Sync, async and multithreading

Sync, Async,
Multithreading in C#
Tuan Chau, Minh Huynh
May, 2020

Presenter
Tuan Chau
tuanchau@kms-technology.com
tuanchau.mt@gmail.com
2
Minh Huynh
minhhuynh@kms-technology.com
minhhuynh1703@gmail.com

AGENDA
• What is Synchronous ?
• And What is Asynchronous ?
• Task – Task Parallel Library
• Multi-Threading
• Thread Pool
• Thread Safety – Debug when working with
Threading
3

Let’s talk about Synchronous
• What is Synchronous ?
Execute code in sequence
4

And Asynchronous
• What is Async ?
5
Asynchronous programming is ability make the code can run independently.
Code don’t need to run in sequence, it can run parallel which others

And Asynchronous
• Async - Await
7
Async provide a “Await” keyword,

What is Task
• Task
8
A task is an object that represents some work that should be done. The task can tell
you if the work is completed and if the operation returns a result, the task gives you the
result.

What is Task
• How does Task Work
9
In Synchronous:
And in Asynchronous:

Task Parallel Library (TPL)
13
What is Parallel Programming?
Parallel Programming is a type of programming in which many calculations or the
execution of processes are carried out simultaneously.
Points to Remember while working with Parallel Programming:
1. The Tasks must be independent.
2. Order of the execution does not matter

• What is TPL?
14
The Task Parallel Library (TPL) in .NET, is a set of public types and APIs in the
System.Threading and System.Threading.Tasks namespaces. TPL has been created in
order to help developers to easily add parallelism and concurrency in their .NET
applications.
The next following example will help you understand about TPL ☺

• C# supports two types of parallelism:
15
1. Data parallelism
2. Task parallelism

• Data parallelism
16
In the case of Data Parallelism, the operation is applied to each element of a collection. Means each
process does the same work on unique and independent pieces of data.
1. Parallel.For
2. Parallel.ForEach

• Parallel.For
17
The main difference between the Parallel For loop and the standard C# for loop:
For Loop Parallel For Loop
Using Single Thread Using Multiple Thread
The loop is iterated in sequential order The order of the iteration is not going to be
in sequential order

• Parallel.For
18

• Parallel.For
19

• Parallel.For
20

• Parallel.ForEach
21

22

• Task parallelism
23
In the case of Task Parallelism independent computations are executed in parallel. Means each process
performs a different function or executes different code sections that are independent.
1. Parallel.Invoke

• Parallel.For
24

25

26

What is Multi-Threading
• Multi-threading
27
Multithreading is a process in which multiple threads work simultaneously.
It is a process to achieve multitasking. It saves time because multiple tasks
are being executed at a time.
To use Multi-thread, we will
use the namespace
System.Threading

• Life Cycle of Multi-thread
28

• Life Cycle of Multi-thread
• Unstarted: Instance of a thread is created, but haven’t call
Start().
• Ready: Thread is ready to run and waiting for CPU cycle.
• Running: Only one thread within a process can be executed at a
time. At the time of execution, the thread is running state.
• Not-Runnable: Thread is not executable when:
– Sleep() was called.
– Wait() was called.
– Prevented by I/O process.
• Dead: Thread is completed or removed.
29

30
The Thread is in unstarted State

31
The thread is in Running State

32
The thread is not runnable state
Kỹ hơn cho
wait/sleep/join

33
The thread is in Dead State
End thread

• Method of Thread class
34
Join(): Allows one thread to wait until
another thread completes its execution.

35
Join(): Allows one thread to wait until another thread completes its execution.
With join() Without join()

36
Abort(): use for terminating a thread.
Abort() will throws ThreadAbortException to the thread in which it called

• ThreadAbortException
37
Exception when use Abort():
• SecurityException: If the caller does not have the required
permission.
• ThreadStateException: If the thread that is being aborted is
currently suspended.

