      COYOTE Closure Overview    ®




      Choose a member of the COYOTE Closure
      Family that Best Suits your Application......
      It all began with the development of a new breed of fiber optic         unique solutions to the varied requirements of an ever-evolving
      closure. Craft friendly. Easily installed. Competitively priced.        fiber optic network. From aerial to underground to every step
      And designed to go wherever fiber optic cable takes you. Over           of the last mile, the COYOTE family of fiber optic closures is
      the years the philosophy has remained constant, and the fam-            there to provide performance you can count on.
      ily has grown with each successive member offering its own


      COYOTE GLC (Ground Level Closure)                                       COYOTE Terminal Closure (Dual Chamber) (Page 1-11)
      Pedestal System (Page 1-4)
                                                                                                                            T h e C OYO T E
                                             The COYOTE GLC Pedestal                                                        Terminal Closure is
                                             System is the first truly her-                                                 available in two
                                             metically sealed pedestal                                                      configurations –
                                             system. With its patented                                                      Dual and Single
                                             segmented end plate design,                                                    Chamber:
                                             it allows you to make adjust-
                                             ments on site or move to an                                                 The unique dual
                                             enclosed work environment.                                                  chamber design
                                             The design also permits a                     RUS LISTED                    provides two dis-
                                             high volume of uncut slack                                                  tinct chambers that
                                             cable storage if needed.         can be configured differently to support up to 24 externally
                                                                              mounted hardened connections, internally mounted cross-
                RUS LISTED
                                                                              connect bulkhead connections or a combination of both. A
                                                                              window designed within the closure interior allows fibers to
      COYOTE Dome Closure (Page 1-9)                                          be passed between chambers. High drop capacity out each
                                            T h e C OYOT E D o m e            of the eight cable ports and the ability to use standard or
                                            Closure was specifically          hardened adapter covers, provides infinite options to support
                                            designed for applications         your network design.
                                            where a domed-st yle
                                            configuration is preferred.       COYOTE Terminal Closure (Single Chamber) (Page 1-12)
                                            It features an innovative                                               The COYOTE Terminal
                                            end plate design with                                                   Closure (Single Chamber)
                                            segmented sections that                                                 is the ideal choice for net-
                                            allow for individual access                                             work designs requiring
                RUS LISTED                  of each cable without                                                   hardened adapter termina-
                                            disruption to surrounding                                               tion. Externally mounted
      cables. A full line of multi-hole grommets ensures the ultimate                                               OptiTap* hardened adapt-
      level of flexibility to meet the demands of ever evolving                                                     ers allow for future instal-
      communications networks.                                                           RUS LISTED
                                                                                                                    lation of up to 12 hardened
                                                                              drops without closure reentry. Compact size allows the closure
      COYOTE In-Line RUNT (Page 1-10)                                         to be installed into pedestals and small hand holes. Additional
                                         The COYOTE In-Line RUNT              drop capacity through the 4 entry ports of the closure base,
                                         Closure has the versatility and      provide added flexibility for the closure to act as a distribution
                                         features that make it a perfect      point for closures deeper in your network.
                                         choice for distribution, node and
                                         fiber to the premises networks.      COYOTE Aerial Drop Closure (Page 1-15)
                                         The compact size allows the                                                  The COYOTE Aerial
                                         closure to be installed into ped-                                            Drop Closure is a
                                         estals and small hand holes,                                                 value priced solution.
                                         keeping your installation costs                                              Features include its
                                         down. High drop capacity and                                                 compact size and
              RUS LISTED                 the capability to be converted to                                            ease of installation –
                                         a terminal closure will allow room                                           no special tools need-
                                         for expansion long after the                                                 ed. It is capable of
                                         initial installation.                                                        higher splice capaci-
                                                                              ties and is designed for PLP’s easy-to-use grommet system.
                                                                              Included is the universal mounting bracket, which permits pole
                                                                              mounting with straps, strand mounting with strand clamps or
                                                                              suspension from “J” hooks secured to a pole.

1-2
      *OptiTap™ is a trademark of Corning Cable Systems.
PREVIOUS         SECTION CONTENTS             SEARCH     NEXT

                                                                                                                   COYOTE® Closure Series: Section


                                                                                                                                                    1
COYOTE Closure Overview  ®




                                                                                                                                                Closure Overview
                                                                                                                                                    COYOTE®
COYOTE LCC (Low Count Closure) (Page 1-16)                               COYOTE Closure (Page 1-25)
                                        The COYOTE LCC is                                            Setting the bar against which all
                                        designed specifically                                        other fiber closures are measured
                                        for low fiber count in-                                      was no small task for our design
                                        stallations and repairs                                      team. But years of research &
                                        within your Fiber-to-                                        development eventually paid off in
                                        the-Home, Node or                                            the form of a rugged and reliable
                                        Curb deployments.                                            design that has become legend.
                                        The closure's compact                                        After over ten years of field use and
            RUS LISTED                  size, use of the versa-                                      several hundred thousand units
                                        tile grommet system                                          sold, the original COYOTE Closure
and internal LITE-GRIP® Splice Platform, make this rugged                                            still remains one of the most highly
closure the economical choice for your network. Designed with                  RUS LISTED            regarded and widely used fiber
ease of use in mind and maximum versatility. Kits have also                                          optic closures in the industry.
been created to support copper applications.
                                                                         COYOTE Cross-Connect and Cross-Connect/
COYOTE DTC (Drop Termination Closure) (Page 1-21)                        Express Closure (Page 1-33)
                                    This new closure design is                                       The COYOTE Cross-Connect
                                    constructed to support butt or                                   C l o s u re wa s d e s i g n e d fo r
                                    inline low count splice applica-                                 applications requiring connector-
                                    tions in a direct buried or below                                ization or cross connecting in the
                                    grade environment and pole/                                      outside plant network. Addition-
                                    wall mounted applications                                        ally, the COYOTE Cross-Connect/
                                    near the end of you network.                                     Express Closure was configured
                                    The closures’ compact size                                       to allow for convenient and safe
                                    and rugged exterior allow for                                    storage of uncut buffer tubes in
installation in tight spaces without compromising functionality.                                     the feeder cable, while providing
                                                                                                     individual connectivity to the fibers
COYOTE Taut Closure (Page 1-22)                                                                      of the drop cables.
                                     The COYOTE Taut Closure
                                     simplifies branch cable taps
                                     or repairs of taut fiber optic      COYOTE Retrofit Closure (Page 1-38)
                                     cables. Features the innova-                                    The COYOTE Retrofit Closure is
                                     tive End Plate from the Dome                                    the right choice for replacement or
                                     Closure and full line of multi                                  expansion of existing fiber optic
                                     hole grommets.                                                  closures.



COYOTE RUNT Closure (Page 1-23)
                                    T h e c o m p a c t C OYOT E         COYOTE® MPC (Multi-Purpose Closure) (Page 16-3)
                                    RUNT Closure is ideal for low
                                                                                                            The COYOTE MPC focuses
                                    fiber count, (up to 48 splices),
                                                                                                            on the MDU environment,
                                    end-of-the-line, node and fiber-
                                                                                                            providing a flexible platform
                                    to-the-curb installations. It will
                                                                                                            to address the multitude of
                                    easily fit into most pedestals
                                                                                                            applications that exist in
                                    and hand holes, and the rug-
                                                                                                            residential and commercial
                                    ged design allows it to be used
                                                                                                            FTTx installations. Con-
                                    in all environments.
                                                                                                            structed of durable, UV
        RUS LISTED                                                                                          stabilized, flame-retardant
                                                                                   RUS LISTED               polymer, the closure permits
                                                                                                            interior or exterior applica-
COYOTE PUP Closure (Page 1-24)                                           tions. Accepting an easy-to-use grommet system and standard
                                    The COYOTE PUP Closure               commercially available fittings, eight cable entrance ports are
                                    offers the perfect choice for low    available around the closure exterior. The MPC’s interior
                                    fiber count distribution applica-    can be configured to address slack storage, splicing, cross
                                    tions involving butt and inline      connect, hardened adapter application or a combination of
                                    installations.The compact size       all. In addition, to minimize installation labor, the closure is
                                    and rugged design allow the          available in pre-terminated configurations.
                                    closure to be applied in below
                                    grade, aerial and buried instal-
                                    lations. Supported by a full line
                                    of COYOTE accessories, this
        RUS LISTED                  closure can grow along with
                                                                                                                                              1-3
                                    your network.
PREVIOUS            SECTION CONTENTS    SEARCH   NEXT




      COYOTE GLC (Ground Level Closure)
                            ®




      The innovation and reliability
                                                                      ■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■



                                                                         PLP Feature Focus
      you have come to expect from                                           ©2009 Preformed Line Products
                                                                      ■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■




      PLP since 1947                                                         Film available at
                                                                            www.preformed.com


      PLP Introduces the COYOTE® GLC (Ground Level Closure),
      the first truly hermetically sealed pedestal system and the
      only pedestal system with PLP’s patented segmented end
      plate design. GLC is the first design that doesn’t force you
      to work where it’s installed and this unique design permits
      a high volume of uncut slack cable storage if needed.

      Key Features:
      •	 Compact: 9.5" x 17" Dome Enclosure secures to a
         19.5" L x 19.5" W x 13" H Base
      •	 Cost Effective: Blended design eliminates the need to
         purchase separate components
      •	 Sealable, Re-Enterable, & Re-Usable: Utilizes the
         same silicone grommet sealing system and segmented
         end plate design that is found throughout the COYOTE
         Dome Closure Family
      •	 Transportable: Slack storage of uncut cable allows
         dome enclosure to be carried to a splice truck or other
         suitable working environment
      •	 Adjustable: Stackable spacer system adapts to the
         base for changing grade levels
      •	 Independent Grounding System: Accessible isolated
         grounding system that allows ground testing to occur
         without entering the splice enclosure
      •	 Durable: Manufactured out of a flame and impact
         resistant polymer
      •	 Securable: Collar latch mechanism allows attachment
         of different security devices
      •	 Modular: Split design allows parts to be added
         or replaced without disrupting other assembled
         components
      •	 Customizable:
         Create the closure
         that fits your
         application needs                RUS LISTED
      •	 Patent	Pending




1-4
PREVIOUS        SECTION CONTENTS      SEARCH     NEXT

                                                                                                            COYOTE® Closure Series: Section


                                                                                                                                         1
COYOTE GLC (Ground Level Closure)
                          ®




                                                                                                                                     (Ground Level Closure)
                                                                                                                                         COYOTE® GLC
Configuration Selection
COYOTE® GLC (Ground Level Closure)
Base with Flat Cover (C1)                                               C1
•	 Ideal	for	slack	storage	of	fiber	optic	cable	with	diameters
   up to .60" (15.24 mm) during initial construction
•	 Base	can	store	100	ft	of	slack	cable
•	 Exterior	Base	Dimensions:	19.5"	L	x	19.5"	W	x	13"	H
   (49 cm x 49 cm x 33 cm)
•	 Protective	cable	routing	channel	on	base	exterior
•	 Slots	provided	in	base	for	securing	cable
•	 Split	base	to	allow	for	installation/replacement	without
   disrupting previously installed GLC components
•	 Base	retention	stakes	available	to	secure	base	in	ground
   (see Accessories Selection)
•	 Base	height	can	be	increased	with	the	use	of	spacers
   (see Accessories Selection)                                                       Cat. No.: COYGLC-C1-000
•	 Durable	flat	cover	with	integrated	handles



COYOTE GLC Dome Assembly with Platform (C2)
•	 Used	for	splicing	cable	stored	in	a	previously	installed	GLC	        C2
   base with flat cover
•	 Dome	Assembly	includes:	(1)	GLC	dome,	(1)	collar,	(1)	fiber
   organizer (see Fiber Organzier Selection), & (1) platform
•	 Dome	Assembly	provides	a	hermetical	seal	to	keep	out	water,
   insects, and rodents
•	 Dome	Size:	9.5"	W	x	17"	L	(24	cm	x	43	cm)
•	 Collar	system	provides	quick	re-entry.	No	special	tools	required.
•	 Integrated	handles	in	collar	allow	for	ease	of	handling	when
   installing/removing dome assembly with platform from base
•	 Collar	latch	allows	for	other	security	devices	to	be	used
•	 Platform	allows	dome	assembly	to	be	attached/detached	from
   GLC base
•	 Split	platform	to	allow	for	installation/replacement	without
   disrupting previously installed GLC components
                                                                        Cat. No.: COYGLC-F1-000       Cat. No.: COYGLC-F3-000
                                                                        Cat. No.: COYGLC-F2-000       Cat. No.: COYGLC-F4-000


Full COYOTE GLC Assembly (C3)
•	 Used	for	splicing	and	storing	cable	during	initial	construction      C3
•	 Allows	for	fiber	splicing	at	a	fixed	or	remote	location	such	as	a
   splice trailer
•	 Dome	Assembly	provides	a	hermetical	seal	to	keep	out	water,
   insects, rodents, and other harmful elements
•	 Various	fiber	organizers	available	to	suit	your	splicing	needs
   (see Fiber Organizer Selection)
•	 Full	GLC	Assembly	includes:	(1)	GLC	Dome,	(1)	Collar,	(1)
   fiber organizer (see Fiber Organzier Selection), (1) platform,
   and (1) base
•	 All	GLC	components	are	modular	and	can	easily	be	replaced
•	 GLC	base	allows	for	storage	of	50	ft	(1524	cm)	cable	legs
•	 Base	retention	stakes	available	to	secure	base	in	ground
   (see Accessory Selection)
•	 Base	height	can	be	increased	with	the	use	of	spacers
   (see Spacer Selection)
                                                                        Cat. No.: COYGLC-F1B-000      Cat. No.: COYGLC-F3B-000
                                                                        Cat. No.: COYGLC-F2B-000      Cat. No.: COYGLC-F4B-000     1-5
PREVIOUS        SECTION CONTENTS            SEARCH    NEXT




      COYOTE GLC (Ground Level Closure)
                 ®




      Fiber Organization Selection
                     Buffer Tube and Unitube/Ribbon Organizer (F1)
      F1             •	 Ideal	for	traditional	single	fusion	or	mass	fusion/
                        ribbon splicing
                                                                              •	 Patented	segmented	end	plate	allows	for	cables
                                                                                 to be added without disrupting previously
                     •	 Accommodates	up	to	96ct	buffer	tube	cable	               installed cables
                        or 144ct unitube/ribbon cable measuring .60"          •	 Provided	with	4	port	end	plate
                        (15.2 mm) or smaller                                  •	 7	port	end	plate	available	upon	request
                     •	 Organizer	includes:	(1)	4-port	end	plate	with	        •	 Adaptable	to	larger	handholes;	if	greater	below
                        universal organizer, (1) gasket, (4) grommets*,          ground storage or if larger cable diameters are
                        (4) strength member brackets, (1) LITE-GRIP®             required for your application
                        Short Splice Tray for Single Fusion, and
                        miscellaneous hardware                                *Standard Kit Grommets include (2)8003663
                     •	 See	Splice	Tray	Section	Chart	on	pg.	1-8               (1)8003664 (1)8003665 – Custom grommet
                     •	 Features	the	latest,	easy	to	use	grommet	              combinations available upon request
                        sealing system

                     Buffer Tube Organizer for Increased Tray and Storage Capacity (F2)
      F2             •	 Ideal	for	traditional	single	fusion	splicing	where
                        more expressed buffer tube storage and/or
                                                                              •	 Patented	segmented	end	plate	allows	for	cables
                                                                                 to be added without disrupting previously
                        splice tray capacity is needed                           installed cables
                     •	 Accommodates	up	to	96ct	buffer	tube	cable	            •	 Provided	with	4	port	end	plate
                        measuring .60" (15.2 mm) or smaller                   •	 7	port	end	plate	available	upon	request
                     •	 Organizer	includes:	(1)	4-port	end	plate	with	        •	 Adaptable	to	larger	handholes;	if	greater	below
                        buffer tube organizer, (1) gasket, (4) grommets*,        ground storage or if larger cable diameters are
                        (4) strength member brackets, (1) LITE-GRIP              required for your application
                        Short Splice Tray for Single Fusion, and
                        miscellaneous hardware                                *Standard Kit Grommets include (2)8003663
                     •	 See	Splice	Tray	Section	Chart	on	pg.	1-8               (1)8003664 (1)8003665 – Custom grommet
                     •	 Features	the	latest,	easy	to	use	grommet	              combinations available upon request
                        sealing system

                     Cross-Connect Organizer for Buffer Tube and Unitube/Ribbon (F3)
      F3             •	 Ideal	for	traditional	single	fusion	or	mass	fusion/
                        ribbon splicing where cross-connect capabilities
                                                                              •	 Features	the	latest,	easy	to	use	grommet
                                                                                 sealing system
                        are needed                                            •	 Patented	segmented	end	plate	allows	for
                     •	 Accommodates	up	to	96ct	buffer	tube	cable	               cables to be added without disrupting previously
                        or 144ct unitube/ribbon cable measuring .60"             installed cables
                        (15.2 mm) or smaller                                  •	 Provided	with	4	port	end	plate
                     •	 Organizer	includes:	(1)	4-port	end	plate	with	        •	 7	port	end	plate	available	upon	request
                        cross-connect organizer, (1) gasket, (4)              •	 Adaptable	to	larger	handholes;	if	greater	below
                        grommets*, (4) strength member brackets, (1)             ground storage or if larger cable diameters are
                        LITE-GRIP Short Splice Tray for Single Fusion,           required for your application
                        and miscellaneous hardware
                     •	 Accommodates	up	to	4	SC,	ST,	LC,	or	FC	               *Standard Kit Grommets include (2)8003663
                        adapter plate modules                                  (1)8003664 (1)8003665 – Custom grommet
                     •	 Can	support	pre-connectorized	splitters                combinations available upon request
                     •	 See	Splice	Tray	Section	Chart	on	pg.	1-8

                     OptiTap™ Organizer for Buffer Tube and Unitube/Ribbon (F4)
      F4             •	 Ideal	for	traditional	single	fusion	or	mass	fusion/
                        ribbon splicing where OptiTap connections
                                                                              •	 Features	the	latest,	easy	to	use	grommet
                                                                                 sealing system
                        might be needed                                       •	 Patented	segmented	end	plate	allows	for	cables
                     •	 Accommodates	up	to	96ct	buffer	tube	cable	               to be added without disrupting previously
                        or 144ct unitube/ribbon cable measuring .60"             installed cables
                        (15.2 mm) or smaller                                  •	 Provided	with	4	port	end	plate
                     •	 Organizer	includes:	(1)	4-port	end	plate	with	        •	 Adaptable	to	larger	handholes;	if	greater	below
                        OptiTap organizer and shroud, (1) gasket, (4)            ground storage or if larger cable diameters are
                        grommets*, (4) strength member brackets, (1)             required for your application
                        LITE-GRIP Short Splice Tray for Single Fusion,
                        and miscellaneous hardware                            *Standard Kit Grommets include (2)8003663
                     •	 Accommodates	up	to	8	OptiTap	adapters                  (1)8003664 (1)8003665 – Custom grommet
                     •	 Can	support	pre-connectorized	splitters                combinations available upon request
1-6                  •	 See	Splice	Tray	Section	Chart	on	pg.	1-8
PREVIOUS   SECTION CONTENTS    SEARCH       NEXT

                                                                                                COYOTE® Closure Series: Section


                                                                                                                             1
COYOTE GLC (Ground Level Closure)
                         ®




                                                                                                                         (Ground Level Closure)
                                                                                                                             COYOTE® GLC
Spacer Selection
Standard Spacer (S1)
•	 Ideal	for	adjusting	the	GLC	base	height	to	ground	level	during	     S1
   the back filling process of the installation of the base
•	 Split	design	allows	for	installation/replacement	without
   disrupting previously installed GLC components
•	 Can	be	stacked	to	achieve	desired	base	height
•	 Each	spacer	increases	the	base	height	by	3"	(7.6	cm)
•	 Standard	Spacer	Kit	includes:	(2)	standard	spacer	halves,
   (4) spacer studs, and (2) self tapping bolts




Grounding Spacer (S2)
•	 Ideal	for	isolated	ground	testing	without	having	to	re-enter	the
   splice enclosure
                                                                       S2
•	 Provides	up	to	7	isolated	ground	connections
•	 Removable	access	plate	on	spacer	exterior	conceals
   grounding plate
•	 Screw-on	terminal	head	for	#6	ground	wire	allows	for	quick
   connection to grounding plate
•	 2.5	ft	(76.2	cm)	flexible	ground	leads	make	connecting	ground
   studs of splice enclosure to the grounding plate in spacer easy
•	 Easily	removable	busbar	permits	quick	ground	isolation
•	 Split	design	allows	for	installation/replacement	without
   disrupting previously installed GLC components
•	 Can	be	stacked	on	top	of	multiple	standard	spacers	(S1)	to
   achieve desired base height
•	 Grounding	spacer	increases	the	base	height	by	3"	(7.6	cm)
•	 Grounding	Spacer	Kit	includes:	(1)	standard	spacer	half,
   (1) grounding spacer half, (1) removable access plate,
   (1) grounding plate, (1) removable buss bar, (4) ground leads,
   (1) screw-on terminal head (4) spacer studs, and (2) self
   tapping bolts




Dual Grounding Spacer (S3)
•	 Includes	all	the	features	and	benefits	as	a	standard	grounding
   spacer (S2)
                                                                       S3
•	 Provides	up	to	14	isolated	ground	connections
•	 Removable	access	plates	on	spacer	exterior	conceal
   grounging plates
•	 Screw	on	terminal	head	for	#6	ground	wire	allows	for	quick
   connection to grounding plate
•	 Dual	Grounding	Spacer	Kit	includes:	(2)	grounding
   spacer halves, (2) removable access plates, (2) ground-
   ing plates, (2) removable buss bars, (8) ground leads,
   (2) screw-on terminal heads (4) spacer studs, and
   (2) self tapping bolts
                                                                                                                       1-7
PREVIOUS        SECTION CONTENTS         SEARCH   NEXT




      COYOTE GLC (Ground Level Closure)
                              ®




                          Grommet Selection                                                  Accessory Selection
      Catalog       Cable Range                                               Catalog
                                           Description    Grommets                                   Description            Accessory
      Number        Inches (mm)                                               Number

                       .40 - .60             1-hole
      8003691                                                                 80809005                 Dome
                     (10.7 - 15.2)          grommet


                       .42 - .60             2-hole                           80809006               Dome Collar
      8003663
                     (10.7 - 15.2)          grommet

                 .50 - .60 (12.7 - 15.2)                                      80809775              Dome Gasket
                                             4-hole
      8003990     .125 - .25 (3.2 - 6.4)
                                            grommet
                     and Flat Drop
                                                                                                     Dome Collar
                                                                              80809793
                       .30 - .43             4-hole                                                 Lock Assembly
      8003664
                      (7.6 - 10.9)          grommet
                                                                              80809781                Cover Kit
                       .125 - .25
                                             6-hole
      8003665          (3.2 - 6.4)
                                            grommet
                     and Flat Drop
                                                                                             42" Base Retention Stake
                                                                              80809788
                 .42 - .60 (10.7 - 15.2)                                                         with Anchor Plate
                                             7-hole
      8003676     .125 - .25 (3.2 - 6.4)
                                            grommet
                     and Flat Drop                                                             Base Retention Stake
                                                                              80809791
                       .125 - .25                                                                   Driver Cap
                                             8-hole
      8003677          (3.3 - 6.4)
                                            grommet                                           LITE-GRIP Splice Blocks
                                                                                                         ®

                     and Flat Drop
                                                                             LGSBS8-5        for Single Fusion (Yellow) -
                                                                                                    5 splice blocks
                       Flat Drop             4-hole
      8003989
                      Cable Only            grommet                                         LITE-GRIP Splice Blocks for
                                                                             LGSBR3-5           Mass Fusion/Ribbon
                                                                                              (Purple) - 5 splice blocks
                       Flat Drop             12-hole
      8003796
                      Cable Only            grommet                                                 COYOTE     ®

                                                                             800013213
                                                                                                Cross-Connect Tray

                                                                                            Express Fiber Storage Ring
                                                                              80808613
                          Splice Tray Selection                                              for LITE-GRIP Splice Tray

                                                             GLC Fiber                            Parking Lot for
                                                             Organizer        80808817      Cross-Connect Organizer –
                                                             Reference                         Holds 6 Connectors
                   Splice                                      Code
      Catalog      Count/                     Splice                                            CORNING OptiTap     TM


      Number        Type      Description      Tray      F1 F2 F3 F4          80808152
                                                                                                    Adapter
                  16 Single LITE-GRIP®
      LGSTS16                                            2     6   2     2
                   Fusion    Short Tray                                       80807972        OptiTap Installation Tool

                  40 Single LITE-GRIP
      80808945                                           2     6   2     2
                   Fusion   Short Tray                                        80809766           Shield Connector
                  144 Mass
                           LITE-GRIP
      LGSTR144     Fusion/                               2     6   2     2   Contact PLP
                           Short Tray                                                          COYOTE PLC Splitter
                   Ribbon                                                     for details
                  12 Single
      80806033                  Standard                 3     8   3     3   Contact PLP
                   Fusion                                                                         Adapter Modules
                                                                              for details
                  12 Single
      80807701              Low Profile                  4    13   4     4
                   Fusion                                                    Contact PLP
                                                                                              Pigtail Cable Assemblies
                                                                              for details

                                                                             Contact PLP        Optical Drop Cable
                                                                              for details           Assembly
1-8
PREVIOUS            SECTION CONTENTS                          SEARCH    NEXT

                                                                                                                         COYOTE® Closure Series: Section


                                                                                                                                                                  1
COYOTE Dome Closure     ®




                                                                                                                                                              Dome Closure
                                                                                                                                                                COYOTE®
Evolution of the Breed Continues…                                                                          ■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■




