1. The End of Polling
Why and how to transform a REST API
into a Data Streaming API
@StreamdataIOstreamdataio

2. ABOUT ME
Developer Relations Co-Leader France
@Audrey_Neveu
@StreamdataIOstreamdataio

3. MODERN TIMES
@StreamdataIOstreamdataio

4. OUR GOAL
@StreamdataIOstreamdataio

5. ANIMATION IS THE
KEY...
BUT WHY?
@StreamdataIOstreamdataio

6. BECAUSE OF EVOLUTION
@StreamdataIOstreamdataio

7. USER INTERFACE
@StreamdataIOstreamdataio

8. KEEP CALM AND...
@StreamdataIOstreamdataio
LEAVE.

9. REFRESH BUTTON IS EVIL
@StreamdataIOstreamdataio

10. REAL-TIME USER EXPERIENCE
@StreamdataIOstreamdataio

11. @StreamdataIOstreamdataio
F.O.M.O (FEAR OF MISSING OUT)

12. API STREAMING
@StreamdataIOstreamdataio

13. SOLUTIONS FOR REAL-TIME APPLICATIONS
✓ WebHooks
✓ (Long) Polling
@StreamdataIOstreamdataio
✓ Push technologies
✓ Pub/Sub

14. IT’S ALL ABOUT FREQUENCY ...
@StreamdataIOstreamdataio

15. … AND USAGE
@StreamdataIOstreamdataio

16. (Long) Polling
@StreamdataIOstreamdataio

17. POLLING
98.5% of polls are
wasted
Source:
http://resthooks.org/
@StreamdataIOstreamdataio
IS NOT A SOLUTIONMADNESS ™

18. WebHooks
@StreamdataIOstreamdataio

19. @StreamdataIOstreamdataio
✓ webhooks.org
✓ aka User Defined HTTP Callback
✓ concept / method
WEBHOOKS
✓

20. Consumer
HTTP/1.1 201 Created
Link:<http://subscription-
server.com/subscription>;
rel="subscription"
@StreamdataIOstreamdataio
WEBHOOKS
POST /eventsource HTTP/1.1
Host: subscription-server.com
Pragma: subscribe
Callback:
<http://example.com/callback>;
method="POST"
rel="subscriber"
API Provider
POST /callback HTTP/1.1
Host: example.com
Link: <http://subscription-
server.com/subscription>;
rel="subscription"
Content-HMAC: sha1
C+7Hteo/D9vJXQ3UfzxbwnXaijM=
Content-Length: 21
Content-Type: application/x-
www-form-urlencoded
payload=Hello%20world

21. @StreamdataIOstreamdataio
✓ Define a callback URL ✓ Create a subscription endpoint
- GET /webhook
- POST /webhook
- GET /webhook/{id}
- PUT /webhook/{id}
- DELETE /webhook/{id}
TODO LIST
Consumer API Provider
✓ Implement your webhook queue
- inline HTTP Requests
- SQL-based queue
- AMQP broker
- batch

22. @StreamdataIOstreamdataio
CONSUMER SETUP

23. @StreamdataIOstreamdataio
EVENT RECEIVED
POST /callback HTTP/1.1
Host: www.example.com
X-Github-Delivery: 72d3162e-
cc78-11e3-81ab-4c9367dc0958
User-Agent: GitHub-
Hookshot/044aadd
Content-Type: application/json
Content-Length: 6615
X-GitHub-Event: issues
Payload=
{
"action": "opened",
"issue": {
"url": "https://api.github.com/repos/octocat/Hello-World/issues/1347",
"number": 1347,
...
},
"repository" : {
"id": 1296269,
"full_name": "octocat/Hello-World",
"owner": {
"login": "octocat",
"id": 1,
...
},
...
},
"sender": {
"login": "octocat",
"id": 1,
...
}
}

24. PROS AND CONS
@StreamdataIOstreamdataio
✓ Real-Time updates
✓ Easily consumed
✓ Without dedicated resources
✓ Poor user experience
✓ Does not work with all clients
✓ Manual setup✓ Easily integrated
✓ Debugging
✓ (almost) Real-Time updates

25. KNOWN ISSUES
@StreamdataIOstreamdataio
Consumer API Provider
✓ DDoS Attack
✓ Missed notification
✓ DDoS Attack
✓ Deduplication

26. CHECK LIST
@StreamdataIOstreamdataio
Consumer API Provider
✓ Implement authentication
✓ Answers expected?
✓ Monitor payload size
✓ Handle request number
✓ Handle duplicates
✓ One callback per webhook

27. @StreamdataIOstreamdataio
DYNAMIC SUBSCRIPTIONS
✓ HTTP Subscriptions Specification
✓ Restful Webhooks
✓ REST Hooks
✓ PubSubHubbub

