The Federal/HX Group operates an industrial park in Linfen, Shanxi Province, China covering the area of 680 football fields. The park has 11 casting production lines with an annual capacity of 230,000 tons and 25 machining lines with an annual capacity of 65 million pieces. It produces parts for various industries such as construction machinery, compressors, automobiles, pumps, valves, and pipes. In 2012, the group produced 160,000 tons of castings and achieved $210 million in sales.

1. The Federal/HX
Group

2. Combined Layout
Located in Linfen city, Shanxi Province
This industrial park occupies approximately the same space as 680 football fields

3. Currently TFG/HX has 11 casting production lines with annual capacity 230,000
tons & 25 machining lines with annual capacity 65 million pieces.
Capacity
6 DISA lines
2 KOYO lines
25 machining lines
3 SINTO V lines
Casting
230,000 tons
Machining
65 million pcs
11 lines
115,000 tons
30,000 tons
85,000 tons
capacity

4. Machining plants
Annual capacity are more than 7 million pieces of machining part.
(Crankcase、crankshaft、flange ) mainly serve customers in Eastern
China.
TFG/HX Plant 1
Annual design capacity Flange 2.4 million pieces/year, Roller 30
Million pieces/year，Mainly serve customers in South China.
TFG/HX Plant 2
Annual capacity are more than 25 million pieces of machining part.
(Crankcase、crankshaft、flange、cylinder ) mainly serve customers in
North China.
TFG/HX Plant 3

5. Production Lines
These 11 casting production lines are:
8 vertical molding lines,
2 vacuum molding lines
1 resin sand molding line.
Construction
Machinery, 120000,
34%
Compressor, 100000,
29%
Automobible , 80000,
23%
Pump,Valve and
Pipe, 10000, 3% Wind Power,
40000, 11%
Construction Machinery
Compressor
Automobible
Pump,Valve and Pipe
Wind Power
Market Structure of 350,000 tons

6. In 2012 the TFG/HX output was 160,000 tons of castings and achieved a
sale of 1.3 billion RMB (210million USD)
Sales
Annual sales
X10,000

7. Main Customers
SECO
ISO9001
ISO14001
OHSAS 18001
TS16949
Management Systems Include

8. Major Products
Compressors Automobile

9. Pump,Valve,Pipe Railway
Major Products

10. Products
Compressor Components

11. Automobile Components
Components of Pump, Valve
Products

12. Casting Equipment
DISA Match 2013 Vertical Molding Machine
Molding Dimension：
480(L)×600(W)×120-330 (thickness) mm
Molding Speed：
325 molds per hour (no cores)
Capacity: 25,000 tons(2 lines)
KOYO SM-60V Vertical Molding Machine
Molding Dimension：
480(L)×600(W)×120-330 (thickness) mm
Molding Speed：
340 molds per hour (no cores)
Capacity:30,000 tons(2 lines)

13. Casting Equipment
DISA 231B Vertical Molding Machine
Molding Dimension：535(L)×650(W)×120-400 (thickness) mm
Molding Speed：500 molds per hour (no cores)
Capacity: 50,000 tons (2lines)

14. Casting Equipment
DISA 131B Vertical Molding Machine
Molding Dimension：535(L)×650(W)×120-400 (thickness) mm
Molding Speed：400 molds per hour (no cores)
Capacity:40,000 tons (2 lines)

15. Casting Equipment
Induction Furnace
(4*5 tons/P; 12 *3 tons/P)
Cupola
(4 * 15 tons/P; 2 *10 tons/P;2 *5 tons/P)

16. Automatic Pouring Machine
from Inductotherm
Cooling Drum
Casting Equipment

17. Machining Equipment
240 units CNC Turning Lathe,
72 units M/C, 23 units Milling ,
114 units different purpose
Drilling machine and 72 units
other purpose machine.

18. Machining Equipment
M/C
CNC Lathe
CNC Lathe CNC Lathe
DrillingM/C

19. Quality Assurance
Analysis of Chemical
Composition
Incoming Inspection Devices
of Raw Material

20. On-site Inspecting Device
of Sand Property
Analyzing Device of Sand Property
Quality Assurance

21. Microstructure Device
(2 Sets)
Spectro Analyzer
(3 Sets)
Quality Assurance

22. Digimatic Universal Testing Machine Digimatic Hardness Tester
Quality Assurance

23. 3D ScannerCMM
Quality Assurance

24. X-Ray Testing Device
Quality Assurance

25. Inspecting Device
CMM Profilometer Leak Tester

26. Thank You！
The Federal/HX Group
Robert Levy, CEO
Info@tfgusa.com
(248) 545-5000 Ext. 102
(248) 545-7014 Fax
www.tfgusa.com
ISO 9001 Certified
