Level II Ultrasound   How we do it                      RICON 2011, Lucknow
INTRODUCTION             Detailed                          second                         trimester                       ...
Level II ultrasound    How to start                                                 LMP                                  ...
Fetal biometry BPD Any plane with B/L  thalami and third  ventricle. Maximum transverse  diameter from the outer  edge ...
Head circumference Go more cephaled anteriorly for the plane which will include                              Image   Thi...
Femur length Transducer aligned to long  axis of diaphysis                                   Image Measure only ossified...
Abdominal circumference AC (abdominal  circumference) measures the  outer perimeter of the        Image  abdomen At the ...
The intracranial anatomy Views for cerebral ventricle, Thalami and third ventricle, The cerebellum and cistern  magna....
Ventriculomegaly  Ventricle should measured     from outer to outer wall.    In ventriculomegaly atrial     diameter >10...
Choroid plexus cyst Seen in I-6% of fetus Cystic area in choroid plexus, Typically small <10 mm Can be unilateral or b...
Other AnomaliesAbsence of cranial vault Anencephaly : Exencephaly:Acrania Encephalocele Holoprosencephaly   Lobar   S...
Corpus callosal agenesis• Corpus callosum begins to  develop at 12 wk & fully formed  by 20 wk• CSP seen by 17 wk• Absence...
For cerebellum  Sub-occipito-bragmatic view  It is dumb bell shaped has two   lateral lobes and triangular   shape conne...
Nuchal fold thickness, Measured from the outer  border of occiput to  outer border of skin                               ...
Fetal spine Screen in all three planes sagittal, transverse and coronal For three ossification centre with intact overly...
Fetal spine Transverse view- Three ossification centres are seen in  triangular shape Screen all the vertebra with sligh...
Spina bifida Results from incomplete closure  of bony element of spine  posteriorly It can be open or closed. Most comm...
Fetal chest and diaphragm Most important structure is heart in    the thorax.   Any hypoechoic area other than    heart ...
Fetal chestCongenital cysticadenomatoid malformation:•Stocker’s classification- I, II, III•Azdick’s 2 forms- macrocystic &...
Fetal heart Four chamber view, The aortic outflow tract, The pulmonary artery outflow  tract The crossover of aorta an...
In four chamber view The two ventricles and    ventricular walls should be of    equal size.   Two atria and atrial wall...
Fetal heart Aortic outflow tract this view shows  continuity of inter-ventricular  septum with the anterior wall of  aort...
3 vessel view SVC, Aorta and Pulmonaryartery.Fetal heart rate should beregular(110-150 bpm)                             23
Fetal abdomen Look for normal stomach bubble, It will be seen after 16 wks. If absent rescan after 20  min. Still not s...
 Another bubble is seen adjacent to stomach bubble other  than gall bladder suspect duodenal atresia(double bubble) D/D ...
Fetal abdomen Fetal liver –left lobe is larger in fetus Gall bladder –located to the right side of intra-  hepatic umbil...
Coming to the bowel Dilated bowel can be seen in    abdomen indicative of    obstruction.   It should be >7mm in small  ...
Anterior abdominal wall Look for intact anterior abdominal  wall with cord insertion Anterior abdominal wall defect i.e....
Gastroschiasis Body folds fused normally A small defect arise in the  abdominal wall usually below  the cord insertion....
Fetal hydrops Abnormal accumulation of  fluid in at least 2 body  cavities/ tissues or single  serous collection and  ana...
The urinary tract Fetal kidneys can be seen from 14    wks of gestation trans-abdominal   Best located from transverse s...
MILD RENAL PELVIC DIALATION Renal pelvis AP diameter should  taken inner to inner aspect of  pelvis outline in transverse...
Cystic renal diseaseMulticystic dysplastic kidney (MCDK) Kidney- enlarged & replaced by multiple cysts with  no functioni...
Fetal bladder Usually visible trans-abdominally  from 12 wks of gestation. Normally it empties every 30 to  45 min. Dem...
Obstructive uropathy Presents with bilateral hydro-uretero-nephrosis . Common cause posterior urethral valve. Present w...
Fetal limbs Confirm the three long bones in    all four limbs   Presence of two hands and two    feet with normal carryi...
Skeletal dysplasia-key features Shortening of limbs entire limb-micromelia Humerus / femur –rhizomelia Both bone forea...
Fetal limbs All long bones should be  scanned in longitudinal  section. These should be straight  and symmetrical. AP v...
Fetal limbslateral view of lower leg shows foot  in sagittal section - exclude  rocker bottom foot which is  associated wi...
Hand Outstretched hand view - to  confirm normal appearance of  forefingers and thumb to  exclude  clinodactyly/polydacty...
Fetal face Few views are important Nose lip view Facial profile view Axial views of orbit,  maxilla and mandible Mid ...
Eyes and orbit orbits should be symmetrical separated by a distance equal  to size of an orbit. Lenses should be seen w...
Profile view(sagittal midline) Assessment of forehead, nose    and chin   Anomalies can be seen are   Frontal bossing, ...
Cleft lip/cleft palate Two views are important Nose lip view(coronal face) Axial view of maxilla(alveolar ridge)
Cleft lip and palate
3D & 4D ULTRASOUND• 3D US- Acquisition of a series of 2D  images over a volume f/b image  display in different orientation...
Conclusions The continuing improvement in resolution of ultrasound    systems gives us ability to identify an ever-increa...
Thank You            48
