1. SORTING ALGORITHMS
Engr. Shaheer Ahmed

2. ALGO - INSERTION SORT (N, A)
A : Array
N : Length of Array A[]
Start Algo
For i:=1 to N-1 do
value := A[i]
j := i-1
while j >= 0 and A[j] > value do
A[j+1] := A[j]
j := j-1
endwhile
A[j+1] = value
Endfor
End Algo

3. Program – Insertion Sort
#include<iostream>
using namespace std;
main()
{
int A[6] = {6,5,4,3,2,1};
int N=6;
int i,j,val;
for(i=1;i<N;i++)
{
val=A[i];
j=i-1;
while(j>=0 && A[j]>val)
{
A[j+1]=A[j];
j=j-1;
}
A[j+1]=val;
}
cout<<endl;
for(int i = 0 ; i<N ; i++)
cout<<A[i]<<" ";
system("pause");
}

4. Insertion Sort

5. Worst case analysis of Insertion Sort
Apply Insertion Sort on the following Data:
7,6,5,4,3,2,1

6. Selection Sort

7. Program – Selection Sort
#include<iostream>
using namespace std;
main()
{
int A[6] = {5,2,6,4,3,1};
int N=6;
int i,sel=0,min,index,swap=0, temp;
//Find smallest number and swap with selected index with each iteration of outer loop
while(sel<N)
{
min = A[sel];
for(i = sel; i< N; i++)
{
if(A[i]<min) //if smaller number is found
{
min=A[i];
index=i; // save index of smaller number
swap=1; // swapping required..
}
}
//swapping
if(swap==1)
{
A[sel] = A[sel] + A[index]; // a = a+b
A[index] = A[sel] - A[index]; // b = a - b
A[sel] = A[sel] - A[index]; // a = a-b
}
sel++;
swap=0;
}
for(int i = 0 ; i<N ; i++)
cout<<A[i]<<" ";
system("pause");
}

8. Apply Selection Sort on the following Data:
7,6,5,4,3,2,1
Worst case analysis of Selection Sort

9. Quick Sort
15 20 35 10 25 55 50 45 40 30
3015 20 10 25 35 55 50 45 40
3015 20 2510 4535 40 50 55
15 2010 25 35 4540 50 55
10 15 20 25 30 35 40 45 50 55
30

10. MERGE SORT
15 , 20 , 35 , 10 , 25 , 55 , 50 , 45
15 20 10 35 25 55 45 50
10 15 20 35 25 45 50 55
10 15 20 25 35 45 50 55
GIVEN DATA
