1. THREAD SYNCRONIZATION IN JAVA

2. Threads
 Threads are lightweight processes as the overhead
of switching between threads is less
 The can be easily spawned
 The Java Virtual Machine spawns a thread when
your program is run called the Main Thread

3. Why do we need
threads?
 To enhance parallel processing
 To increase response to the user
 To utilize the idle time of the CPU
 Prioritize your work depending on priority

4. Example
• Consider a simple web server
• The web server listens for request and serves it
• If the web server was not multithreaded, the requests
processing would be in a queue, thus increasing the
response time and also might hang the server if there
was a bad request.
• By implementing in a multithreaded environment, the
web server can serve multiple request simultaneously
thus improving response time

5. Creating
threads
 In java threads can be created by
extending the Thread class or
implementing the Runnable Interface
 It is more preferred to implement the
Runnable Interface so that we can extend
properties from other classes
 Implement the run() method which is the
starting point for thread execution

6. Running threads
• Example
class mythread implements Runnable{
public void run(){
System.out.println(“Thread Started”);
}
}
class mainclass {
public static void main(String args[]){
Thread t = new Thread(new mythread()); // This is the way to
instantiate a thread implementing runnable
interface
t.start(); // starts the thread by running the run method
}
}
• Calling t.run() does not start a thread, it is just a
simple method call.
• Creating an object does not create a thread, calling
start() method creates the thread.

7. Synchronization
Synchronization is prevent
data corruption
Synchronization allows
only one thread to perform
an operation on a object at
a time.
If multiple threads require
an access to an object,
synchronization helps in
maintaining consistency.

8. Example
public class Counter{
private int count = 0;
public int getCount(){
return count;
}
public setCount(int count){
this.count = count;
}
}
 In this example, the counter tells how many an access
has been made.
 If a thread is accessing setCount and updating count
and another thread is accessing getCount at the same
time, there will be inconsistency in the value of count.

9. Fixing the example
public class Counter{
private static int count = 0;
public synchronized int getCount(){
return count;
}
public synchoronized setCount(int count){
this.count = count;
}
}
 By adding the synchronized keyword we make sure that
when one thread is in the setCount method the other
threads are all in waiting state.
 The synchronized keyword places a lock on the object,
and hence locks all the other methods which have the
keyword synchronized. The lock does not lock the
methods without the keyword synchronized and hence
they are open to access by other threads.

10. What about static
methods?
public class Counter{
private int count = 0;
public static synchronized int getCount(){
return count;
}
public static synchronized setCount(int count){
this.count = count;
}
}
 In this example the methods are static and hence are
associated with the class object and not the instance.
 Hence the lock is placed on the class object that is,
Counter.class object and not on the object itself. Any other non
static synchronized methods are still available for access by
other threads.

11. Common
Synchronization mistake
public class Counter{
private int count = 0;
public static synchronized int getCount(){
return count;
}
public synchronized setCount(int count){
this.count = count;
}
}
 The common mistake here is one method is static
synchronized and another method is non static synchronized.
 This makes a difference as locks are placed on two different
objects. The class object and the instance and hence two
different threads can access the methods simultaneously.

12. Object locking
• The object can be explicitly locked in this way
synchronized(myInstance){
try{
wait();
}catch(InterruptedException ex){
}
System.out.println(“Iam in this “);
notifyAll();
}
• The synchronized keyword locks the object. The wait keyword waits for
the lock to be acquired, if the object was already locked by another
thread. Notifyall() notifies other threads that the lock is about to be
released by the current thread.
• Another method notify() is available for use, which wakes up only the next
thread which is in queue for the object, notifyall() wakes up all the threads
and transfers the lock to another thread having the highest priority.

13. 13
Thread Synchronization
• Monitors
• Object with synchronized methods
• Any object can be a monitor
• Methods declared synchronized
• public synchronized int myMethod( int x
)
• Only one thread can execute a synchronized
method at a time
• Obtaining the lock and locking an object
• If multiple synchronized methods, only one may be
active
• Java also has synchronized blocks of code

14. 14
Thread Synchronization
• Thread may decide it cannot proceed
• May voluntarily call wait while accessing a
synchronized method
• Removes thread from contention for monitor object and
processor
• Thread in waiting state
• Other threads try to enter monitor object
• Suppose condition first thread needs has now been met
• Can call notify to tell a single waiting thread to enter
ready state
• notifyAll - tells all waiting threads to enter ready
state

15. 15
Daemon Threads
• Daemon threads
• Threads that run for benefit of other
threads
• E.g., garbage collector
• Run in background
• Use processor time that would
otherwise go to waste
• Unlike normal threads, do not
prevent a program from terminating -
when only daemon threads remain,
program exits
• Must designate a thread as daemon
before start called:
void setDaemon( true );
• Method boolean isDaemon()
• Returns true if thread is a daemon
thread

16. SchedulingThreads
I/O operation completes
start()
Currently executed
thread
Ready queue
•Waiting for I/O operation to be completed
•Waiting to be notified
•Sleeping
•Waiting to enter a synchronized section
Newly created
threads
What happens when
a program with a
ServerSocket calls
accept()?

17. Critical
Section
 The synchronized methods define
critical sections
 Execution of critical sections is mutually
exclusive. Why?

