Slides from the webcast on Dec 2 2015 via NotesCode

1. Utilizing the OpenNTF Domino API
Oliver Busse
We4IT GmbH, Germany
December 2, 2015

2. Oliver Busse
• „Bleeding Yellow“ since R4.5
• Software Architect at We4IT
• Member of the development team of
Aveedo® Application Framework
• IBM Champion for ICS in 2015 + 2016
• OpenNTF Member Director
• XPages Advocate
• IBM Bluemix curious
@zeromancer1972
www.oliverbusse.com

3. Agenda
• What is the OpenNTF Domino API?
• Setup and Implementation
• Other Considerations
• Tons of examples

4. What is the OpenNTF Domino API?

5. What is the OpenNTF Domino API?
• It‘s an open source project on OpenNTF
• It‘s was started in April 2013
• It‘s maintained by generous developers you may know
• It fills the gaps and gives the power you always wanted in Java for
Domino
• It‘s often refered to as „ODA“

6. What is the OpenNTF Domino API? (cont‘d)
• The ODA consists of several packages
• core
• formula
• rest
• xsp
• …
• It‘s an OSGi plugin
• It‘s designed for running on the Domino server (9.0.x+)
• It‘s designed for XPages (Java, SSJS) and Plugins
• It can‘t be used in Java Agents 

7. Key developers of the ODA
• Nathan T. Freeman
• Paul S. Withers
• Jesse Gallagher
• Roland Praml
• Martin Jinoch
• René Winkelmeyer
• Tim Tripcony (never forgotten)

8. Setup and Implementation

9. Resources
• Grab it from OpenNTF (recommended)
• http://www.openntf.org/main.nsf/project.xsp?r=project/OpenNTF%20Domino%20
API
• Grab it from the Git-Repo
• https://github.com/OpenNTF/org.openntf.domino
• Grab it from the OpenNTF Stash
• https://stash.openntf.org/projects/ODA

10. System Logging
• Since the ODA is an OSGi plugin you can install it via the update site
mechanism
• It runs as an extension to the XSP runtime on the HTTP server JVM
• It comes with it‘s own logger

11. Setup: prepare the server
• Set the signer of the NSF as „Sign or run…“ in server
document‘s security section

12. Setup: prepare the updatesite
• Create an updatesite NSF
• Name it whatever you
want
• Make sure you set ACL to
let the server READ
documents

13. Setup: import ODA into update site
• Find the site.xml file to import it as a local update site
into your NSF
• After import goto „Actions, Sign all Content“

14. Setup: add the ODA to server startup
• Add a new line to your server‘s notes.ini file
• edit file manually or
• use a configuration setting (prefered)
• OSGI_HTTP_DYNAMIC_BUNDLES=updatesite.nsf

15. Setup: add the ODA to server startup
• This is what you should see when the server starts:
HTTP JVM: CLFAD0330I: NSF Based plugins are being installed
in the OSGi runtime. For more information please consult the
log
• Check the plugins with
– tell http osgi ss openntf

16. Setup: prepare Domino Designer
• Open DDE‘s preferences
• Goto „Domino Designer“ section
• Activate „Enable Eclipse plug-in install“
• Open the update site NSF you just created
• Goto „Actions, Show URLs“
• Copy one of the two URLs to clipboard
• Goto „File, Application, Install“
• Choose „Search for new features to install“
• On the next screen „Add (a) Remote Location“
• Enter a name for it and paste the URL in the clipboard
• On the next screen check the ODA entry and click next/yes if you are asked to

17. Other Considerations

18. Other Considerations
• ODA utilizes the OpenLog project
• XspOpenLogUtil.logEvent(…)
• XspOpenLogUtil.logError(…)
• Get familiar with the OpenLog project from OpenNTF
• Create a new OpenLog.nsf file in your server‘s root (if you haven‘t
already)

19. Examples

20. Examples
• Session handling
• View handling (loops)
• Document & Field handling
• DateTime enhancements
• Transactions
• Xots
• Graphs

21. Session handling

22. Session handling: different approaches
• Extension Library
• ExtlibUtil.getCurrentSession();
• ExtlibUtil.getCurrentSessionAsSigner();
• ExtlibUtil.getCurrentSessionAsSignerWithFullAccess();
• needs exception handling
• XSPUtil
• like ExtlibUtil
• needs exception handling
• Factory
• Factory.getSession();
• uses enums for different session types
• no exception handling needed!

