Draw up state<br />
  21. No UI updates while JavaScript is executing<br />
  22. JavaScript May Cause UI Update<br /><button id="btn" style="font-size: 30px; padding: 0.5em 1em">Click Me</button><br /><script type="text/javascript"><br />window.onload = function(){<br /> document.getElementById("btn").onclick = function(){<br /> var div = document.createElement(“div”);<br /> div.className = “tip”;<br /> div.innerHTML = “You clicked me!”;<br /> document.body.appendChild(div);<br /> };<br />};<br /></script><br />
  23. A UI update must use the latest info available<br />
  24. Long-running JavaScript=Unresponsive UI<br />
  25. Responsive UI<br />UI Thread<br />JavaScript<br />UI Update<br />UI Update<br />time<br />
  26. Unresponsive UI<br />UI Thread<br />JavaScript<br />UI Update<br />UI Update<br />time<br />
  27. The longer JavaScript runs,the worse the user experience<br />
  28. The runaway script timer prevents JavaScript<br />from running for too long<br />Each browser imposes its own limit (except Opera)<br />
  29. Internet Explorer<br />
  30. Firefox<br />
  31. Safari<br />
  32. Chrome<br />
  33. Runaway Script Timer Limits<br />Internet Explorer: 5 million statements<br />Firefox: 10 seconds<br />Safari: 5 seconds<br />Chrome: Unknown, hooks into normal crash control mechanism<br />Opera: none<br />
  34. How Long Is Too Long?<br />“0.1 second [100ms] is about the limit for having the user feel that the system is reacting instantaneously, meaning that no special feedback is necessary except to display the result.”<br />- Jakob Nielsen<br />
  35. Translation:No single JavaScript job should execute for more than 100ms to ensure a responsive UI<br />
  36. Recommendation:Limit JavaScript execution to no more than 50msmeasured on IE6 :)<br />
  37. Loadtime TechniquesDon't let JavaScript interfere with page load performance<br />
  38. During page load, JavaScript takes more time on the UI thread<br />
  39. <!doctype html><br /><html><br /><head><br /> <title>Example</title><br /></head><br /><body><br /> <p>Hello world!</p><br /><script src="foo.js"></script><br /> <p>See ya!</p><br /></body><br /></html><br />
  40. Result<br />UI Thread<br />JavaScript<br />UI Update<br />UI Update<br />time<br />
  41. Result<br />UI Thread<br />foo.js<br />See ya!<br />Hello world!<br />time<br />
  42. Result<br />UI Thread<br />Download<br />See ya!<br />Hello world!<br />Parse<br />Run<br />time<br />The UI thread needs to wait for the script to<br />download, parse, and run before continuing<br />
  43. Result<br />UI Thread<br />Download<br />See ya!<br />Hello world!<br />Parse<br />Run<br />Variable<br />Constant<br />Download time takes the longest and is variable<br />
  44. Translation:The page doesn't render while JavaScript is downloading, parsing, or executing during page load<br />
  45. <!doctype html><br /><html><br /><head><br /> <title>Example</title><br /></head><br /><body><br /><script src="foo.js"></script><br /> <p>Hello world!</p><br /><script src="bar.js"></script><br /> <p>See ya!</p><br /><script src="baz.js"></script><br /> <p>Uh oh!</p><br /></body><br /></html><br />
  46. Result<br />UI Thread<br />JavaScript<br />UI Update<br />UI Update<br />JavaScript<br />JavaScript<br />time<br />The more scripts to download in between UI<br />updates, the longer the page takes to render<br />
  47. Technique #1: Load scripts dynamically<br />
  48. Basic Technique<br />var script = document.createElement("script"),<br /> body;<br />script.type = "text/javascript";<br />script.src = "foo.js";<br />body.insertBefore(script, body.firstChild);<br />Dynamically loaded scripts are non-blocking<br />
  49. Downloads no longer block the UI thread<br />
  50. <!doctype html><br /><html><br /><head><br /> <title>Example</title><br /></head><br /><body><br /> <p>Hello world!</p><br /><script src="foo.js"></script><br /> <p>See ya!</p><br /></body><br /></html><br />
  51. Using HTML <script><br />UI Thread<br />Download<br />See ya!<br />Hello world!<br />Parse<br />Run<br />time<br />
  52. <!doctype html><br /><html><br /><head><br /> <title>Example</title><br /></head><br /><body><br /> <p>Hello world!</p><br /> <script><br /> var script = document.createElement("script"),<br /> body = document.body;<br /> script.type = "text/javascript";<br /> script.src = "foo.js";<br /> body.insertBefore(script, body.firstChild);<br /> </script><br /> <p>See ya!</p><!-- more content --><br /></body><br /></html><br />
  53. Using Dynamic Scripts<br />UI Thread<br />See ya!<br />Hello world!<br />UI Update<br />Run<br />time<br />Download<br />Parse<br />Only code execution happens on the UI thread,<br />which means less blocking of UI updates<br />
