Steel framed structures consist of vertical columns and horizontal beams connected by bolting or welding. There are different types including wall bearing, skeleton, and long span frames. Advantages are high strength, longevity, versatility, sustainability, and faster construction. Disadvantages include high maintenance costs, need for fireproofing, and susceptibility to buckling.

1. STEEL FRAMES
STRUCTURE
BY : HUZAIFA TARIQ

2. UNIVERSITY OF ENGINEERING &
TECHNOLOGY PESHAWAR
Subject : Structural Analysis -1 (Lab)
Course Code : CE-215
Presentation By :
Huzaifa Tariq
Reg No : 20PWCIV5469
ROLL No : 182
DEPARTEMENT OF CIVIL ENGINEERING

3. CONTENTS
Types Of
Frames
Structure Steel Frames
Structure
Types of steel
framed
structures
Advandtages
Disadvantage
Video
Frames
Structure

4. Frame structure
• Definition :
Frames are often used in buildings
and are composed of beams and columns that
are either pin or fixed connected.
• Frames can be extend in two (plane frames) or
three dimensions (space frames).
• The loading on a frame causes bending of its
members, and if it has rigid joint connections.

5. There are different types of structures some of them are :
• R.C.C frame structure
• Steel framed structure
• Timber framed structure
Types of framed structures

6. TYPES OF FRAMED STRUCTURES
Rcc Framed Structure Steel Framed Structure Timber Framed Structure

7. STEEL FRAMED STRUCTURE
• Definition:
Steel frame is typically consisting
of vertical column and horizontal beams which
are riveted, bolted or welded together in a
rectilinear grid. Steel beams are horizontal
structural members that resist loads applied
laterally to their axis. Columns are vertical
structural members that transfer compressive
loads. It can be used to form the skeleton of a
building

8. TYPES OF STEEL FRAMED STRUCTURE
• Some types of steel frame structures are:
Wall Bearing Structure
Skeleton Steel Frame Long Span Steel Frame

9. ADVANTAGES OF STEEL FRAMED STRUCTURE
Some of the most beneficial advantages of steel framed structures
are:
• Higher strength
• Longevity
• Versatility
• Sustainability
• Safety
• Faster build-times
• Cost-effective
• Space maximization

10. DISADVANTAGES OF STEEL FRAMED STRUCTURE
Some of the disadvantages of steel framed structures are:
• High Maintenance Costs And More Corrosion
• Fireproofing Costs
• Susceptibility To Buckling
• Higher Initial Cost / Less Availability

11. PROCEDURE VIDEO

12. SURFACE FINISHING