The COYOTE Dome
                                                                                                              PLP Feature Focus
                                                                      RUS
                                                                                                                   ©2009 Preformed Line Products
Closure Family has                                                                                         ■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■


increased in size! The
new 9.5" x 28" High                                                  LISTED                                        Film available at
                                                                                                                  www.preformed.com
Capacity Dome Closure
is available in three                                                                     COYOTE Dome Closure Kits
different configurations
                                                                       Catalog
and can also be used                                                   Number       Description
with 9.5" Ar madillo                                                   8006944      6.5" x 17" COYOTE Dome for Buffer Tube (Loose Tube)
Stainless shells, further
                                                                       8006945      6.5" x 17" COYOTE Dome for Ribbon
expanding the possibilities to address your network needs.
                                                                      800012587     6.5" x 17" COYOTE Dome for Ribbon – Expanded Storage
The innovative, segmented end plate design in the new 9.5"
diameter offers 7 cable entrance ports capable of accepting            8006988      6.5" x 17" COYOTE Dome Express (Loose Tube)
cables with a maximum diameter of 1.25" (32 mm).The unique                          6.5" x 17" COYOTE Dome Cross-Connect (Empty)
                                                                      800012185
                                                                                    (Loose Tube)
design allows each cable entrance to be accessed without
disruption to the surrounding cables. The new end plate               800012940     6.5" x 17" COYOTE Dome Flame Retardant (Ribbon)
accepts the full line of multi-hole grommets designed to              800012941     6.5" x 17" COYOTE Dome Flame Retardant (Loose Tube)
ensure the ultimate flexibility and high capacity to meet the         800012942     6.5" x 22" COYOTE Dome Flame Retardant (Loose Tube)
demands of ever evolving communication networks.                      800012943     6.5" x 22" COYOTE Dome Flame Retardant
                                                                       8006877      6.5" x 22" COYOTE Dome for Buffer Tube (Loose Tube)
The COYOTE Dome Closure was built from the ground up                  800012606     6.5" x 22" COYOTE Dome for Copper
using the same craft-friendly fiber management technology              8006878      6.5" x 22" COYOTE Dome for Ribbon
that placed the COYOTE family among the most respected                800012441     6.5" x 22" COYOTE Dome for Ribbon – Expanded Storage
and reliable in the industry. Re-entry is quick and requires no
                                                                       8006946      6.5" x 22" COYOTE Dome Express (Loose Tube)
special tools or re-entry kits. Both the 6.5" and 9.5" designs
                                                                                    6.5" x 22" COYOTE Dome Cross-Connect (Empty)
are also convertible to closure shells for in-line applications or    800012184
                                                                                    (Loose Tube)
to provide additional drop capacity. For connectivity solutions,
                                                                       8006879      6.5" x 28" COYOTE Inline Dome for Buffer Tube (Loose Tube)
the COYOTE Dome closures are also available in cross-
                                                                       8006880      6.5" x 28" COYOTE Inline Dome for Ribbon
connect configurations. By combining these features with a
wide offering of splice trays and accessories, PLP has the             80061055     9.5" x 28" COYOTE Dome for Buffer Tube (Loose Tube)
ability to address virtually any network design.                       80061056     9.5" x 28" COYOTE Dome for Ribbon
                                                                       80061057     9.5" x 28" COYOTE Dome for High Capacity (Max Tray Count)
The COYOTE Dome Closure is tested in accordance with the
demanding requirements of the Telcordia GR-771-CORE                               Mounting Hardware And Accessory Kits
specification for all aerial, buried and underground environ-
                                                                       Catalog
ments. Manufactured in accordance with ISO9001:2008                    Number       Description
procedures to assure quality and backed by the experience              8003681      End Plate Kit – 6.5" Dome
and field support that PLP has been noted for since 1947  .
                                                                       8003839      End Plate Kit – 9.5" Dome
                                                                      80807383      Hardware Bag for End Plate
Key Features:                                                         80808651      Extended Strength Member Bracket Kit
•	 Available	Sizes:	6.5"	x	17"	(17cm	x	43cm),	                        80808878      Large Strength Member Adapter Kit
   6.5" x 22" (17cm x 56cm), 9.5" x 28" (24cm x 71cm)                 80807848      End Plate Gasket – 6.5" Dome
•	 Patented	segmented	End	Plate	design	provides	indepen-              80808426      End Plate Gasket – 9.5" Dome
   dent access to every cable                                         80808456      End Plate Assembly Fixture – 6.5" or 9.5" Dome
•	 6.5"	End	Plate:	4	entry	ports	accepting	max	cable	                  8003702      Pole / Wall Mount Bracket – 6.5" Dome
   diameter of 1-1/4" (32mm)                                                        Aerial Hanger Bracket – Dome Mount
                                                                       8003831
•	 9.5"	End	Plate:	7	entry	ports	accepting	max	cable	                               (Strand Mount) – 6.5" Dome
   diameter of 1-1/4" (32mm)                                           8003707      Swing Arm for Hand Holes – 6.5" Dome
•	 Fiber	Organizers	and	End	Plates	come	fully	assembled	               8003835      Universal Mounting Bracket Kit for Hand Holes – 6.5" Dome
   – minimizing the parts to handle                                    8003942      Pole / Wall Mount Bracket – 9.5" Dome
•	 Simple	to	use	multi	hole	and	single	hole	grommets	                  8003941      Aerial Hanger Bracket – End Plate Mount – 9.5" Dome
   provide the ability to support high drop capacities                 8003940      Aerial Hanger Bracket – Dome Mount – 9.5" Dome
•	 No	special	tools	or	torque	wrenches	required	for	installation
                                                                     Maximum splice capacities are calculated by multiply-
•	 Collar	system	allows	for	quick	re-entry                           ing the maximum tray quantity per closure by the
•	 Tested	in	accordance	to	Telcordia	GR-771	CORE                     maximum splice capacity per splice tray. Achieving
                                                                     the maximum splice capacity for each closure may
•	 Accepts	a	wide	variety	of	PLP	splice	trays                        require adjustments to the volume of fiber stored
•	 Patented	End	Plate	Design                                         within the fiber organizers. Contact a PLP represen-
                                                                     tative to discuss the details of achieving the maximum
•	 RUS listed                                                        capacities for your installation.
                                                                                                                                                            1-9
PREVIOUS            SECTION CONTENTS                SEARCH   NEXT




       COYOTE In-Line RUNT Closure
                              ®




       Evolution of the Breed Continues…                                                 COYOTE IN-LINE RUNT Closure Kits
                                                                            Catalog
                                                                            Number       Description
                                                                           8006951       Hermetically Sealed
                                                                           8006952       Free Breathing
                                                                           80061004      Express, Hermetically Sealed
                                                                           80061049      Flame Retardant Hermetically Sealed

                                                                                         COYOTE IN-LINE RUNT Accessories
                                                                            Catalog
                                                                            Number       Description
                                                                                                      Splice Tray Kits
                                                                                         12 Count Low Profile Tray w/plastic splice block –
                                                                           80807701
                                                                                         single fusion splices
                                                                                         12 Count Standard Tray w/Elastomeric splice block
                                                                           80806033
                                                                                         – single fusion & mechanical fusion
                                                                                         16/40* Count Tray w/LITE-GRIP® splice blocks for
                                                                           LGSTS16
                                                                                         single fusion splice
                                                                                         144/180* Count Tray w/LITE-GRIP splice blocks for
                                                                          LGSTR144
                                                                                         ribbon splices
                                                                                         24 Count Low Profile Tray w/plastic splice blocks for
                                                                            8003468      single fusion splices
       Versatile                                                                         NOTE: Requires 8003757 Tray Conversion Kit
                                                                                         72 Count Ribbon Tray w/Elastomeric Splice Block for
       The COYOTE® In-Line RUNT Closure has the versatility and            80807114
                                                                                         Mass Fusion
       features that make it a perfect choice for distribution and
                                                                                                          Cover Kit
       fiber to the premise networks. The compact size allows the
                                                                            8003719      COYOTE In-Line RUNT Cover Kit
       closure to be installed into pedestals and small hand holes,
       keeping your installation costs down. High drop capacity and                          Miscellaneous Accessory Kits
       the capability to be converted to a terminal closure will allow      8003733      End Plate Kit
       room for expansion long after the initial installation.             80807794      Hardware Bag
                                                                            8003713      Express Brackets
       Rugged and Reliable                                                  8003757      24 Count, Low Profile Splice Tray Conversion Kit
       The COYOTE In-Line RUNT Closure is tested in accordance             80807571      Spiral	Tube	Kit;	6'	Length
       with the demanding requirements of Telcordia GR-771-                              Transport	Tube	Kit	.135"	ID;	includes	(6)	34"	long
                                                                           80805293
                                                                                         transport tubes
       CORE for all aerial, buried and underground environments.
       Manufactured in accordance with ISO 9001:2008 proce-                              Transport	Tube	Kit	.25"	ID;	kit	includes	(3)	6'
                                                                           80808639
                                                                                         transport tubes
       dures and backed by the experience and field support that
                                                                           80807989      Transport Tube 100' reel 0.170" ID
       PLP has been noted for since 1947.
                                                                           80807991      Transport Tube 100' reel 0.25" ID
                                                                            8003862      Fiber Organizer Kit for Ribbon Applications
       Key Features:
                                                                                                 Mounting Hardware Kits
       •	 Compact	Size:	17.5"	L	x	10"	W	x	3.5"	H
                                                                            8003703      Pole/Wall Mount Bracket
          (44 cm x 25 cm x 9 cm)
                                                                            8003797      Aerial Hanger Bracket
       •	 High	drop	capacity	–	See	grommet	chart
                                                                            8003706      Swing Arm for Hand Holes
       •	 4 entry ports, each accept 1-1/4" maximum cable diameter                       Pedestal Mounting Bracket for Emerson PRO12
                                                                            8003714
       •	 Hermetically	sealed,	free	breathing,	express	and	flame	                        Pedestal PLP Fiber Optic Products
          retardant configurations available                                             Universal Mounting Bracket Kit for Handhole
                                                                            8003835
       •	 Quick	and	easy	assembly	–	no	special	tools	required                            Applications

       •	 Simple-to-use	grommet	sealing	system
       •	 Hinged	cover	reduces	number	of	parts	required	upon	                                            Capacities
          re-entry                                                        Splice Tray                        Splices      Trays per      Splice
                                                                            Depth          Description       per tray      Closure      capacity
       •	 Internal	organizer	manages	buffer	tube	or	ribbon	cable
                                                                           Low Profile    Single Fusion          12            4            48
       •	 Integrated	air	valve	to	test	assembly	seal
                                                                                         Single Fusion or
       •	 Convertible	to	a	COYOTE	Terminal	Closure	with	available	         Standard                              12            2            24
                                                                                           Mechanical
          cover kits – request COYOTE Terminal brochure                     Ribbon         Mass Fusion           72            2            144
       •	 Full	line	of	mounting	hardware	available                       *50% more storage for midsheath (express) applications, but 50% less
                                                                          splice capacity
       •	 Tested	in	accordance	to	Telcordia	GR-771-CORE
1-10   •	 RUS	Listed
PREVIOUS        SECTION CONTENTS          SEARCH     NEXT

                                                                                                 COYOTE® Closure Series: Section


                                                                                                                               1
COYOTE Terminal Closure (Dual Chamber)
                      ®




                                                                                                                            Terminal Closure
                                                                                                                               COYOTE®
Evolution of the Breed Continues…
                                                         The COYOTE Terminal Closure (Dual Chamber) is the
                                                         choice for network designs requiring ultimate flexibility. The
                                                         unique dual chamber design provides two distinct chambers
                                                         that can be configured differently to support externally
                                                         mounted OptiTap™ style hardened adaptors, internally
                                                         mounted cross-connect bulkhead connections or a combi-
                                                         nation of both. A window designed within the closure inte-
                                                         rior allows fibers to be passed between chambers. High
                                                         drop capacity from each of the eight cable ports and the
                                                         ability to use standard or hardened adapter covers, provides
                                                         infinite options to support your network design.
Terminal Closure (Dual Chamber) with hardened adaptors
                                                         Key Features:
                                                         •	 Compact	Size:	17.5"	L	x	10"	W	x	12"	H
                                                            (44 cm x 25 cm x 30 cm)
                                                         •	 Accepts	up	to	24	hardened	adapters
                                                         •	 Eight	Entry	ports	each	accept	1-1/4"	maximum
                                                            cable diameter
                                                         •	 High	drop	capacity	–	8	through	each	port
                                                         •	 Available	in	hermetically	sealed,	free	breathing
                                                            and express configurations
                                                         •	 Quick	and	easy	assembly	–	no	special	tools	required
                                                         •	 Simple	to	use	grommet	sealing	system
   Terminal Closure (Dual Chamber) with hardened         •	 Provided	standard	with	SC/APC	pigtails
         adaptors installed in both covers               •	 Capability	to	field	install	or	remove	hardened
                                                            adapter assemblies
                                                         •	 Internal	organizer	manages	buffer	tube	or	ribbon	cable
                                                         •	 Integrated	air	valve	provides	field	flash	test	point
                                                         •	 Full	line	of	hardware	available	for	strand,	pole	and
                                                            hand-hole installations
                                                         •	 Tested	in	accordance	to	Telcordia	GR-771	CORE
                                                         •	 RUS	Listed




       Splice Compartment – Terminal Closure
       (Dual Chamber) with Internal Bulkhead




        Drop Cable Chamber – Terminal Closure
        (Dual Chamber) with Internal Bulkhead
                                                                                                                          1-11
*OptiTap™ is a trademark of Corning Cable Systems
PREVIOUS        SECTION CONTENTS          SEARCH    NEXT




       COYOTE Terminal Closure (Single Chamber)
                             ®




       Evolution of the Breed Continues…
                                                           The COYOTE Terminal Closure (Single Chamber) is the
                                                           ideal choice for network designs requiring hardened
                                                           adapter termination. Externally mounted OptiTap* style
                                                           hardened adapters allow for future installation of up to 12
                                                           hardened drops without closure reentry. Compact size
                                                           allows the closure to be installed into pedestals and small
                                                           hand holes. Additional drop capacity through the four entry
                                                           ports of the closure base, provide added flexibility for the
                                                           closure to act as a distribution point for closures deeper in
                                                           your network.

                                                           Key Features:
                                                           •	 Compact	Size:	17.5"	L	x	10"	W	x	6"	H
                                                              (44 cm x 25 cm x 15 cm)
        Outside View – Terminal Closure (Single Chamber)   •	 Accepts	up	to	12	hardened	adapters
                                                           •	 Four	Entry	ports	each	accept	1¼"	maximum
                                                              cable diameter
                                                           •	 High	drop	capacity	–	8	through	each	port
                                                           •	 Available	in	hermetically	sealed,	free	breathing
                                                              and express configurations
                                                           •	 Quick	and	easy	assembly	–	no	special	tools	required
                                                           •	 Simple	to	use	grommet	sealing	system
                                                           •	 Provided	standard	with	SC/APC	pigtails
                                                           •	 Port	identification	numbers	to	simplify	assembly
                                                           •	 Capability	to	field	install	or	remove	hardened
                                                              adapter assemblies
                                                           •	 Internal	organizer	manages	buffer	tube	or
                                                              ribbon cable
                                                           •	 Integrated	air	valve	provides	field	flash	test	point
                  End Plate with Distribution Cable
                  and 6-port Drop Cable Grommet            •	 Full	line	of	hardware	available	for	strand,	pedestal,	pole
                                                              and hand-hole installations
                                                           •	 Tested	in	accordance	to	Telcordia	GR-771	CORE
                                                           •	 RUS	Listed




         Inside View – Terminal Closure (Single Chamber)   Drop wire with mating connectors for terminal are
                                                           available in various lengths. Contact your local PLP
                                                           representative or customer service for more details.


1-12
       *OptiTap™ is a trademark of Corning Cable Systems
PREVIOUS     SECTION CONTENTS     SEARCH      NEXT

                                                                                                            COYOTE® Closure Series: Section


                                                                                                                                       1
COYOTE Terminal Closure   ®




                                                                                                                                     Terminal Closure
                                                                                                                                        COYOTE®
Evolution of the Breed Continues…




Installation of Hardened                  COYOTE Terminal
       Connectors                          Closure – Hand
                                          Hole Application




                                                                            COYOTE Terminal Closure –
                                                                              Pedestal Application


                                                       Coyote Terminal Closure Kits
  Catalog                                                                  Chamber       Adapter   Plug        Cover Type
  Number        Description                                                  Type          Qty     Qty     Terminal Standard
 800012002      COYOTE Terminal Closure – 2 Port                            Single          2        4        1          0
  8006993       COYOTE Terminal Closure – 3 Port                            Single          3        3        1          0
  8006953       COYOTE Terminal Closure – 4 Port                            Single          4        2        1          0
  8006954       COYOTE Terminal Closure – 6 Port                             Single        6         0        1        0
  8006955       COYOTE Terminal Closure – 8 Port                             Single         8        1        1        0
 800012003      COYOTE Terminal Closure – 9 Port                             Single         9        0        1        0
 80061067       COYOTE Terminal Closure – 12 Port                            Single        12        0        1        0
 80061029       COYOTE Terminal Dual Chamber – 6 Port                         Dual          6        0        1        1
  8006991       COYOTE Terminal Dual Chamber – 8 Port                         Dual          8        1        1        1
 800012140      COYOTE Terminal Dual Chamber – 9 Port                         Dual          9        0        1        1
 80061030       COYOTE Terminal Dual Chamber – 10 Port                        Dual         10        2        2        0
 800011830      COYOTE Terminal Dual Chamber – 12 Port                        Dual         12        0        2        0
 800012605      COYOTE Terminal Dual Chamber – 24 Port                        Dual         24        0        2        0
 800011839      COYOTE Terminal Dual Chamber – EMPTY                          Dual         0         0        0        2
  8006956       COYOTE Terminal Closure w/6 SCAPC Internal Bulkhead           Dual         0         0        0        2
Terminal includes SC/AP Adapters and (1) Splice Tray




                                                                                                                                  1-13
PREVIOUS         SECTION CONTENTS      SEARCH   NEXT




       COYOTE Terminal Closure    ®




                                                  COYOTE In-line RUNT & Terminal Closure Accessories
                                                                                                                           Terminal
          Catalog                                                                                           In-Line    Single     Dual
          Number       Description                                                                           RUNT     Chamber Chamber
                                                                     Splice Tray Kits
         80807701      12 Count Low Profile Tray w/plastic splice block – single fusion splices               X          X       X
        80807531       12 Count Low Profile Tray (Blank) – no splice block                                    X          X       X
        80806033       12 Count Standard Tray w/elastomeric splice block – fusion & mechanical splices        X          X       X
        80806182       12 Count Standard Tray (Blank) – no splice                                             X          X       X
         80807114      72 Count Ribbon Tray w/elastomeric splice block for mass fusion                        X          X       X
        80808160       Ribbon Tray (Blank) – no splice block                                                  X          X       X
         LGSTS16       16/40* Count LITE-GRIP® Tray (Short) for single fusion                                 X          X       X
        LGSTR144       144/180* Count LITE-GRIP Tray (Short) for Ribbon                                       X          X       X
        *Requires additional LITE-GRIP Splice Block kit for enhanced capacity

                                                                        Cover Kits
         8003719       COYOTE In-Line RUNT Cover Kit*                                                         X          X       X
         8003742       COYOTE Terminal Closure Cover Kit 2-Port with Hardened Adapters                        X          X       X
         8003739       COYOTE Terminal Closure Cover Kit 3-Port with Hardened Adapters                        X          X       X
         8003720       COYOTE Terminal Closure Cover Kit 4-Port with Hardened Adapters                        X          X       X
         8003721       COYOTE Terminal Closure Cover Kit 6-Port with Hardened Adapters                        X          X       X
         8003722       COYOTE Terminal Closure Cover Kit 8-Port with Hardened Adapters                        X          X       X
         8003735       COYOTE Terminal Closure Cover Kit 9-Port with Hardened Adapters                        X          X       X
         8003810       COYOTE Terminal Closure Cover Kit 12-Port with Hardened Adapters                       X          X       X
                                                                 Adapter Accessory Kits
         8003715*      Hardened Adapter Kit – Field Installable – Includes 80807972                                      X       X
         8003724*      Port Plug Kit-Field Installable – Includes 80807972                                               X       X
         80807972      Hardened Adapter Installation Tool                                                                X       X
         80808157      Fiber Optic Pigtail Kit (2-Pigtails)                                                              X       X
         80807939      Fiber Optic Pigtail Kit (3-Pigtails)                                                              X       X
         80807806      Fiber Optic Pigtail Kit (4-Pigtails)                                                              X       X
         80807807      Fiber Optic Pigtail Kit (6-Pigtails)                                                              X       X
         80807808      Fiber Optic Pigtail Kit (8-Pigtails)                                                              X       X
         80808158      Fiber Optic Pigtail Kit (9-Pigtails)                                                              X       X
         80808700      Fiber Optic Pigtail Kit (12-pigtails)                                                             X       X
                                                              Miscellaneous Accessory Kits
         8003733       End Plate Kit                                                                          X          X       X
         80807794      Hardware bag                                                                           X          X       X
         80807972      Adapter Installation Tool                                                                         X       X
                       Transport Tube Kit .135" ID: includes six 34" long transPort with Hardened
         80805293                                                                                             X          X       X
                       Adapters tubes, used to bring fiber from transition compartment to splice tray
                       Transport Tube Kit .25" ID: includes six 34" long transPort with Hardened Adapters
         80806439                                                                                             X          X       X
                       tubes, used to bring fiber from transition compartment to splice tray
         80807989      Transport Tube 100' coil 0.135" ID                                                     X          X       X
         80807991      Transport Tube 100' coil 0.25" ID                                                      X          X       X
                                                                 Mounting Hardware Kits
         8003713       Express Bracket Kit                                                                    X          X       X
                       Pole/Wall mount bracket kit for In-Line RUNT and Terminal
         8003703                                                                                              X          X       X
                       (Standard and Dual Chamber)
         8003704       Aerial Hanging Bracket Kit for COYOTE In-Line RUNT and Terminal Closure                X          X
         8003705       Aerial Hanging Bracket Kit for COYOTE Terminal Dual Chamber                                               X
         8003706       Swing Arm Bracket for COYOTE In-Line RUNT and Terminal Closures                        X          X       X
                       Pedestal Mounting Bracket for COYOTE In-Line RUNT and Terminal Closure
         8003714                                                                                              X          X
                       (Emerson PRO12 Pedestal)
       *Hardened Adapter Kit or Plug kit can only be used with terminal closure covers
1-14
PREVIOUS        SECTION CONTENTS              SEARCH    NEXT

                                                                                                      COYOTE® Closure Series: Section


                                                                                                                                       1
COYOTE Aerial Drop Closure
                      ®




                                                                                                                                   Aerial Drop Closure
                                                                                                                                        COYOTE®
A Simple Solution, a Breed Apart




          The COYOTE® Aerial Drop Closure                                        Kit Components


Key Features:                                                         COYOTE Aerial Fiber Drop Closure Kits
•	 Compact	Size	–	9”	W	x	16.5”	L	x	2.5”	D
                                                                Catalog
•	 Feature	rich	and	value	priced	solution                       Number       Description
•	 Easy	to	install	–	no	special	tools	required                               COYOTE Aerial Fiber Drop Closure Kit
                                                               COYDAC03      Includes: Cover, Base and components
•	 Easy-to-use	grommet	sealing	system
                                                                             shown above
•	 Includes	splicing	platform
                                                                            COYOTE Splice Platform Kits
•	 Accepts	2	splice	platforms	for	a	splice	capacity
                                                                             Splice Plate Kit – 12 Count Splice Block –
   of 24 fibers                                                 8003792
                                                                             Single Fusion
•	 Capable	of	higher	splice	capacities	with	alternative	                     Splice Plate Kit – 12 Count Splice Block –
                                                                8003751
   splice holders. Consult a PLP representative for details.                 Unprotected Single Fusion
•	 Includes	universal	mounting	bracket	with	features	to	                     Splice Plate Kit – 24 Count LITE-GRIP Splice
                                                                8003793
   permit pole mounting with straps, strand mounting with                    Block – Single Fusion
   strand clamps or suspension from “J” hooks secured                        Splice Plate Kit – 72 Count LITE-GRIP Splice
                                                                8003794
   to a pole                                                                 Block – Ribbon
                                                                    COYOTE Aerial Fiber Drop Accessory Kits
PLP Reliability                                                80808256      12 Entry Grommet Kit with Bobbin
                                                                             End Plate Kit – includes (2) End Plates,
The COYOTE Fiber Optic Aerial Drop Closure is manufac-          8003753
                                                                             Bolts and Tether
tured in accordance with ISO 9001-2008 procedures to
                                                                             Strength Member Bracket Kit for Single
assure quality and is backed by the experience and field        8003777
                                                                             Cable Entry
support that Preformed Line Products has been noted for
                                                               80808257      Fiber Organizer Clip Kit
in fiber optic closures for over 20 years.
                                                               8003775       Hanger Bracket Kit




                                                                                                                                 1-15
PREVIOUS                SECTION CONTENTS                        SEARCH   NEXT




       COYOTE LCC (Low Count Closure)
                               ®




       Maximum Flexibility in a Small Package
                                                                                  RUS
                                                                                                                   ■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■



                                                                                                                        PLP Feature Focus
                                                                                                                           ©2009 Preformed Line Products

                                                                                 LISTED                            ■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■



                                                                                                                           Film available at
                                                                                                                          www.preformed.com



                                                                                                                        Grommets




                                                                                             8003796 12 Hole
                                                                                             8003691 1 Hole
                                                                                             8003692 1 Hole
                                                                                             8003693 1 Hole
                                                                                             8003694 1 Hole
                                                                                             8003663 2 Hole
                                                                                             8003990 4 Hole
                                                                                             8003664 4 Hole
                                                                                             8003665 6 Hole

                                                                                             8003677 8 Hole
                                                                                             8003989 4 Hole
                                                                                              8003676 7 Hole
                                                                                               Splice Type*