  54. function loadScript(url, callback){var script = document.createElement("script"), body = document.body;script.type = "text/javascript";<br />if (script.readyState){ //IE <= 8 script.onreadystatechange = function(){if (script.readyState == "loaded" || script.readyState == "complete"){ script.onreadystatechange = null; callback(); } };} else { //Others script.onload = function(){ callback(); };}script.src = url;body.insertBefore(script, body.firstChild);<br />}<br />
  55. Usage<br />loadScript("foo.js", function(){<br /> alert("Loaded!");<br />});<br />
  56. Timing Note:Script execution begins immediately after download and parse – timing of execution is not guaranteed<br />
  57. Technique #2: Defer scripts<br />
  58. <!doctype html><br /><html><br /><head><br /> <title>Example</title><br /></head><br /><body><br /> <p>Hello world!</p><br /><script defer src="foo.js"></script><br /> <p>See ya!</p><br /> <!-- even more markup --><br /></body><br /></html><br />
  59. Support for <script defer><br />?<br />5.0<br />3.5<br />7.0<br />4.0<br />
  60. Deferred scripts begin to download immediately, but don't execute until all UI updates complete<br />
  61. Using <script defer><br />UI Thread<br />See ya!<br />Hello world!<br />More UI<br />Run<br />More UI<br />time<br />Download<br />Parse<br />Similar to dynamic script nodes, but with a<br />guarantee that execution will happen last<br />
  62. Timing Note:Although scripts always execute after UI updates complete, the order of multiple <script defer> scripts is not guaranteed across browsers<br />
  63. Technique #3: Asynchronous scripts<br />
  64. <!doctype html><br /><html><br /><head><br /> <title>Example</title><br /></head><br /><body><br /> <p>Hello world!</p><br /><script async src="foo.js"></script><br /> <p>See ya!</p><br /> <!-- even more markup --><br /></body><br /></html><br />
  65. Support for <script async><br />?<br />5.0<br />3.6<br />7.0<br />10<br />
  66. Asynchronous scripts behave a lot like dynamic scripts<br />
  67. Using <script async><br />UI Thread<br />See ya!<br />Hello world!<br />UI Update<br />Run<br />time<br />Download<br />Parse<br />Download begins immediately and execution is<br />slotted in at first available spot<br />
  68. Note:Order of execution is explicitly not preserved for asynchronous scripts<br />
  69. Runtime TechniquesWays to ensure JavaScript doesn't run away<br />
  70. function processArray(items, process, callback){<br />for (var i=0,len=items.length; i < len; i++){<br /> process(items[i]);<br /> }<br /> callback();<br />}<br />
  71. Technique #1: Timers<br />
  72. //create a new timer and delay by 500ms<br />setTimeout(function(){<br />//code to execute here<br />}, 500);<br />setTimeout() schedules a function to be added to the UI queue after a delay<br />
  73. function timedProcessArray(items, process, callback){<br />//create a clone of the original var todo = items.concat();<br /> setTimeout(function(){<br />var start = +new Date();<br />do {<br /> process(todo.shift());<br /> } while (todo.length > 0 &&<br /> (+new Date() - start < 50));<br />if (todo.length > 0){<br /> setTimeout(arguments.callee, 25);<br /> } else {<br /> callback(items);<br /> }<br /> }, 25);<br />}<br />
  74. When Clicked<br />UI Thread<br />time<br />UI Queue<br />UI Update<br />onclick<br />UI Update<br />
  75. When Clicked<br />UI Thread<br />UI Update<br />time<br />UI Queue<br />onclick<br />UI Update<br />
  76. When Clicked<br />UI Thread<br />onclick<br />UI Update<br />time<br />UI Queue<br />UI Update<br />
  77. When Clicked<br />UI Thread<br />UI Update<br />UI Update<br />onclick<br />time<br />UI Queue<br />
  78. After 25ms<br />UI Thread<br />UI Update<br />UI Update<br />onclick<br />time<br />UI Queue<br />JavaScript<br />
  79. After 25ms<br />UI Thread<br />JavaScript<br />UI Update<br />UI Update<br />onclick<br />time<br />UI Queue<br />
  80. After Another 25ms<br />UI Thread<br />JavaScript<br />UI Update<br />UI Update<br />onclick<br />time<br />UI Queue<br />JavaScript<br />
  81. After Another 25ms<br />UI Thread<br />JavaScript<br />JavaScript<br />UI Update<br />UI Update<br />onclick<br />time<br />UI Queue<br />
  82. Technique #2: Script Yielding<br />NEW!<br />
  83. //delay a function until after UI updates are done<br />setImmediate(function(){<br />//code to execute here<br />});<br />setImmediate() adds code to the UI queue after pending UI updates are finished<br />