23. View handling

24. View handling: what you are used to (1)

25. View handling: what you are used to (2)

26. What you now are able to do

27. Document handling

28. Safe lines of code by using new methods
• New creation methods
• Database.createDocument(String, Object, …)
• Database.createDocument(HashMap fields)
• Alternatives to replaceItemValue
• Document.put(String field, Object o)
• Document.putAll(HashMap fields)
• Alternatives to getItemValueXXX
• Document.get(Object o) // document acts like a Map<?>
• Document.getItemValue(String field, Class type)

29. getItemValue: what you are used to
• getItemValue returns a Vector
• Vectors are not type safe
• editor / compiler complains non-type-safety
• they can contain „anything“
• you have to check what is inside
• if the item does not exist you are running into trouble…

30. getItemValue: what you can do now
• cast to a type of your choice
• ArrayList<?> values = doc.getItemValue(„foo", ArrayList.class);
• forget type safety
• define your own!
• a non existing item is returned as null, not as empty Vector
• can be handled

31. DateTime enhancements

32. DateTime enhancements
• Session.createDateTime(y,m,d,hh,mm,ss)
• uses int values
• conversion toJavaDate() not necessary
• DateTime.isBefore();
• DateTime.isAfter();
• useful comparisons
• DateTime.equalsIgnoreDate();
• DateTime.equalsIgnoreTime();

33. Transactions

34. Transactions
• ODA adds transactional capabilities to your Notes data
• You can modify documents without saving them
individually (e.g. in a loop)
• You can also rollback every modification if you need to
(e.g. when you run into an error)

35. Transactions (cont‘d)
• Create a new DatabaseTransaction object from the database
• DatabaseTransaction txn = db.startTransaction();
• Perform your modifications
• Decide whether to commit or rollback
• txn.commit();
• txn.rollback();

36. Xots

37. Xots
• Xots = XPages OSGi Tasklet Service
• It‘s the extended version of DOTS (Domino Tasklet Service)
• Use cases
• Can be coded inside the NSF, no plugin project needed
• Multi-threaded tasks like Runnable, but you can return values
• Bulk execution of time consuming code
• very new feature (alpha)

38. Xots (cont‘d)
• Advantages
• More granular time and event triggering than in Agents
• Can run with server-side permissions
• Runs in a shared container (JVM) unlikely of an Agent which runs in a dedicated
JVM
• you can exchange data between tasklets
• It‘s coded in a plain Java class and not in an Agent design element
• You can use SCM systems

39. Xots (cont‘d)
• Core elements of tasklet
• Interface Callable<?>
• Interface Future<?>
• get() method to get the return value(s)
• only if you are interested in a return value
• Class Xots from the ODA
• submit() method to create a tasklet
• schedule() methods to create a periodic tasklet
• use the PeriodicScheduler!

40. „Graphs“
http://whatis.techtarget.com/definition/graph-database

41. Graph DB
A graph database, also called a graph-oriented database, is a type of NoSQL database
that uses graph theory to store, map and query relationships.
A graph database is essentially a collection of nodes and edges. Each node represents
an entity (such as a person or business) and each edge represents a connection or
relationship between two nodes.
http://whatis.techtarget.com/definition/graph-database

42. Graphs – terminology
• Vertices (Nodes)
• Properties (Key-Value pairs)
• Edges
• Connections, Relations between Vertices
• ElementStores
• for us: NSF databases
• MetaverseIDs
• Replica + UNID (hashed)
• internal use only (don‘t care about them)

43. Graph DB – in Domino?
• Vertices and Edges are stored as Documents
• The data container is a NSF
• The ElementStore defines the filepath to the NSF
• An ElementStore can hold different types of Vertices
• Usually you create one ElementStore for each Vertice type

44. Let‘s see the demo &
some code

45. Resources
• The XPages demo application
• https://bitbucket.org/zeromancer1972/sutol-2015-oda-graph-demo
• A nice glossary
• http://www.intec.co.uk/from-xpages-to-web-app-glossary/
• OpenNTF Domino API
• http://www.openntf.org/main.nsf/project.xsp?r=project/OpenNTF%20Domino%20API
• http://www.openntf.org/main.nsf/project.xsp?r=project/OpenNTF%20Domino%20API%20Demo%20Database
• Xots
• http://www.intec.co.uk/xots-background-and-multithreaded-tasks-the-openntf-domino-api-way-part-one/
• http://www.intec.co.uk/xots-background-and-multithreaded-tasks-the-openntf-domino-api-way-part-two/
• http://www.intec.co.uk/xots-background-and-multithreaded-tasks-the-openntf-domino-api-way-part-three/
• Graphs
• http://de.slideshare.net/ktree19/the-graph-revolution

46. Q & A