                                                                                                L Bracket
                                                                                                 Bobbin
                                                                            COYOTE LCC and COYOTE LCC Flame Retardant Kits for Fiber
                                                                               Catalog
                                                                               Number
                                                                            COYLCC-F001      S         2                                        1             1
                                                                            COYLCC-F002       S    1   2                                        1             1
       Every splice location, regardless of the FTTX Architecture,          COYLCC-F003 R              2                   2
       must be protected from the elements to provide the maximum           COYLCC-F004       S        2                                        2
       reliability your customers expect. The new COYOTE LCC                COYLCC-F005       S        2                   2
       (Low Count Closure) is the latest edition to the COYOTE              COYLCC-F006       S        2                              2
       Fiber Optics product line for your Fiber to the Home, Node,          COYLCC-F007       S        2                                        1    1
       or Curb deployment.
                                                                            COYLCC-F008       S        2   1                                         1
       The Closure’s compact size, use of the versatile grommet             COYLCC-F009       S        2                                                      2
       system and internal LITE-GRIP® Splice Platform are                   COYLCC-F010                    1                                                  1
       designed to make this rugged closure the economical choice           COYOTE LCC Kits for Copper
       for new installations and critical repair situations. Kits have      COYLCC-C001 C                  2
       also been created to support copper applications. The                COYLCC-C002 C                      2
       COYOTE LCC for Copper will support up to 25 pair in a butt
                                                                            COYLCC-C003 C                           2
       application and 50 pair in an In-Line configuration.
                                                                            COYLCC-C004 C                  1               1
       The COYOTE LCC represents the maximum versatility,                   COYLCC-C005 C                                             2
       reliability and technical support you’ve come to expect             NOTES:
       from PLP.                                                           All COYOTE LCC Kits for Fiber include: (2) grommets, (1) splice platform,
                                                                           (3) splice blocks, (2) cable restraint brackets, lubricant and measure tape
       Key Features:                                                       All COYOTE LCC Kits for Copper include: (2) grommets, (2) MINI-MORAY
                                                                           Shield Connectors, (1) bonding bridge, lubricant and measure tape
       •	 Compact	Size	–	17"	L	x	7"	W	x	2.5"	D	                            For the COYOTE LCC Flame Retardant catalog numbers, insert “FR” into
          (43cm x 18cm x 7cm)                                              the catalog number code,
                                                                           Ex.: COYLCCFR-F001. The grommets provided will be the same as
       •	 Max	Splice	Capacity	–	Single	Fusion	–	24	splices                 shown in the chart.
       •	 Max	Splice	Capacity	–	Ribbon/Mass	Fusion	–	72                    *Splice Type: S = Single Fusion R = Ribbon C = Copper

       •	 Capable	of	Inline	or	Butt	applications
       •	 Designed for aerial, below grade or direct buried applications
                                                                                                  COYOTE LCC Accessories
       •	 Same	craft	friendly	grommet	system	as	the	COYOTE	                     Catalog
          Dome Closures                                                         Number         Description
                                                                               80808633        Strength Member Bobbin Kit
       •	 Flat	shape	allows	for	mounting	in	small	areas
                                                                               8003843         Strength Member L Bracket Kit
       •	 Utilizes	LITE-GRIP	Splice	Block	System,	which	permits	                               Splice Platform Kit for Single Fusion –
                                                                                8003793
          single fusion, mass fusion, mechanical, PLC splitters                                includes 3 splice blocks
          or a combination of all within one closure                            8003794
                                                                                               Splice Platform Kit for Ribbon –
                                                                                               includes 2 splice blocks
       •	 Quick,	easy	installation	is	ideal	for	drop	repair	applications                       LITE-GRIP Splice Block for Single Fusion – accepts
                                                                               LGSBS8-5
       •	 Fire	Retardant	versions	available                                                    8 splice protectors per block – 5 pcs per kit
                                                                                               LITE-GRIP Splice Block for Ribbon – accepts 3
       •	 Tested	in	accordance	to	TR-NWT-000251	by	an	                         LGSBR3-5
                                                                                               mass fusion protectors per block – 5 pcs per kit
1-16      independent outside lab
       •	 RUS listed
PREVIOUS        SECTION CONTENTS           SEARCH    NEXT

                                                                  COYOTE® Closure Series: Section


                                                                                                 1
COYOTE LCC (Low Count Closure)
       ®




                                                                                             (Low Count Closure)
                                                                                                COYOTE® LCC
             COYOTE LCC Installation Options
                                                              Part Number
                                 Application Type            and Description

                                                                 8003832
                                      Aerial             Aerial Mounting Bracket
                                                             (Strand Mount)



                                                                 8003830
                                 Pole/Wall Mount              Pole/Wall Mount
                                                                Bracket Kit



                                                                  8003835
                                   Below Grade
                               Large Vault/Hand Hole     Universal Mounting Bracket Kit
                                                          for Hand Hole Applications


                                                             COYOTE LCC:
                                                            COYLCC-XXXX
                                  Below Grade              COYOTE GLC Base
                                 Small Hand Hole            COYGLC-C1-000
                                                            Butt Applications Only
                                                          For small drop and flat drop
                                                               applications only




                                   Direct Buried          No Mounting Brackets
                                                               Needed




                                                               COYOTE LCC
                                     Custom                      for Coax
                                                            Contact PLP for Details




                                                              COYOTE LCC
                                     Custom                   Cross-Connect
                                                            Contact PLP for Details




                                                               COYOTE LCC
                                     Custom                 with Terminal Block
                                                            Contact PLP for Details




                                                                                           1-17
PREVIOUS            SECTION CONTENTS                SEARCH    NEXT




       COYOTE Long Trays and Closures
                                   ®




             Short Splice
               Trays &
              Closures                                                                    COYOTE             COYOTE
                                                     COYOTE                               Terminal           Terminal          6.5"x17"
                                    COYOTE           Expanded           COYOTE             (Single            (Dual            COYOTE
                                     RUNT              RUNT          In-Line RUNT         Chamber)          Chamber)2           Dome          COYOTE PUP




                                     3 Trays           6 Trays           4 Trays           4 Trays            8 Trays           6 Trays           6 Trays

             Low Profile Tray1       36 Max           72 Max            48 Max             48 Max            96 Max            72 Max             72 Max
             (12 splice count)     Splice count     Splice count      Splice count       Splice count      Splice count      Splice count       Splice count
             Cat.	#	80807701
            (w/splice blocks) or
              8001130 (blank)




                                     2 Trays           4 Trays           2 Trays           2 Trays            4 Trays           4 Trays           4 Trays
                                     24 Max           48 Max            24 Max             24 Max            48 Max            48 Max             48 Max
              Standard Tray        Splice count     Splice count      Splice count       Splice count      Splice count      Splice count       Splice count
             (12 splice count)
             Cat.	#	80806033
            (w/splice block) or
            80806182 (blank)




                                       1 Tray          2 Trays           2 Trays           2 Trays            4 Trays           3 Trays           2 Trays
                                     72 Max          144 Max           144 Max            144 Max           288 Max           216 Max            144 Max
               Ribbon Tray         Splice count     Splice count      Splice count       Splice count      Splice count      Splice count       Splice count
             (72 splice count)
             Cat.	#	80807114
            (w/splice block) or
            80808160 (blank)




                                       1 Tray          2 Trays           2 Trays           2 Trays            4 Trays           3 Trays           2 Trays
                                     40 Max           80 Max            80 Max             80 Max           160 Max           120 Max             80 Max
                LITE-GRIP ®        Splice count     Splice count      Splice count       Splice count      Splice count      Splice count       Splice count
                Short Tray3
             (40 splice count)
             Cat.	#	LGSTS16
              (Single Fusion)




                                       1 Tray          2 Trays           2 Trays           2 Trays            4 Trays           3 Trays            2 Trays

                LITE-GRIP           144 Max          216 Max           288 Max            288 Max           576 Max           432 Max            288 Max
                Short Tray         Splice count    Splice count4      Splice count       Splice count      Splice count      Splice count       Splice count
             (144 splice count)
             Cat.	#	LGSTR144
           (Mass Fusion/Ribbon)

       1
        	24	count	Low	Profile	Tray	(Cat.	#	8003468)	is	available	for	COYOTE	In-Line,	COYOTE	Terminal	(Single	Chamber),	&	COYOTE	Terminal	(Dual	Cham-
         ber)	closures.	Tray	Conversion	Kit	(Cat.	#	8003757)	is	required	to	use	this	tray	in	these	closures.
       2
         The maximum splice count for the COYOTE Terminal (Dual Chamber) requires trays to be installed in both chambers of the closure.
       3
        	Each	tray	(Cat.	#	LGSTS16)	is	provided	with	splice	blocks	to	support	16	single	fusion	splices.	Splice	Block	Kit	(Cat.	#	LGSBS8-5)	is	required	for	each
1-18     tray to achieve maximum splice count.
       4
         Capacity is limited by the maximum cable size through the entry ports.
PREVIOUS           SECTION CONTENTS                SEARCH    NEXT

                                                                                                                                    COYOTE® Closure Series: Section


                                                                                                                                                                 1
COYOTE Long Trays and Closures ®




                                                                                                                                                                     COYOTE Long Trays and Closures
                                                                                                                                                                                    ®
      Long Splice
        Trays &
       Closures
                              6.5"x22"                                            6.5"x22"           8"x28"          9.5"x28"
                              COYOTE           6.5"x22"          8.5"x22"         COYOTE            COYOTE           COYOTE              9.5"x28"
                               Dome            COYOTE            COYOTE          Splice Case       Splice Case      Splice Case        COYOTE Dome




                              6 Trays           6 Trays          11 Trays          6 Trays           9 Trays          13 Trays            18 Trays
       Low Profile Tray      216 Max           216 Max          396 Max           216 Max           324 Max           468 Max             648 Max
      (36 splice count)     Splice count      Splice count     Splice count      Splice count      Splice count      Splice count        Splice count
       Cat.	#	8001127
      (w/ plastic splice
     blocks) or 8001130
           (blank)




                              4 Trays           4 Trays          8 Trays           5 Trays           7 Trays          10 Trays            15 Trays
        Standard Tray        144 Max           144 Max          288 Max           180 Max           252 Max           360 Max             540 Max
      (36 splice count)     Splice count      Splice count     Splice count      Splice count      Splice count      Splice count        Splice count
      Cat.	#	80805514
    (w/ elastomer splice
     block), 80805110
     (w/ rigid slots), or
     80805509 (blank)




                              3 Trays           2 Trays          4 Trays           2 Trays           5 Trays           6 Trays             6 Trays
        Ribbon Tray          432 Max           288 Max          576 Max           288 Max           720 Max           864 Max             864 Max
     (144 splice count)     Splice count      Splice count     Splice count      Splice count      Splice count      Splice count        Splice count
      Cat.	#	80805515
    (w/ elastomer splice
     blocks), 80805146
     (w/ rigid slots), or
     80805510 (blank)




                              3 Trays                            5 Trays           2 Trays           5 Trays           6 Trays             9 Trays
                                                  Not
                             240 Max                            400 Max           160 Max           400 Max           480 Max             720 Max
         LITE-GRIP®                            Applicable
                            Splice count                       Splice count      Splice count      Splice count      Splice count        Splice count
          Long Tray1
      (80 splice count)
      Cat.	#	LGSTS40
       (Single Fusion)




                              3 Trays                             5 Trays          2 Trays            5 Trays           6 Trays             6 Trays
                                                  Not
        LITE-GRIP            648 Max                            1,080 Max         432 Max           1,080 Max         1,296 Max           1,296 Max
                                               Applicable
         Long Tray          Splice count                       Splice count      Splice count      Splice count      Splice count        Splice count
     (216 splice count)
     Cat.	#	LGSTR216
       (Mass Fusion/
          Ribbon)

1
    Each	tray	(Cat.	#	LGSTS40)	is	provided	with	splice	blocks	to	support	40	single	fusion	splices.	Splice	Block	Kit	(Cat.	#	LGSBS8-5)	is	required	for	each
    tray to achieve maximum splice count.
2
    Each	tray	(Cat.#	LGSTS40)	is	provided	with	splice	blocks	to	support	40	single	fusion	splices.	Splice	block	kit	(Cat.	#	LGSBS8-5)	is	required	for	each
    tray to achieve maximum splice count.                                                                                                                     1-19
PREVIOUS        SECTION CONTENTS           SEARCH   NEXT




       COYOTE Silicone Grommet Kits     ®




       ■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■



          PLP Feature Focus
              ©2009 Preformed Line Products
       ■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■



              Film available at
             www.preformed.com

                                                        COYOTE® Silicone Grommet Kits
                              for use in COYOTE GLC, LCC, Aerial Drop, In-Line RUNT, Terminal, Dome and Taut Closures
              Catalog                             Cable Range
                                                                                        Description                      Grommets
              Number                              Inches (mm)

                                              .42 - .60 (10.7 - 15.2)
             8003701*                                                                 2-hole grommet
                                              .60 - .85 (15.2 - 21.6)



             8003691                          .40 - .60 (10.7 - 15.2)                 1-hole grommet



             8003692                          .60 - .85 (15.2 - 21.6)                 1-hole grommet



             8003693                          .85 - 1.0 (21.6 - 25.4)                 1-hole grommet



             8003694                          1.0 - 1.25 (25.4 - 31.6)                1-hole grommet



             8003663                          .42 - .60 (10.7 - 15.2)                 2-hole grommet


                                              .50 - .60 (12.7 - 15.2)
             8003990                           .125 - .25 (3.2 - 6.4)                 4-hole grommet
                                                  and Flat Drop


             8003664                           .30 - .43 (7.6 - 10.9)                 4-hole grommet



             8003989                             Flat Drop Only                       4-hole grommet



                                              .125 - .25 (3.2 - 6.4)
             8003665                                                                  6-hole grommet
                                                 and Flat Drop


                                              .42 - .60 (10.7 - 15.2)
             8003676                           .125 - .25 (3.2 - 6.4)                 7-hole grommet
                                                  and Flat Drop


                                              .125 - .25 (3.3 - 6.4)
             8003677                                                                  8-hole grommet
                                                 and Flat Drop



             8003796                             Flat Drop Only                      12-hole grommet


       Note: Grommet Kit contains (1) Grommet, (1) Cable Measure Tape, (2) Silicone Lubricant Packs, (1) Set of Plugs (where applicable)
1-20   *8003701 is not recommended for 9.5" Dome and GLC Closures
PREVIOUS   SECTION CONTENTS    SEARCH       NEXT

                                                                                         COYOTE® Closure Series: Section


                                                                                                                     1
COYOTE DTC (Drop Termination Closure)
                         ®




                                                                                                                  (Drop Termination Closure)
                                                                                                                        COYOTE® DTC
Ease of Use Just Got Easier!
Versatile, compact and quick to install are the words most
commonly used to describe the new COYOTE DTC (Drop
Termination Closure). This new closure design is con-
structed to support butt or inline low count splice applica-
tions in a direct buried or below grade environment and
pole/wall mounted applications near the end of your net-
work. The closures’ compact size and rugged exterior
allow for installation in tight spaces without compromising
functionality. Four corner entrance ports provide the in-
staller the flexibility to quickly configure the closure as
needed. The cover of the two piece design contains a
factory installed gasket and is able to be quickly snapped
onto the base during assembly. No fasteners to tighten or
torque. With the capacity to support up to 16 single fusion
splices or multiple ribbon splices, it will quickly become
the closure you will want to have on hand. The COYOTE
DTC, another example of the quality, versatility and in-
novation you’ve come to expect from PLP.

Key Features:
•	 Compact	Size:	7.25"	x	7.75"	x	1.75"
   (18.4 x 19.7 x 4.4 cm)
•	 Quick	to	assemble.	No	tools	required	for	assembly
•	 Flexible	sealing	technology	supports	a	wide	range	of
   flat or round cable profiles
•	 Can	be	used	in	combination	with	the	COYOTE	GLC
   (Cat No: COYGLC-C1-000) Base. Provides a cost
   effective solution for below grade customer drop
   applications.
•	 Designed	for	direct	buried,	below	grade,	pole/wall
   mount or aerial applications
•	 Re-enterable	and	re-usable*
•	 Capable	of	Inline	or	Butt	applications
•	 Max	Splice	Capacity	–	16	single	fusion
•	 Max	Splice	Capacity	–	(3)	12	fiber	ribbons
•	 Flat	shape	allows	for	mounting	in	small	areas
•	 Utilizes	the	LITE-GRIP	Splice	Block	System	which
   permits single fusion, mass fusion, mechanical, PLC
   splitters or a combination of all within one closure.
*The COYOTE DTC is designed to be a secure closure. If re-entry
 and re-use is required you must use the COYOTE DTC Cover
 Removal Tool (PN: 80809842). An alternative method for removal
 is to cut features on the base to remove the cover. This approach
 does not permit re-use of the base.
                   COYOTE DTC Closure Kits
     Catalog
     Number       Description
             COYOTE DTC Kit
             Includes: Closure Assembly with (4) port
  COYDTC-001 sealing grommets (2) single fusion and
             (1) Ribbon LITE-GRIP Splice Blocks, (4) cable
             retention clips and (2) fiber organizer clips
                         Accessory Kits
    80809842      Cover removal tool                                                                           1-21
PREVIOUS      SECTION CONTENTS             SEARCH   NEXT




       COYOTE Taut Closure   ®




       Refinement of the Breed…
       A single closure that simplifies branch cable
       taps or repairs of taut fiber optic cables.

       The 6.5" x 38" (165 x 965 mm) COYOTE Taut Closure
       organizes and protects up to 12 branch splices in either
       or both directions, or up to 12 pairs of fiber splices for
       repairing damaged cable.

       The end plates are the same innovative design used in
       the COYOTE Dome Closure and employ the easy-to-use
       grommet system which can also be used in the COYOTE
       Taut Closure.

       The unique mainframe assembly protects the fibers being
       “expressed” through the closure and organizes the splices
       on those fibers being spliced to the branch cables. Slack
       fibers from the branch cables or slack fibers between repair
       splices are stored in the center region of the mainframe.      Catalog
       The entire splice is protected by our rugged plastic           Number       Description
       COYOTE shells.                                                              6.5" x 38" (165 x 965 mm) COYOTE Taut
                                                                      8006947
                                                                                   Closure Kit




1-22
PREVIOUS             SECTION CONTENTS                    SEARCH    NEXT

                                                                                                                                COYOTE® Closure Series: Section


                                                                                                                                                                  1
COYOTE RUNT Closure          ®




                                                                                                                                                                 RUNT Closure
                                                                                                                                                                   COYOTE®
Refinement of the Breed…
                                                                                  COYOTE RUNT & Expanded COYOTE RUNT Closure
                                                                                Catalog
                                                                                Number   Description
                                                                                            COYOTE RUNT Closure Kits
                                                                                         COYOTE RUNT Closure Kit, Includes LOCK-TAPE™
                                                                                8006671
                                                                                         Sealant, Bond Brackets and transport tubing
                                                                                         Expanded COYOTE RUNT Closure Kit, Includes
                                                                                8006794  LOCK-TAPE Sealant, Bond Brackets and
                                                                                         transport tubing
                                                                                         RUS Listed COYOTE RUNT Closure Kit,
                                                                                8006692  Includes LOCK-TAPE Sealant, Bond Brackets
                    COYOTE RUNT Closures                                                 and transport tubing
                                                                               800011397 COYOTE RUNT Closure for Copper Application
The COYOTE RUNT Closure was specifically designed for
fiber distribution networks. The small compact size of the                      8006916  Expanded COYOTE RUNT Cross Connect
COYOTE RUNT Closures make them an ideal fit for                                                   Splice Tray Kits
smaller hand holes and pedestals in the last fiber mile.                                       12 Count Low Profile Tray w/plastic splice block
                                                                               80807701
                                                                                               – single fusion splices
Key Features:                                                                                  12 Count Standard Tray w/elastomeric splice
                                                                               80806033
•	 Compact	Size:	14.75"	L	x	8.5"	W	x	3"	H	                                                     block – fusion & mechanical splices
   (37.5cm x 21.6cm x 7.6cm)                                                                   72 Count Ribbon Tray w/elastomeric splice block
                                                                               80807114
•	 Expanded	Size:	14.75"	L	x	8.5"	W	x	4.75"	H                                                  for mass fusion
   (37.5cm x 21.6cm x 10.8cm)                                                                  LITE-GRIP® Short Tray for Single Fusion –
•	 Three	cable	entrance	ports	(2)	3/4"	(19mm)	port	                            LGSTS16*        Includes (2) LITE-GRIP Splice Blocks for Single
   and (1) 1" (25mm) port                                                                      Fusion – Splice Capacity 16 Splices
•	 Size	allows	for	mounting	in	small	pedestals	and	hand	holes                                  LITE-GRIP Short Tray for Ribbon – Includes
                                                                              LGSTR144
•	 Provided	with	LOCK-TAPE™ Sealing System                                                     (4) LITE-GRIP Splice Blocks
•	 Accepts	a	wide	variety	of	grommets	for	multi	drop	                                                    Accessory Kits
   applications – See grommet chart in COYOTE Closure                                          Future Cable Port Kit. Includes Future Cable Port
   End Plate and Accessories section                                            8003407        for 1" port, plug and clamps for installation of
•	 Universal	internal	organizer	allows	for	loose	tube	or	                                      future cable port during initial assembly
   ribbon fiber applications                                                                   Future Cable Port Installation Kit. Includes
•	 Permanent	neoprene	gasket	system	requires	no	                                8003291        LOCK-TAPE sealant, bead sealant and L-bracket
   re-entry kits                                                                               for preparation of future cable up to 1" in diameter
•	 Future	cable	ports	provide	capability	for	future	cable	                                     Future Cable Port/Installation kit. Complete kit
                                                                                8003408
   installation without end plate removal                                                      includes catalog nos. 8003407 and 8003291
•	 Standard	cover	can	be	replaced	with	expanded	to	                            80806037        3/4" Plug kit (contains 2 plugs)
   increase splice capacity                                                    80806038        1" Plug kit (contains 2 plugs)
•	 Express	friendly	internal	organizer	features                                80806112        Transport tube kit, contains 4 tubes
•	 Integrated	air	valve	to	verify	integrity	of	final	assembly                                  Shell expansion kit includes Expanded top shell
•	 Full	line	of	mounting	hardware                                               8003574
                                                                                               and longer studs to increase tray capacity
•	 UL Approved and RUS Listed                                                                         Installation Materials
•	 Tested	in	accordance	to	Telcordia	GR-771	CORE                               80805238        C-Cement, 1 oz. Tube
                   Splice Tray/Closure Capacities                              80805925        LOCK-TAPE Sealant, 1" W x 15' L roll
                                        Standard RUNT    Expanded Runt                                Bonding Acessories
                             Splices Trays             Trays                                   Fiber Optic Shield Connector (1 per kit)
   Catalog                    per      Per   Closure    Per   Closure          80803989
                                                                                               3M#4460-F/FO
   Number      Description    Tray   Closure Capacity Closure Capacity
 80807701        Single                                                         8003281        External Bonding Clip
                                 12      3       36       6       72
 Low Profile     Fusion                                                                             Mounting Hardware Kits
                 Single                                                         8003467        Aerial Hanger Bracket
  80806033
                Fusion &         12      2       24       4       48
  Standard
               Mechanical                                                       8003470        Manhole Support Bracket
  80807114     Mass Fusion                                                      8003523        Wall Mount Bracket
                                 72      1       72       2       144
   Ribbon       (Ribbon)                                                        8003571        Universal Wall/Pole Mount Bracket
               LITE-GRIP®
                                                                            *Tray will hold a max of 5 splice blocks for a total splice capacity of
  LGSTS16*        Single     16/40*      1     16/40*     2     33/80*
                                                                             40 splices
                 Fusion
  LGSTR144     LITE-GRIP     144/180*    1    144/180*    2     288/360*
                                                                                                                                                               1-23
*Requires additional LITE-GRIP splice block kit to reach maximum capacity
PREVIOUS           SECTION CONTENTS                 SEARCH   NEXT




       COYOTE PUP Closure     ®




       Refinement of the Breed…
                                                                                           COYOTE PUP Closure Kits
                                                                         Catalog
                                                                         Number      Description
                                                                                     COYOTE PUP Closure Kit for Buffer Tube – includes
                                                                         8006622     (1) 3 section 6 Port End Plate, (1) blank end plate and
                                                                                     organizer
                                                                                     COYOTE PUP Closure Kit for Unitube – includes (1) 3
                                                                         8006621     section 6 Port End Plate, (1) blank end plate, transport
                                                                                     tube kit and organizer
                                                                                     RUS Listed COYOTE PUP Closure Kit for Buffer Tube
                                                                         8006661     – includes (1) 3 section 6 Port End Plate, (1) blank end
                                                                                     plate, organizer and (2) RUS listed shield connectors.
                                                                                     COYOTE PUP Closure Kit for Copper Applications with
                                                                         800011398
                                                                                     6-Port End Plates
       The COYOTE PUP Closure offers the perfect choice for low
                                                                                     COYOTE PUP Closure Kit for Copper Applications with
       fiber count distribution applications involving butt and inline   800011399
                                                                                     4-Port End Plates
       installations. The compact size and rugged design allow
                                                                                     COYOTE PUP Closure for Buffer Tube Applications
       the closure to be applied in below grade, aerial and buried       800010515
                                                                                     with 4-Port End Plate
       installations. Supported by a full line of COYOTE acces-
                                                                                                   Splice Tray Kits
       sories, this closure can grow along with your network.
                                                                                     12 Count Low Profile Tray w/plastic splice block –
                                                                         80807701
                                                                                     single fusion splices
       Key Features:
                                                                                     12 Count Standard Tray w/elastomeric splice block –
       •	 Compact	Size:	17"	L	x	8.6"	W	x	7.2"	H	                         80806033
                                                                                     fusion & mechanical splices
          (43.2 cm x 21.9 cm x 18.4 cm)                                              72 Count Ribbon Tray w/elastomeric splice block for
       •	 Two	end	plate	options	–	4	Port	and	6	Port                      80807114
                                                                                     mass fusion
          – 6 Port provides (4) 7/8" (22mm) ports                                            Mounting Hardware Kits
              and (2) 3/4" (19mm) ports
                                                                         8003325     Aerial hanger bracket
          – 4 Port provides (2) 1-1/4" (32mm) ports
              and (2) 1" (25mm) ports                                    8003279     Manhole support bracket
       •	 Can	be	configured	for	butt	or	in-line	applications             8003372     Pole/wall mount bracket (vertical)
       •	 Organizers	designed	for	loose	buffer	tube	and	                                         Accessories Kits
          ribbon applications                                            End Plate See Grommet Chart in COYOTE Closure End Plate
       •	 Size	allows	for	mounting	in	small	hand	holes                   Grommets and Accessories Section
       •	 Provided	with	LOCK-TAPE™ Sealing System                        80805795 Shell Kit 6" x 17"
       •	 Accepts	a	wide	variety	of	grommets	for	multi	                  80805771 Buffer Tube Storage Compartment
          drop applications                                              80805775 Unitube Storage (Transition) Compartment
       •	 Permanent	neoprene	gasket	system	requires
                                                                                     6 Port End Plate Kit, Includes (1) end plate assembly,
          no re-entry kits                                               80805105
                                                                                     (1) full set of plugs, and LOCK-TAPE™ Sealing material
       •	 Future	cable	ports	provide	capability	for	future	cable
                                                                                     4 Port End Plate Kit, Includes (1) end plate assembly,
          installation, without end plate removal                        80805739
                                                                                     (1) full set of plugs, and LOCK-TAPE sealing material
       •	 Integrated air valve to confirm integrity of final assembly
                                                                         80805260 Blank end plate kit
       •	 Full	line	of	mounting	hardware
       •	 UL Approved, RUS Listed                                                    Future Cable Port Kit, Includes Future Cable Port for
                                                                         8003371     7/8" port, plug and clamps for installation of future
       •	 Tested	in	accordance	to	Telcordia GR-771 CORE                              cable port during initial assembly
                                                                                     Future Cable Installation Kit, includes LOCK-TAPE
                                                                         8003291     Sealant, bead sealant and L-bracket for preparation of
                                                                                     future cable up to .86" in diameter
                                                                                     Future Cable Port/Cable Installation Kit. Complete kit
                                                                         8003289
                                                                                     includes Cat. Nos. 8003289 and 8003291
                                                                         80806037 3⁄4" Plug Kit (contains 2 plugs)
                                                                         80806180    7⁄8" Plug Kit (contains 2 plugs)
                                                                         80806038 1" Plug Kit (contains 2 plugs)
                       Splice Tray/Closure Capacities                    80806181    1-1⁄4" Plug Kit (contains 2 plugs)
         Splice                         Splices Trays                    80805293 Transport Tube Kit (contains 6 tubes)
          Tray                            per      per  Closure                      Transition Tube Kit, used to transition fibers from top
                                                                         8003280
         Depth          Description      Tray   Closure Capacity                     section of end plate to the transition compartment
       Low Profile     Single Fusion       12       6      72            8003418     Heat Shield for PUP Closure
                      Single Fusion &                                                          Installation Materials
        Standard                           12       4      48
                     Single Mechanical                                   80805238 C-Cement, 1 oz. tube
1-24     Ribbon         Mass Fusion       72        2     144            80805925 LOCK-TAPE Sealant 1" W x 15" L Roll
PREVIOUS            SECTION CONTENTS                  SEARCH     NEXT

                                                                                                                     COYOTE® Closure Series: Section


                                                                                                                                               1
COYOTE Closure        ®




                                                                                                                                                  COYOTE® Closure
Origin of the Species…
                                                                             ■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■



                                                                                PLP Feature Focus
                                                                                     ©2009 Preformed Line Products
                                                                             ■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■



                                                                                     Film available at
                                                                                    www.preformed.com




                   PATENTED
                                                                 Size             L (cm)                  W (cm)             H (cm)
                                                               6.0" x 22"         22" (56)              8-1/2" (22)          7" (18)
Setting the bar against which all other fiber closures are
measured was no small task for our design team. But years      8.5" x 22"         22" (56)             10-3/4" (27)        9-1/4" (24)
of research & development eventually paid off in the form
of a rugged and reliable design that has become legend.
After over ten years of field use and several hundred thou-
sand units sold, the original COYOTE Closure still remains
one of the most highly regarded and widely used fiber
optic closures in the industry.

