This was a project with Nokia, building a basis towards life sensing. In particular, accelerometer is not too strong in detecting in-vehicle mode. We used the data-driven approach and teased out a couple of other non-GPS sensors that appear strong for user in-vehicle detection.

1. Towards Life Sensing
Barometer-‐based in-‐vehicle detection
Jialing Li
October 2014
Internal Use Only

2. Contextual sensing
Motivation 1:
Context-‐aware apps can tailor user experience (﴾e.g. switching on the
audio interface when user is driving)﴿.
Internal Use Only

3. Smartphone as a virtual assistant
Internal Use Only
Commuting to work
on my scenic back road
Meeting got
rescheduled
to an earlier slot
Re-‐routing to a
faster path
+

4. Contextual sensing
Motivation 2:
Machine-‐learning algorithms (﴾such as voice recognition)﴿ perform more
accurately when contextual information is supplied.
Internal Use Only

5. How does barometer-‐based
in-‐vehicle detection work?
Internal Use Only

7. Vertical Speed ~ the Rate of Pressure Change
Internal Use Only
Wikipedia

8. Feature Engineering
Internal Use Only

9. Internal Use Only
Smoothed Speed
“Drive” Labeled
Air Pressure
"/"$ ![&'(!)(*++,(*]
Smoothed "/"$ ![&'(!
)(*++,(*]
Threshold of ↑ at
0.005
Median of Smoothed
"/"$ ![&'(!)(*++,(*]
Threshold of ↑ at
0.007
Reference
Generating
input for
model

10. Visual inspection of separation between two classes
Internal Use Only

11. Visual inspection of separation between two classes
Internal Use Only

12. Accuracy measurement
Internal Use Only

13. Internal Use Only
Air Pressure
"/"$ ![&'(!)(*++,(*]
Smoothed "/"$ ![&'(!
)(*++,(*]
Threshold of ↑ at
0.005
Median of Smoothed
"/"$ ![&'(!)(*++,(*]
Threshold of ↑ at
0.007
Prediction
Prediction binned on
each 30 seconds
Ground Truth
>reported by user BB
Generating
input for
model
Output
from
model
Ground
Truth

14. Towards a Population Model
Random Forest
Train on one set of users and test on another set
Internal Use Only

15. Internal Use Only
Next: Trip Recognition

17. One major area that needs improvement
Internal Use Only

18. Slow%Driving%is%Hard%to%Detect
Internal Use Only
detected%
annotated%
300%sec%lag% 60%sec%ahead%%
Low%Speed% Low%Speed%

19. What other sensors can we use?
-‐ work in progress
Internal Use Only

20. 1)﴿ Audio sensor
Internal Use Only

21. Harmonics*in*car*engine*noise
Internal Use Only

22. Harmonics*in*car*engine*noise
Internal Use Only
4/2 ! 2200/60 !=!73.33!Hz!

23. Harmonics*in*car*engine*noise
Internal Use Only
Increasing*engine*RPM*

24. Harmonics*FFT of an auidni*os acmlipp ldeu*crilnipg
and after ignition
Internal Use Only

25. Harmonics*Not every cliinp* sisa mthpisl ec*leclaipn
Internal Use Only

26. Borrowing concepts from voice recognition
Internal Use Only

27. Engine on and not idling
Engine off
Engine idling

28. Engine idling
Engine on and not idling
Engine off

29. Potential issues with audio
• Privacy concerns
• Battery drain is huge if continuously
sampled (a barometer-audio hybrid
solution could reduce this problem)
• Sound from other cars = false detection
(need a hybrid solution and/or a system
with memory)

30. 2)﴿ Compass sensor
Internal Use Only

31. • Field strengths
differ at different
locations inside the
car
• Degree of tire
magnetization
varies among
different brands

32. On
Engine State FFT of Compass Speed 16
Off
10
0
0
car entry?

33. As expected,
clear patterns only exist
for a limited number of brands.
Internal Use Only

34. Summary
• Before us, in-vehicle detection relies mostly on GPS,
accelerometer and gyroscope sensors.
• Our POC model using barometer sensor shows huge
improvement in in-vehicle detection over the state-of-the-
art commercial-grade accelerometer-based model.
• The issue with slow-drive can be remedied with audio
(and occasionally compass) sensor.

35. More on barometer
Internal Use Only

36. Extension to other
transportation modes
