Build radare2 plugins to support the cLEMENCy architecture introduced in DEF CON 25 CTF Finals https://github.com/MaskRay/r2cLEMENCy

1. r2cLEMENCy
Build plugins to support the cLEMENCy architecture
MaskRay
September 9, 2017
r2con 2017

2. whoami
• MaskRay (宋方睿 Sòng Fāng-ruì)
• https://maskray.me Twitter @HaskRay
• Software Engineer, San Francisco Bay Area, California, US
• Member of Tea Deliverers (CTF team)
• DEF CON 21∼25 CTF Finals (21∼23 blue-lotus, 24 b1o0p,
25 Tea-Deliverers)
• Sadly my RE skill has not improved much over the years…
1

3. Tea Deliverers
• Tea Deliverers = blue-lotus + Nu1L + 110066 + Chaitin Tech
• Chinese
https://maskray.me/blog/2017-08-01-defcon-25-ctf
2

4. DEF CON 25 CTF Finals
Curtain call of 5-year organizer Legitimate Business Syndicate
3

5. cLEMENCy
• Architecture developed by Lightning
• 1 ‘byte’ (nyte) = 9 bits
• 32 27-bit registers + 1 flags register
(Zero,Carry,Overflow,Sign+others)
• ST=r29 (stack register), RA=r30 (link register), PC=r31, r28
(frame register)
• middle-endian
• https://github.com/legitbs/cLEMENCy
• https://blog.legitbs.net/2017/07/
def-con-ctf-2017-final-scores-and-data.html
4

6. cLEMENCy manual
5

7. clemency-emu
% cLEMENCy/cLEMENCy-emu/clemency-emu-debug -d 0 hello.bin
> t # step
R00: 0000000 R01: 0000019 R02: 0000002 R03: 0000007
R04: 0000000 R05: 0000000 R06: 0000000 R07: 0000000
R08: 0000000 R09: 0000000 R10: 0000000 R11: 0000000
R12: 0000000 R13: 0000000 R14: 0000000 R15: 0000000
R16: 0000000 R17: 0000000 R18: 0000000 R19: 0000000
R20: 0000000 R21: 0000000 R22: 0000000 R23: 0000000
R24: 0000000 R25: 0000000 R26: 0000000 R27: 0000000
R28: 0000000 ST: 0000000 RA: 0000000 PC: 0000006
FL: 0000000
0000006: 5200780 smp R00, R01, E
> db 2 3 # hexdump
0000002: 040 001 000
> u 0 2 # disassemble
0000000: 2b0402000002b8 ldt R01, [R00 + 0x57, 3]
0000006: 5200780 smp R00, R01, E
6

8. Instructions
• 2,3,4,6 nytes
• AD r0, r1, r2 # ADd
• ADCI r0, r1, -4 # ADd Immediate with Carry
• M-suffixed instructions: adjacent registers as a pair
• DVSM r3, r27, r31 # r3:r4 = (r27<<27 | r28) /
(r31<<27 | r0)
• LD[SWT] # LoaD 1/2/3 nytes, middle-endian
• ST[SWT] # STore 1/2/3 nytes, middle-endian
7

9. Middle-endian
Word of 2 nytes: a[1] << 9 | a[0]
low 0 1 high
Tri-word of 3 nytes: a[1] << 27 | a[2] << 18 | a[0]
low 2 0 1 high
8

10. Instruction decoding
Instructions consist of 3-nyte groups, with permutation in each group
Opcode in high bits
2 nytes low 0 1 high
3 nytes low 2 0 1 high
4 nytes low 3 2 0 1 high
6 nytes low 5 3 4 2 0 1 high
9

11. Memory mappings
[0000000,4000000) Main Program Memory
[4000000,400001e) Clock IO
[4010000,4011000) Flag IO # Capture the Flag!
[5000000,5002000) Data Received
[5002000,5002003) Data Received Size
[5010000,5012000) Data Sent
[5012000,5012003) Data Sent Size
[5100000,5104000) NFO file
[7ffff00,7ffff1c) Interrupt Pointers
[7ffff80,8000000) Processor Identification and Features
left-closed right-open intervals are convenient
10

12. radare2 plugins
• https://github.com/MaskRay/r2cLEMENCy
• io_9bit.so: IO
• core_clcy.so: custom commands
• bin_clcy.so: loader
• asm_clcy.so: (dis)assembler
• anal_clcy.so: instruction semantics and emulation
• parse_clcy.so: C-like pseudo disassembler and asm.varsub
• More plugin types in core/libs.c:r_core_loadlibs_init
• language, filesystem, debugger, debugger breakpoint, egg
11