Key Features:
•	 Available	in	two	sizes
   – 6.0" x 22" (15cm x 56cm)                                                    COYOTE Splice Trays
   – 8.5" x 22" (22cm x 56cm)
•	 Two	end	plate	options	–	4	Port	and	6	Port                             Splice Tray Installation Materials Kits
   – 6 Port provides (4) 7/8" (22mm) ports                     Catalog
       and (2) 3/4" (19mm) ports                               Number       Description
   – 4 Port provides (2) 1-1/4" (32mm) ports                  8003509       60 mm heat shrink splice protector (12 per kit)
       and (2) 1" (25mm) ports                                80808187      40 mm heat shrink protector (12 per kit)
•	 Large	splice	capacity                                      8003717       60 mm heat shrink protector (50 per kit)
   – Up to 396 with single fusion                                           Splice protector (single fusion), NON heat shrink,
   – UP to 576 with mass fusion                               8003092
                                                                            250/250 micron (20 per kit)
•	 Can	be	configured	for	butt	or	in-line	applications                       Splice protector (mass fusion), NON heat shrink
                                                              8003425
•	 Organizers	designed	for	loose	buffer	tube	and	                           (12 per kit)
   ribbon applications                                        8003490       Felt strips 1-1/8" x 9" (6 per kit)
•	 Compact	size	allows	for	mounting	in	smaller	locations      8003381       12-Count soft elastomer splice block kit (3 per kit)
•	 Provided	with	LOCK-TAPE	Sealant	System                                   Transport tube kit, includes (6) transport tubes
                                                              80805293
                                                                            0.135" I.D.
•	 Accepts	a	wide	variety	of	grommets	for	multi
                                                                            Transport tube kit, includes (6) transport tubes
   drop applications                                          80806439
                                                                            0.170" I.D. will contain (6) 12 fiber ribbons
•	 Field	proven	permanent	neoprene	gasket	system	                           Transport tube kit (bulk) – 100 ft coil of transport
                                                              80807989
•	 No	re-entry	kits	required                                                tube 0.170" I.D. – will contain (6) 12 fiber ribbons
•	 Future	cable	ports	provide	capability	for	future	cable	                  Transport tube kit (bulk) – 100 ft coil of transport
                                                              80807991
   installation, without end plate removal                                  tube 0.250" I.D. – will contain (12) 12 fiber ribbons
•	 Integrated	air	valve	to	confirm	integrity	of	final	                      Transport tube kit, color coded, includes
                                                              8003285
                                                                            (6) transport tubes 0.135" I.D.
   assembly
•	 Full	line	of	mounting	hardware
•	 UL Approved and RUS Listed
•	 Tested	in	accordance	to	Telcordia	GR-771	CORE



                                                                                                                                           1-25
PREVIOUS        SECTION CONTENTS              SEARCH   NEXT




       COYOTE Closure            ®




                                                              Splice Tray/Closure Capacities
                                                                                    6.5" x 22"                         8.5" x 22"
           Splice Tray                                      Splices           Trays           Closure            Trays           Closure
             Depth                 Description              per Tray       per Closure       Capacity         per Closure       Capacity
           Low Profile            Single Fusion                36               6               216                11              396
                                 Single Fusion &
            Standard                                           36               4                144                8                288
                                Single Mechanical
             Ribbon                Mass Fusion                144               2                288                4                576


                                                                    COYOTE Closure Kits
          Catalog Number
         6 Port     4 Port
        End Plate End Plate          Organizer Type     Description
                                                        6" x 22" COYOTE Closure, includes (1) 3 section end plate,
        8006560       8006633          Buffer Tube
                                                        (1) blank end plate, organizer and LOCK-TAPE sealant
                                   Unitube Transition   6" x 22" COYOTE Closure, includes (1) 3 section end plate, (1) blank end plate,
        8006540       8006631
                                    Compartment         organizer, transport tube kit, transition tube kit and LOCK-TAPE sealant
                                        Express         6" x 22" COYOTE Closure, includes (1) 3 section end plate, (1) blank end plate, express
        8006587       8006635
                                      Buffer Tube       organizer and LOCK-TAPE sealant
                                                        RUS LISTED - 6" x 22" COYOTE Closure, includes (1) 3 section end plate, (1) blank
        8006659                        Buffer Tube
                                                        end plate, organizer, LOCK-TAPE sealant and (2) RUS listed shield connectors
                                                        8.5" x 22" COYOTE Closure, includes (1) 3 section end plate,
        8006561       8006634          Buffer Tube
                                                        (1) blank end plate, organizer and LOCK-TAPE sealant
                                   Unitube Transition   8.5" x 22" COYOTE Closure, includes (1) 3 section end plate, (1) blank end plate,
        8006541       8006632
                                    Compartment         organizer, transport tube kit, transition tube kit and LOCK-TAPE sealant
                                        Express         8.5" x 22" COYOTE Closure, includes (1) 3 section end plate, (1) blank end plate,
        8006588       8006636
                                     Buffer Tube        express organizer and LOCK-TAPE sealant
                                                        RUS LISTED - 8.5" x 22" COYOTE Closure, includes (1) 3 section end plate, (1) blank
        8006660                        Buffer Tube
                                                        end plate, organizer, LOCK-TAPE sealant and (2) RUS listed shield connectors

       UL Approved, RUS Listed, Patented

                                                             COYOTE Closure Splice Tray Kits
           Catalog                                                                                                 6.5" x 17"       6" x 22"
           Number        Description                                                                               or Smaller      or Larger
          80807701       12 Count Low Profile Tray w/plastic splice block – single fusion splices                      X
         80807769        12 Count Low Profile Tray (Blank) No Splice Block                                             X
         80806033        12 Count Standard Tray w/elastomeric splice block – Fusion & mechanical splices               X
         80806182        12 Count Standard Tray (Blank) – No Splice Block                                              X
          80807114       72 Count Ribbon Tray w/Elastomeric Splice Block for Mass Fusion                               X
         80808160        Ribbon Tray (Blank) No splice Block                                                           X
          LGSTS16        16/40* Count LITE-GRIP® Tray (Short) for Single Fusion                                        X
         LGSTR144        144/180* Count LITE-GRIP Tray (Short) for Ribbon                                              X
           8001127       36 Count Low Profile Tray w/plastic splice block – single fusion splices                                      X
         80807531        Blank Low Profile Splice Tray                                                                                 X
           8001130       Blank Low Profile Splice Tray                                                                                 X
         80805514        36 Count Standard Tray w/elastomeric splice blocks – Fusion & mechanical splices                              X
          80805110       36 Count Standard Tray w/fixed rigid slots                                                                    X
         80805509        36 Count Standard Tray (Blank) – No Splice Block
          LGSTS40        40/80* Count LITE-GRIP® Tray (Short) for Single Fusion                                                        X
         LGSTR216        216/288* Count LITE-GRIP Tray (Short) for Ribbon                                                              X
         80805146        144 Count Ribbon Tray w/fixed rigid slots                                                                     X
         80805515        144 Count Ribbon Tray w/2 elastomeric splice blocks                                                           X
         80805510        144 Count Ribbon Tray (Blank) – No splice blocks                                                              X
         LGSBR3-5        LITE-GRIP Splice Block Kit – Ribbon Fiber (5 ea per kit)                                       X              X
         LGSBS8-5        LITE-GRIP Splice Block Kit – Single Fusion (5 ea per kit)                                      X              X
       *Requires additional LITE-GRIP block kit to achieve maximum capacity.
1-26
PREVIOUS         SECTION CONTENTS               SEARCH    NEXT

                                                                                                            COYOTE® Closure Series: Section


                                                                                                                                             1
COYOTE Closure End Plates and Accessories
                       ®




                                                                                                                                          Plates and Accessories
                                                                                                                                          COYOTE® Closure End
Origin of the Species…
                 COYOTE Closure Shell Kits                         Unitube Transition Compartment
 Catalog
 Number      Description (mm)
80805258     6.0" (152) x 22.0" (559) COYOTE Shell Kit
80805259     8.5" (216) x 22.0" (559) COYOTE Shell Kit


    Transition and Buffer Tube Storage Compartments
 Catalog
 Number Description (mm)
             6.0"(152) x 22.0" (559) Transition
80805112
             Compartment Kit
             8.5" (216)x 22.0" (559) Transition
80805113
             Compartment Kit
                                                                                   Loose Buffer Tube Storage Compartment
             6.0" (152) x 22.0" (559) Loose Buffer
80805262
             Tube Storage Compartment Kit
             6.0" (152) x 22.0" (559) COYOTE Express
80805419
             Organizer (for loose buffer tube applications)
             8.5" (216) x 22.0" (559) Loose Buffer
80805263
             Tube Storage Compartment Kit
             8.5" (216) x 22.0" (559) COYOTE Express
80805420
             Organizer (for loose buffer tube applications)
             Transition Tube Kit for fiber transition from top
 8003280
             section of end plate to transition compartment


                    Installation Materials
 Catalog
 Number      Description (mm)
80805238     C-Cement, 1 oz. tube
                                                                        Adjustable Aerial
80802377     C-Cement, 4 oz. can
                                                                        Hanger Bracket
80803448     Moisture Blocking Sealant, 3 oz. tube
80805925     LOCK-TAPE™ Sealant 1" (25) W x 15' (4 m) L
             Splice Protector, non-heat shrink 250/250 micron,
 8003092
             pack of 20
             Mass Fusion Splice Protector, non-heat shrink,
 8003425
             pack of 12                                                                                 Vertical Mount Bracket
 8003509     60 mm Heat Shrink Splice Protector, pack of 12
 8003490     Felt strips (blue) 1-1/8" (29) x 9" (229), 6 strips                 Mounting Brackets/Supports
                                                                     Catalog
                                                                     Number    Description (mm)
                                                                     8003325   Adjustable Aerial Hanger Bracket Kit
                                                                     8003279   Manhole Support Bracket Kit
                                                                               Vertical Mount Bracket Kit (for 6.0" (152) or
                                                                     8003372   8.5"(216) COYOTE Closure or 6.0" (152)
                                                                               COYOTE PUP Closure)




                                                                                                                                        1-27
PREVIOUS        SECTION CONTENTS            SEARCH   NEXT




       COYOTE Closure End Plates and Accessories
                           ®




       Origin of the Species…




        Strength Member Bracket




                                                                          Exterior Bond Braid




        Extended Strength Member Bracket



                     Miscellaneous Accessories                                   Bonding and Grounding Kits
        Catalog                                                     Catalog
        Number    Description (mm)                                  Number     Description (mm)
       80805260   Blank End Plate Kit                               8003281    External bond clip kit
       80805107   Strength Member Bracket Kit – two per kit         8003360    External bond braid kit
                  Extended Strength Member Bracket Kit –                       External isolation terminal kit, includes (2)
       80805431
                  two per Kit                                       8003463    isolation	terminals	with	7"	long	#6	cable	stub
                  Heat Shield for 6.0" (152) x 22.0"                           and splice sleeve
        8003386
                  (559) COYOTE Closure                                         External isolation terminal kit, includes (2)
                  Heat Shield for 8.5" (216) x 22.0"                8003464    isolation	terminals	with	7"	long	#6	cable	stub
        8003387                                                                and quick disconnect
                  (559) COYOTE Closure
                  Flame-Retardant Blanket for 6.0"                  8003465    Quick	disconnect	kit	(2	per	kit)
        8003385
                  (152) x 22.0" (559) COYOTE Closure                           External isolation connector for COYOTE
                                                                    80806750
                  Flame-Retardant Blanket for 8.5"                             Closures
        8003388
                  (216) x 22.0" (559) COYOTE Closure                           Fiber optic shield connector, RUS Listed 3M
                                                                    80803989
                  Transition Tube Kit Used to transition fibers                #4460-D/FO	(1	per	kit)
        8003280   from the top section of the End Plate to the                 Fiber optic shield connector for up to .5" (13mm)
                                                                    80806743
                  Transition Compartment.                                      cable O.D.
        8000475   COYOTE Closure End Plate Removal Tool                        Fiber optic shield connector for .5" to .8"
                                                                    80806744
                  Transport Tube Kit .135" ID: includes six 34"                (13 - 20mm) cable O.D.
                  long transPort with Hardened Adapter tubes,                  Fiber optic shield connector for .8" to 1.6"
       80805293                                                     80806745
                  used to bring fiber from transition compartment              (20 - 41mm) cable O.D.
                  to splice tray                                               Adapter bracket kit for AT&T bond
                                                                    80805286
                  Transport Tube Kit .25" ID: includes six 34"                 connector (4 per kit)
                  long transPort with Hardened Adapter tubes,       8003322    Isolated ground kit for 0.27" to .31" (7 - 8mm)
       80806439
                  used to bring fiber from transition compartment
                  to splice tray                                               Strength member bracket isolation kit, includes
                                                                    8003424
                                                                               (6) nylon washers and bushings
                                                                               Bonding Braid, .5" W x 7" L with (2) eyelets
                                                                    80806179
                                                                               spaced 6" apart




1-28
PREVIOUS    SECTION CONTENTS         SEARCH      NEXT

                                                                                             COYOTE® Closure Series: Section


                                                                                                                         1
COYOTE Closure End Plates and Accessories
                 ®




                                                                                                                      Plates and Accessories
                                                                                                                      COYOTE® Closure End
                                       Single Port Grommets
                                                             Coyote RUNT
                                               Accepted      Standard and      COYOTE 6 Port    COYOTE 4 Port
                                                Cable         Expanded           End Plate        End Plate
  Catalog                                      Diameter       Port Sizes         Port Sizes       Port Sizes
  Number        Hole               Factory      Range
(End Color)    Pattern   Entries     Slit    inches (mm)     3/4"       1"     3/4"    7/8"      1"     1-1/4"
 8003394                                       .31 - .38
                           1        NO                        X                 X
 (Green)                                      (7.8 - 9.6)

 8003395                                       .31 - .38
                           1        NO                                                   X
 (Green)                                      (7.8 - 9.6)

 8003473                                       .43 - .48
                           1        NO                                   X                        X
(Light Blue)                                  (11 - 12.2)

 8003494                                       .48 - .53
                           1        NO                                   X                        X
 (Yellow)                                    (12.2 - 13.5)

 8003495                                       .53 - .58
                           1        NO                                   X                        X
  (Gray)                                     (13.4 - 14.7)

 8003496                                       .43 - .48
                           1        NO                                                                    X
(Light Blue)                                  (11 - 12.2)

 8003497                                       .48 - .53
                           1        NO                                                                    X
 (Yellow)                                    (12.2 - 13.5)

 8003498                                       .53 - .58
                           1        NO                                                                    X
  (Gray)                                     (13.4 - 14.7)

 8003500                                      .38 - .43
                           1        NO                        X                 X
 (Orange)                                     (9.6 - 11)

 8003501                                      .38 - .43
                           1        NO                                                   X
 (Orange)                                     (9.6 - 11)

 8003596                                       .43 - .48
                           1        NO                        X                 X
(Light Blue)                                  (11 - 12.2)

  8003597                                      .43 - .48
                           1        NO                                                   X
(Light Blue)                                  (11 - 12.2)

 8003598                                       .48 - .53
                           1        NO                        X                 X
 (Yellow)                                    (12.2 - 13.5)

 8003599                                       .48 - .53
                           1        NO                                                   X
 (Yellow)                                    (12.2 - 13.5)

 8003600                                       .53 - .58
                           1        NO                        X                 X
  (Gray)                                     (13.4 - 14.7)

 8003601                                       .53 - .58
                           1        NO                                                   X
  (Gray)                                     (13.4 - 14.7)

 8003497                                       .48 - .53
                           1        NO                                                                    X
 (Yellow)                                    (12.2 - 13.5)

 8003671                                       .43 - .48
                           1        YES                       X                 X
(Light Blue)                                  (11 - 12.2)

 8003674                                       .53 - .58
                           1        YES                       X                 X
  (Gray)                                     (13.4 - 14.7)

 8003689                                       .48 - .53
                           1        YES                       X                 X
 (Yellow)                                    (12.2 - 13.5)

 8003675                                       .53 - .58
                           1        YES                                                  X
  (Gray)                                     (13.4 - 14.7)


                                                                                                                   1-29
PREVIOUS    SECTION CONTENTS        SEARCH   NEXT




       COYOTE Closure End Plates and Accessories
                         ®




                                                 Multi-Port Grommets
                                                                     COYOTE RUNT
                                                       Accepted       Standard and     COYOTE 6 Port   COYOTE 4 Port
                                                        Cable          Expanded          End Plate       End Plate
         Catalog                                       Diameter        Port Sizes        Port Sizes      Port Sizes
         Number         Hole               Factory      Range
       (End Color)     Pattern   Entries     Slit    inches (mm)     3/4"       1"     3/4"    7/8"     1"     1-1/4"
         8003392                                        .27 - .31
                                   2        NO                        X                 X
          (Red)                                        (6.8 - 7.8)

         8003393                                        .31 - .38
                                   2        NO                                                   X
         (Green)                                       (7.8 - 9.6)

         8003399                                       .38 - .43
                                   2        NO                                   X                      X
         (Orange)                                      (9.6 - 11)

         8003608                                     Corning SST
                                   2        NO                        X                 X
        (Light Blue)                                  (Flat Drop)

         8003730                                     Corning SST
                                   2        YES                       X                 X
        (Light Blue)                                  (Flat Drop)

         8003536                                        .18 - .24
                                   3        NO                                   X                      X
          (Black)                                      (4.5 - 6.1)

        800010621                                       .18 - .24
                                   3        NO                                                   X
          (Black)                                      (4.5 - 6.1)

         8003389                                        .27 - .31
                                   3        NO                                                   X
          (Red)                                        (6.8 - 7.8)

         8003390                                        .20 - .27
                                   3        NO                                                   X
          (Blue)                                       (5.1 - 6.8)

         8003391                                        .20 - .27
                                   3        NO                        X                 X
          (Blue)                                       (5.1 - 6.8)

         8003400                                        .31 - .38
                                   3        NO                                   X                      X
          (Blue)                                       (7.8 - 9.6)

         8003402                                        .27 - .31
                                   3        NO                                   X                      X
          (Red)                                        (6.8 - 7.8)

         8003403                                       .38 - .43
                                   3        NO                                                                   X
         (Orange)                                      (9.6 - 11)

         8003609                                     Corning SST
                                   3        NO                                                   X
        (Light Blue)                                  (Flat Drop)

         8003401                                        .20 - .27
                                   4        NO                                   X                      X
          (Blue)                                       (5.1 - 6.8)

         8003404                                        .31 - .38
                                   4        NO                                                                   X
         (Green)                                       (7.8 - 9.6)

         8003405                                        .20 - .27
                                   4        NO                                                                   X
          (Blue)                                       (5.1 - 6.8)

         8003406                                        .27 - .31
                                   4        NO                                                                   X
          (Red)                                        (6.8 - 7.8)

         8003575                                       .12 - .16
                                   4        NO                                                   X
         (Brown)                                       (3 - 4.1)

         8003607                                        .27 - .31
                                   4        NO                                   X                      X
          (Red)                                        (6.8 - 7.8)

          8003610                                    Corning SST
                                   4        NO                                   X                      X
        (Light Blue)                                  (Flat Drop)

         8003576                                       .12 - .16
                                   6        NO                                   X                      X
         (Brown)                                       (3 - 4.1)

          8003611                                    Corning SST
                                   6        NO                                                                   X
        (Light Blue)                                  (Flat Drop)

         8003582                                       .12 - .16
                                   10       NO                                                                   X
         (Brown)                                       (3 - 4.1)
1-30
PREVIOUS       SECTION CONTENTS        SEARCH       NEXT

                                                                                                 COYOTE® Closure Series: Section


                                                                                                                             1
COYOTE Closure End Plates and Accessories
                      ®




                                                                                                                          Plates and Accessories
                                                                                                                          COYOTE® Closure End
User options for COYOTE Closure Three-Section End Plate Ports
                                       Three-Section Six Port End Plate
                                             (Cat. No. 80805105)
Two 3/4" (19 mm) Ports                                                          Four 7/8"(22 mm) Ports
Available options:                                                              Available options:
•	 Cables	up	to	0.75"	(19	mm)	                                                  •	 Cables	up	to	0.88"	(22	mm)
   in diameter                                                                     in diameter
                                                          7/8"
                                                7/8" 3/4
                                                        "
•	 See	Grommet	table                                                            •	 Future	Cable	Port,	0.56"
•	 3/4" (19 mm) Plug (Cat. No.                                                     (14 mm) max. cable diameter
   80806037, two per kit)                                                       •	 See	Grommet	table
                                                7/8" 3/4 7/8
                                                        "   "
Note: Three-Section Six Port End                                                •	 7⁄8" Plug Kit (80806180)
Plate Kits include three 7/8" (22
mm) Plugs, two (2) 3/4" (19 mm)
Plugs and two Strength Member
Brackets.


                                       Three-Section Four Port End Plate
                                              (Cat. No. 80805739)
Two 1" (25 mm) Ports                                                        Two 1-1/4" (32 mm) Ports
Available options:                                                          Available options:
•	 Cables	up	to	1.00"	(21	mm)	in	                                           •	 Cables	up	to	1.25"	(32	mm)	in
   diameter                                                                    diameter
•	 Future	Cable	Port,	0.81"	(21	mm)	                          1"            •	 Future	Cable	Port,	1"	(25	mm)	max.
   max. cable diameter                                                         cable diameter
•	 See	Grommet	table
                                                      1"                    •	 See	Grommet	table
•	 1"	Plug	Kit	(80806038)                                    11/4"          •	 1-1/4"	Plug	Kit	(80806181)
                                                     11/4"




1" (25 mm) Ports
Available options:
                                           COYOTE RUNT End Plate
•	 Cables	up	to	1.0"	(25	mm)	in
   diameter
•	 Future	Cable	Port,	0.81"	(21	mm)
   max. cable diameter
•	 See	Grommet	table
•	 1"	Plug	Kit	(80806038)



                                                                     3/4"
                                                             1 "

                                                      3/4"
                                                                            Two 3/4" (19 mm) Ports
                                                                            Available options:
                                                                            •	 Cables	up	to	0.75"	(19	mm)
                                                                               in diameter
                                                                            •	 See	Grommet	table
                                                                            •	 3/4" Plug (80806181) Two/Kit            1-31
PREVIOUS         SECTION CONTENTS             SEARCH   NEXT




       COYOTE Closure End Plates and Accessories
                              ®




       Future Cable Port Kit
       When installed during the initial assembly, Future Cable
       Ports allow for the addition of branch cables in the future
       with no disruption to the existing cables and the fibers
       within them.




