My talk about Static Analysis from the IPC Berlin 2016,

1. Static Analysis of PHP
Code
How the Heck did I write so many Bugs?
International PHP Conference Berlin, June 2016
By Rouven Weßling ( )
Ecosystem Developer / Developer Evangelist, Contentful
@RouvenWessling
photo credit: by Achim FischerBrandenburg Gate Berlin (license)

3. What is Static
Analysis?

4. Analysing software without
executing it.

5. Dynamic Analysis
xdebug
xhprof
PHP Analyzer
PHP Vulnerability Hunter
Assertions

6. Why use Static
Analysis?

7. Spend less time on unit tests...

8. ...and code review

10. class ClientTest extends PHPUnit_Framework_TestCase
{
public function testGetSynchronizationManager()
{
$client = new Client('b4c0n73n7fu1', 'cfexampleapi');
$this->assertInstanceOf(Manager::class, $client->getSynchronizationManager());
}
}

11. Easy to integrate in Continuous
Integration

13. Find issues that can not be found
through unit tests

14. PHP 7
Abstract Syntax Tree
Scalar Types
Strict Types

15. PHP is dynamic
Reflection
Variable variables
Referencing classes/functions/properties by string

16. The more static your code is, the
easier it's to reason about.

17. Some tools

18. phpmd phan phpcs phpunit phploc phpcpd phpsa php7cc
Coupling Detector Mondrian PHP
Assumption PhpCodeAnalyzer PHPCodeFixer php7mar PHP
Semantic Versioning Checker PHP Inspection PHP
lint PHP Depend PhpMetrics PHPCheckstyle PHP
Reaper PHP vuln hunter RIPS Parse SonarQube Side
Channel
Analyzer TaintPHP Deptrac PhpDependencyAnalysis PHP
semver checker

19. phpmd phan phpcs phpunit phploc phpcpd phpsa php7cc
Coupling Detector Mondrian PHP
Assumption PhpCodeAnalyzer PHPCodeFixer php7mar PHP
Semantic Versioning Checker PHP Inspection PHP
lint PHP Depend PhpMetrics PHPCheckstyle PHP
Reaper PHP vuln hunter RIPS Parse SonarQube Side
Channel
Analyzer TaintPHP Deptrac PhpDependencyAnalysis PHP
semver checker

20. phpmd phan phpcs phpunit phploc phpcpd phpsa php7cc
Coupling Detector Mondrian PHP
Assumption PhpCodeAnalyzer PHPCodeFixer php7mar PHP
Semantic Versioning Checker PHP Inspection PHP
lint PHP Depend PhpMetrics PHPCheckstyle PHP
Reaper PHP vuln hunter RIPS Parse SonarQube Side
Channel
Analyzer TaintPHP Deptrac PhpDependencyAnalysis PHP
semver checker

21. phpmd phan phpcs phpunit phploc phpcpd phpsa php7cc
Coupling Detector Mondrian PHP
Assumption PhpCodeAnalyzer PHPCodeFixer php7mar PHP
Semantic Versioning Checker PHP Inspection PHP
lint PHP Depend PhpMetrics PHPCheckstyle PHP
Reaper PHP vuln hunter RIPS Parse SonarQube Side
Channel
Analyzer TaintPHP Deptrac PhpDependencyAnalysis PHP
semver checker

22. phpmd phan phpcs phpunit phploc phpcpd phpsa php7cc
Coupling Detector Mondrian PHP
Assumption PhpCodeAnalyzer PHPCodeFixer php7mar PHP
Semantic Versioning Checker PHP Inspection PHP
lint PHP Depend PhpMetrics PHPCheckstyle PHP
Reaper PHP vuln hunter RIPS Parse SonarQube Side
Channel
Analyzer TaintPHP Deptrac PhpDependencyAnalysis PHP
semver checker

23. phpmd phan phpcs phpunit phploc phpcpd phpsa php7cc
Coupling Detector Mondrian PHP
Assumption PhpCodeAnalyzer PHPCodeFixer php7mar PHP
Semantic Versioning Checker PHP Inspection PHP
lint PHP Depend PhpMetrics PHPCheckstyle PHP
Reaper PHP vuln hunter Parse SonarQube Side
Channel
Analyzer TaintPHP Deptrac PhpDependencyAnalysis PHP
semver checker

24. phpmd phan phpcs phpunit phploc phpcpd phpsa php7cc
Coupling Detector Mondrian PHP
Assumption PhpCodeAnalyzer PHPCodeFixer php7mar PHP
Semantic Versioning Checker PHP Inspection PHP
lint PHP Depend PhpMetrics PHPCheckstyle PHP
Reaper PHP vuln hunter Parse SonarQube Side
Channel
Analyzer TaintPHP Deptrac PhpDependencyAnalysis PHP
semver checker