13. 1 nyte = 9 bits
Expand 1 nyte to 16-bit unsigned short
12

14. r_io_plugin_clcy
RIOPlugin r_io_plugin_clcy = {
.name = "clcy",
.desc = "cLEMENCy io",
.license = "LGPL3",
.check = _check,
.close = _close,
.extend = _extend,
.lseek = _lseek,
.open = _open,
.read = _read,
.write = _write,
};
13

15. io_clcy
• .open: file → 9-bit units → 16-bit units (2 bytes)
• len = len_bytes*8/9; buf = malloc(len*2);
• One address unit has 2 bytes
io->addrbytes = 2; // RIO::addrbytes
• len argument in read/write still refers to bytes, not 16-bit
• Make sure buffers used by read()/write() are aware of
RIO::addrbytes
• .close: 16-bit → 9-bit → file
14

16. RIO::addrbytes
// A buffer of length RCore::blocksize (default: 256) contains
// blocksize/addrbytes (256/2=128) address units
// Before (every address unit is 1 byte):
while (idx < len) {
r_anal_op (anal, &op, addr + idx, buf + idx,
len - idx);
// After (buf access is aware of RIO::addrbytes):
while (addrbytes * idx < len) {
r_anal_op (anal, &op, addr + idx, buf + addrbytes * idx,
len - addrbytes * idx);
15

17. Call path of a user command
• r_core_prompt_exec
• r_core_cmd
• r_core_subst(;,repeat,comment)
• r_core_subst_i
• r_core_subst_i(@,backquotes,double
quotes,grep,pipe,redirection)
• r_cmd_call
• RCorePlugin::call / builtin commands
(RCore.cmds.cmd['p'])
16

18. r_core_plugin_clcy
RCorePlugin r_core_plugin_clcy = {
.name = "clcy",
.desc = "cLEMENCy core",
.license = "LGPL3",
.call = r_cmd_clcy,
};
static int r_cmd_clcy(struct r_core_t *core, const char *input) {
if (input[0] == '_') {
...
case 'x': hexdump_9byte (core, input, l); break; // "_px"
case 'w': hexdump_18word (core, input, l); break; // "_pw"
case 't': hexdump_27tri (core, input, l); break; // "_pt"
...
return true;
}
return false;
}
17

19. bin_clcy
• Create sections according to cLEMENCy memory mappings
• .add=true, .name="Main", .paddr=0, .size=sz,
• .vsize=0x4000000, .srwx=R_IO_READ|R_IO_EXEC
• Simple IO Layer creates two RIOMap
• file map [0, size) + null map [size, vsize)
18

20. om
[Main_Program_Memory:0x00000000]> om
10 fd: 3 +0x00000000 0x00000000 - 0x00006b67 -r-x fmap.Main_Program_Memory
9 fd: 12 +0x00000000 0x00006b68 - 0x03ffffff -r-x mmap.Main_Program_Memory
8 fd: 11 +0x00000000 0x00000000 - 0x0000001d -rw- mmap.Clock_IO
7 fd: 10 +0x00000000 0x04010000 - 0x04010fff -r-- mmap.Flag_IO
6 fd: 9 +0x00000000 0x05000000 - 0x05001fff -rw- mmap.Data_Received
5 fd: 8 +0x00000000 0x05002000 - 0x05002001 -rw- mmap.Data_Received_Size
4 fd: 7 +0x00000000 0x05010000 - 0x05011fff -rw- mmap.Data_Sent
3 fd: 6 +0x00000000 0x05012000 - 0x05012001 -rw- mmap.Data_Sent_Size
#2 fd: 5 +0x00000000 0x05100000 - 0x05103fff -r-x mmap.NFO
1 fd: 4 +0x00000000 0x07ffff00 - 0x07ffff1b -rw- mmap.Interrupt_Pointers
Main Program Memory has both file map (fmap.) and null map (mmap.)
19

21. r_bin_plugin_clcy
RBinPlugin r_bin_plugin_clcy = {
.name = "clcy",
.desc = "cLEMENCy bin plugin",
.license = "LGPL3",
.baddr = _baddr,
.check_bytes = _check_bytes,
.create = _create,
.destroy = _destroy,
.info = _info,
.load = _load,
.minstrlen = 0,
.patch_relocs = _patch_relocs,
.sections = _sections,
};
20

