Provisioning With Cobbler Michael DeHaan 2007
Common Provisioning Goals Fully Automated Installs PXE Reinstalls (w/o PXE) Virtualization
Existing Solutions Are (Usually) ... Non-comprehensive Bought ($$$) or Custom-Built ($$$) Limited In Scope
Cobbler Is... Simple / Unified Open / Sharable Feature-Rich
Cobbler In Action....
Importing A DVD cobbler check  (and edit /var/lib/cobbler/settings) cobbler import --mirror=/media/dvd --name=FC-7
Behind The Scenes Input /usr/bin/cobbler -> /var/lib/cobbler/* Output /tftpboot/* /var/www/cobbler/* /etc/dhcp.conf
Configuration Concepts
Configuration Concepts
Configuration Concepts
Configuration Concepts
Manual Configurations cobbler distro add cobbler profile add cobbler system add
Viewing The Configuration cobbler list cobbler report
PXE Setup manage_dhcp = 1  in /var/lib/cobbler/settings & “cobbler sync” ... (or just set your next-server entry)
PXE Menus Type “menu” Pick a profile Default = local boot
Introducing koan koan  --list-profiles  --server=bootserv.example.com
koan & reinstallation koan  --profile=FC6-x86_64-webserver  --replace-self --server=bootserv.example.com
koan & virtualization koan --virt --profile=virtual-testbed --server=bootserv.example.com
Advanced Features ...
Kernel Options /var/lib/cobbler/settings --kopts
Kickstart Templating examples in /etc/cobbler cobbler system add --ksmeta=”foo=2 bar=8” “$foo $bar” http://cheetahtemplate...
PXE Templating /etc/cobbler ... dhcp.template pxedefault.template pxeprofile.template pxesystem.template
Repository Mirroring cobbler repo add --name=fc6i386updates --mirror=http://... cobbler profile add ...  --repos=”fc6i386u...
Kickstart Tracking /var/log/cobbler ... File Requests Syslog “cobbler status”
Remote Control cobbler enchant --address=192.168.1.100 --profile=FC-7-foo --virt=yes
Summary Unified Provisioning Environment Easy to Use Feature Rich Free / Open / Sharable
Useful Links http://cobbler.et.redhat.com git clone git://et.redhat.com/cobbler git clone git://et.redhat.com/koan [email_...
Q&A
