1. Protocol buffers and
Microservices
Vladimir Dejanović
Voxxed Days Bristol 02Mar2017
@VladimirD_42#VDB17

2. Let’s Meet
@VladimirD_42#VDB17

3. Agenda
@VladimirD_42#VDB17

4. Agenda
Before Protocol Buffers
@VladimirD_42#VDB17

5. Agenda
Before Protocol Buffers
Protocol Buffers
@VladimirD_42#VDB17

6. Agenda
Before Protocol Buffers
Protocol Buffers
Should I care about Protocol Buffers
@VladimirD_42#VDB17

7. Agenda
Before Protocol Buffers
Protocol Buffers
Should I care about Protocol Buffers
Questions
@VladimirD_42#VDB17

8. In the beginning there was a message
@VladimirD_42#VDB17

9. In the beginning there was a message
@VladimirD_42#VDB17

10. In the beginning there was a message
@VladimirD_42#VDB17

11. In the beginning there was a message
@VladimirD_42#VDB17

12. In the beginning there was a message
@VladimirD_42#VDB17
Message

13. In the beginning there was a message
@VladimirD_42#VDB17
Message
Message => Format

14. Fast Forward to 1996
@VladimirD_42#VDB17

15. Fast Forward to 1996
XML - Extensible Markup Language
@VladimirD_42#VDB17

16. Fast Forward to 1996
XML - Extensible Markup Language
@VladimirD_42#VDB17
Both Human-readable and Machine-readable

17. @VladimirD_42#VDB17
<attendee>
<firstName>John</firstName>
<lastName>Doe</lastName>
<address>
<city>Bristol</city>
<street>Canon's Road</street>
<number>1</number>
</address>
</attendee>
XML Example

18. @VladimirD_42#VDB17
<attendee>
<firstName>John</firstName>
<lastName>Doe</lastName>
<address>
<city>Bristol</city>
<street>Canon's Road</street>
<number>1</number>
</address>
</attendee>
XML Example

19. @VladimirD_42#VDB17
<attendee>
<firstName>John</firstName>
<lastName>Doe</lastName>
<address>
<city>Bristol</city>
<street>Canon's Road</street>
<number>1</number>
</address>
</attendee>
XML Example

20. @VladimirD_42#VDB17
<xsd:element name="attendee" type="AttendeeType"/>
<xsd:complexType name="AttendeeType">
<xsd:sequence>
<xsd:element name="firstName" type="xsd:string"/>
<xsd:element name="lastName" type="xsd:string"/>
<xsd:element name="address" type="AddressType"/>
</xsd:sequence>
</xsd:complexType>
<xsd:complexType name="AddressType">
<xsd:sequence>
<xsd:element name="city" type="xsd:string"/>
<xsd:element name="street" type="xsd:string"/>
<xsd:element name="number" type="xsd:decimal"/>
</xsd:sequence>
</xsd:complexType>

21. @VladimirD_42#VDB17
<attendee>
<firstName>John</firstName>
<lastName>Doe</lastName>
<address>
<city>Bristol</city>
<street>Canon's Road</street>
<number>1</number>
</address>
</attendee>
XML Example

22. @VladimirD_42#VDB17
<attendee>
<firstName>John</firstName>
<lastName>Doe</lastName>
<address>
<city>Bristol</city>
<street>Canon's Road</street>
<number>1</number>
</address>
</attendee>
XML Example
159

23. @VladimirD_42#VDB17
<attendee>
<firstName>John</firstName>
<lastName>Doe</lastName>
<address>
<city>Bristol</city>
<street>Canon's Road</street>
<number>1</number>
</address>
</attendee>
XML Example
159
68