18. Example
public class BankAccount {
private float balance;
public synchronized void deposit(float amount) {
balance += amount;
}
public synchronized void withdraw(float amount) {
balance -= amount;
}
}

19. Critical Sections
Bank Account
deposit()
t1t2t3

20. Deadlock Example
public class BankAccount {
private float balance;
public synchronized void deposit(float amount) {
balance += amount;
}
public synchronized void withdraw(float amount) {
balance -= amount;
}
public synchronized void transfer(float amount,
BankAccount target) {
withdraw(amount);
target.deposit(amount);
}
}

21. public class MoneyTransfer implements Runnable {
private BankAccount from, to;
private float amount;
public MoneyTransfer(
BankAccount from, BankAccount to, float amount) {
this.from = from;
this.to = to;
this.amount = amount;
}
public void run() {
source.transfer(amount, target);
}
}

22. BankAccount aliceAccount = new BankAccount();
BankAccount bobAccount = new BankAccount();
...
// At one place
Runnable transaction1 =
new MoneyTransfer(aliceAccount, bobAccount, 1200);
Thread t1 = new Thread(transaction1);
t1.start();
// At another place
Runnable transaction2 =
new MoneyTransfer(bobAccount, aliceAccount, 700);
Thread t2 = new Thread(transaction2);
t2.start();

23. Deadlocks
deposit()
aliceAccount bobAccount
t1 t2
deposit()
?
transfer()
withdraw()
transfer()
withdraw()

24. Thread Synchronization
 We need to synchronized between
transactions, for example, the consumer-
producer scenario

25. Wait and Notify
 Allows two threads to cooperate
 Based on a single shared lock object
 Marge put a cookie wait and notify Homer
 Homer eat a cookie wait and notify Marge
 Marge put a cookie wait and notify Homer
 Homer eat a cookie wait and notify Marge

26. The wait() Method
 The wait() method is part of the
java.lang.Object interface
 It requires a lock on the object’s monitor to execute
 It must be called from a synchronized method, or from a
synchronized segment of code. Why?

27. Consumer
synchronized (lock) {
while (!resourceAvailable()) {
lock.wait();
}
consumeResource();
}

28. Producer
produceResource();
synchronized (lock) {
lock.notifyAll();
}

29. WAIT/NOTIFY SEQUENCE
Lock Object
Consumer
Thread
Producer
Thread
1. synchronized(lock){
2. lock.wait();
3. produceResource()
4. synchronized(lock) {
5. lock.notify();
6.}
7. Reacquire lock
8. Return from wait()
9. consumeResource();
10. }

30. WAIT/NOTIFY SEQUENCE
Lock Object
Consumer
Thread
Producer
Thread
1. synchronized(lock){
2. lock.wait();
3. produceResource()
4. synchronized(lock) {
5. lock.notify();
6.}
7. Reacquire lock
8. Return from wait()
9. consumeResource();
10. }

31. WAIT/NOTIFY SEQUENCE
Lock Object
Consumer
Thread
Producer
Thread
1. synchronized(lock){
2. lock.wait();
3. produceResource()
4. synchronized(lock) {
5. lock.notify();
6.}
7. Reacquire lock
8. Return from wait()
9. consumeResource();
10. }

32. WAIT/NOTIFY SEQUENCE
Lock Object
Consumer
Thread
Producer
Thread
1. synchronized(lock){
2. lock.wait();
3. produceResource()
4. synchronized(lock) {
5. lock.notify();
6.}
7. Reacquire lock
8. Return from wait()
9. consumeResource();
10. }

33. WAIT/NOTIFY SEQUENCE
Lock Object
Consumer
Thread
Producer
Thread
1. synchronized(lock){
2. lock.wait();
3. produceResource()
4. synchronized(lock) {
5. lock.notify();
6.}
7. Reacquire lock
8. Return from wait()
9. consumeResource();
10. }

34. WAIT/NOTIFY SEQUENCE
Lock Object
Consumer
Thread
Producer
Thread
1. synchronized(lock){
2. lock.wait();
3. produceResource()
4. synchronized(lock) {
5. lock.notify();
6.}
7. Reacquire lock
8. Return from wait()
9. consumeResource();
10. }

35. WAIT/NOTIFY SEQUENCE
Lock Object
Consumer
Thread
Producer
Thread
1. synchronized(lock){
2. lock.wait();
3. produceResource()
4. synchronized(lock) {
5. lock.notify();
6.}
7. Reacquire lock
8. Return from wait()
9. consumeResource();
10. }

36. WAIT/NOTIFY SEQUENCE
Lock Object
Consumer
Thread
Producer
Thread
1. synchronized(lock){
2. lock.wait();
3. produceResource()
4. synchronized(lock) {
5. lock.notify();
6.}
7. Reacquire lock
8. Return from wait()
9. consumeResource();
10. }

37. WAIT/NOTIFY SEQUENCE
Lock Object
Consumer
Thread
Producer
Thread
1. synchronized(lock){
2. lock.wait();
3. produceResource()
4. synchronized(lock) {
5. lock.notify();
6.}
7. Reacquire lock
8. Return from wait()
9. consumeResource();
10. }

38. WAIT/NOTIFY SEQUENCE
Lock Object
Consumer
Thread
Producer
Thread
1. synchronized(lock){
2. lock.wait();
3. produceResource()
4. synchronized(lock) {
5. lock.notify();
6.}
7. Reacquire lock
8. Return from wait()
9. consumeResource();
10. }

39. WAIT/NOTIFY SEQUENCE
Lock Object
Consumer
Thread
Producer
Thread
1. synchronized(lock){
2. lock.wait();
3. produceResource()
4. synchronized(lock) {
5. lock.notify();
6.}
7. Reacquire lock
8. Return from wait()
9. consumeResource();
10. }