28. PubSubHubbub
@StreamdataIOstreamdataio
aka PubSub
aka PuSH

29. @StreamdataIOstreamdataio
RSS / Atom feeds
pubsubhubbub/
Open Protocol
Based on Publish / Subscribe Pattern
PUBSUB
Topic

30. Publishers SubscribersHub
@StreamdataIOstreamdataio
PUBSUB

31. Discovery
@StreamdataIOstreamdataio
SUBSCRIBE - PUBLISHERS
Publishers
Link: <https://my-hub.com/>; rel="hub"
Link: <https://my.resource.com>; rel="self"
<link rel="self" href="https://my-resource.com/">
<link rel="hub" href="https://my-hub.com/">

32. @StreamdataIOstreamdataio
SUBSCRIBE - SUBSCRIBERS 1/2
Subscribers Send subscription request to the Hub
POST https://my-hub.com/
…
hub.mode="subscribe"
hub.topic="https://my-resource.com/"
hub.callback="http://example.com/callback"
hub.secret="my-token"

33. @StreamdataIOstreamdataio
SUBSCRIBE - HUB
Hub Verify intent of the subscribers
GET http://example.com/callback
…
hub.mode="subscribe"
hub.topic="https://my-resource.com/"
hub.challenge="a random string"
hub.lease_seconds=86400

34. @StreamdataIOstreamdataio
SUBSCRIBE - SUBSCRIBERS 2/2
Subscribers
HTTP/1.1 200 OK
Body:{
hub.challenge: "a random string"
}
Answer verification request

35. CONSUMER SETUP
@StreamdataIOstreamdataio

36. @StreamdataIOstreamdataio
PUBLISH - PUBLISHERS
Publishers Ping the Hub
POST https://my-hub.com/
…
hub.mode=publish
hub.url=https://my.updated-resource.com

37. @StreamdataIOstreamdataio
PUBLISH - HUB
Hub (Authenticated) Content Distribution
POST http://example.com/callback
Link: <https://my-hub.com/>; rel="hub"
Link: <https://my.updated-resource.com>;
rel="self"
X-Hub-Signature="my-sha1-signature"

38. @StreamdataIOstreamdataio
PUBLISH - SUBSCRIBERS
Subscribers Pull the updated resource
GET https://my.updated-resource.com

39. @StreamdataIOstreamdataio
{
"object":"page",
"entry":[
{
"id":"51044240199134611",
"time":1447342027,
"changes":[
{
"field":"leadgen",
"value":{
"adgroup_id":0,
"ad_id":0,
"created_time":1447342026,
"leadgen_id":55459717045641545,
"page_id":516540199134611,
"form_id":551111744595541
}
}
]
}
]
}
EVENT RECEIVED

40. @StreamdataIOstreamdataio
UNSUBSCRIBE - SUBSCRIBERS 1/2
Subscribers Send unsubscription request to the Hub
POST https://my-hub.com/
…
hub.mode="unsubscribe"
hub.topic="https://my-resource.com/"
hub.callback="http://example.com/callback"
hub.secret="my-token"

41. @StreamdataIOstreamdataio
UNSUBSCRIBE - HUB
Hub Verify intent of the subscribers
GET http://example.com/callback
…
hub.mode="unsubscribe"
hub.topic="https://my-resource.com/"
hub.challenge="a random string"

42. @StreamdataIOstreamdataio
UNSUBSCRIBE - SUBSCRIBERS 2/2
Subscribers Answer verification request
HTTP/1.1 200 OK
Body:{
hub.challenge: "a random string"
}

43. PROS AND CONS
@StreamdataIOstreamdataio
✓ (almost) Real-Time updates
✓ Easily consumed
✓ Without dedicated resources
✓ Poor user experience
✓ Does not work with all clients
✓ Manual setup✓ Easily integrated
✓ Debugging
✓ Need another call to get data

44. KNOWN ISSUES
@StreamdataIOstreamdataio
Consumer API Provider
✓ DDoS Attack
✓ Missed notification
✓ DDoS Attack
✓ Deduplication