22. bin_clcy
• How to initialize NFO?
21

23. bin_clcy
• How to initialize NFO?
• .patch_relocs
21

24. bin_clcy
• How to initialize NFO?
• .patch_relocs
• Patch relocations in ELF/bFLT/CGC (Cyber Grand
Challenge), especially useful for ET_REL
21

25. bin_clcy
• How to initialize NFO?
• .patch_relocs
• Patch relocations in ELF/bFLT/CGC (Cyber Grand
Challenge), especially useful for ET_REL
• Abuse it: create and initialize a malloc:// map
21

26. bin_clcy _patch_relocs
static RList *_patch_relocs(RBin *b) {
...
RIOSection sec = {.name = "NFO", .size = n_buf * 2, .vsize = 0x4000,
.flags = R_IO_READ | R_IO_EXEC};
(void)r_io_create_mem_map (b->iob.io, &sec, NFO_VADDR, false);
(void)r_io_write_at (b->iob.io, NFO_VADDR, (const ut8 *)buf, len * 2);
...
}
22

27. asm_clcy
• IDA Pro processor in the game, processor_t.{ana,out}
• disassembler
• assembler
• https://github.com/pwning/defcon25-public by Plaid
Parliament of Pwning
• X macros
23

28. r_asm_plugin_clcy
static RAsmPlugin r_asm_plugin_clcy = {
.name = "clcy",
.desc = "cLEMENCy asm",
.arch = "clcy",
.license = "LGPL3",
.bits = 64, // in accordance with r_anal_plugin_clcy
.disassemble = _disassemble,
.assemble = _assemble,
};
24

29. asm_clcy struct inst_t
typedef struct {
ut64 code, opcode;
int id, size;
ut32 pc, funct;
st32 imm;
ut16 cc, reg_count;
ut8 adj_rb, arith_signed, is_imm, mem_flags, rA, rB, rC, rw, uf;
} inst_t;
25

30. asm_clcy disassembler
// Group instructions by forms
do {
FORMAT( R ) // assume this is an R-form instruction
// If funct == 0b0000000 && arith_signed == 0 && is_imm == 0
// This is ad --> break
INS_3( ad, 0b0000000, funct, 0, arith_signed, 0, is_imm, 0 )
// Try adc
INS_3( adc, 0b0100000, funct, 0, arith_signed, 0, is_imm, 0 )
// Try others
...
FORMAT( R_IMM ) // assume this is an R_IMM-form instruction
INS_2( adci, 0b0100000, arith_signed, 0, is_imm, 1 )
...
} while (0);
#define FORMAT(fmt) ok = decode_##fmt ...
#define INS_1(x,opc,f1,v1) if (inst.opcode==opc && inst.f1==v1) ...
#define INS_2(x,opc,f1,v1,f2,v2) if (inst.opcode==opc && inst.f1==v1 &&
inst.f2==v2) ...
26

31. pdf
Descriptions: asm/d/clcy.sdb
27

32. asm_clcy assembler
• "wa ldt r1, [r0+0x57, 7]; ad. r0,r1,r1"
• Recursive descent parser:
parse_{imm,rA,rB,rC,uf,comma,space,…}
• Reuse X macros in disassembler
Suggest using a recursive descent parser in command parsing
28

33. asm_clcy assemble_BIN_R_IMM
#define FIELD(name, offset, count) | ((ut64)inst->name <<
bit_size-count-offset)
#define FORM_BIN_R_IMM
FIELD(opcode, 0, 8)
FIELD(rA, 8, 5)
FIELD(imm, 13, 14)
static int assemble_BIN_R_IMM(inst_t *inst, const char **src) {
int bit_size = 27;
if (parse_space (inst, src)) return 1; // parse error
if (parse_rA (inst, src)) return 1;
if (parse_comma (inst, src)) return -1;
if (parse_imm_st (inst, src, 14)) return 2;
inst->imm &= (1 << 14) - 1;
if (parse_end (src)) return 2;
inst->size = 3; // 3 nytes
inst->code = 0 FORM_BIN_R_IMM; // assemble all components
return 0;
}
29

34. wa
30

35. anal_clcy
• IDA Pro processor in the game, processor_t.emu
• Differentiate JMP/CALL/MOV/PUSH/RET/SWI/…, whether
COND,IND,MEM,REG,… are used
• R_ANAL_OP_TYPE_{JMP,COND,RCALL,RJMP,CRET,…}
• include/r_anal.h anal/p/anal_gb.c
• Stack pointer delta (arguments, local variables), add_stkpnt
• ESIL translator
31