24. Fast Forward to 2000 ( sort of )
@VladimirD_42#VDB17

25. Fast Forward to 2000 ( sort of )
@VladimirD_42#VDB17
JSON

26. Fast Forward to 2000 ( sort of )
@VladimirD_42#VDB17
JSON
“JavaScript Object Notation” (sometimes)

27. Fast Forward to 2000 ( sort of )
@VladimirD_42#VDB17
JSON
“JavaScript Object Notation” (sometimes)
Both Human-readable and Machine-readable

28. Fast Forward to 2000 ( sort of )
@VladimirD_42#VDB17
JSON
“JavaScript Object Notation” (sometimes)
Both Human-readable and Machine-readable
Developer Friendly

29. JSON Example
@VladimirD_42#VDB17
{
firstName : "John",
lastName: "Doe",
address: {
city: "Bristol",
street: "Canon's Road",
number: 1
}
}

30. JSON Example
@VladimirD_42#VDB17
{
firstName : "John",
lastName: "Doe",
address: {
city: "Bristol",
street: "Canon's Road",
number: 1
}
}
90 vs 159

31. JSON Example
@VladimirD_42#VDB17
{
firstName : "John",
lastName: "Doe",
address: {
city: "Bristol",
street: "Canon's Road",
number: 1
}
}
90 vs 159
68

32. No JSON Schema
@VladimirD_42#VDB17

33. No JSON Schema
@VladimirD_42#VDB17
JSON Schema is an Internet Draft currently
in its 5th version, which was released on
October 13, 2016

34. No JSON Schema
@VladimirD_42#VDB17
JSON Schema is an Internet Draft currently
in its 5th version, which was released on
October 13, 2016
http://json-schema.org/latest/json-schema-core.html

35. Fast Forward some more ….
@VladimirD_42#VDB17

36. Fast Forward some more ….
@VladimirD_42#VDB17
Welcome to Microservice Era

37. Fast Forward some more ….
@VladimirD_42#VDB17
Welcome to Microservice Era (Present Time)

38. Fast Forward some more ….
@VladimirD_42#VDB17
Welcome to Microservice Era
Monolith is OUT
(Present Time)

39. Fast Forward some more ….
@VladimirD_42#VDB17
Welcome to Microservice Era
Micro is IN
Monolith is OUT
(Present Time)

40. In the Nutshell
@VladimirD_42#VDB17

41. In the Nutshell
@VladimirD_42#VDB17

42. In the Nutshell
@VladimirD_42#VDB17

43. In the Nutshell
@VladimirD_42#VDB17

44. Network Call, Message and Format
@VladimirD_42#VDB17

45. Network Call, Message and Format
@VladimirD_42#VDB17
Which format should we use

46. Network Call, Message and Format
@VladimirD_42#VDB17
Which format should we use
XML or JSON

47. XML vs JSON
@VladimirD_42#VDB17

48. XML vs JSON
@VladimirD_42#VDB17
XML - security for valid messages ( XSD )

49. XML vs JSON
@VladimirD_42#VDB17
XML - security for valid messages ( XSD )
JSON - we hope all messages will be good

50. XML vs JSON
@VladimirD_42#VDB17
XML - potentially huge size

51. XML vs JSON
@VladimirD_42#VDB17
XML - potentially huge size
JSON - smaller size

52. XML vs JSON
@VladimirD_42#VDB17
High traffic Financial system

53. XML vs JSON
@VladimirD_42#VDB17
Most systems with high traffic
and not “critical” data

54. New Contender
@VladimirD_42#VDB17

55. New Contender
@VladimirD_42#VDB17
Protocol Buffers

56. New Contender
@VladimirD_42#VDB17
Protocol Buffers
Google public release V2 in 2008

57. Protocol Buffer
@VladimirD_42#VDB17

58. Protocol Buffer
@VladimirD_42#VDB17
Protocol buffers are a flexible, efficient,
automated mechanism for serializing
structured data – think XML, but smaller, faster,
and simpler.

59. Protocol Buffer
@VladimirD_42#VDB17
Protocol buffers are a flexible, efficient,
automated mechanism for serializing
structured data – think XML, but smaller,
faster, and simpler.