                                                               Future Cable Port Kits

         Catalog                                                                                                     End Plate Usage
         Number     Description                                                     7/8"      1.0"      1-1/4"    Runt    6 Port   4 Port
                    Future cable port kit for 7/8"" Port, includes (1) cable
         8003371                                                                     X                                        X
                    port, (1) plug and (1) clamp
                    Future cable port kit for 1" Port, includes (1) cable port,
         8003407                                                                               X                    X                      X
                    (1) plug and (1) clamp
                    Future cable port kit for 1-1/4" Port includes (1) cable
         8003409                                                                                          X                                X
                    port, (1) plug and (1) clamp
                    Future cable installation kit, includes LOCK-TAPE
         8003291                                                                     X         X          X         X         X            X
                    sealant, bead sealant and l-bracket
                    Future cable port for 7/8" port plus installation kit
         8003289                                                                     X                                        X
                    (8003291)
                    Future cable port for 1" port plus installation kit
         8003408                                                                               X                    X
                    (8003291)
                    Future cable port for 1-1/4" port plus installation kit
         8003410                                                                                          X                                X
                    (8003291)



       COYOTE Closure End Plate Grommets

                                                                                             End Plate Installation Material Kits
                                                                                  Catalog
                                                                                  Number     Description
                                                                                             6 Port end plate kit, includes
                                                                                  80805105   (1) end plate assembly,
                                                                                             (1) full set of plugs and LOCK-TAPE sealant
                                             End Plate Grommets                              4 Port end plate kit, includes
                                             expand the capacity of               80805739   (1) end plate assembly,
                                             the COYOTE Closure                              (1) full set of plugs and LOCK-TAPE sealant
                                             T h re e - S e c t i o n E n d       80806037   Plug Kit for 3/4" ports (2 per kit)
                                             Plates for applications              80806180   Plug Kit for 7/8" ports (2 per kit)
                                             with smaller diameter                80806038   Plug Kit for 1.0" ports (2 per kit)
                                             cables or insulated
                                                                                  80806181   Plug Kit for 1-1/4" ports (2 per kit)
                                             ground wires.

       The grommets are manufactured from a weather-resistant
       urethane material that is designed to ensure a tight and
       permanent seal. A Silicone Sealant is provided to lubricate
       the grommet and cables for easy installation.

       The entry holes in the multi-entry grommets are covered
       with a thin layer of urethane material to provide a choice of
       which entries are to be used for future cable entries.

       See Grommet charts on pages 1-29 and 1-30.


1-32
PREVIOUS       SECTION CONTENTS          SEARCH    NEXT

                                                                                                         COYOTE® Closure Series: Section


                                                                                                                                        1
COYOTE                 ®
                           Cross-Connect and Cross-Connect/Express Closures




                                                                                                                                    Cross-Connect/Express Closures
                                                                                                                                       COYOTE Cross-Connect &
Refinement of the Breed…




                                                                                                                                                           ®
The COYOTE Cross-Connect Closure
provides long-term peace of mind.

The COYOTE Cross-Connect and Cross-Connect/Express-
Closures allow you to splice up to 96 single fiber splices            PATENTED
and cross connect up to 48 pigtails on both the office and
distribution side. Consult PLP support for details on ribbon
fiber splices. By redirecting fiber for outside plant, the
COYOTE Cross-Connect Closure saves time and money:
because you splice only once.

The COYOTE Cross-Connect and Cross-Connect/Express-
Closures are made from the same durable UV stabilized
material as the COYOTE Closure.

The internal bulkhead is designed to accept a variety of
connector styles. Place your order as soon as you have
chosen the connector for your application and determined
your pigtail requirements. This customization process saves
time and money by limiting the order to only the parts required.

Each end plate allows for multiple entries. Isolated ground
studs simplify troubleshooting, and provide additional
support for strength member tie-off.

The family of COYOTE Cross Connect/Express Closures                The COYOTE Cross-Connect Closure is waterproof and
is configured to conveniently and safely store uncut buffer        uses the revolutionary LOCK-TAPE™ Sealant System,
tubes of the feeder cable, while providing individual              providing field-proven durability. The neoprene gasket also
connectivity to the fibers of the drop cables.                     aids in keeping the closure’s contents accessible again and
                                                                   again without a costly re-entry kit. The COYOTE Closure is
                                                                   tested in accordance with Bellcore GR-771-CORE.


COYOTE Cross-Connect Closure components

                                                                                 Bulkhead
    8.5" (216 mm)
    COYOTE® Closure Shell                                                            Blank
                                                                                     End Plate

                                                                                                 Transition Compartment Kit
                                                                                                 with Pigtail Guides




                 Three-Section
                 End Plate


                                                                                             8.5" (216 mm)
                                COYOTE®
                                                                                             COYOTE® Closure Shell
                                Splice Trays (4)


                                                                                                                                 1-33
PREVIOUS         SECTION CONTENTS             SEARCH   NEXT




       COYOTE                 ®
                                  Cross-Connect and Cross-Connect/Express Closures


       Refinement of the Breed…
       Ordering Information
       Included in all COYOTE Cross-Connect Closure Kits is one
       Three-Section End Plate, one Blank End Plate, Transition
       Compartment Kit with Pigtail Guides, Bulkhead, and four
       COYOTE Splice Trays (single fiber). ST, SC and FC Half-
       Loaded and Fully-Loaded Kits contain additional items which
       are described in the table below.


                                                       COYOTE Cross-Connect Closure
         Catalog
         Number     Description
                    COYOTE Cross Connect-Closure (Standard Unit) includes one three-section End Plate, one blank End Plate, transition
         8006572
                    compartment kit with pigtail guides, bulkhead, and four COYOTE Splice Trays (single fiber)
                    COYOTE Cross-Connect Closure – ST half loaded (24 count) includes standard unit, plus four (Bulkhead) coupler
         8006576    panels with six singlemode ST couplers, four field pigtail kits with ST connector (6) and transport tube, and four service
                    pigtail kits with ST connector (6) and transport tube
                    COYOTE Cross-Connect Closure – ST fully loaded (48 count) includes standard unit, plus eight (Bulkhead) coupler
         8006577    panels with six singlemode ST couplers, eight field pigtail kits with ST connector (6) and transport tube, and eight
                    service pigtail kits with ST connector (6) and transport tube
                    COYOTE Cross-Connect Closure – SC half loaded (24 count) includes standard unit, plus four (Bulkhead) coupler
         8006591    panels with six singlemode SC couplers, four field pigtail kits with SC connector (6) and transport tube, and four
                    service pigtail kits with SC connector (6) and transport tube
                    COYOTE Cross-Connect Closure – SC fully loaded (48 count) includes standard unit, plus eight (Bulkhead) coupler
         8006592    panels with six singlemode SC couplers, eight field pigtail kits with SC connector (6) and transport tube, and eight
                    service pigtail kits with SC connector (6) and transport tube
                    COYOTE Cross-Connect Closure – FC half loaded (24 count) includes standard unit, plus four (Bulkhead) coupler
         8006593    panels with six singlemode FC couplers, four field pigtail kits with FC connector (6) and transport tube, and four
                    service pigtail kits with FC connector (6) and transport tube
                    COYOTE Cross-Connect Closure – FC fully loaded (48 count) includes standard unit, plus eight (Bulkhead) coupler
         8006594    panels with six singlemode FC couplers, eight field pigtail kits with FC connector (6) and transport tube, and eight
                    service pigtail kits with FC connector (6) and transport tube
                    COYOTE Cross-Connect Closure – AP/SC fully loaded (48 count) includes standard unit, plus eight (Bulkhead) coupler
         8006670    panels with six singlemode AP/SC couplers, eight field pigtail kits with AP/SC connector (6) and transport tube, and
                    eight service pigtail kits with AP/SC connector (6) and transport tube




1-34
PREVIOUS        SECTION CONTENTS              SEARCH    NEXT

                                                                                                          COYOTE® Closure Series: Section


                                                                                                                                           1
COYOTE                 ®
                           Cross-Connect and Cross-Connect/Express Closures




                                                                                                                                       Cross-Connect/Express Closures
                                                                                                                                          COYOTE Cross-Connect &
Refinement of the Breed…




                                                                                                                                                              ®
Cross connect and store expressed fibers
in the same closure

The family of COYOTE Cross-Connect Express Closures
are configured to conveniently and safely store uncut buffer
tubes of the feeder cable, while providing individual
connectivity to the fibers of the drop cables.

        COYOTE Cross-Connect/Express Closure
 Catalog
 Number Description
          Expanded COYOTE RUNT Cross-Connect/Express
 8006916
          Closure, Includes one 12 count splice tray
          COYOTE PUP Cross-Connect/Express Closure, with
 8006920                                                         PATENTED
          6-port end plate, includes two 12 count splice trays
          COYOTE PUP Cross-Connect/Express Closure, with                                Adaptor Plates
 8006921
          4-port end plate, includes two 12 count splice trays
                                                                  Catalog
          6" x 22" COYOTE Cross-Connect/Express Closure,          Number            Connector                   Adaptor
 8006911 with 6-port end plate, includes two 36 count
          splice trays                                            6SMSC                SC                          6
          6" x 22" Cross-Connect/Express Closure, with            6SCAPC             SC/APC                        6
 8006912                                                         12SMDSC               SC                       6 Duplex
          4-port end plate, includes two 36 count splice trays
          8.5" x 22" COYOTE Cross-Connect/Express                 8SMSC                SC                          8
 8006612 Closure with 6-port end plate, includes two 36            6SMST               ST                          6
          count splice trays
                                                                   8SMST               ST                          8
          8.5" x 22" COYOTE Cross-Connect/ Express
                                                                   6SMFC               FC                          6
 8006915 Closure, with 4-port end plate, includes two 36
          count splice trays                                       8SMFC               FC                          8
          6.5" x 22" COYOTE Dome Cross-Connect/Express            6FCAPC             FC/APC                        6
800012184
          Closure, (Empty)                                         6SMLC               LC                          6
          6.5" x 17" COYOTE Dome Cross-Connect/Express            12SMLC               LC                          12
800012185
          Closure, (Empty)                                          600               Blank                         –
                                                                  Catalog
                    Capacities Adapter                            Number     Description
                 Max.       No. of     No. of                                (Bulkhead) Coupler Panel with six holes for ST
                                                                  80805605
                Feeder     Adapter     Splice        Splices                 Feed-Thru Adapters
   Closure      Cable       Plates     Trays         per Tray                (Bulkhead) Coupler Panel with six holes for SC
                                                                  80805606
  Expanded                                                                   Feed-Thru Adapters
                48-fiber        1           1           12
    RUNT                                                                     (Bulkhead) Coupler Panel with six holes for FC
                                                                  80805607
    PUP        144-fiber        2           2           12                   Feed-Thru Adapters
   6" x 22"    144-fiber        3           2           36
  8.5" x 22"   288-fiber        3           4           36                      Pigtail Kits and Accessories
  17" Dome      48-fiber        1           1           12        Catalog
  22" Dome     144-fiber        2           2           12        Number     Description
                                                                             Pigtail Kit with ST Singlemode Connector (6) and
                                                                  8003292
                                                                             Transport Tube, FIELD
                                                                             Pigtail Kit with SC Singlemode Connector (6) and
                                                                  8003314
                                                                             Transport Tube, FIELD
                                                                             Pigtail Kit with FC Singlemode Connector (6) and
                                                                  8003316
                                                                             Transport Tube, FIELD
                                                                             Pigtail Kit with ST Singlemode Connector (6) and
                                                                  8003293
                                                                             Transport Tube, SERVICE
                                                                             Pigtail Kit with SC Singlemode Connector (6) and
                                                                  8003315
                                                                             Transport Tube, SERVICE
                                                                             Pigtail Kit with FC Singlemode Connector (6) and
                                                                  8003317
                                                                             Transport Tube, SERVICE
                                                                             Pigtail Transition Tube Kit, includes one Transport
                                                                  8003368
                                                                             Tube with Transition and Reducing Tubes
                                                                                                                                    1-35
PREVIOUS        SECTION CONTENTS             SEARCH   NEXT




       COYOTE Drop Cable Closure
                             ®




       Refinement of the Breed…
       The perfect solution to the splicing or
       repair of low fiber count drop cables

       The COYOTE Drop Cable Closure is a re-enterable (not
       re-usable), encapsulant filled closure for splicing buried
       fiber optic drop cables (up to 6-fiber).

       The COYOTE Drop Cable Closure will accept either dielec-
       tric or shielded fiber optic drop cables with an outside
       diameter of up to 0.5" (13 mm).

       Each Closure body is factory filled with field proven (over
       14 years) POLY-BEE™ Sealant to provide a protective           Catalog
       barrier around the sealed splice tray assembly.               Number     Description
                                                                                COYOTE Drop Cable Closure, includes sealed
       The sealed splice tray assembly has an integral bond clamp    8006876    splice tray assembly and six (6) heat shrink
       which provides both conductivity between the cable shields               splice protectors.
       and cable restraint.                                                     COYOTE Drop Cable Closure unfilled includes
                                                                     8006914    splice tray assembly & six (6) heat shrink splice
                                                                                protectors.
       The splice block on the splice tray assembly holds up to
       six heat-shrink fusion splice protectors. Six 40 mm long
       protectors are provided.

       Assembly is simple:
       •	 Prepare	&	secure	cables	to	splice	tray
       •	 Splice	fibers
       •	 Seal	splice	tray
       •	 Place	splice	tray	in	encapsulated	closure
       •	 Secure	closure	with	closing	clamp

       Unfilled version for aerial fiber optic drop cables (up to
       6-fiber) are available. Cable entries and closure seams
       are still sealed to prevent the ingress of wind-driven rain
       and dust.




                                                                     Length (mm)          Height (mm)            Width (mm)
                                                                       12" (305)             3" (76)              3.5" (89)




1-36
PREVIOUS          SECTION CONTENTS             SEARCH    NEXT

                                                                                                                    COYOTE® Closure Series: Section


                                                                                                                                                    1




                                                                                                                                               COYOTE Closures for High Fiber
COYOTE Closures for High Fiber Count Applications
                      ®




                                                                                                                                                    Count Applications
                                                                                                                                                                     ®
Refinement of the Breed…
Larger sizes for High Fiber Count
Metropolitan Networks.

COYOTE Closures are now available in 9.5" x 28" (241 mm
x 711 mm) and 9.5" x 38" (241 mm x 965 mm) for high fiber
count applications.

These larger COYOTE Closures use the same drillable end
plates and fiber management systems as the COYOTE
Splice Case (see section 2), but incorporate a new light-
weight, durable non-metallic shell.




                                                                                              COYOTE Hi-Count Closure
                                                                                              Catalog Number 800010810

                                                         COYOTE Closure Kits
  Catalog
  Number      Description (mm)
                                                            Closure Kits
           9.5" x 28" (241 x 711) COYOTE Hi-Count Closure for buffer tube applications, up to 432 single fiber splices, holds up to
 800010810
           eighteen 24-count splice trays
  8003469 24-count Splice Tray for COYOTE Hi-Count Closure (heat shrink protector only)
           9.5" x 28" (241 x 711) COYOTE Closure, unitube version, holds up to six 144-fiber ribbon splice trays (mass fusion),
 800010897
           864-fiber capacity or ten 36 fiber single fiber splice trays, 360-fiber capacity, for use with central core ribbon fiber cables
           9.5" x 28" (241 x 711) COYOTE Closure, buffer tube version, holds up to six 144-fiber ribbon splice trays (mass fusion),
 800010884 864-fiber capacity or ten 36 fiber single fiber splice trays, 360-fiber capacity, for use with flexible buffered ribbon
           fiber cables
           9.5" x 38" (241 x 965) COYOTE Closure, unitube version, holds up to nine 144-fiber ribbon splice trays (mass fusion),
  8006765 1296-fiber capacity or sixteen 36-fiber single fiber splice trays, 576-fiber capacity, for use with central core ribbon
           fiber cables
                                                           Splice Tray Kits
 80805146 144 Count Ribbon Tray w/fixed rigid slots
 80805515 144 Count Ribbon Tray w/2 elastomeric splice blocks
 80805514 36 Count Standard Tray w/elastomeric splice blocks – fusion & mechanical splices
  8001127  36 Count Low Profile Tray w/plastic splice block – single fusion splices
                                                      Installation Accessories
  8006792 9.5" x 28" (241 x 711) COYOTE Closure Shell Kit
  8006793 9.5" x 38" (241 x 965) COYOTE Closure Shell Kit




                                                                                                                                             1-37
PREVIOUS        SECTION CONTENTS           SEARCH   NEXT




       COYOTE Retrofit Closure ®




       Refinement of the Breed…
       The ideal Closure for replacement
       or expansion

       The COYOTE Retrofit Closure contains a versatile Fiber
       Management System which makes simple work out of
       retrofitting existing fiber optic closures for either closure
       replacement or closure capacity expansion.

       Specifically, the COYOTE Retrofit Closure will accommodate
       the existing fiber management systems (slack buffer tubes
       or fiber and splice trays) from closures manufactured by
       Lucent Technologies (UCB Series), 3M (2178 Series) and
       other suppliers.

       In addition to accommodating the existing splice trays and
       fiber storage, the COYOTE Retrofit Closure will hold up to                                 Closure Kits
       four single fiber splice trays, six low-profile trays or up to two   Catalog
       ribbon fiber trays. The total added capacity of the COYOTE           Number     Description
       Splice Trays is 216 single fiber, or 288 mass fusion.                                        Closure Kit
                                                                                       8.5" x 22.0" (216 x 559 mm) COYOTE Retrofit
       As part of the family of COYOTE Closures, the COYOTE                            Closure. Includes two (2) Three-Section Six Port
       Retrofit Closure uses the permanent neoprene gasket in               8006638
                                                                                       End Plates, hybrid Fiber Management System,
       the shell halves and the proven LOCK-TAPE™ Sealing                              Ten (10) End Plate Plugs and four (4) L-Brackets
       System for the End Plate and cable seals. These features                                   Splice Tray Kits
       mean that the COYOTE Retro-fit Closure will meet the same                       36 Count Standard Tray w/elastomeric splice
                                                                            80805514
       performance standards as the COYOTE Closure in aerial,                          blocks – Fusion & mechanical splices
       underground and buried applications.The COYOTE Closure               80805146   144 Count Ribbon Tray w/fixed rigid slots
       has been tested in accordance with the requirements of                          36 Count Low Profile Tray w/plastic splice block
       Telcordia GR-771-CORE.                                               8001127
                                                                                       – single fusion splices

       In addition, the COYOTE Retrofit Closure uses the same
       accessories as available for the COYOTE Closure, including
       Future Cable Ports, End Plate Grommets, Aerial or Manhole
       Brackets and Splice Trays. See COYOTE Accessories
       section for catalog numbers for accessories.




1-38
PREVIOUS         SECTION CONTENTS             SEARCH     NEXT

                                                                                                                   COYOTE® Closure Series: Section


                                                                                                                                                 1
COYOTE Closures (ADOBE Series)
                         ®                                                    ™




                                                                                                                                               COYOTE® Closures
                                                                                                                                                (ADOBE™ Series)
Refinement of the Breed…
Low profile ADOBE™ Series Trays allow more
splices to be stored in groups of 12 or 24
For applications which require a limited number of splices
per splice tray, the COYOTE® Closure configured for 12-count
or 24-count ADOBE Splice Trays provides the answer. The
low profile ADOBE Splice Trays combined with the versatile
buffer tube management system of the COYOTE Closure
organize and protect the buffer tubes and fibers while
maintaining maximum overall storage capacity.

See the COYOTE Closure End Plates, End Plate Grommets,
Future Cable Port Kits, Mounting Brackets and other
common COYOTE Closure accessories.

See page 1-25 for COYOTE Closure dimensions.


                                                COYOTE Closure (ADOBE Series) Kit
   Catalog Numbers
  6-Port      4-Port
 End Plate End Plate         Description (mm)
                             6.0" x 22" (152 x 559) COYOTE Closure Kit configured for ADOBE-12 or ADOBE-24 splice trays.
  8006684       8006688
                             Includes: 1 Three-Section End Plate, 1 Blank End Plate, and Buffer Tube Storage Compartment
                             8.5" x 22" (216 x 559) COYOTE Closure Kit configured for ADOBE-12 or ADOBE-24 splice trays.
  8006685       8006686
                             Includes: 1 Three-Section End Plate, 1 Blank End Plate, and Buffer Tube Storage Compartment
                             6.0" x 22" (152 x 559) COYOTE Express Closure Kit configured for ADOBE-12 or ADOBE-24 splice trays.
  8006806       8006820
                             Includes: 1 Three-Section End Plate, 1 Blank End Plate, and Express Buffer Tube Storage Compartment
                             8.5" x 22" (216 x 559) COYOTE Express Closure Kit configured for ADOBE-12 or ADOBE-24 splice trays.
  8006807       8006819
                             Includes: 1 Three-Section End Plate, 1 Blank End Plate, and Express Buffer Tube Storage Compartment


                                                      ADOBE Series Splice Trays
  Catalog
  Number       Description
  8001122      ADOBE-12 Splice Tray (12 Count) with Heat Shrink Splice Block. Includes: Tray, Cover, Tie Wraps and Felt Strips
  8001096      ADOBE-12 Splice Tray (12 Count) with Molded-in Splice Block. Includes: Tray, Cover, Tie Wraps and Felt Strips
  8001120      ADOBE-12 Splice Tray Blank. Includes: Tray, Cover, Tie Wraps and Felt Strips
  8001121      ADOBE-24 Splice Tray (24 Count) with 2 Heat Shrink Splice Blocks. Includes: Tray, Cover, Tie Wraps and Felt Strips
  8001119      ADOBE-24 Splice Tray Blank. Includes: Tray, Cover, Tie Wraps and Felt Strips
ADOBE-12 Splice Trays are 13" L x 315⁄16" W x 11⁄32" H (330 x 100 x 9 mm)
ADOBE-24 Splice Trays are 13" L x 4¾" W x 11⁄32" H (330 x 121 x 9 mm)

                                                               Capacities
                               Splice Tray       Usable Splice         Splice Capacity        Max. Number of          Max. Closure
      Closure (mm)             Catalog No          Protectors              Per Tray          Trays Per Closure       Splice Capacity
                                8001122         Heat Shrink Only              12                    12                     144
  6.0" x 22" (152 x 559 )       8001096         Protected Fusion              12                    12                     144
                                8001121         Heat Shrink Only              24                     6                     144
                                8001122         Heat Shrink Only              12                    18                     216
  8.5" x 22" (216 x 559 )       8001096         Protected Fusion              12                    18                     216
                                8001121         Heat Shrink Only              24                    12                     288
Note: Maximum number of trays per closure and closure capacity for COYOTE Express Closure Kits (8006806, 8006807, 8006819 and 8006820) are
reduced by 50%.