Thread Pool
Thread pool is a collection of threads which can be used to perform no of task
in background.
Once thread completes its task then it sent to the pool to a queue of waiting
threads, where it can be reused. This reusability avoids an application to create
more threads and this enables less memory consumption.
39

Thread Pool
Using namespace System.Threading
40

Task vs Thread vs BackgroundWorker
42
Pros Cons
Thread - an Actual OS-Level Thread Costly.
Each thread consumes a non-trivial
amount of memory for its stack, and adds
additional CPU overhead as the processor
context-switch between Thread.
ThreadPool - a wrapper around a pool of
threads,
Avoid creating too many Thread.
Best use for short operations, where the
caller does not need the result.
If submit too many task, it can get full and
later work can end up waiting for long-
running items to finish
Task - does not create its own OS thread.
instead, tasks are executed by a
TaskScheduler which simply runs on the
ThreadPool
Task allows user find out when it finishes
and return result.
Task provides LongRunning option, which
will tell the TaskScheduler to spin up a new
Thread rather than running on ThreadPool
Synchronous waiting for a task is bad
practice, it prevents the calling thread
from doing other works, and can lead to
deadlocks
BackgroundWorker - create a thread and
run it in background (
Thread.IsBackground = true)
use when a time-consuming process need
to be executed without affecting the
responsive of user interface.

• How to pass a parameter to thread
48
In Thread class, ParameterizedThreadStart delegate provides an easy way to
pass an object containing data to a thread when you call the Thread.Start method
overload.

Thread Priority
• What is Thread Priority
49
In a Multithreading environment, each thread has their own priority. A thread’s priority shows how
frequently a thread gains the access to CPU resources. Whenever we create a thread in C#, it
always has some priority assigned to it.
public ThreadPriority Priority{ get; set; }
The priorities are:
• Highest: The value of this priorities is 4.
• Above Normal: The value of this priorities is 3
• Normal: The value of this priorities is 2
• Below Normal: The value of this priorities is 1
• Lowest: The value of this priorities is 0

Thread Synchronization
• Lock an object when being used by a thread
52
Lock keyword ensures that one thread is executing a piece of code at one
time. The lock keyword ensures that one thread does not enter a critical section
of code while another thread is in that critical section.
There are 2 way to do:
• Using Lock keyword
• Using Monitor

• Lock
53

• Lock
54

55
Monitor provides a mechanism that synchronizes access to objects. It can
be done by acquiring a significant lock so that only one thread can enter in a
given piece of code at one time. Monitor is no different from lock but the
monitor class provides more control over the synchronization of various
threads trying to access the same lock of code.
The Monitor class has the following methods for the synchronize access to a
region of code by taking and releasing a lock:
• Monitor.Enter
• Monitor.TryEnter
• Monitor.Exit
• Monitor.Wait
• Monitor.Pulse
Monitor.PulseAll

56
Lock and monitor are basically used for the same purpose in multithreading, the
difference is that only when we want more control over synchronization with multiple
threads running for a specific section of code.

• Monitor
– It is associated with an object on demand.
– It is unbound, which means it can be called directly from
any context.
– An instance of the Monitor class cannot be created.
57

58
ACTION DESCRIPTION
Enter, TryEnter Acquires a lock for an object. This action also marks the beginning of a critical section. No
other thread can enter the critical section unless it is executing the instructions in the critical
section using a different locked object.
Wait Releases the lock on an object in order to permit other threads to lock and access the
object. The calling thread waits while another thread accesses the object. Pulse signals are
used to notify waiting threads about changes to an object's state.
Pulse (signal),
PulseAll
Sends a signal to one or more waiting threads. The signal notifies a waiting thread that the state of
the locked object has changed, and the owner of the lock is ready to release the lock. The waiting
thread is placed in the object's ready queue so that it might eventually receive the lock for the
object. Once the thread has the lock, it can check the new state of the object to see if the required
state has been reached.
Exit Releases the lock on an object. This action also marks the end of a critical section protected by the
locked object.

• Monitor.Enter()
Acquires an exclusive lock on a specified object.
59

62
Signaling With Monitor
Using Wait – Pulse – PulseAll
Wait and Pulse signaling, however, has some disadvantages over event wait
handles:
• Wait/Pulse cannot span application domains or processes on a computer.
• You must remember to protect all variables related to the signaling logic with
locks.
• Wait/Pulse programs may confuse developers relying on Microsoft’s
documentation.