60. Protocol Buffer
@VladimirD_42#VDB17

61. Generate Code
$ protoc --java_out=src_dir attendee.proto
@VladimirD_42#VDB17

62. @VladimirD_42#VDB17
syntax = "proto2";
package voxxed.bristol;
option java_package = "com.voxxed.bristol.pojo";
option java_outer_classname = "AttendeeProto";
message Attendee {
required string first_name = 1;
required string last_name = 2;
message Address {
required string city = 1;
required string street = 2;
required int32 number = 3;
}
optional Address address = 3;
}

63. @VladimirD_42#VDB17
syntax = "proto2";
package voxxed.bristol;
option java_package = "com.voxxed.bristol.pojo";
option java_outer_classname = "AttendeeProto";
message Attendee {
required string first_name = 1;
required string last_name = 2;
message Address {
required string city = 1;
required string street = 2;
required int32 number = 3;
}
optional Address address = 3;
}

64. @VladimirD_42#VDB17
syntax = "proto2";
package voxxed.bristol;
option java_package = "com.voxxed.bristol.pojo";
option java_outer_classname = "AttendeeProto";
message Attendee {
required string first_name = 1;
required string last_name = 2;
message Address {
required string city = 1;
required string street = 2;
required int32 number = 3;
}
optional Address address = 3;
}

65. @VladimirD_42#VDB17
syntax = "proto2";
package voxxed.bristol;
option java_package = "com.voxxed.bristol.pojo";
option java_outer_classname = "AttendeeProto";
message Attendee {
required string first_name = 1;
required string last_name = 2;
message Address {
required string city = 1;
required string street = 2;
required int32 number = 3;
}
optional Address address = 3;
}

66. @VladimirD_42#VDB17
syntax = "proto2";
package voxxed.bristol;
option java_package = "com.voxxed.bristol.pojo";
option java_outer_classname = "AttendeeProto";
message Attendee {
required string first_name = 1;
required string last_name = 2;
message Address {
required string city = 1;
required string street = 2;
required int32 number = 3;
}
optional Address address = 3;
}

67. @VladimirD_42#VDB17
syntax = "proto2";
package voxxed.bristol;
option java_package = "com.voxxed.bristol.pojo";
option java_outer_classname = "AttendeeProto";
message Attendee {
required string first_name = 1;
required string last_name = 2;
message Address {
required string city = 1;
required string street = 2;
required int32 number = 3;
}
optional Address address = 3;
}

68. @VladimirD_42#VDB17
syntax = "proto2";
package voxxed.bristol;
option java_package = "com.voxxed.bristol.pojo";
option java_outer_classname = "AttendeeProto";
message Attendee {
required string first_name = 1;
required string last_name = 2;
message Address {
required string city = 1;
required string street = 2;
required int32 number = 3;
}
optional Address address = 3;
}

69. @VladimirD_42#VDB17
syntax = "proto2";
package voxxed.bristol;
option java_package = "com.voxxed.bristol.pojo";
option java_outer_classname = "AttendeeProto";
message Attendee {
required string first_name = 1;
required string last_name = 2;
message Address {
required string city = 1;
required string street = 2;
required int32 number = 3;
}
optional Address address = 3;
}

70. @VladimirD_42#VDB17
syntax = "proto2";
package voxxed.bristol;
option java_package = "com.voxxed.bristol.pojo";
option java_outer_classname = "AttendeeProto";
message Attendee {
required string first_name = 1;
required string last_name = 2;
message Address {
required string city = 1;
required string street = 2;
required int32 number = 3;
}
optional Address address = 3;
}

71. @VladimirD_42#VDB17
syntax = "proto2";
package voxxed.bristol;
option java_package = "com.voxxed.bristol.pojo";
option java_outer_classname = "AttendeeProto";
message Attendee {
required string first_name = 1;
required string last_name = 2;
message Address {
required string city = 1;
required string street = 2;
required int32 number = 3;
}
optional Address address = 3;
}

