Our presentation to UKNOF in September 2020
In two very long nights of maintenance we acheived:
- Full table BGP on VyOS converge time in seconds
- Routing on MikroTiks converges near-instantly
- BCP38 (customers cannot spoof source address)
- IRR filtering* (only accept where route/route6 object)
- RPKI (will not accept invalid routes from P/T)
- Templated configuration (repeatable, automated) Single source of truth (the docs become the config)
Marek discusses how his company Faelix uses MikroTik hardware and RouterOS at their network edges to route over 600k IPv4 and 30k IPv6 routes. While there were some initial issues, MikroTik has proven reliable and cost-effective. Marek then explains how Faelix implements firewalling with zero filter rules through a multi-step process. They use fail2ban to block brute force attacks, AMQP to share block lists across routers, and destination NAT misbehaving traffic. Most importantly, they leverage the "/ip route rule" feature to route blocked traffic to a separate routing table for easy isolation without complex firewall rules.
Full table BGP on VyOS converge time in seconds
Routing on MikroTiks converges near-instantly
BCP38 (customers cannot spoof source address)
IRR filtering (only accept where route/route6 object)
RPKI (will not accept invalid routes from P/T)
Templated configuration (repeatable, automated)
Single source of truth (the docs become the config)
VyOS SaltStack YAML Netbox BGP OSPF FRR RPKI IRR XDP
bgpq3 UTRS RTBH NetFlow