36. ESIL
• Evaluable Strings Intermedate Language
• anal/esil.c
• Stack-oriented, Forth, DWARF expressions
• mh r0, 0xffdf: 0x3ff,r0,&,10,65503,<<,|,r0,=
• Decent support for 32/64 bits, needing work for 8/16 bits
• What if 27-bit/54-bit (register pair) + middle-endian?
32

37. anal_clcy ESIL
• Just set RAnal::bits to 64 and define custom commands
(r_anal_esil_set_op)
• binop: another argument for variants (carry/multi reg/imm/
signedness/update flags) + instruction family (add/sub/…)
• addcm. r3,r2,r0 : "r0,r2,r3,'.cm+,binop"
• '.cm+
• ' no special, arbitrary character borrowed from Lisp
• . update flags
• c with carry
• + add
33

38. clcy_custom_binop
r_anal_esil_set_op (esil, "binop", clcy_custom_binop);
static int clcy_custom_binop(RAnalEsil *esil) {
bool carry = false, uf = false, mf;
char *op = r_anal_esil_pop (esil), *op1 = op + 1,
*rA = r_anal_esil_pop (esil), *rB = r_anal_esil_pop (esil),
*rC = r_anal_esil_pop (esil);
...
if (*op1 == '.') uf = true, op1++; // .: update flags
if (*op1 == 'c') carry = true, op1++; // c: carry
if (*op1 == 'm') ... // m: multi reg
switch (*op1) {
case '+': a = b + c; if (carry && read_fl (esil) & 2) a++; ...
case '-': ...
}
if (uf) { /* update Carry/Overflow/Sign/Zero flags */ }
...
}
34

39. Local variables/arguments detection
• Analysis engine detects with patterns like 0x..,st,+
• We have custom load/store commands to emulate
LD[STW], ST[STW]
• No-op 0x34,st,+,POP to appease analysis engine
35

40. RAnalPlugin
static RAnalPlugin r_anal_plugin_clcy = {
.name = "clcy",
.desc = "cLEMENCy analysis",
.license = "LGPL3",
.arch = "clcy",
.bits = 64, // we use 64-bit integers in esil to emulate 27-bit and 54-bit
.esil_init = esil_clcy_init,
.esil_fini = esil_clcy_fini,
.esil_intr = esil_clcy_intr,
.esil = true,
.op = &clcy_op,
.set_reg_profile = set_reg_profile,
};
36

41. VV
37

42. parse_clcy
• Bad name
https://github.com/radare/radare2/issues/4317
• How to substitue variables for BP/SP offsets: asm.varsub
• How to generate C-like pseudo disassembly: pdc
38

43. r_parse_plugin_clcy
static int _parse(RParse *p, const char *src, char *dst);
static bool _varsub(RParse *p, RAnalFunction *f, ut64 addr,
int oplen, char *src, char *dst, int len);
RParsePlugin r_parse_plugin_clcy = {
.name = "clcy",
.desc = "cLEMENCy",
.parse = _parse,
.varsub = _varsub,
};
39

44. parse_clcy _parse
static int _parse(RParse *p, const char *src, char *dst) {
RCore *core = p->user;
RAsmOp op;
int len;
// `assemble` could be saved if we had access to metadata of previous
// call to `assemble`
if ((len = assemble (core->assembler->pc, &op, src)) > 0 &&
disassemble (core->assembler->pc, &op, op.buf, len, true) > 0) {
strcpy (dst, op.buf_asm);
} else {
strcpy (dst, src);
}
return true;
}
40

45. pdc
41

46. parse_clcy _varsub
static bool _varsub(RParse *p, RAnalFunction *f, ut64 addr, int oplen,
char *src, char *dst, int len) {
...
// Stack register variable st+%#x
r_list_foreach (bpargs, iter, var) {
if (var->delta >= 0) {
sub = r_str_newf ("[st+%#x", var->delta);
} else {
sub = r_str_newf ("[st-%#x", -var->delta);
}
// replace sub with var->name
...
}
42

47. asm.varsub
See local_* variables. 0 offset is not handled currently
43

48. debug_clcy
Left as exercise.
44

49. https://github.com/MaskRay/r2cLEMENCy
Questions?
45