                                                                                                                                             1-39

Plp comm catsec1-2010t

  • 1.
    PREVIOUS SECTION CONTENTS SEARCH NEXT COYOTE® Closure Series: Section 1 Section 1 – COYOTE® Closure Series Table of Contents Page COYOTE Closure Overview ....................................................................1-2 COYOTE GLC (Ground Level Closure) ..................................................1-4 COYOTE Dome Closure ..........................................................................1-9 COYOTE In-Line RUNT..........................................................................1-10 COYOTE Terminal Closure – Dual Chamber.......................................1-11 COYOTE Terminal Closure – Single Chamber....................................1-12 COYOTE Terminal Closure ...................................................................1-13 COYOTE Aerial Drop Closure...............................................................1-15 COYOTE LCC (Low Count Closure).....................................................1-16 COYOTE Splice Tray Capacity Charts .................................................1-18 COYOTE Silicone Grommet Kits ..........................................................1-20 COYOTE DTC (Drop Termination Closure) .........................................1-21 COYOTE Taut Closure ..........................................................................1-22 COYOTE RUNT Closure ........................................................................1-23 COYOTE PUP Closure...........................................................................1-24 COYOTE Closure ...................................................................................1-25 COYOTE Closure End Plates and Accessories ..................................1-27 COYOTE Cross-Connect and Cross-Connect/Express Closure .......1-33 COYOTE Drop Cable Closure ...............................................................1-36 COYOTE Closures for High Fiber Count Applications ......................1-37 COYOTE Retrofit Closure .....................................................................1-38 COYOTE Closures (ADOBE™ Series) ...................................................1-39
  • 2.
    PREVIOUS SECTION CONTENTS SEARCH NEXT COYOTE Closure Overview ® Choose a member of the COYOTE Closure Family that Best Suits your Application...... It all began with the development of a new breed of fiber optic unique solutions to the varied requirements of an ever-evolving closure. Craft friendly. Easily installed. Competitively priced. fiber optic network. From aerial to underground to every step And designed to go wherever fiber optic cable takes you. Over of the last mile, the COYOTE family of fiber optic closures is the years the philosophy has remained constant, and the fam- there to provide performance you can count on. ily has grown with each successive member offering its own COYOTE GLC (Ground Level Closure) COYOTE Terminal Closure (Dual Chamber) (Page 1-11) Pedestal System (Page 1-4) T h e C OYO T E The COYOTE GLC Pedestal Terminal Closure is System is the first truly her- available in two metically sealed pedestal configurations – system. With its patented Dual and Single segmented end plate design, Chamber: it allows you to make adjust- ments on site or move to an The unique dual enclosed work environment. chamber design The design also permits a RUS LISTED provides two dis- high volume of uncut slack tinct chambers that cable storage if needed. can be configured differently to support up to 24 externally mounted hardened connections, internally mounted cross- RUS LISTED connect bulkhead connections or a combination of both. A window designed within the closure interior allows fibers to COYOTE Dome Closure (Page 1-9) be passed between chambers. High drop capacity out each T h e C OYOT E D o m e of the eight cable ports and the ability to use standard or Closure was specifically hardened adapter covers, provides infinite options to support designed for applications your network design. where a domed-st yle configuration is preferred. COYOTE Terminal Closure (Single Chamber) (Page 1-12) It features an innovative The COYOTE Terminal end plate design with Closure (Single Chamber) segmented sections that is the ideal choice for net- allow for individual access work designs requiring RUS LISTED of each cable without hardened adapter termina- disruption to surrounding tion. Externally mounted cables. A full line of multi-hole grommets ensures the ultimate OptiTap* hardened adapt- level of flexibility to meet the demands of ever evolving ers allow for future instal- communications networks. RUS LISTED lation of up to 12 hardened drops without closure reentry. Compact size allows the closure COYOTE In-Line RUNT (Page 1-10) to be installed into pedestals and small hand holes. Additional The COYOTE In-Line RUNT drop capacity through the 4 entry ports of the closure base, Closure has the versatility and provide added flexibility for the closure to act as a distribution features that make it a perfect point for closures deeper in your network. choice for distribution, node and fiber to the premises networks. COYOTE Aerial Drop Closure (Page 1-15) The compact size allows the The COYOTE Aerial closure to be installed into ped- Drop Closure is a estals and small hand holes, value priced solution. keeping your installation costs Features include its down. High drop capacity and compact size and RUS LISTED the capability to be converted to ease of installation – a terminal closure will allow room no special tools need- for expansion long after the ed. It is capable of initial installation. higher splice capaci- ties and is designed for PLP’s easy-to-use grommet system. Included is the universal mounting bracket, which permits pole mounting with straps, strand mounting with strand clamps or suspension from “J” hooks secured to a pole. 1-2 *OptiTap™ is a trademark of Corning Cable Systems.
  • 3.
    PREVIOUS SECTION CONTENTS SEARCH NEXT COYOTE® Closure Series: Section 1 COYOTE Closure Overview ® Closure Overview COYOTE® COYOTE LCC (Low Count Closure) (Page 1-16) COYOTE Closure (Page 1-25) The COYOTE LCC is Setting the bar against which all designed specifically other fiber closures are measured for low fiber count in- was no small task for our design stallations and repairs team. But years of research & within your Fiber-to- development eventually paid off in the-Home, Node or the form of a rugged and reliable Curb deployments. design that has become legend. The closure's compact After over ten years of field use and RUS LISTED size, use of the versa- several hundred thousand units tile grommet system sold, the original COYOTE Closure and internal LITE-GRIP® Splice Platform, make this rugged still remains one of the most highly closure the economical choice for your network. Designed with RUS LISTED regarded and widely used fiber ease of use in mind and maximum versatility. Kits have also optic closures in the industry. been created to support copper applications. COYOTE Cross-Connect and Cross-Connect/ COYOTE DTC (Drop Termination Closure) (Page 1-21) Express Closure (Page 1-33) This new closure design is The COYOTE Cross-Connect constructed to support butt or C l o s u re wa s d e s i g n e d fo r inline low count splice applica- applications requiring connector- tions in a direct buried or below ization or cross connecting in the grade environment and pole/ outside plant network. Addition- wall mounted applications ally, the COYOTE Cross-Connect/ near the end of you network. Express Closure was configured The closures’ compact size to allow for convenient and safe and rugged exterior allow for storage of uncut buffer tubes in installation in tight spaces without compromising functionality. the feeder cable, while providing individual connectivity to the fibers COYOTE Taut Closure (Page 1-22) of the drop cables. The COYOTE Taut Closure simplifies branch cable taps or repairs of taut fiber optic COYOTE Retrofit Closure (Page 1-38) cables. Features the innova- The COYOTE Retrofit Closure is tive End Plate from the Dome the right choice for replacement or Closure and full line of multi expansion of existing fiber optic hole grommets. closures. COYOTE RUNT Closure (Page 1-23) T h e c o m p a c t C OYOT E COYOTE® MPC (Multi-Purpose Closure) (Page 16-3) RUNT Closure is ideal for low The COYOTE MPC focuses fiber count, (up to 48 splices), on the MDU environment, end-of-the-line, node and fiber- providing a flexible platform to-the-curb installations. It will to address the multitude of easily fit into most pedestals applications that exist in and hand holes, and the rug- residential and commercial ged design allows it to be used FTTx installations. Con- in all environments. structed of durable, UV RUS LISTED stabilized, flame-retardant RUS LISTED polymer, the closure permits interior or exterior applica- COYOTE PUP Closure (Page 1-24) tions. Accepting an easy-to-use grommet system and standard The COYOTE PUP Closure commercially available fittings, eight cable entrance ports are offers the perfect choice for low available around the closure exterior. The MPC’s interior fiber count distribution applica- can be configured to address slack storage, splicing, cross tions involving butt and inline connect, hardened adapter application or a combination of installations.The compact size all. In addition, to minimize installation labor, the closure is and rugged design allow the available in pre-terminated configurations. closure to be applied in below grade, aerial and buried instal- lations. Supported by a full line of COYOTE accessories, this RUS LISTED closure can grow along with 1-3 your network.
  • 4.
    PREVIOUS SECTION CONTENTS SEARCH NEXT COYOTE GLC (Ground Level Closure) ® The innovation and reliability ■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■ PLP Feature Focus you have come to expect from ©2009 Preformed Line Products ■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■ PLP since 1947 Film available at www.preformed.com PLP Introduces the COYOTE® GLC (Ground Level Closure), the first truly hermetically sealed pedestal system and the only pedestal system with PLP’s patented segmented end plate design. GLC is the first design that doesn’t force you to work where it’s installed and this unique design permits a high volume of uncut slack cable storage if needed. Key Features: • Compact: 9.5" x 17" Dome Enclosure secures to a 19.5" L x 19.5" W x 13" H Base • Cost Effective: Blended design eliminates the need to purchase separate components • Sealable, Re-Enterable, & Re-Usable: Utilizes the same silicone grommet sealing system and segmented end plate design that is found throughout the COYOTE Dome Closure Family • Transportable: Slack storage of uncut cable allows dome enclosure to be carried to a splice truck or other suitable working environment • Adjustable: Stackable spacer system adapts to the base for changing grade levels • Independent Grounding System: Accessible isolated grounding system that allows ground testing to occur without entering the splice enclosure • Durable: Manufactured out of a flame and impact resistant polymer • Securable: Collar latch mechanism allows attachment of different security devices • Modular: Split design allows parts to be added or replaced without disrupting other assembled components • Customizable: Create the closure that fits your application needs RUS LISTED • Patent Pending 1-4
  • 5.
    PREVIOUS SECTION CONTENTS SEARCH NEXT COYOTE® Closure Series: Section 1 COYOTE GLC (Ground Level Closure) ® (Ground Level Closure) COYOTE® GLC Configuration Selection COYOTE® GLC (Ground Level Closure) Base with Flat Cover (C1) C1 • Ideal for slack storage of fiber optic cable with diameters up to .60" (15.24 mm) during initial construction • Base can store 100 ft of slack cable • Exterior Base Dimensions: 19.5" L x 19.5" W x 13" H (49 cm x 49 cm x 33 cm) • Protective cable routing channel on base exterior • Slots provided in base for securing cable • Split base to allow for installation/replacement without disrupting previously installed GLC components • Base retention stakes available to secure base in ground (see Accessories Selection) • Base height can be increased with the use of spacers (see Accessories Selection) Cat. No.: COYGLC-C1-000 • Durable flat cover with integrated handles COYOTE GLC Dome Assembly with Platform (C2) • Used for splicing cable stored in a previously installed GLC C2 base with flat cover • Dome Assembly includes: (1) GLC dome, (1) collar, (1) fiber organizer (see Fiber Organzier Selection), & (1) platform • Dome Assembly provides a hermetical seal to keep out water, insects, and rodents • Dome Size: 9.5" W x 17" L (24 cm x 43 cm) • Collar system provides quick re-entry. No special tools required. • Integrated handles in collar allow for ease of handling when installing/removing dome assembly with platform from base • Collar latch allows for other security devices to be used • Platform allows dome assembly to be attached/detached from GLC base • Split platform to allow for installation/replacement without disrupting previously installed GLC components Cat. No.: COYGLC-F1-000 Cat. No.: COYGLC-F3-000 Cat. No.: COYGLC-F2-000 Cat. No.: COYGLC-F4-000 Full COYOTE GLC Assembly (C3) • Used for splicing and storing cable during initial construction C3 • Allows for fiber splicing at a fixed or remote location such as a splice trailer • Dome Assembly provides a hermetical seal to keep out water, insects, rodents, and other harmful elements • Various fiber organizers available to suit your splicing needs (see Fiber Organizer Selection) • Full GLC Assembly includes: (1) GLC Dome, (1) Collar, (1) fiber organizer (see Fiber Organzier Selection), (1) platform, and (1) base • All GLC components are modular and can easily be replaced • GLC base allows for storage of 50 ft (1524 cm) cable legs • Base retention stakes available to secure base in ground (see Accessory Selection) • Base height can be increased with the use of spacers (see Spacer Selection) Cat. No.: COYGLC-F1B-000 Cat. No.: COYGLC-F3B-000 Cat. No.: COYGLC-F2B-000 Cat. No.: COYGLC-F4B-000 1-5
  • 6.
    PREVIOUS SECTION CONTENTS SEARCH NEXT COYOTE GLC (Ground Level Closure) ® Fiber Organization Selection Buffer Tube and Unitube/Ribbon Organizer (F1) F1 • Ideal for traditional single fusion or mass fusion/ ribbon splicing • Patented segmented end plate allows for cables to be added without disrupting previously • Accommodates up to 96ct buffer tube cable installed cables or 144ct unitube/ribbon cable measuring .60" • Provided with 4 port end plate (15.2 mm) or smaller • 7 port end plate available upon request • Organizer includes: (1) 4-port end plate with • Adaptable to larger handholes; if greater below universal organizer, (1) gasket, (4) grommets*, ground storage or if larger cable diameters are (4) strength member brackets, (1) LITE-GRIP® required for your application Short Splice Tray for Single Fusion, and miscellaneous hardware *Standard Kit Grommets include (2)8003663 • See Splice Tray Section Chart on pg. 1-8 (1)8003664 (1)8003665 – Custom grommet • Features the latest, easy to use grommet combinations available upon request sealing system Buffer Tube Organizer for Increased Tray and Storage Capacity (F2) F2 • Ideal for traditional single fusion splicing where more expressed buffer tube storage and/or • Patented segmented end plate allows for cables to be added without disrupting previously splice tray capacity is needed installed cables • Accommodates up to 96ct buffer tube cable • Provided with 4 port end plate measuring .60" (15.2 mm) or smaller • 7 port end plate available upon request • Organizer includes: (1) 4-port end plate with • Adaptable to larger handholes; if greater below buffer tube organizer, (1) gasket, (4) grommets*, ground storage or if larger cable diameters are (4) strength member brackets, (1) LITE-GRIP required for your application Short Splice Tray for Single Fusion, and miscellaneous hardware *Standard Kit Grommets include (2)8003663 • See Splice Tray Section Chart on pg. 1-8 (1)8003664 (1)8003665 – Custom grommet • Features the latest, easy to use grommet combinations available upon request sealing system Cross-Connect Organizer for Buffer Tube and Unitube/Ribbon (F3) F3 • Ideal for traditional single fusion or mass fusion/ ribbon splicing where cross-connect capabilities • Features the latest, easy to use grommet sealing system are needed • Patented segmented end plate allows for • Accommodates up to 96ct buffer tube cable cables to be added without disrupting previously or 144ct unitube/ribbon cable measuring .60" installed cables (15.2 mm) or smaller • Provided with 4 port end plate • Organizer includes: (1) 4-port end plate with • 7 port end plate available upon request cross-connect organizer, (1) gasket, (4) • Adaptable to larger handholes; if greater below grommets*, (4) strength member brackets, (1) ground storage or if larger cable diameters are LITE-GRIP Short Splice Tray for Single Fusion, required for your application and miscellaneous hardware • Accommodates up to 4 SC, ST, LC, or FC *Standard Kit Grommets include (2)8003663 adapter plate modules (1)8003664 (1)8003665 – Custom grommet • Can support pre-connectorized splitters combinations available upon request • See Splice Tray Section Chart on pg. 1-8 OptiTap™ Organizer for Buffer Tube and Unitube/Ribbon (F4) F4 • Ideal for traditional single fusion or mass fusion/ ribbon splicing where OptiTap connections • Features the latest, easy to use grommet sealing system might be needed • Patented segmented end plate allows for cables • Accommodates up to 96ct buffer tube cable to be added without disrupting previously or 144ct unitube/ribbon cable measuring .60" installed cables (15.2 mm) or smaller • Provided with 4 port end plate • Organizer includes: (1) 4-port end plate with • Adaptable to larger handholes; if greater below OptiTap organizer and shroud, (1) gasket, (4) ground storage or if larger cable diameters are grommets*, (4) strength member brackets, (1) required for your application LITE-GRIP Short Splice Tray for Single Fusion, and miscellaneous hardware *Standard Kit Grommets include (2)8003663 • Accommodates up to 8 OptiTap adapters (1)8003664 (1)8003665 – Custom grommet • Can support pre-connectorized splitters combinations available upon request 1-6 • See Splice Tray Section Chart on pg. 1-8
  • 7.
    PREVIOUS SECTION CONTENTS SEARCH NEXT COYOTE® Closure Series: Section 1 COYOTE GLC (Ground Level Closure) ® (Ground Level Closure) COYOTE® GLC Spacer Selection Standard Spacer (S1) • Ideal for adjusting the GLC base height to ground level during S1 the back filling process of the installation of the base • Split design allows for installation/replacement without disrupting previously installed GLC components • Can be stacked to achieve desired base height • Each spacer increases the base height by 3" (7.6 cm) • Standard Spacer Kit includes: (2) standard spacer halves, (4) spacer studs, and (2) self tapping bolts Grounding Spacer (S2) • Ideal for isolated ground testing without having to re-enter the splice enclosure S2 • Provides up to 7 isolated ground connections • Removable access plate on spacer exterior conceals grounding plate • Screw-on terminal head for #6 ground wire allows for quick connection to grounding plate • 2.5 ft (76.2 cm) flexible ground leads make connecting ground studs of splice enclosure to the grounding plate in spacer easy • Easily removable busbar permits quick ground isolation • Split design allows for installation/replacement without disrupting previously installed GLC components • Can be stacked on top of multiple standard spacers (S1) to achieve desired base height • Grounding spacer increases the base height by 3" (7.6 cm) • Grounding Spacer Kit includes: (1) standard spacer half, (1) grounding spacer half, (1) removable access plate, (1) grounding plate, (1) removable buss bar, (4) ground leads, (1) screw-on terminal head (4) spacer studs, and (2) self tapping bolts Dual Grounding Spacer (S3) • Includes all the features and benefits as a standard grounding spacer (S2) S3 • Provides up to 14 isolated ground connections • Removable access plates on spacer exterior conceal grounging plates • Screw on terminal head for #6 ground wire allows for quick connection to grounding plate • Dual Grounding Spacer Kit includes: (2) grounding spacer halves, (2) removable access plates, (2) ground- ing plates, (2) removable buss bars, (8) ground leads, (2) screw-on terminal heads (4) spacer studs, and (2) self tapping bolts 1-7
  • 8.
    PREVIOUS SECTION CONTENTS SEARCH NEXT COYOTE GLC (Ground Level Closure) ® Grommet Selection Accessory Selection Catalog Cable Range Catalog Description Grommets Description Accessory Number Inches (mm) Number .40 - .60 1-hole 8003691 80809005 Dome (10.7 - 15.2) grommet .42 - .60 2-hole 80809006 Dome Collar 8003663 (10.7 - 15.2) grommet .50 - .60 (12.7 - 15.2) 80809775 Dome Gasket 4-hole 8003990 .125 - .25 (3.2 - 6.4) grommet and Flat Drop Dome Collar 80809793 .30 - .43 4-hole Lock Assembly 8003664 (7.6 - 10.9) grommet 80809781 Cover Kit .125 - .25 6-hole 8003665 (3.2 - 6.4) grommet and Flat Drop 42" Base Retention Stake 80809788 .42 - .60 (10.7 - 15.2) with Anchor Plate 7-hole 8003676 .125 - .25 (3.2 - 6.4) grommet and Flat Drop Base Retention Stake 80809791 .125 - .25 Driver Cap 8-hole 8003677 (3.3 - 6.4) grommet LITE-GRIP Splice Blocks ® and Flat Drop LGSBS8-5 for Single Fusion (Yellow) - 5 splice blocks Flat Drop 4-hole 8003989 Cable Only grommet LITE-GRIP Splice Blocks for LGSBR3-5 Mass Fusion/Ribbon (Purple) - 5 splice blocks Flat Drop 12-hole 8003796 Cable Only grommet COYOTE ® 800013213 Cross-Connect Tray Express Fiber Storage Ring 80808613 Splice Tray Selection for LITE-GRIP Splice Tray GLC Fiber Parking Lot for Organizer 80808817 Cross-Connect Organizer – Reference Holds 6 Connectors Splice Code Catalog Count/ Splice CORNING OptiTap TM Number Type Description Tray F1 F2 F3 F4 80808152 Adapter 16 Single LITE-GRIP® LGSTS16 2 6 2 2 Fusion Short Tray 80807972 OptiTap Installation Tool 40 Single LITE-GRIP 80808945 2 6 2 2 Fusion Short Tray 80809766 Shield Connector 144 Mass LITE-GRIP LGSTR144 Fusion/ 2 6 2 2 Contact PLP Short Tray COYOTE PLC Splitter Ribbon for details 12 Single 80806033 Standard 3 8 3 3 Contact PLP Fusion Adapter Modules for details 12 Single 80807701 Low Profile 4 13 4 4 Fusion Contact PLP Pigtail Cable Assemblies for details Contact PLP Optical Drop Cable for details Assembly 1-8
  • 9.
    PREVIOUS SECTION CONTENTS SEARCH NEXT COYOTE® Closure Series: Section 1 COYOTE Dome Closure ® Dome Closure COYOTE® Evolution of the Breed Continues… ■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■ The COYOTE Dome PLP Feature Focus RUS ©2009 Preformed Line Products Closure Family has ■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■ increased in size! The new 9.5" x 28" High LISTED Film available at www.preformed.com Capacity Dome Closure is available in three COYOTE Dome Closure Kits different configurations Catalog and can also be used Number Description with 9.5" Ar madillo 8006944 6.5" x 17" COYOTE Dome for Buffer Tube (Loose Tube) Stainless shells, further 8006945 6.5" x 17" COYOTE Dome for Ribbon expanding the possibilities to address your network needs. 800012587 6.5" x 17" COYOTE Dome for Ribbon – Expanded Storage The innovative, segmented end plate design in the new 9.5" diameter offers 7 cable entrance ports capable of accepting 8006988 6.5" x 17" COYOTE Dome Express (Loose Tube) cables with a maximum diameter of 1.25" (32 mm).The unique 6.5" x 17" COYOTE Dome Cross-Connect (Empty) 800012185 (Loose Tube) design allows each cable entrance to be accessed without disruption to the surrounding cables. The new end plate 800012940 6.5" x 17" COYOTE Dome Flame Retardant (Ribbon) accepts the full line of multi-hole grommets designed to 800012941 6.5" x 17" COYOTE Dome Flame Retardant (Loose Tube) ensure the ultimate flexibility and high capacity to meet the 800012942 6.5" x 22" COYOTE Dome Flame Retardant (Loose Tube) demands of ever evolving communication networks. 800012943 6.5" x 22" COYOTE Dome Flame Retardant 8006877 6.5" x 22" COYOTE Dome for Buffer Tube (Loose Tube) The COYOTE Dome Closure was built from the ground up 800012606 6.5" x 22" COYOTE Dome for Copper using the same craft-friendly fiber management technology 8006878 6.5" x 22" COYOTE Dome for Ribbon that placed the COYOTE family among the most respected 800012441 6.5" x 22" COYOTE Dome for Ribbon – Expanded Storage and reliable in the industry. Re-entry is quick and requires no 8006946 6.5" x 22" COYOTE Dome Express (Loose Tube) special tools or re-entry kits. Both the 6.5" and 9.5" designs 6.5" x 22" COYOTE Dome Cross-Connect (Empty) are also convertible to closure shells for in-line applications or 800012184 (Loose Tube) to provide additional drop capacity. For connectivity solutions, 8006879 6.5" x 28" COYOTE Inline Dome for Buffer Tube (Loose Tube) the COYOTE Dome closures are also available in cross- 8006880 6.5" x 28" COYOTE Inline Dome for Ribbon connect configurations. By combining these features with a wide offering of splice trays and accessories, PLP has the 80061055 9.5" x 28" COYOTE Dome for Buffer Tube (Loose Tube) ability to address virtually any network design. 80061056 9.5" x 28" COYOTE Dome for Ribbon 80061057 9.5" x 28" COYOTE Dome for High Capacity (Max Tray Count) The COYOTE Dome Closure is tested in accordance with the demanding requirements of the Telcordia GR-771-CORE Mounting Hardware And Accessory Kits specification for all aerial, buried and underground environ- Catalog ments. Manufactured in accordance with ISO9001:2008 Number Description procedures to assure quality and backed by the experience 8003681 End Plate Kit – 6.5" Dome and field support that PLP has been noted for since 1947 . 8003839 End Plate Kit – 9.5" Dome 80807383 Hardware Bag for End Plate Key Features: 80808651 Extended Strength Member Bracket Kit • Available Sizes: 6.5" x 17" (17cm x 43cm), 80808878 Large Strength Member Adapter Kit 6.5" x 22" (17cm x 56cm), 9.5" x 28" (24cm x 71cm) 80807848 End Plate Gasket – 6.5" Dome • Patented segmented End Plate design provides indepen- 80808426 End Plate Gasket – 9.5" Dome dent access to every cable 80808456 End Plate Assembly Fixture – 6.5" or 9.5" Dome • 6.5" End Plate: 4 entry ports accepting max cable 8003702 Pole / Wall Mount Bracket – 6.5" Dome diameter of 1-1/4" (32mm) Aerial Hanger Bracket – Dome Mount 8003831 • 9.5" End Plate: 7 entry ports accepting max cable (Strand Mount) – 6.5" Dome diameter of 1-1/4" (32mm) 8003707 Swing Arm for Hand Holes – 6.5" Dome • Fiber Organizers and End Plates come fully assembled 8003835 Universal Mounting Bracket Kit for Hand Holes – 6.5" Dome – minimizing the parts to handle 8003942 Pole / Wall Mount Bracket – 9.5" Dome • Simple to use multi hole and single hole grommets 8003941 Aerial Hanger Bracket – End Plate Mount – 9.5" Dome provide the ability to support high drop capacities 8003940 Aerial Hanger Bracket – Dome Mount – 9.5" Dome • No special tools or torque wrenches required for installation Maximum splice capacities are calculated by multiply- • Collar system allows for quick re-entry ing the maximum tray quantity per closure by the • Tested in accordance to Telcordia GR-771 CORE maximum splice capacity per splice tray. Achieving the maximum splice capacity for each closure may • Accepts a wide variety of PLP splice trays require adjustments to the volume of fiber stored • Patented End Plate Design within the fiber organizers. Contact a PLP represen- tative to discuss the details of achieving the maximum • RUS listed capacities for your installation. 1-9