45. WEBHOOK VS DYNAMIC SUBSCRIPTIONS

46. Push Technologies
@StreamdataIOstreamdataio

47. PUSH TECHNOLOGIES
Web-Sockets Server-Sent Events
2008 2006
@StreamdataIOstreamdataio
W3C Specification

48. PUSH TECHNOLOGIES
Web-Sockets Server-Sent Events
Text + Binary Text
@StreamdataIOstreamdataio

49. HTTP/1.1 101 Switching Protocols
Upgrade: websocket
Connection: Upgrade
Sec-WebSocket-Accept: HSmrc0sMlYUkAGmm5OPpG2HaGWk=
Sec-WebSocket-Protocol: chat
Sec-WebSocket-Version: 13
PROTOCOLS
GET /chat HTTP/1.1
Host: example.com
Upgrade: websocket
Connection: Upgrade
Sec-WebSocket-Key: dGhlIHNhbXBsZSBub25jZQ==
Sec-WebSocket-Protocol: chat
Sec-WebSocket-Version: 13
GET /stream HTTP/1.1 1
Host: example.com
Accept: text/event-stream
Web-Sockets
(RFC-6455)
Server-Sent
Events
@StreamdataIOstreamdataio

50. CONFIGURATION
Server-Sent Events
@StreamdataIOstreamdataio
Web-Sockets

51. MESSAGES FORMAT
var msg = {
type: "message",
text: "Hello World!",
id: 12345,
date: Date.now()
};
data: Hello World!
data: Hello World!
data: with two lines
data: {"time": "16:34:36", "text": "Hello World!"}
id: 12345
event: foo
data: Hello World!
retry: 10000
@StreamdataIOstreamdataio
Web-Sockets Server-Sent Events

52. IMPLEMENTATION
Server-Sent Events
@StreamdataIOstreamdataio
Web-Sockets
var websocket =
new WebSocket
('ws://websocketserver/echo');
var eventSource =
new EventSource
('http://sseserver/echo');
websocket.onOpen = function(){
...
};
eventSource.onopen = function(){
...
};
websocket.onMessage = function(e){
var data = e.data;
var message = data.msg;
...
};
eventSource.onMessage = function(e){
var message = e.data;
...
};
websocket.onError = function(e){
...
};
eventSource.onError = function(e){
...
};
...
eventSource
.addEventListener('foo',function(e){
// do something
}, false);
eventSource
.addEventListener('bar',function(e){
// do something else
}, false);

53. LOST IN CONNECTION
Server-Sent Events
@StreamdataIOstreamdataio
Web-Sockets

54. BROWSER SUPPORT
Server-Sent Events
56. 51. 10. 42. 11. 14. 56. 51. 10. 42. 11. UC.
@StreamdataIOstreamdataio
Web-Sockets
source : http://caniuse.com/

55. MOBILE BROWSER SUPPORT
source : http://caniuse.com/
@StreamdataIOstreamdataio
Server-Sent Events
55. 51. 10.2. 21. 53.
Web-Sockets
55. 51. 10.2. 21. 53.

56. PERFORMANCES
8s 5s x1.6
8s 6s x1.3
16s 7s x.2.2
Web-Sockets SSE
source: http://matthiasnehlsen.com/blog/2013/05/01/server-sent-events-vs-websockets/
Diff
@StreamdataIOstreamdataio

57. CHOOSE WISELY
@StreamdataIOstreamdataio

58. Proxy-as-a-Service
✓ works with any JSON API
✓ streaming based on Server-Sent Events
✓ dynamic cache
✓ incremental updates
STREAMDATA.IO
@StreamdataIOstreamdataio

59. JSON-PATCH (RFC-6902)
[{"title":"Value 0","price":66,"param1":"1","param2":"22","param3":"33"},
{"title":"Value 1","price":63,"param1":"11","param2":"2","param3":"53"},
{"title":"Value 2","price":85,"param1":"1","param2":"22","param3":"33"},
{"title":"Value 3","price":21,"param1":"31","param2":"12","param3":"4"},
{"title":"Value 4","price":10,"param1":"151","param2":"22","param3":"33"},
{"title":"Value 5","price":6,"param1":"11","param2":"21","param3":"33"},
{"title":"Value 6","price":60,"param1":"11","param2":"222","param3":"33"}]
[{"title":"Value 0","price":66,"param1":"1","param2":"22","param3":"33"},
{"title":"Value 1","price":63,"param1":"11","param2":"2","param3":"53"},
{"title":"Value 2","price":5,"param1":"1","param2":"22","param3":"33"},
{"title":"Value 3","price":21,"param1":"31","param2":"32","param3":"4"},
{"title":"Value 4","price":10,"param1":"151","param2":"22","param3":"33"},
{"title":"Value 5","price":6,"param1":"11","param2":"21","param3":"33"},
{"title":"Value 6","price":60,"param1":"11","param2":"222","param3":"33"}]
[{"op":"replace","path":"/2/price","value":5},
{"op":"replace","path":"/3/param2","value":"32"}]
@StreamdataIOstreamdataio

60. DEMO
@StreamdataIOstreamdataio

61. VOTE SERVER-SENT EVENTS!
@StreamdataIOstreamdataio

62. THANKS!
Q&A