  84. Support for Script Yielding<br />?<br />?<br />?<br />?<br />10<br />msSetIntermediate()<br />
  85. functionyieldingProcessArray(items, process, callback){<br />//create a clone of the originalvartodo = items.concat();<br />setImmediate(function(){<br />var start = +new Date();<br />do {<br /> process(todo.shift());<br /> } while (todo.length > 0 &&<br /> (+new Date() - start < 50));<br />if (todo.length > 0){<br />setImmediate(arguments.callee);<br /> } else {<br /> callback(items);<br /> }<br />});<br />}<br />
  86. When Clicked<br />UI Thread<br />time<br />UI Queue<br />UI Update<br />onclick<br />UI Update<br />
  87. When Clicked<br />UI Thread<br />UI Update<br />time<br />UI Queue<br />onclick<br />UI Update<br />
  88. When Clicked<br />UI Thread<br />onclick<br />UI Update<br />time<br />UI Queue<br />UI Update<br />
  89. When Clicked<br />UI Thread<br />UI Update<br />UI Update<br />onclick<br />time<br />UI Queue<br />
  90. After Last UI Update<br />UI Thread<br />UI Update<br />UI Update<br />onclick<br />time<br />UI Queue<br />JavaScript<br />
  91. After Last UI Update<br />UI Thread<br />JavaScript<br />UI Update<br />UI Update<br />onclick<br />time<br />UI Queue<br />
  92. No Other UI Updates<br />UI Thread<br />JavaScript<br />UI Update<br />UI Update<br />onclick<br />time<br />UI Queue<br />JavaScript<br />
  93. No Other UI Updates<br />UI Thread<br />JavaScript<br />JavaScript<br />UI Update<br />UI Update<br />onclick<br />time<br />UI Queue<br />
  94. Technique #3: Web Workers<br />
  95. Support for Web Workers<br />10.6<br />4.0<br />3.5<br />4.0<br />10<br />
  96. Web Workers<br />Asynchronous JavaScript execution<br />Execution happens outside the UI thread<br />Doesn’t block UI updates<br />Data-Driven API<br />Data is serialized going into and out of the worker<br />No access to DOM or BOM<br />Separate execution environment<br />
  97. //in page<br />var worker = new Worker("process.js");<br />worker.onmessage = function(event){<br /> useData(event.data);<br />};<br />worker.postMessage(values);<br />//in process.js<br />self.onmessage = function(event){<br />var items = event.data;<br />for (var i=0,len=items.length; i < len; i++){<br /> process(items[i]);<br /> }<br /> self.postMessage(items);<br />};<br />
  98. When Clicked<br />UI Thread<br />time<br />UI Queue<br />UI Update<br />onclick<br />UI Update<br />
  99. When Clicked<br />UI Thread<br />UI Update<br />time<br />UI Queue<br />onclick<br />UI Update<br />
  100. When Clicked<br />UI Thread<br />onclick<br />UI Update<br />time<br />UI Queue<br />UI Update<br />
  101. When Clicked<br />UI Thread<br />onclick<br />UI Update<br />time<br />UI Queue<br />Worker Thread<br />UI Update<br />
  102. When Clicked<br />UI Thread<br />UI Update<br />UI Update<br />onclick<br />time<br />UI Queue<br />Worker Thread<br />JavaScript<br />
  103. Worker Thread Complete<br />UI Thread<br />UI Update<br />UI Update<br />onclick<br />time<br />UI Queue<br />onmessage<br />
  104. Worker Thread Complete<br />UI Thread<br />onmessage<br />UI Update<br />UI Update<br />onclick<br />time<br />UI Queue<br />
  105. Recap<br />
  106. The browser UI thread is responsible for<br />both UI updates and JavaScript execution<br />Only one can happen at a time<br />
  107. Responsive UI<br />UI Thread<br />JavaScript<br />UI Update<br />UI Update<br />time<br />
  108. Unresponsive UI<br />UI Thread<br />JavaScript<br />UI Update<br />UI Update<br />time<br />
  109. Avoid Slow Loading JavaScript<br />Dynamically created scripts<br />Deferred scripts<br />Asynchronous scripts<br />
  110. Avoid Slow JavaScript<br />Don't allow JavaScript to execute for more than 50ms<br />Break up long JavaScript processes using:<br />Timers<br />Script Yielding (future)<br />Web Workers<br />
  111. Etcetera<br />My blog: www.nczonline.net<br />Twitter: @slicknet<br />These Slides: slideshare.net/nzakas<br />Hire us: projects@stubbornella.org<br />
  112. Questions?<br />
  113. Creative Commons Images Used<br />http://www.flickr.com/photos/lrargerich/3115367361/<br />http://www.flickr.com/photos/hippie/2406411610/<br />http://www.flickr.com/photos/55733754@N00/3325000738/<br />http://www.flickr.com/photos/eurleif/255241547/<br />http://www.flickr.com/photos/off_the_wall/3444915939/<br />http://www.flickr.com/photos/wwarby/3296379139/<br />http://www.flickr.com/photos/derekgavey/4358797365/<br />http://www.flickr.com/photos/mulad/286641998/<br />http://www.flickr.com/photos/torley/2361164281/<br />http://www.flickr.com/photos/ottoman42/455242/<br />http://www.flickr.com/photos/goincase/3843348908/<br />

×
