2011




1       Confidential
    1
Our Core




Design & Manufacture leading products and solutions for the motion
market with focus on Digital Servo Drives –

    Standard Product Lines for Industrial & Commercial applications
    Optimized, cost-effective customer specific tailored application solutions.
    Harsh Environment Solutions




2
Since 1987... Always in Motion
Corporate
Timeline
                                          1996:                               2000:
                                                                                                              2009:
                                  Kollmorgen acquired                    Danaher acquires
               1987:                                                                                 Danaher sells Servotronix
                               Servotronix for standard and         Kollmorgen - Servotronix is
            Established                                                                                   to Servotronix
                                   custom electronics               the Customization center of
                                                                                                           management
                                      development                           excellence




Products
Timeline

                                                                1997
            1990                   1994                         CD drives family                    2007                2011
            Advanced digital       Digital servo drive          (Series 2, Series 5,                Advanced            Servotronix
            servo control          control board for            Pico-Drive series,                  Kollmorgen drive    4th Gen. Drive
            algorithms             Baldor                       PWM Drive series)                   (AKD) Family        Family- CDHD

                                                                1999
                                                                Standard PC based
                          1991                                  Multi-Axis Sercos        2003
                          Amongst first PC                      based Motion             Sensorless
                          integrated 48 axes                    Controller               drive for A/C
                          motion controller                                              applications



                                                              1997 - Numerous customer specific motion applications



    3
Locations




    HQ
    Industrial Hi-Tech Park Petah-Tikva,
    Israel

    Global presence:
         North America
         Europe
         Asia

                                  STX Direct Presence



4
Servotronix Core




5
Our Core


                  • Technology Driven
    Performance
                  • 4 generations of successful families in the market!




                  • 25 years - developing & manufacturing servo drives
    Experience    • More than 500,000 delivered axes
                  • 1,000 man years of motion control



                  • Flexibility - customer specific products and features
    Value         • Focus on QDC - Quality, Delivery, Cost
                  • 30 months warranty on our flagship CDHD drive family!

6
Our Industries

Textile                                  CNC


                                                         Printing

                     Glass
                     Forming




      Wire Bonding
                      Robotics in Semi
                                               Medical




  7
Some of Our Many Customers




8
Servotronix Product Line




9
Standard Products

       CDHD                                     MTHD
4 Gen full featured Drive                       Motors




        PPB                  Low-Voltage Drives          CD Series 5
PWM Interface to Delta Tau                         Full-featured, High performance
                                PicoDAD   LVD




  10
Servotronix 4th Generation
Drive Family:
CDHD




11
CDHD - Servotronix 4thG Drive

World class servo performance packed in a cost effective high power
density drive

Power Range: 1.5, 3, 6, 13 Arms
Features
 Outstanding performance
 Control linear, rotary, DC brushless or brush motors
 Interfaces with most of the existing motor feedbacks in the market
 Supports wide range of communication busses
 Supports a wide range of applications and requirements
 Seamless commissioning - user friendly GUI-based ServoStudio software



 12
Servotronix

     Customization Abilities




13
Flexibility

Custom designed solutions meeting                  Building Blocks Approach
     • Form • Fit • Function • Cost

Building blocks approach
     Ready to use Software and Hardware elements      Layout        Feedback
     Professional development of new elements
     required for specific applications

Higher degree of integration
     Peripheral electronics in the drive           Communications   Motors

     Customer algorithms embedded in the drive
     - Proprietary maintained
     - Customer uses internal resources for core
       competency
                                                     Algorithms     Power Stage

Customer gains unique, competitive Solution

14
Custom Solutions Examples



                E&A
                            Medical
                                            Semi




                                      CNC
     Robotics



                                            Textile
                      A&D


15
Servotronix

     Difference Making Performance




16
Performance / Technology


Focus on Technology and innovative solutions for leading Performance

  Unparalleled dynamic adaptive algorithms:
      Advanced Non-linear Control (ANC): Minimizes settling time and tracking error
      Advanced Linear PWM Current Loop Control (APC): Improved BW; tighter current loop control
      Adaptive Auto-tuning Control (ATC): Adapts to continual load variations


  Application Adaptable:
      Adapts to virtually almost any brushless motor
      Adapts to virtually any feedback configuration
      Capabilities for many types of field bus networking


  Other
      Sensorless motor control
      Cogging Compensation – Automatic motor harmonic correction
      Resolver Correction - Feedback harmonic correction
      Bode Feature - Online, built-in, frequency domain system analysis


 17
Summary



     Our Core: Performance + Experience + Value

     Latest Technology – CDHD Servo Drive Family

     Customizations Capabilities




18
Thank You All
      Toda Raba
