This document provides an overview of use case modeling. It defines what use cases are, how they are created, and the elements that comprise them. Use cases describe the functional requirements of a system from the perspective of an actor. They are developed through user interviews and documentation analysis to understand how users interact with the system. Use cases are then written as text descriptions and organized visually in a use case diagram to show relationships between use cases and actors.

1. .
Week 5 : Use Case Modelling

2. Objectives
■ Understand the rules and style guidelines for use
cases and use case diagrams.
■ Be able to create functional models using activity
diagrams, use cases, and use case diagrams.

3. Key Ideas
• A use case illustrates the activities that are
performed by users of a system.
• Use cases are logical models -- they describe
the activities of a system without specifying
how the activities are implemented.

4. What are Use-Case
Descriptions?
• Describe basic functions of the system
•What the user can do
•How the system responds
• Use cases are building blocks for continued design
activities.

5. How Are Use-Cases
Created?
• Two steps:
• Write text-based case descriptions
• Translate descriptions into diagrams
• Describes one and only one function, but
may have multiple paths.
• Developed working with users for content.

6. Types of Use-Cases
• Overview versus detail
■ The use case represents an important business
process.
■ The use case supports revenue generation or
cost reduction.
■ Technology needed to support the use case is
new or risky and therefore will require
considerable research.
• Essential versus real

7. Elements of a Use-Case
Description
Use Case Name: ID: Importance Level:
Primary Actor: Use Case Type:
Stakeholders and Interests:
Brief Description:
Trigger:
Relationships: (Association, Include, Extend, Generalization)
Normal Flow of Events:
Subflows:
Alternate/Exceptional Flows:

8. Guidelines for Creating Use-Case
Descriptions
• Write each step in “SVDPI” form (write each individual
step in the form subject–verb–direct object and,
optionally, preposition–indirect object)
• Clarify initiator and receivers of action
• Write from independent observer perspective
• Write at same level of abstraction
• Ensure a sensible set of steps
• Apply KISS principle liberally (If the use case becomes
too complex and/or too long, the use case should be
decomposed into a set of use cases)
• Write repeating instructions after the set of steps to be
repeated.

9. Your Turn
• How would you make requirements
gathering (interviews, questionnaires,
observation, and document analysis) more
effective by knowing that eventually you will
be creating use-case descriptions and
diagrams?

10. USE-CASE DIAGRAMS

11. Syntax for Use-Case Diagram

12. The Use-Case Diagram for
Appointment System

13. Types of relationships between use cases:
• 2 types of stereotyped dependencies are:
• extend
• include (sometimes referred as uses)
• stereotypes are written as text strings in
« » symbol such as:
«extend» and «include»
- Stereotypes are placed along the relationship line.
Relationship between Use
Cases

14. • An extend relationship is used when you wish to show
that a use case provides additional functionality that may
be required in another use case.
• Purpose:
• To model optional behaviour or alternative at certain
point in separate use case.
• To mitigate the complexity of base use case
• View as optional system behaviour
Extend Relationship

15. editor
spell checking grammar checking
edit text
<<extend>> <<extend>>
Every time an editor wants to edit
text, he can do spell checking or
grammar checking use case
Extend Relationship

16. • An include relationship is used when you wish to show
that a use case provides additional functionality that
always required in another use case.
• Never stands alone
• Purpose:
• a use case may include more than one other use
cases
• can be used to separate out a sequence of behaviour
that is used in many use cases (reusable or common
behaviour)
Include Relationship

17. customer
deposit funds
withdraw money
verify customer
<<include>>
<<include>>
Every time a customer wants to
deposit funds, he must verify
himself to the system.
Include Relationship

18. • Generalization
• Actors can also be implemented as classes. So, they
can also have the same relationship as classes.
• Common behaviour between a number of actors can
be modelled using generalization relationship
• When several actors play a more general role, it is
described as generalization. The specialized actor
inherit the behaviour of the super class.
• shows that one actor can participate in all the
associations with use cases that the more specific
actor can plus some additional use cases
Relationship between
Actors

19. Relationship between
Actors
Individual
customer corporate
customer
customer
perform card transaction
Credit Card Validation System

20. CREATING USE-CASE
DESCRIPTIONS AND USE-
CASE DIAGRAMS

21. Major Steps in Writing Use-Cases
• Identify the major use-cases
• Expand the major use-case
• Confirm the major use-cases
• Create the use-case diagram

22. Identifying the Major Use-Cases
• Identify the system’s boundaries
• List the primary actors
• List the goals of each primary actor
• Identify and write the major use-cases
• Carefully review use-cases

23. Selecting the Appropriate
Techniques
Interviews JAD Questionnaires Document Observation
Analysis
Type of As-Is As-Is As-Is As-Is As-Is
Information Improve. Improve. Improve.
To-Be To-Be
Depth of High High Medium Low Low
Information
Breadth of Low Medium High High Low
Information
Integration Low High Low Low Low
of Info.
User Medium High Low Low Low
Involvement
Cost Medium Low- Low Low Low-
Medium Medium

24. Summary
• Use-case descriptions are the basis for
further analysis and design.
• Use-case diagrams present a graphical
overview of the main functionality of a
system.

25. Your Turn
• Create the Use Case description and Use
Case diagram for your project