72. @VladimirD_42#VDB17
syntax = "proto2";
package voxxed.bristol;
option java_package = "com.voxxed.bristol.pojo";
option java_outer_classname = "AttendeeProto";
message Attendee {
required string first_name = 1;
required string last_name = 2;
message Address {
required string city = 1;
required string street = 2;
required int32 number = 3;
}
optional Address address = 3;
}

73. @VladimirD_42#VDB17
syntax = "proto2";
package voxxed.bristol;
option java_package = "com.voxxed.bristol.pojo";
option java_outer_classname = "AttendeeProto";
message Attendee {
required string first_name = 1;
required string last_name = 2;
message Address {
required string city = 1;
required string street = 2;
required int32 number = 3;
}
optional Address address = 3;
}

74. @VladimirD_42#VDB17
syntax = "proto2";
package voxxed.bristol;
option java_package = "com.voxxed.bristol.pojo";
option java_outer_classname = "AttendeeProto";
message Attendee {
required string first_name = 1;
required string last_name = 2;
message Address {
required string city = 1;
required string street = 2;
required int32 number = 3;
}
optional Address address = 3;
}

75. @VladimirD_42#VDB17
syntax = "proto2";
package voxxed.bristol;
option java_package = "com.voxxed.bristol.pojo";
option java_outer_classname = "AttendeeProto";
message Attendee {
required string first_name = 1;
required string last_name = 2;
message Address {
required string city = 1;
required string street = 2;
required int32 number = 3;
}
optional Address address = 3;
}

76. Generated Code
Message Classes are all immutable
@VladimirD_42#VDB17

77. Generated Code
Each Message Class has Builder
@VladimirD_42#VDB17

78. Generated Code
static Attendee parseFrom(byte[] data)
static Attendee parseFrom(InputStream input)
@VladimirD_42#VDB17

79. Generated Code
byte[] toByteArray()
void writeTo(OutputStream output)
@VladimirD_42#VDB17

80. Backward Compatibility Don'ts
@VladimirD_42#VDB17

81. Backward Compatibility Don'ts
Change the tag numbers of any existing fields
@VladimirD_42#VDB17

82. Backward Compatibility Don'ts
Change the tag numbers of any existing fields
Add or Delete any required fields
@VladimirD_42#VDB17

83. Backward Compatibility Do's
@VladimirD_42#VDB17

84. Backward Compatibility Do's
Delete optional or repeated fields.
@VladimirD_42#VDB17

85. Backward Compatibility Do's
Delete optional or repeated fields.
Add new optional or repeated fields
@VladimirD_42#VDB17

86. Backward Compatibility Do's
Delete optional or repeated fields.
Add new optional or repeated fields
(But you must use fresh tag numbers )
@VladimirD_42#VDB17

87. Demo
@VladimirD_42#VDB17

88. Conclusion
@VladimirD_42#VDB17

89. Conclusion
JSON and XML are Human friendly
@VladimirD_42#VDB17

90. Conclusion
JSON and XML are Human friendly
@VladimirD_42#VDB17
Protocol Buffers proto file needed

91. Conclusion
Protocol Buffers compact and fast
@VladimirD_42#VDB17

92. Conclusion
Protocol Buffers compact and fast
@VladimirD_42#VDB17
JSON is everywhere

93. Conclusion
Protocol Buffers vs JSON
@VladimirD_42#VDB17

94. Conclusion
Protocol Buffers vs JSON
@VladimirD_42#VDB17
Protocol Buffers vs XML

95. Conclusion
Protocol Buffers would not be a good way to
model a text-based document with markup
@VladimirD_42#VDB17

96. Questions
@VladimirD_42
ed.wong.iv@gmail.com
@VladimirD_42#VDB17

97. Thank You
@VladimirD_42#VDB17