63
Signaling With Monitor

Exception of Multi-Threading
• Cross Thread Exception
A cross-thread operation in C# is a call that accesses components from a different thread.
67

Exception of Multi-Threading
• Cross Thread Exception
68

What is Thread safety
Thread safety is a technique which manipulates shared data structure in a
manner that guarantees the safe execution of a piece of code by the multiple
threads at the same time. (what)
Thread safety help to remove 2 conditions in the code: (why to use)
•Race Condition
•Deadlocks
Thread safety is often achieved by synchronizing threads to make sure that
any updates are atomic. (how)

Race condition occurs when two threads access a shared variable at the same time. The first thread
reads the variable, and the second thread writes to the same variable at the same time
Deadlock happens in concurrent or multi-threaded environment. A situation in which two or more
competing threads or tasks wait for the other task to finish and they never finish.

How to make a Thread-safe
•The Interlocked Class :
•The Monitor Class
•ReaderWriterLock Class (.NET 2.0)
•Lock Event (.NET 4.0)
•ManualResetEvents
•Mutex
•Semaphore

• The Interlocked static class provides methods to turn nonatomic operations into atomic ones.
• Helps with threaded programs. It safely changes the value of a shared variable from multiple
threads
• The Interlocked has three basic
operations:
Increment
Decrement
Add
Exchange
CompareExchange
The Interlocked class

• Thread-safety
73
Mutex:
Mutex works like a lock in C# for thread synchronization, but it works across multiple processes. Mutex
provides safety against the external threads.
The Mutex class provides the WaitOne() method which we need to call to lock the resource and
similarly it provides ReleaseMutex() which is used to unlock the resource. Note that a Mutex can only
be released from the same thread which obtained it.

• Mutex
74

• Thread-safety
75
Semaphore:
The Semaphore in C# is used to limit the number of threads that can have access to a shared resource
concurrently.
In other words, we can say that Semaphore allows one or more threads to enter into the
critical section and execute the task concurrently with thread safety.
So, in real-time, we need to use Semaphore when we have a limited number of resources and we want
to limit the number of threads that can use it.

• Thread-safety
76
Semaphore:
The Semaphore in C# is used to limit the number of threads that can have access to a shared resource
concurrently.
In other words, we can say that Semaphore allows one or more threads to enter into the
critical section and execute the task concurrently with thread safety.
So, in real-time, we need to use Semaphore when we have a limited number of resources and we want
to limit the number of threads that can use it.

• Thread-safety
77
Semaphore:
Semaphore semaphore = new Semaphore(2,3); //(InitialCount, MaximumCount)
The InitialCount parameter sets the value for the Int32 variable. That is it defines the initial number of
requests for the semaphore that can be granted concurrently.
MaximumCount parameter defines the maximum number of requests for the semaphore that can be
granted concurrently.

• Mutex
78

Debugging in Multi-threading
• Example
79

• Parallel Stacks Window
80

• Task Window
81

• Parallel Watch
82

Foreground and Background Thread
93
FOREGROUND BACKGROUND
• Foreground threads are those threads that keep
running even after the application exits or quits.
It also has the ability to prevent the current
application from terminating.
• The CLR will not shut down the application until
all Foreground Threads have stopped.
• Background Threads are those threads that will
quit if our main application quits. In short, if our
main application quits, the background thread
will also quit.
• Background threads are views by the CLR and if
all foreground threads have terminated, any
and all background threads are automatically
stopped when the application quits.
From the main thread, we can create other threads for doing the desired task in the program.
The process of developing a program for execution with multiple threads is called
multithreaded programming and the process of execution is called multithreading.

References
94
• Jon Skeet – (2019). C# in Depth, Fourth Edition. Manning Publications
• C#.NET Tutorials For Beginners and Professionals - https://dotnettutorials.net/
• Artemakis Artemiou – (2019) - .NET Multithreading Example Using Task Parallel Library -
https://www.mssqltips.com/sqlservertip/5991/net-multithreading-example-using-task-parallel-
library/

Sync, async and multithreading

More Related Content

What's hot

Similar to Sync, async and multithreading

Recently uploaded

Sync, async and multithreading
