This document provides an overview of the RezShield Multihousing Access Control System from Kaba. It summarizes the system components which include an M-Unit Palm device for programming locks, an RFID encoder for encoding credentials, browser-based software, and 79 series locks. It also outlines the system capabilities, benefits like easy use and audit trails, credential options, compliance certifications, and Kaba's installation and support services.

1. Kaba Multihousing & Institutional
RezShield™ Multihousing Access Control  79 Lock Series

2. RezShield™ Multihousing Access Control
System Overview
Sales Presentation © Kaba 12/1/2009 1

3. RezShield™ Multihousing Access Control
System Overview
M-Unit Palm Device OS 4.1
• Used to program and interrogate locks
• Also interrogate with Lock Audit key
RFID Encoder
• Connects directly to PC via USB or to
Ethernet network via TCP/IP
• Supports off-the-shelf MIFARE (ISO
14443A) credentials
• Encodes multiple credentials
Sales Presentation © Kaba 12/1/2009 2

4. RezShield™ Multihousing Access Control
System Overview
• Uses true .net technology – fully distributed open architecture capable
• Browser-based system using Internet Explorer 6.0 or higher
• Property size: up to 16,000 rooms/dorms and 1,000 common door suites (plus
eight inner doors per suite)
• Common areas: 64 areas for both residents and staff
• Time zones: eight customer-defined time zones for residents available with
remote access. Predefined time zones available for staff keycards
• Restricted areas: 200
• Authorization levels: five
• Audit trail of keycard-making transactions: unlimited
Sales Presentation © Kaba 12/1/2009 3

5. RezShield™ Multihousing Access Control
Ideal Market Applications
Public housing authorities
Assisted living facilities
and nursing homes
Transitional
housing programs
Commercial offices
Daycare facilities
Market-rate apartments Condominiums and
town houses
Student housing
Sales Presentation © Kaba 12/1/2009 4

6. RezShield™ Multihousing Access Control
Credential Options
MIFARE Mini
• Resident keys (no audit trail)
MIFARE 1K
• Staff or resident keys
(audit on card, 100 events)
• Available as cards, fobs
and wristbands
Fobs
MIFARE 4K
Keycards • Lock audit key (300 events)
• Key holds one lock audit
(300 events)
Wristbands
Sales Presentation © Kaba 12/1/2009 5

7. RezShield™ Multihousing Access Control
System Benefits
• Easy to use PC-based GUI interface
complete with online help and
tool tips to guide user through
programming functions
• No changes to property network
infrastructure
• Single or multi-station capable
Sales Presentation © Kaba 12/1/2009 6

8. RezShield™ Multihousing Access Control
System Benefits
• Lost or stolen credentials automatically
cancelled by new credential
• Accountability with complete
system audit trail
• Staff credentials with time zones
for controlled access
• Resident credentials with audit
trail for added security
Sales Presentation © Kaba 12/1/2009 7

9. 79 Lock Series
User- Friendly Features
• Standalone lock - no wiring required
• Contactless RFID technology
• Completely sealed reader
• Operates with MIFARE RFID
credentials
• Locks audited using contactless
smart cards
Sales Presentation © Kaba 12/1/2009 8

10. 79 Lock Series
Lock Features
• Keycards do not demagnetize
• Credentials can be presented in any
direction to activate lock reader
• Staff credentials programmable to log
use-history to monitor staff movement
around property
Sales Presentation © Kaba 12/1/2009 9

11. 79 Lock Series
Other Features
Functionality mode Perimeter Access
• 79M – Standard, always locked • RAC
• 79T – Toggle for residential use • Exit device operator
• 79L - Always locked, no thumbturn,
no deadbolt
Model options
• ASM (1 ¼” or 1” faceplate with or without ADB)
• Cylindrical (2 ¾” or 2 3/8” backset with or without thumbturn)
• ESM
Sales Presentation © Kaba 12/1/2009 10

12. 79 Lock Series
Other Features
Override options:
• E - electrical only
• K - standard or recodable
• B - Best Small IC adaptor lever
Lever options:
• E - long or short levers
• K - long or short levers
Finish options:
• Satin Chrome
• Satin Chrome Oceanfront
• Satin Brass
Sales Presentation © Kaba 12/1/2009 11

13. Differentiators
• Developed exclusively for Multihousing
applications
• Patented RFID wake-up function
 Fast read-write
 Long battery-life
(120,000 door openings)
• Off-the-shelf MIFARE credentials
(fobs, wristbands, cards)
• System flexibility (single to multiple
workstations)
• Key override options
 Mechanical
 Electronic
Sales Presentation © Kaba 12/1/2009 12

14. Compliance and Certification
• ADA-compliant levers
• RoHS- and Shabbat-compliant
• UL 10C and ULC S-104, on fire-rated doors
• Florida building code -up to and including three hours: FL13061
• ANSI/BHMA A156.13 mortise locks
• ANSI/BHMA A156.25 electrified locks
• FCC part 15 Class A and CE directive 89/336/EEC
Sales Presentation © Kaba 12/1/2009 13

15. Service & Support
Installations
Factory-certified installation crews throughout the U.S. and Canada
Training
Conducted based upon the completion of installation
Product Service
Technical Support Group available 24/7
call 800.849.8324
Sales Presentation © Kaba 12/1/2009 14