25. phpmd phan phpcs phpunit phploc phpcpd phpsa PHP
Coupling Detector Mondrian PHP
Assumption PhpCodeAnalyzer PHPCodeFixer php7mar PHP
Semantic Versioning Checker PHP Inspection PHP
lint PHP Depend PhpMetrics PHPCheckstyle PHP
Reaper PHP vuln hunter Parse SonarQube Side
Channel
Analyzer TaintPHP Deptrac PhpDependencyAnalysis PHP
semver checker

26. PHP lint
php -l

28. Compiles PHP script with the actual PHP compiler
It's already installed on your computer
Can be used to test compatibility with multiple PHP
versions

29. <?php
namespace ContentfulLog
use PsrHttpMessageRequestInterface;
use PsrHttpMessageResponseInterface;
class NullLogger implements LoggerInterface
{
public function getTimer()
{
return new NullTimer;
}
public function log($api, RequestInterface $request, StandardTimer $timer, ResponseInter
{
}
}

30. PHP 7.0.3 | 10 parallel jobs
.................................X...... 40/40 (100 %)
Checked 40 files in 0.5 seconds
Syntax error found in 1 file
------------------------------------------------------------
Parse error: src/Log/NullLogger.php:9
7| namespace ContentfulLog
8|
> 9| use PsrHttpMessageRequestInterface;
10| use PsrHttpMessageResponseInterface;
11|
Unexpected 'use' (T_USE), expecting '{'

31. Make your life easier
Use PHP-Parallel-Lint

32. Deptrac

33. Software has layers
There should be rules about those layers
Rules are easily broken

34. 1. Define the layers of your architecture
2. Define what layers another layer can access
3. Profit!!!

35. layers:
- name: Controller
collectors:
- type: className
regex: .*Controller.*
- name: Entity
collectors:
- type: className
regex: AstaRwthVorkursticketBundleEntity.*

36. ruleset:
Controller:
- Service
- Entity
- Form
Service:
- Repository
Command:
- Entity
Entity:
- Validator

37. How it works
Parses all files in your code
Stores which classes access which others classes
Checks the graph for rule violations

38. deptrac is alpha, not production ready.
please help us and report feedback / bugs.
Start to create an AstMap for 24 Files.
........................
AstMap created.
start emitting dependencies "InheritanceDependencyEmitter"
start emitting dependencies "BasicDependencyEmitter"
end emitting dependencies
start flatten dependencies
end flatten dependencies
collecting violations.
formatting dependencies.
[...]ServicesPdfOrder::5 must not depend on [...]EntityVorkursticket (Service on Entity)
[...]ServicesPdfOrder::23 must not depend on [...]EntityVorkursticket (Service on Entity)
Found 2 Violations

40. phan

42. Type safety for PHP
Checks docblocks
Signature mismatches
Unused code

43. How it works
Makes 2 passes over the codebase
1. Build a list of all classes, functions, methods, etc.
2. Go trough each function and follow the type of
each variable

44. /**
* @param Locale|string|null $locale
*
* @return string
*/
public function getDescription($locale = null)
{
$localeCode = $this->getLocaleFromInput($locale);
// This checks happens after the call to getLocaleFromInput to make sure
// the Exception for invalid locales is still thrown.
if ($this->description === null) {
return null;
}
return $this->description->$localeCode;
}
src/Delivery/Asset.php:74 PhanTypeMismatchReturn Returning type null
but getDescription() is declared to return string

45. class ContentType
{
/**
* The fields, keyed by ID.
*
* @var object
*/
private $fields = [];
}
src/Delivery/ContentType.php:34 PhanTypeMismatchProperty Assigning array to
property but contentfuldeliverycontenttype::fields is object

46. public function __call($name, $arguments)
{
// Lots of code here
if ($result instanceof Link) {
return $client->resolveLink($result);
}
return array_map(function ($value) use ($client) {
if ($value instanceof Link) {
return $client->resolveLink($value);
}
return $value;
}, $result);
}
src/Delivery/DynamicEntry.php:126
PhanTypeMismatchArgumentInternal Argument 2 (input1) is
contentfuldeliverylink but array_map() takes array
Not a bug

47. Don't trust blindly

48. Bad news?
Requires php-ast
Not easy to deal with library code
Noisy - not easily integrated in CI.

49. The future

50. phan is using brute force for type checking
Roughly as good as the compiler for a statically
typed language
Works, but a Control Flow Graph could give even
deeper insight

51. int foo(int length) {
int x = 0;
for (int i = 0; i < length; i++)
x += 1
return length/x;
}

53. Bottom line
There are dozens of tools - pick what's necessary for
you
Make them part of your Continuous Integration setup
Never trust. Make sure you understand where the
error is coming from.

54. Slides available on Slideshare:
http://www.slideshare.net/rwessling/static-analysis-of-
php-code-ipc-berlin-2016