  • 10.
    PREVIOUS SECTION CONTENTS SEARCH NEXT COYOTE In-Line RUNT Closure ® Evolution of the Breed Continues… COYOTE IN-LINE RUNT Closure Kits Catalog Number Description 8006951 Hermetically Sealed 8006952 Free Breathing 80061004 Express, Hermetically Sealed 80061049 Flame Retardant Hermetically Sealed COYOTE IN-LINE RUNT Accessories Catalog Number Description Splice Tray Kits 12 Count Low Profile Tray w/plastic splice block – 80807701 single fusion splices 12 Count Standard Tray w/Elastomeric splice block 80806033 – single fusion & mechanical fusion 16/40* Count Tray w/LITE-GRIP® splice blocks for LGSTS16 single fusion splice 144/180* Count Tray w/LITE-GRIP splice blocks for LGSTR144 ribbon splices 24 Count Low Profile Tray w/plastic splice blocks for 8003468 single fusion splices Versatile NOTE: Requires 8003757 Tray Conversion Kit 72 Count Ribbon Tray w/Elastomeric Splice Block for The COYOTE® In-Line RUNT Closure has the versatility and 80807114 Mass Fusion features that make it a perfect choice for distribution and Cover Kit fiber to the premise networks. The compact size allows the 8003719 COYOTE In-Line RUNT Cover Kit closure to be installed into pedestals and small hand holes, keeping your installation costs down. High drop capacity and Miscellaneous Accessory Kits the capability to be converted to a terminal closure will allow 8003733 End Plate Kit room for expansion long after the initial installation. 80807794 Hardware Bag 8003713 Express Brackets Rugged and Reliable 8003757 24 Count, Low Profile Splice Tray Conversion Kit The COYOTE In-Line RUNT Closure is tested in accordance 80807571 Spiral Tube Kit; 6' Length with the demanding requirements of Telcordia GR-771- Transport Tube Kit .135" ID; includes (6) 34" long 80805293 transport tubes CORE for all aerial, buried and underground environments. Manufactured in accordance with ISO 9001:2008 proce- Transport Tube Kit .25" ID; kit includes (3) 6' 80808639 transport tubes dures and backed by the experience and field support that 80807989 Transport Tube 100' reel 0.170" ID PLP has been noted for since 1947. 80807991 Transport Tube 100' reel 0.25" ID 8003862 Fiber Organizer Kit for Ribbon Applications Key Features: Mounting Hardware Kits • Compact Size: 17.5" L x 10" W x 3.5" H 8003703 Pole/Wall Mount Bracket (44 cm x 25 cm x 9 cm) 8003797 Aerial Hanger Bracket • High drop capacity – See grommet chart 8003706 Swing Arm for Hand Holes • 4 entry ports, each accept 1-1/4" maximum cable diameter Pedestal Mounting Bracket for Emerson PRO12 8003714 • Hermetically sealed, free breathing, express and flame Pedestal PLP Fiber Optic Products retardant configurations available Universal Mounting Bracket Kit for Handhole 8003835 • Quick and easy assembly – no special tools required Applications • Simple-to-use grommet sealing system • Hinged cover reduces number of parts required upon Capacities re-entry Splice Tray Splices Trays per Splice Depth Description per tray Closure capacity • Internal organizer manages buffer tube or ribbon cable Low Profile Single Fusion 12 4 48 • Integrated air valve to test assembly seal Single Fusion or • Convertible to a COYOTE Terminal Closure with available Standard 12 2 24 Mechanical cover kits – request COYOTE Terminal brochure Ribbon Mass Fusion 72 2 144 • Full line of mounting hardware available *50% more storage for midsheath (express) applications, but 50% less splice capacity • Tested in accordance to Telcordia GR-771-CORE 1-10 • RUS Listed
  • 11.
    PREVIOUS SECTION CONTENTS SEARCH NEXT COYOTE® Closure Series: Section 1 COYOTE Terminal Closure (Dual Chamber) ® Terminal Closure COYOTE® Evolution of the Breed Continues… The COYOTE Terminal Closure (Dual Chamber) is the choice for network designs requiring ultimate flexibility. The unique dual chamber design provides two distinct chambers that can be configured differently to support externally mounted OptiTap™ style hardened adaptors, internally mounted cross-connect bulkhead connections or a combi- nation of both. A window designed within the closure inte- rior allows fibers to be passed between chambers. High drop capacity from each of the eight cable ports and the ability to use standard or hardened adapter covers, provides infinite options to support your network design. Terminal Closure (Dual Chamber) with hardened adaptors Key Features: • Compact Size: 17.5" L x 10" W x 12" H (44 cm x 25 cm x 30 cm) • Accepts up to 24 hardened adapters • Eight Entry ports each accept 1-1/4" maximum cable diameter • High drop capacity – 8 through each port • Available in hermetically sealed, free breathing and express configurations • Quick and easy assembly – no special tools required • Simple to use grommet sealing system Terminal Closure (Dual Chamber) with hardened • Provided standard with SC/APC pigtails adaptors installed in both covers • Capability to field install or remove hardened adapter assemblies • Internal organizer manages buffer tube or ribbon cable • Integrated air valve provides field flash test point • Full line of hardware available for strand, pole and hand-hole installations • Tested in accordance to Telcordia GR-771 CORE • RUS Listed Splice Compartment – Terminal Closure (Dual Chamber) with Internal Bulkhead Drop Cable Chamber – Terminal Closure (Dual Chamber) with Internal Bulkhead 1-11 *OptiTap™ is a trademark of Corning Cable Systems
  • 12.
    PREVIOUS SECTION CONTENTS SEARCH NEXT COYOTE Terminal Closure (Single Chamber) ® Evolution of the Breed Continues… The COYOTE Terminal Closure (Single Chamber) is the ideal choice for network designs requiring hardened adapter termination. Externally mounted OptiTap* style hardened adapters allow for future installation of up to 12 hardened drops without closure reentry. Compact size allows the closure to be installed into pedestals and small hand holes. Additional drop capacity through the four entry ports of the closure base, provide added flexibility for the closure to act as a distribution point for closures deeper in your network. Key Features: • Compact Size: 17.5" L x 10" W x 6" H (44 cm x 25 cm x 15 cm) Outside View – Terminal Closure (Single Chamber) • Accepts up to 12 hardened adapters • Four Entry ports each accept 1¼" maximum cable diameter • High drop capacity – 8 through each port • Available in hermetically sealed, free breathing and express configurations • Quick and easy assembly – no special tools required • Simple to use grommet sealing system • Provided standard with SC/APC pigtails • Port identification numbers to simplify assembly • Capability to field install or remove hardened adapter assemblies • Internal organizer manages buffer tube or ribbon cable • Integrated air valve provides field flash test point End Plate with Distribution Cable and 6-port Drop Cable Grommet • Full line of hardware available for strand, pedestal, pole and hand-hole installations • Tested in accordance to Telcordia GR-771 CORE • RUS Listed Inside View – Terminal Closure (Single Chamber) Drop wire with mating connectors for terminal are available in various lengths. Contact your local PLP representative or customer service for more details. 1-12 *OptiTap™ is a trademark of Corning Cable Systems
  • 13.
    PREVIOUS SECTION CONTENTS SEARCH NEXT COYOTE® Closure Series: Section 1 COYOTE Terminal Closure ® Terminal Closure COYOTE® Evolution of the Breed Continues… Installation of Hardened COYOTE Terminal Connectors Closure – Hand Hole Application COYOTE Terminal Closure – Pedestal Application Coyote Terminal Closure Kits Catalog Chamber Adapter Plug Cover Type Number Description Type Qty Qty Terminal Standard 800012002 COYOTE Terminal Closure – 2 Port Single 2 4 1 0 8006993 COYOTE Terminal Closure – 3 Port Single 3 3 1 0 8006953 COYOTE Terminal Closure – 4 Port Single 4 2 1 0 8006954 COYOTE Terminal Closure – 6 Port Single 6 0 1 0 8006955 COYOTE Terminal Closure – 8 Port Single 8 1 1 0 800012003 COYOTE Terminal Closure – 9 Port Single 9 0 1 0 80061067 COYOTE Terminal Closure – 12 Port Single 12 0 1 0 80061029 COYOTE Terminal Dual Chamber – 6 Port Dual 6 0 1 1 8006991 COYOTE Terminal Dual Chamber – 8 Port Dual 8 1 1 1 800012140 COYOTE Terminal Dual Chamber – 9 Port Dual 9 0 1 1 80061030 COYOTE Terminal Dual Chamber – 10 Port Dual 10 2 2 0 800011830 COYOTE Terminal Dual Chamber – 12 Port Dual 12 0 2 0 800012605 COYOTE Terminal Dual Chamber – 24 Port Dual 24 0 2 0 800011839 COYOTE Terminal Dual Chamber – EMPTY Dual 0 0 0 2 8006956 COYOTE Terminal Closure w/6 SCAPC Internal Bulkhead Dual 0 0 0 2 Terminal includes SC/AP Adapters and (1) Splice Tray 1-13
  • 14.
    PREVIOUS SECTION CONTENTS SEARCH NEXT COYOTE Terminal Closure ® COYOTE In-line RUNT & Terminal Closure Accessories Terminal Catalog In-Line Single Dual Number Description RUNT Chamber Chamber Splice Tray Kits 80807701 12 Count Low Profile Tray w/plastic splice block – single fusion splices X X X 80807531 12 Count Low Profile Tray (Blank) – no splice block X X X 80806033 12 Count Standard Tray w/elastomeric splice block – fusion & mechanical splices X X X 80806182 12 Count Standard Tray (Blank) – no splice X X X 80807114 72 Count Ribbon Tray w/elastomeric splice block for mass fusion X X X 80808160 Ribbon Tray (Blank) – no splice block X X X LGSTS16 16/40* Count LITE-GRIP® Tray (Short) for single fusion X X X LGSTR144 144/180* Count LITE-GRIP Tray (Short) for Ribbon X X X *Requires additional LITE-GRIP Splice Block kit for enhanced capacity Cover Kits 8003719 COYOTE In-Line RUNT Cover Kit* X X X 8003742 COYOTE Terminal Closure Cover Kit 2-Port with Hardened Adapters X X X 8003739 COYOTE Terminal Closure Cover Kit 3-Port with Hardened Adapters X X X 8003720 COYOTE Terminal Closure Cover Kit 4-Port with Hardened Adapters X X X 8003721 COYOTE Terminal Closure Cover Kit 6-Port with Hardened Adapters X X X 8003722 COYOTE Terminal Closure Cover Kit 8-Port with Hardened Adapters X X X 8003735 COYOTE Terminal Closure Cover Kit 9-Port with Hardened Adapters X X X 8003810 COYOTE Terminal Closure Cover Kit 12-Port with Hardened Adapters X X X Adapter Accessory Kits 8003715* Hardened Adapter Kit – Field Installable – Includes 80807972 X X 8003724* Port Plug Kit-Field Installable – Includes 80807972 X X 80807972 Hardened Adapter Installation Tool X X 80808157 Fiber Optic Pigtail Kit (2-Pigtails) X X 80807939 Fiber Optic Pigtail Kit (3-Pigtails) X X 80807806 Fiber Optic Pigtail Kit (4-Pigtails) X X 80807807 Fiber Optic Pigtail Kit (6-Pigtails) X X 80807808 Fiber Optic Pigtail Kit (8-Pigtails) X X 80808158 Fiber Optic Pigtail Kit (9-Pigtails) X X 80808700 Fiber Optic Pigtail Kit (12-pigtails) X X Miscellaneous Accessory Kits 8003733 End Plate Kit X X X 80807794 Hardware bag X X X 80807972 Adapter Installation Tool X X Transport Tube Kit .135" ID: includes six 34" long transPort with Hardened 80805293 X X X Adapters tubes, used to bring fiber from transition compartment to splice tray Transport Tube Kit .25" ID: includes six 34" long transPort with Hardened Adapters 80806439 X X X tubes, used to bring fiber from transition compartment to splice tray 80807989 Transport Tube 100' coil 0.135" ID X X X 80807991 Transport Tube 100' coil 0.25" ID X X X Mounting Hardware Kits 8003713 Express Bracket Kit X X X Pole/Wall mount bracket kit for In-Line RUNT and Terminal 8003703 X X X (Standard and Dual Chamber) 8003704 Aerial Hanging Bracket Kit for COYOTE In-Line RUNT and Terminal Closure X X 8003705 Aerial Hanging Bracket Kit for COYOTE Terminal Dual Chamber X 8003706 Swing Arm Bracket for COYOTE In-Line RUNT and Terminal Closures X X X Pedestal Mounting Bracket for COYOTE In-Line RUNT and Terminal Closure 8003714 X X (Emerson PRO12 Pedestal) *Hardened Adapter Kit or Plug kit can only be used with terminal closure covers 1-14
  • 15.
    PREVIOUS SECTION CONTENTS SEARCH NEXT COYOTE® Closure Series: Section 1 COYOTE Aerial Drop Closure ® Aerial Drop Closure COYOTE® A Simple Solution, a Breed Apart The COYOTE® Aerial Drop Closure Kit Components Key Features: COYOTE Aerial Fiber Drop Closure Kits • Compact Size – 9” W x 16.5” L x 2.5” D Catalog • Feature rich and value priced solution Number Description • Easy to install – no special tools required COYOTE Aerial Fiber Drop Closure Kit COYDAC03 Includes: Cover, Base and components • Easy-to-use grommet sealing system shown above • Includes splicing platform COYOTE Splice Platform Kits • Accepts 2 splice platforms for a splice capacity Splice Plate Kit – 12 Count Splice Block – of 24 fibers 8003792 Single Fusion • Capable of higher splice capacities with alternative Splice Plate Kit – 12 Count Splice Block – 8003751 splice holders. Consult a PLP representative for details. Unprotected Single Fusion • Includes universal mounting bracket with features to Splice Plate Kit – 24 Count LITE-GRIP Splice 8003793 permit pole mounting with straps, strand mounting with Block – Single Fusion strand clamps or suspension from “J” hooks secured Splice Plate Kit – 72 Count LITE-GRIP Splice 8003794 to a pole Block – Ribbon COYOTE Aerial Fiber Drop Accessory Kits PLP Reliability 80808256 12 Entry Grommet Kit with Bobbin End Plate Kit – includes (2) End Plates, The COYOTE Fiber Optic Aerial Drop Closure is manufac- 8003753 Bolts and Tether tured in accordance with ISO 9001-2008 procedures to Strength Member Bracket Kit for Single assure quality and is backed by the experience and field 8003777 Cable Entry support that Preformed Line Products has been noted for 80808257 Fiber Organizer Clip Kit in fiber optic closures for over 20 years. 8003775 Hanger Bracket Kit 1-15
  • 16.
    PREVIOUS SECTION CONTENTS SEARCH NEXT COYOTE LCC (Low Count Closure) ® Maximum Flexibility in a Small Package RUS ■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■ PLP Feature Focus ©2009 Preformed Line Products LISTED ■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■ Film available at www.preformed.com Grommets 8003796 12 Hole 8003691 1 Hole 8003692 1 Hole 8003693 1 Hole 8003694 1 Hole 8003663 2 Hole 8003990 4 Hole 8003664 4 Hole 8003665 6 Hole 8003677 8 Hole 8003989 4 Hole 8003676 7 Hole Splice Type* L Bracket Bobbin COYOTE LCC and COYOTE LCC Flame Retardant Kits for Fiber Catalog Number COYLCC-F001 S 2 1 1 COYLCC-F002 S 1 2 1 1 Every splice location, regardless of the FTTX Architecture, COYLCC-F003 R 2 2 must be protected from the elements to provide the maximum COYLCC-F004 S 2 2 reliability your customers expect. The new COYOTE LCC COYLCC-F005 S 2 2 (Low Count Closure) is the latest edition to the COYOTE COYLCC-F006 S 2 2 Fiber Optics product line for your Fiber to the Home, Node, COYLCC-F007 S 2 1 1 or Curb deployment. COYLCC-F008 S 2 1 1 The Closure’s compact size, use of the versatile grommet COYLCC-F009 S 2 2 system and internal LITE-GRIP® Splice Platform are COYLCC-F010 1 1 designed to make this rugged closure the economical choice COYOTE LCC Kits for Copper for new installations and critical repair situations. Kits have COYLCC-C001 C 2 also been created to support copper applications. The COYLCC-C002 C 2 COYOTE LCC for Copper will support up to 25 pair in a butt COYLCC-C003 C 2 application and 50 pair in an In-Line configuration. COYLCC-C004 C 1 1 The COYOTE LCC represents the maximum versatility, COYLCC-C005 C 2 reliability and technical support you’ve come to expect NOTES: from PLP. All COYOTE LCC Kits for Fiber include: (2) grommets, (1) splice platform, (3) splice blocks, (2) cable restraint brackets, lubricant and measure tape Key Features: All COYOTE LCC Kits for Copper include: (2) grommets, (2) MINI-MORAY Shield Connectors, (1) bonding bridge, lubricant and measure tape • Compact Size – 17" L x 7" W x 2.5" D For the COYOTE LCC Flame Retardant catalog numbers, insert “FR” into (43cm x 18cm x 7cm) the catalog number code, Ex.: COYLCCFR-F001. The grommets provided will be the same as • Max Splice Capacity – Single Fusion – 24 splices shown in the chart. • Max Splice Capacity – Ribbon/Mass Fusion – 72 *Splice Type: S = Single Fusion R = Ribbon C = Copper • Capable of Inline or Butt applications • Designed for aerial, below grade or direct buried applications COYOTE LCC Accessories • Same craft friendly grommet system as the COYOTE Catalog Dome Closures Number Description 80808633 Strength Member Bobbin Kit • Flat shape allows for mounting in small areas 8003843 Strength Member L Bracket Kit • Utilizes LITE-GRIP Splice Block System, which permits Splice Platform Kit for Single Fusion – 8003793 single fusion, mass fusion, mechanical, PLC splitters includes 3 splice blocks or a combination of all within one closure 8003794 Splice Platform Kit for Ribbon – includes 2 splice blocks • Quick, easy installation is ideal for drop repair applications LITE-GRIP Splice Block for Single Fusion – accepts LGSBS8-5 • Fire Retardant versions available 8 splice protectors per block – 5 pcs per kit LITE-GRIP Splice Block for Ribbon – accepts 3 • Tested in accordance to TR-NWT-000251 by an LGSBR3-5 mass fusion protectors per block – 5 pcs per kit 1-16 independent outside lab • RUS listed
  • 17.
    PREVIOUS SECTION CONTENTS SEARCH NEXT COYOTE® Closure Series: Section 1 COYOTE LCC (Low Count Closure) ® (Low Count Closure) COYOTE® LCC COYOTE LCC Installation Options Part Number Application Type and Description 8003832 Aerial Aerial Mounting Bracket (Strand Mount) 8003830 Pole/Wall Mount Pole/Wall Mount Bracket Kit 8003835 Below Grade Large Vault/Hand Hole Universal Mounting Bracket Kit for Hand Hole Applications COYOTE LCC: COYLCC-XXXX Below Grade COYOTE GLC Base Small Hand Hole COYGLC-C1-000 Butt Applications Only For small drop and flat drop applications only Direct Buried No Mounting Brackets Needed COYOTE LCC Custom for Coax Contact PLP for Details COYOTE LCC Custom Cross-Connect Contact PLP for Details COYOTE LCC Custom with Terminal Block Contact PLP for Details 1-17
  • 18.
    PREVIOUS SECTION CONTENTS SEARCH NEXT COYOTE Long Trays and Closures ® Short Splice Trays & Closures COYOTE COYOTE COYOTE Terminal Terminal 6.5"x17" COYOTE Expanded COYOTE (Single (Dual COYOTE RUNT RUNT In-Line RUNT Chamber) Chamber)2 Dome COYOTE PUP 3 Trays 6 Trays 4 Trays 4 Trays 8 Trays 6 Trays 6 Trays Low Profile Tray1 36 Max 72 Max 48 Max 48 Max 96 Max 72 Max 72 Max (12 splice count) Splice count Splice count Splice count Splice count Splice count Splice count Splice count Cat. # 80807701 (w/splice blocks) or 8001130 (blank) 2 Trays 4 Trays 2 Trays 2 Trays 4 Trays 4 Trays 4 Trays 24 Max 48 Max 24 Max 24 Max 48 Max 48 Max 48 Max Standard Tray Splice count Splice count Splice count Splice count Splice count Splice count Splice count (12 splice count) Cat. # 80806033 (w/splice block) or 80806182 (blank) 1 Tray 2 Trays 2 Trays 2 Trays 4 Trays 3 Trays 2 Trays 72 Max 144 Max 144 Max 144 Max 288 Max 216 Max 144 Max Ribbon Tray Splice count Splice count Splice count Splice count Splice count Splice count Splice count (72 splice count) Cat. # 80807114 (w/splice block) or 80808160 (blank) 1 Tray 2 Trays 2 Trays 2 Trays 4 Trays 3 Trays 2 Trays 40 Max 80 Max 80 Max 80 Max 160 Max 120 Max 80 Max LITE-GRIP ® Splice count Splice count Splice count Splice count Splice count Splice count Splice count Short Tray3 (40 splice count) Cat. # LGSTS16 (Single Fusion) 1 Tray 2 Trays 2 Trays 2 Trays 4 Trays 3 Trays 2 Trays LITE-GRIP 144 Max 216 Max 288 Max 288 Max 576 Max 432 Max 288 Max Short Tray Splice count Splice count4 Splice count Splice count Splice count Splice count Splice count (144 splice count) Cat. # LGSTR144 (Mass Fusion/Ribbon) 1 24 count Low Profile Tray (Cat. # 8003468) is available for COYOTE In-Line, COYOTE Terminal (Single Chamber), & COYOTE Terminal (Dual Cham- ber) closures. Tray Conversion Kit (Cat. # 8003757) is required to use this tray in these closures. 2 The maximum splice count for the COYOTE Terminal (Dual Chamber) requires trays to be installed in both chambers of the closure. 3 Each tray (Cat. # LGSTS16) is provided with splice blocks to support 16 single fusion splices. Splice Block Kit (Cat. # LGSBS8-5) is required for each 1-18 tray to achieve maximum splice count. 4 Capacity is limited by the maximum cable size through the entry ports.
  • 19.
    PREVIOUS SECTION CONTENTS SEARCH NEXT COYOTE® Closure Series: Section 1 COYOTE Long Trays and Closures ® COYOTE Long Trays and Closures ® Long Splice Trays & Closures 6.5"x22" 6.5"x22" 8"x28" 9.5"x28" COYOTE 6.5"x22" 8.5"x22" COYOTE COYOTE COYOTE 9.5"x28" Dome COYOTE COYOTE Splice Case Splice Case Splice Case COYOTE Dome 6 Trays 6 Trays 11 Trays 6 Trays 9 Trays 13 Trays 18 Trays Low Profile Tray 216 Max 216 Max 396 Max 216 Max 324 Max 468 Max 648 Max (36 splice count) Splice count Splice count Splice count Splice count Splice count Splice count Splice count Cat. # 8001127 (w/ plastic splice blocks) or 8001130 (blank) 4 Trays 4 Trays 8 Trays 5 Trays 7 Trays 10 Trays 15 Trays Standard Tray 144 Max 144 Max 288 Max 180 Max 252 Max 360 Max 540 Max (36 splice count) Splice count Splice count Splice count Splice count Splice count Splice count Splice count Cat. # 80805514 (w/ elastomer splice block), 80805110 (w/ rigid slots), or 80805509 (blank) 3 Trays 2 Trays 4 Trays 2 Trays 5 Trays 6 Trays 6 Trays Ribbon Tray 432 Max 288 Max 576 Max 288 Max 720 Max 864 Max 864 Max (144 splice count) Splice count Splice count Splice count Splice count Splice count Splice count Splice count Cat. # 80805515 (w/ elastomer splice blocks), 80805146 (w/ rigid slots), or 80805510 (blank) 3 Trays 5 Trays 2 Trays 5 Trays 6 Trays 9 Trays Not 240 Max 400 Max 160 Max 400 Max 480 Max 720 Max LITE-GRIP® Applicable Splice count Splice count Splice count Splice count Splice count Splice count Long Tray1 (80 splice count) Cat. # LGSTS40 (Single Fusion) 3 Trays 5 Trays 2 Trays 5 Trays 6 Trays 6 Trays Not LITE-GRIP 648 Max 1,080 Max 432 Max 1,080 Max 1,296 Max 1,296 Max Applicable Long Tray Splice count Splice count Splice count Splice count Splice count Splice count (216 splice count) Cat. # LGSTR216 (Mass Fusion/ Ribbon) 1 Each tray (Cat. # LGSTS40) is provided with splice blocks to support 40 single fusion splices. Splice Block Kit (Cat. # LGSBS8-5) is required for each tray to achieve maximum splice count. 2 Each tray (Cat.# LGSTS40) is provided with splice blocks to support 40 single fusion splices. Splice block kit (Cat. # LGSBS8-5) is required for each tray to achieve maximum splice count. 1-19
  • 20.
    PREVIOUS SECTION CONTENTS SEARCH NEXT COYOTE Silicone Grommet Kits ® ■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■ PLP Feature Focus ©2009 Preformed Line Products ■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■ Film available at www.preformed.com COYOTE® Silicone Grommet Kits for use in COYOTE GLC, LCC, Aerial Drop, In-Line RUNT, Terminal, Dome and Taut Closures Catalog Cable Range Description Grommets Number Inches (mm) .42 - .60 (10.7 - 15.2) 8003701* 2-hole grommet .60 - .85 (15.2 - 21.6) 8003691 .40 - .60 (10.7 - 15.2) 1-hole grommet 8003692 .60 - .85 (15.2 - 21.6) 1-hole grommet 8003693 .85 - 1.0 (21.6 - 25.4) 1-hole grommet 8003694 1.0 - 1.25 (25.4 - 31.6) 1-hole grommet 8003663 .42 - .60 (10.7 - 15.2) 2-hole grommet .50 - .60 (12.7 - 15.2) 8003990 .125 - .25 (3.2 - 6.4) 4-hole grommet and Flat Drop 8003664 .30 - .43 (7.6 - 10.9) 4-hole grommet 8003989 Flat Drop Only 4-hole grommet .125 - .25 (3.2 - 6.4) 8003665 6-hole grommet and Flat Drop .42 - .60 (10.7 - 15.2) 8003676 .125 - .25 (3.2 - 6.4) 7-hole grommet and Flat Drop .125 - .25 (3.3 - 6.4) 8003677 8-hole grommet and Flat Drop 8003796 Flat Drop Only 12-hole grommet Note: Grommet Kit contains (1) Grommet, (1) Cable Measure Tape, (2) Silicone Lubricant Packs, (1) Set of Plugs (where applicable) 1-20 *8003701 is not recommended for 9.5" Dome and GLC Closures
  • 21.
    PREVIOUS SECTION CONTENTS SEARCH NEXT COYOTE® Closure Series: Section 1 COYOTE DTC (Drop Termination Closure) ® (Drop Termination Closure) COYOTE® DTC Ease of Use Just Got Easier! Versatile, compact and quick to install are the words most commonly used to describe the new COYOTE DTC (Drop Termination Closure). This new closure design is con- structed to support butt or inline low count splice applica- tions in a direct buried or below grade environment and pole/wall mounted applications near the end of your net- work. The closures’ compact size and rugged exterior allow for installation in tight spaces without compromising functionality. Four corner entrance ports provide the in- staller the flexibility to quickly configure the closure as needed. The cover of the two piece design contains a factory installed gasket and is able to be quickly snapped onto the base during assembly. No fasteners to tighten or torque. With the capacity to support up to 16 single fusion splices or multiple ribbon splices, it will quickly become the closure you will want to have on hand. The COYOTE DTC, another example of the quality, versatility and in- novation you’ve come to expect from PLP. Key Features: • Compact Size: 7.25" x 7.75" x 1.75" (18.4 x 19.7 x 4.4 cm) • Quick to assemble. No tools required for assembly • Flexible sealing technology supports a wide range of flat or round cable profiles • Can be used in combination with the COYOTE GLC (Cat No: COYGLC-C1-000) Base. Provides a cost effective solution for below grade customer drop applications. • Designed for direct buried, below grade, pole/wall mount or aerial applications • Re-enterable and re-usable* • Capable of Inline or Butt applications • Max Splice Capacity – 16 single fusion • Max Splice Capacity – (3) 12 fiber ribbons • Flat shape allows for mounting in small areas • Utilizes the LITE-GRIP Splice Block System which permits single fusion, mass fusion, mechanical, PLC splitters or a combination of all within one closure. *The COYOTE DTC is designed to be a secure closure. If re-entry and re-use is required you must use the COYOTE DTC Cover Removal Tool (PN: 80809842). An alternative method for removal is to cut features on the base to remove the cover. This approach does not permit re-use of the base. COYOTE DTC Closure Kits Catalog Number Description COYOTE DTC Kit Includes: Closure Assembly with (4) port COYDTC-001 sealing grommets (2) single fusion and (1) Ribbon LITE-GRIP Splice Blocks, (4) cable retention clips and (2) fiber organizer clips Accessory Kits 80809842 Cover removal tool 1-21
  • 22.
    PREVIOUS SECTION CONTENTS SEARCH NEXT COYOTE Taut Closure ® Refinement of the Breed… A single closure that simplifies branch cable taps or repairs of taut fiber optic cables. The 6.5" x 38" (165 x 965 mm) COYOTE Taut Closure organizes and protects up to 12 branch splices in either or both directions, or up to 12 pairs of fiber splices for repairing damaged cable. The end plates are the same innovative design used in the COYOTE Dome Closure and employ the easy-to-use grommet system which can also be used in the COYOTE Taut Closure. The unique mainframe assembly protects the fibers being “expressed” through the closure and organizes the splices on those fibers being spliced to the branch cables. Slack fibers from the branch cables or slack fibers between repair splices are stored in the center region of the mainframe. Catalog The entire splice is protected by our rugged plastic Number Description COYOTE shells. 6.5" x 38" (165 x 965 mm) COYOTE Taut 8006947 Closure Kit 1-22
  • 23.
    PREVIOUS SECTION CONTENTS SEARCH NEXT COYOTE® Closure Series: Section 1 COYOTE RUNT Closure ® RUNT Closure COYOTE® Refinement of the Breed… COYOTE RUNT & Expanded COYOTE RUNT Closure Catalog Number Description COYOTE RUNT Closure Kits COYOTE RUNT Closure Kit, Includes LOCK-TAPE™ 8006671 Sealant, Bond Brackets and transport tubing Expanded COYOTE RUNT Closure Kit, Includes 8006794 LOCK-TAPE Sealant, Bond Brackets and transport tubing RUS Listed COYOTE RUNT Closure Kit, 8006692 Includes LOCK-TAPE Sealant, Bond Brackets COYOTE RUNT Closures and transport tubing 800011397 COYOTE RUNT Closure for Copper Application The COYOTE RUNT Closure was specifically designed for fiber distribution networks. The small compact size of the 8006916 Expanded COYOTE RUNT Cross Connect COYOTE RUNT Closures make them an ideal fit for Splice Tray Kits smaller hand holes and pedestals in the last fiber mile. 12 Count Low Profile Tray w/plastic splice block 80807701 – single fusion splices Key Features: 12 Count Standard Tray w/elastomeric splice 80806033 • Compact Size: 14.75" L x 8.5" W x 3" H block – fusion & mechanical splices (37.5cm x 21.6cm x 7.6cm) 72 Count Ribbon Tray w/elastomeric splice block 80807114 • Expanded Size: 14.75" L x 8.5" W x 4.75" H for mass fusion (37.5cm x 21.6cm x 10.8cm) LITE-GRIP® Short Tray for Single Fusion – • Three cable entrance ports (2) 3/4" (19mm) port LGSTS16* Includes (2) LITE-GRIP Splice Blocks for Single and (1) 1" (25mm) port Fusion – Splice Capacity 16 Splices • Size allows for mounting in small pedestals and hand holes LITE-GRIP Short Tray for Ribbon – Includes LGSTR144 • Provided with LOCK-TAPE™ Sealing System (4) LITE-GRIP Splice Blocks • Accepts a wide variety of grommets for multi drop Accessory Kits applications – See grommet chart in COYOTE Closure Future Cable Port Kit. Includes Future Cable Port End Plate and Accessories section 8003407 for 1" port, plug and clamps for installation of • Universal internal organizer allows for loose tube or future cable port during initial assembly ribbon fiber applications Future Cable Port Installation Kit. Includes • Permanent neoprene gasket system requires no 8003291 LOCK-TAPE sealant, bead sealant and L-bracket re-entry kits for preparation of future cable up to 1" in diameter • Future cable ports provide capability for future cable Future Cable Port/Installation kit. Complete kit 8003408 installation without end plate removal includes catalog nos. 8003407 and 8003291 • Standard cover can be replaced with expanded to 80806037 3/4" Plug kit (contains 2 plugs) increase splice capacity 80806038 1" Plug kit (contains 2 plugs) • Express friendly internal organizer features 80806112 Transport tube kit, contains 4 tubes • Integrated air valve to verify integrity of final assembly Shell expansion kit includes Expanded top shell • Full line of mounting hardware 8003574 and longer studs to increase tray capacity • UL Approved and RUS Listed Installation Materials • Tested in accordance to Telcordia GR-771 CORE 80805238 C-Cement, 1 oz. Tube Splice Tray/Closure Capacities 80805925 LOCK-TAPE Sealant, 1" W x 15' L roll Standard RUNT Expanded Runt Bonding Acessories Splices Trays Trays Fiber Optic Shield Connector (1 per kit) Catalog per Per Closure Per Closure 80803989 3M#4460-F/FO Number Description Tray Closure Capacity Closure Capacity 80807701 Single 8003281 External Bonding Clip 12 3 36 6 72 Low Profile Fusion Mounting Hardware Kits Single 8003467 Aerial Hanger Bracket 80806033 Fusion & 12 2 24 4 48 Standard Mechanical 8003470 Manhole Support Bracket 80807114 Mass Fusion 8003523 Wall Mount Bracket 72 1 72 2 144 Ribbon (Ribbon) 8003571 Universal Wall/Pole Mount Bracket LITE-GRIP® *Tray will hold a max of 5 splice blocks for a total splice capacity of LGSTS16* Single 16/40* 1 16/40* 2 33/80* 40 splices Fusion LGSTR144 LITE-GRIP 144/180* 1 144/180* 2 288/360* 1-23 *Requires additional LITE-GRIP splice block kit to reach maximum capacity
  • 24.
    PREVIOUS SECTION CONTENTS SEARCH NEXT COYOTE PUP Closure ® Refinement of the Breed… COYOTE PUP Closure Kits Catalog Number Description COYOTE PUP Closure Kit for Buffer Tube – includes 8006622 (1) 3 section 6 Port End Plate, (1) blank end plate and organizer COYOTE PUP Closure Kit for Unitube – includes (1) 3 8006621 section 6 Port End Plate, (1) blank end plate, transport tube kit and organizer RUS Listed COYOTE PUP Closure Kit for Buffer Tube 8006661 – includes (1) 3 section 6 Port End Plate, (1) blank end plate, organizer and (2) RUS listed shield connectors. COYOTE PUP Closure Kit for Copper Applications with 800011398 6-Port End Plates The COYOTE PUP Closure offers the perfect choice for low COYOTE PUP Closure Kit for Copper Applications with fiber count distribution applications involving butt and inline 800011399 4-Port End Plates installations. The compact size and rugged design allow COYOTE PUP Closure for Buffer Tube Applications the closure to be applied in below grade, aerial and buried 800010515 with 4-Port End Plate installations. Supported by a full line of COYOTE acces- Splice Tray Kits sories, this closure can grow along with your network. 12 Count Low Profile Tray w/plastic splice block – 80807701 single fusion splices Key Features: 12 Count Standard Tray w/elastomeric splice block – • Compact Size: 17" L x 8.6" W x 7.2" H 80806033 fusion & mechanical splices (43.2 cm x 21.9 cm x 18.4 cm) 72 Count Ribbon Tray w/elastomeric splice block for • Two end plate options – 4 Port and 6 Port 80807114 mass fusion – 6 Port provides (4) 7/8" (22mm) ports Mounting Hardware Kits and (2) 3/4" (19mm) ports 8003325 Aerial hanger bracket – 4 Port provides (2) 1-1/4" (32mm) ports and (2) 1" (25mm) ports 8003279 Manhole support bracket • Can be configured for butt or in-line applications 8003372 Pole/wall mount bracket (vertical) • Organizers designed for loose buffer tube and Accessories Kits ribbon applications End Plate See Grommet Chart in COYOTE Closure End Plate • Size allows for mounting in small hand holes Grommets and Accessories Section • Provided with LOCK-TAPE™ Sealing System 80805795 Shell Kit 6" x 17" • Accepts a wide variety of grommets for multi 80805771 Buffer Tube Storage Compartment drop applications 80805775 Unitube Storage (Transition) Compartment • Permanent neoprene gasket system requires 6 Port End Plate Kit, Includes (1) end plate assembly, no re-entry kits 80805105 (1) full set of plugs, and LOCK-TAPE™ Sealing material • Future cable ports provide capability for future cable 4 Port End Plate Kit, Includes (1) end plate assembly, installation, without end plate removal 80805739 (1) full set of plugs, and LOCK-TAPE sealing material • Integrated air valve to confirm integrity of final assembly 80805260 Blank end plate kit • Full line of mounting hardware • UL Approved, RUS Listed Future Cable Port Kit, Includes Future Cable Port for 8003371 7/8" port, plug and clamps for installation of future • Tested in accordance to Telcordia GR-771 CORE cable port during initial assembly Future Cable Installation Kit, includes LOCK-TAPE 8003291 Sealant, bead sealant and L-bracket for preparation of future cable up to .86" in diameter Future Cable Port/Cable Installation Kit. Complete kit 8003289 includes Cat. Nos. 8003289 and 8003291 80806037 3⁄4" Plug Kit (contains 2 plugs) 80806180 7⁄8" Plug Kit (contains 2 plugs) 80806038 1" Plug Kit (contains 2 plugs) Splice Tray/Closure Capacities 80806181 1-1⁄4" Plug Kit (contains 2 plugs) Splice Splices Trays 80805293 Transport Tube Kit (contains 6 tubes) Tray per per Closure Transition Tube Kit, used to transition fibers from top 8003280 Depth Description Tray Closure Capacity section of end plate to the transition compartment Low Profile Single Fusion 12 6 72 8003418 Heat Shield for PUP Closure Single Fusion & Installation Materials Standard 12 4 48 Single Mechanical 80805238 C-Cement, 1 oz. tube 1-24 Ribbon Mass Fusion 72 2 144 80805925 LOCK-TAPE Sealant 1" W x 15" L Roll
  • 25.
    PREVIOUS SECTION CONTENTS SEARCH NEXT COYOTE® Closure Series: Section 1 COYOTE Closure ® COYOTE® Closure Origin of the Species… ■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■ PLP Feature Focus ©2009 Preformed Line Products ■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■ Film available at www.preformed.com PATENTED Size L (cm) W (cm) H (cm) 6.0" x 22" 22" (56) 8-1/2" (22) 7" (18) Setting the bar against which all other fiber closures are measured was no small task for our design team. But years 8.5" x 22" 22" (56) 10-3/4" (27) 9-1/4" (24) of research & development eventually paid off in the form of a rugged and reliable design that has become legend. After over ten years of field use and several hundred thou- sand units sold, the original COYOTE Closure still remains one of the most highly regarded and widely used fiber optic closures in the industry. Key Features: • Available in two sizes – 6.0" x 22" (15cm x 56cm) COYOTE Splice Trays – 8.5" x 22" (22cm x 56cm) • Two end plate options – 4 Port and 6 Port Splice Tray Installation Materials Kits – 6 Port provides (4) 7/8" (22mm) ports Catalog and (2) 3/4" (19mm) ports Number Description – 4 Port provides (2) 1-1/4" (32mm) ports 8003509 60 mm heat shrink splice protector (12 per kit) and (2) 1" (25mm) ports 80808187 40 mm heat shrink protector (12 per kit) • Large splice capacity 8003717 60 mm heat shrink protector (50 per kit) – Up to 396 with single fusion Splice protector (single fusion), NON heat shrink, – UP to 576 with mass fusion 8003092 250/250 micron (20 per kit) • Can be configured for butt or in-line applications Splice protector (mass fusion), NON heat shrink 8003425 • Organizers designed for loose buffer tube and (12 per kit) ribbon applications 8003490 Felt strips 1-1/8" x 9" (6 per kit) • Compact size allows for mounting in smaller locations 8003381 12-Count soft elastomer splice block kit (3 per kit) • Provided with LOCK-TAPE Sealant System Transport tube kit, includes (6) transport tubes 80805293 0.135" I.D. • Accepts a wide variety of grommets for multi Transport tube kit, includes (6) transport tubes drop applications 80806439 0.170" I.D. will contain (6) 12 fiber ribbons • Field proven permanent neoprene gasket system Transport tube kit (bulk) – 100 ft coil of transport 80807989 • No re-entry kits required tube 0.170" I.D. – will contain (6) 12 fiber ribbons • Future cable ports provide capability for future cable Transport tube kit (bulk) – 100 ft coil of transport 80807991 installation, without end plate removal tube 0.250" I.D. – will contain (12) 12 fiber ribbons • Integrated air valve to confirm integrity of final Transport tube kit, color coded, includes 8003285 (6) transport tubes 0.135" I.D. assembly • Full line of mounting hardware • UL Approved and RUS Listed • Tested in accordance to Telcordia GR-771 CORE 1-25
  • 26.
    PREVIOUS SECTION CONTENTS SEARCH NEXT COYOTE Closure ® Splice Tray/Closure Capacities 6.5" x 22" 8.5" x 22" Splice Tray Splices Trays Closure Trays Closure Depth Description per Tray per Closure Capacity per Closure Capacity Low Profile Single Fusion 36 6 216 11 396 Single Fusion & Standard 36 4 144 8 288 Single Mechanical Ribbon Mass Fusion 144 2 288 4 576 COYOTE Closure Kits Catalog Number 6 Port 4 Port End Plate End Plate Organizer Type Description 6" x 22" COYOTE Closure, includes (1) 3 section end plate, 8006560 8006633 Buffer Tube (1) blank end plate, organizer and LOCK-TAPE sealant Unitube Transition 6" x 22" COYOTE Closure, includes (1) 3 section end plate, (1) blank end plate, 8006540 8006631 Compartment organizer, transport tube kit, transition tube kit and LOCK-TAPE sealant Express 6" x 22" COYOTE Closure, includes (1) 3 section end plate, (1) blank end plate, express 8006587 8006635 Buffer Tube organizer and LOCK-TAPE sealant RUS LISTED - 6" x 22" COYOTE Closure, includes (1) 3 section end plate, (1) blank 8006659 Buffer Tube end plate, organizer, LOCK-TAPE sealant and (2) RUS listed shield connectors 8.5" x 22" COYOTE Closure, includes (1) 3 section end plate, 8006561 8006634 Buffer Tube (1) blank end plate, organizer and LOCK-TAPE sealant Unitube Transition 8.5" x 22" COYOTE Closure, includes (1) 3 section end plate, (1) blank end plate, 8006541 8006632 Compartment organizer, transport tube kit, transition tube kit and LOCK-TAPE sealant Express 8.5" x 22" COYOTE Closure, includes (1) 3 section end plate, (1) blank end plate, 8006588 8006636 Buffer Tube express organizer and LOCK-TAPE sealant RUS LISTED - 8.5" x 22" COYOTE Closure, includes (1) 3 section end plate, (1) blank 8006660 Buffer Tube end plate, organizer, LOCK-TAPE sealant and (2) RUS listed shield connectors UL Approved, RUS Listed, Patented COYOTE Closure Splice Tray Kits Catalog 6.5" x 17" 6" x 22" Number Description or Smaller or Larger 80807701 12 Count Low Profile Tray w/plastic splice block – single fusion splices X 80807769 12 Count Low Profile Tray (Blank) No Splice Block X 80806033 12 Count Standard Tray w/elastomeric splice block – Fusion & mechanical splices X 80806182 12 Count Standard Tray (Blank) – No Splice Block X 80807114 72 Count Ribbon Tray w/Elastomeric Splice Block for Mass Fusion X 80808160 Ribbon Tray (Blank) No splice Block X LGSTS16 16/40* Count LITE-GRIP® Tray (Short) for Single Fusion X LGSTR144 144/180* Count LITE-GRIP Tray (Short) for Ribbon X 8001127 36 Count Low Profile Tray w/plastic splice block – single fusion splices X 80807531 Blank Low Profile Splice Tray X 8001130 Blank Low Profile Splice Tray X 80805514 36 Count Standard Tray w/elastomeric splice blocks – Fusion & mechanical splices X 80805110 36 Count Standard Tray w/fixed rigid slots X 80805509 36 Count Standard Tray (Blank) – No Splice Block LGSTS40 40/80* Count LITE-GRIP® Tray (Short) for Single Fusion X LGSTR216 216/288* Count LITE-GRIP Tray (Short) for Ribbon X 80805146 144 Count Ribbon Tray w/fixed rigid slots X 80805515 144 Count Ribbon Tray w/2 elastomeric splice blocks X 80805510 144 Count Ribbon Tray (Blank) – No splice blocks X LGSBR3-5 LITE-GRIP Splice Block Kit – Ribbon Fiber (5 ea per kit) X X LGSBS8-5 LITE-GRIP Splice Block Kit – Single Fusion (5 ea per kit) X X *Requires additional LITE-GRIP block kit to achieve maximum capacity. 1-26
  • 27.
    PREVIOUS SECTION CONTENTS SEARCH NEXT COYOTE® Closure Series: Section 1 COYOTE Closure End Plates and Accessories ® Plates and Accessories COYOTE® Closure End Origin of the Species… COYOTE Closure Shell Kits Unitube Transition Compartment Catalog Number Description (mm) 80805258 6.0" (152) x 22.0" (559) COYOTE Shell Kit 80805259 8.5" (216) x 22.0" (559) COYOTE Shell Kit Transition and Buffer Tube Storage Compartments Catalog Number Description (mm) 6.0"(152) x 22.0" (559) Transition 80805112 Compartment Kit 8.5" (216)x 22.0" (559) Transition 80805113 Compartment Kit Loose Buffer Tube Storage Compartment 6.0" (152) x 22.0" (559) Loose Buffer 80805262 Tube Storage Compartment Kit 6.0" (152) x 22.0" (559) COYOTE Express 80805419 Organizer (for loose buffer tube applications) 8.5" (216) x 22.0" (559) Loose Buffer 80805263 Tube Storage Compartment Kit 8.5" (216) x 22.0" (559) COYOTE Express 80805420 Organizer (for loose buffer tube applications) Transition Tube Kit for fiber transition from top 8003280 section of end plate to transition compartment Installation Materials Catalog Number Description (mm) 80805238 C-Cement, 1 oz. tube Adjustable Aerial 80802377 C-Cement, 4 oz. can Hanger Bracket 80803448 Moisture Blocking Sealant, 3 oz. tube 80805925 LOCK-TAPE™ Sealant 1" (25) W x 15' (4 m) L Splice Protector, non-heat shrink 250/250 micron, 8003092 pack of 20 Mass Fusion Splice Protector, non-heat shrink, 8003425 pack of 12 Vertical Mount Bracket 8003509 60 mm Heat Shrink Splice Protector, pack of 12 8003490 Felt strips (blue) 1-1/8" (29) x 9" (229), 6 strips Mounting Brackets/Supports Catalog Number Description (mm) 8003325 Adjustable Aerial Hanger Bracket Kit 8003279 Manhole Support Bracket Kit Vertical Mount Bracket Kit (for 6.0" (152) or 8003372 8.5"(216) COYOTE Closure or 6.0" (152) COYOTE PUP Closure) 1-27
  • 28.
    PREVIOUS SECTION CONTENTS SEARCH NEXT COYOTE Closure End Plates and Accessories ® Origin of the Species… Strength Member Bracket Exterior Bond Braid Extended Strength Member Bracket Miscellaneous Accessories Bonding and Grounding Kits Catalog Catalog Number Description (mm) Number Description (mm) 80805260 Blank End Plate Kit 8003281 External bond clip kit 80805107 Strength Member Bracket Kit – two per kit 8003360 External bond braid kit Extended Strength Member Bracket Kit – External isolation terminal kit, includes (2) 80805431 two per Kit 8003463 isolation terminals with 7" long #6 cable stub Heat Shield for 6.0" (152) x 22.0" and splice sleeve 8003386 (559) COYOTE Closure External isolation terminal kit, includes (2) Heat Shield for 8.5" (216) x 22.0" 8003464 isolation terminals with 7" long #6 cable stub 8003387 and quick disconnect (559) COYOTE Closure Flame-Retardant Blanket for 6.0" 8003465 Quick disconnect kit (2 per kit) 8003385 (152) x 22.0" (559) COYOTE Closure External isolation connector for COYOTE 80806750 Flame-Retardant Blanket for 8.5" Closures 8003388 (216) x 22.0" (559) COYOTE Closure Fiber optic shield connector, RUS Listed 3M 80803989 Transition Tube Kit Used to transition fibers #4460-D/FO (1 per kit) 8003280 from the top section of the End Plate to the Fiber optic shield connector for up to .5" (13mm) 80806743 Transition Compartment. cable O.D. 8000475 COYOTE Closure End Plate Removal Tool Fiber optic shield connector for .5" to .8" 80806744 Transport Tube Kit .135" ID: includes six 34" (13 - 20mm) cable O.D. long transPort with Hardened Adapter tubes, Fiber optic shield connector for .8" to 1.6" 80805293 80806745 used to bring fiber from transition compartment (20 - 41mm) cable O.D. to splice tray Adapter bracket kit for AT&T bond 80805286 Transport Tube Kit .25" ID: includes six 34" connector (4 per kit) long transPort with Hardened Adapter tubes, 8003322 Isolated ground kit for 0.27" to .31" (7 - 8mm) 80806439 used to bring fiber from transition compartment to splice tray Strength member bracket isolation kit, includes 8003424 (6) nylon washers and bushings Bonding Braid, .5" W x 7" L with (2) eyelets 80806179 spaced 6" apart 1-28
  • 29.
    PREVIOUS SECTION CONTENTS SEARCH NEXT COYOTE® Closure Series: Section 1 COYOTE Closure End Plates and Accessories ® Plates and Accessories COYOTE® Closure End Single Port Grommets Coyote RUNT Accepted Standard and COYOTE 6 Port COYOTE 4 Port Cable Expanded End Plate End Plate Catalog Diameter Port Sizes Port Sizes Port Sizes Number Hole Factory Range (End Color) Pattern Entries Slit inches (mm) 3/4" 1" 3/4" 7/8" 1" 1-1/4" 8003394 .31 - .38 1 NO X X (Green) (7.8 - 9.6) 8003395 .31 - .38 1 NO X (Green) (7.8 - 9.6) 8003473 .43 - .48 1 NO X X (Light Blue) (11 - 12.2) 8003494 .48 - .53 1 NO X X (Yellow) (12.2 - 13.5) 8003495 .53 - .58 1 NO X X (Gray) (13.4 - 14.7) 8003496 .43 - .48 1 NO X (Light Blue) (11 - 12.2) 8003497 .48 - .53 1 NO X (Yellow) (12.2 - 13.5) 8003498 .53 - .58 1 NO X (Gray) (13.4 - 14.7) 8003500 .38 - .43 1 NO X X (Orange) (9.6 - 11) 8003501 .38 - .43 1 NO X (Orange) (9.6 - 11) 8003596 .43 - .48 1 NO X X (Light Blue) (11 - 12.2) 8003597 .43 - .48 1 NO X (Light Blue) (11 - 12.2) 8003598 .48 - .53 1 NO X X (Yellow) (12.2 - 13.5) 8003599 .48 - .53 1 NO X (Yellow) (12.2 - 13.5) 8003600 .53 - .58 1 NO X X (Gray) (13.4 - 14.7) 8003601 .53 - .58 1 NO X (Gray) (13.4 - 14.7) 8003497 .48 - .53 1 NO X (Yellow) (12.2 - 13.5) 8003671 .43 - .48 1 YES X X (Light Blue) (11 - 12.2) 8003674 .53 - .58 1 YES X X (Gray) (13.4 - 14.7) 8003689 .48 - .53 1 YES X X (Yellow) (12.2 - 13.5) 8003675 .53 - .58 1 YES X (Gray) (13.4 - 14.7) 1-29
  • 30.
    PREVIOUS SECTION CONTENTS SEARCH NEXT COYOTE Closure End Plates and Accessories ® Multi-Port Grommets COYOTE RUNT Accepted Standard and COYOTE 6 Port COYOTE 4 Port Cable Expanded End Plate End Plate Catalog Diameter Port Sizes Port Sizes Port Sizes Number Hole Factory Range (End Color) Pattern Entries Slit inches (mm) 3/4" 1" 3/4" 7/8" 1" 1-1/4" 8003392 .27 - .31 2 NO X X (Red) (6.8 - 7.8) 8003393 .31 - .38 2 NO X (Green) (7.8 - 9.6) 8003399 .38 - .43 2 NO X X (Orange) (9.6 - 11) 8003608 Corning SST 2 NO X X (Light Blue) (Flat Drop) 8003730 Corning SST 2 YES X X (Light Blue) (Flat Drop) 8003536 .18 - .24 3 NO X X (Black) (4.5 - 6.1) 800010621 .18 - .24 3 NO X (Black) (4.5 - 6.1) 8003389 .27 - .31 3 NO X (Red) (6.8 - 7.8) 8003390 .20 - .27 3 NO X (Blue) (5.1 - 6.8) 8003391 .20 - .27 3 NO X X (Blue) (5.1 - 6.8) 8003400 .31 - .38 3 NO X X (Blue) (7.8 - 9.6) 8003402 .27 - .31 3 NO X X (Red) (6.8 - 7.8) 8003403 .38 - .43 3 NO X (Orange) (9.6 - 11) 8003609 Corning SST 3 NO X (Light Blue) (Flat Drop) 8003401 .20 - .27 4 NO X X (Blue) (5.1 - 6.8) 8003404 .31 - .38 4 NO X (Green) (7.8 - 9.6) 8003405 .20 - .27 4 NO X (Blue) (5.1 - 6.8) 8003406 .27 - .31 4 NO X (Red) (6.8 - 7.8) 8003575 .12 - .16 4 NO X (Brown) (3 - 4.1) 8003607 .27 - .31 4 NO X X (Red) (6.8 - 7.8) 8003610 Corning SST 4 NO X X (Light Blue) (Flat Drop) 8003576 .12 - .16 6 NO X X (Brown) (3 - 4.1) 8003611 Corning SST 6 NO X (Light Blue) (Flat Drop) 8003582 .12 - .16 10 NO X (Brown) (3 - 4.1) 1-30
  • 31.
    PREVIOUS SECTION CONTENTS SEARCH NEXT COYOTE® Closure Series: Section 1 COYOTE Closure End Plates and Accessories ® Plates and Accessories COYOTE® Closure End User options for COYOTE Closure Three-Section End Plate Ports Three-Section Six Port End Plate (Cat. No. 80805105) Two 3/4" (19 mm) Ports Four 7/8"(22 mm) Ports Available options: Available options: • Cables up to 0.75" (19 mm) • Cables up to 0.88" (22 mm) in diameter in diameter 7/8" 7/8" 3/4 " • See Grommet table • Future Cable Port, 0.56" • 3/4" (19 mm) Plug (Cat. No. (14 mm) max. cable diameter 80806037, two per kit) • See Grommet table 7/8" 3/4 7/8 " " Note: Three-Section Six Port End • 7⁄8" Plug Kit (80806180) Plate Kits include three 7/8" (22 mm) Plugs, two (2) 3/4" (19 mm) Plugs and two Strength Member Brackets. Three-Section Four Port End Plate (Cat. No. 80805739) Two 1" (25 mm) Ports Two 1-1/4" (32 mm) Ports Available options: Available options: • Cables up to 1.00" (21 mm) in • Cables up to 1.25" (32 mm) in diameter diameter • Future Cable Port, 0.81" (21 mm) 1" • Future Cable Port, 1" (25 mm) max. max. cable diameter cable diameter • See Grommet table 1" • See Grommet table • 1" Plug Kit (80806038) 11/4" • 1-1/4" Plug Kit (80806181) 11/4" 1" (25 mm) Ports Available options: COYOTE RUNT End Plate • Cables up to 1.0" (25 mm) in diameter • Future Cable Port, 0.81" (21 mm) max. cable diameter • See Grommet table • 1" Plug Kit (80806038) 3/4" 1 " 3/4" Two 3/4" (19 mm) Ports Available options: • Cables up to 0.75" (19 mm) in diameter • See Grommet table • 3/4" Plug (80806181) Two/Kit 1-31
  • 32.
    PREVIOUS SECTION CONTENTS SEARCH NEXT COYOTE Closure End Plates and Accessories ® Future Cable Port Kit When installed during the initial assembly, Future Cable Ports allow for the addition of branch cables in the future with no disruption to the existing cables and the fibers within them. Future Cable Port Kits Catalog End Plate Usage Number Description 7/8" 1.0" 1-1/4" Runt 6 Port 4 Port Future cable port kit for 7/8"" Port, includes (1) cable 8003371 X X port, (1) plug and (1) clamp Future cable port kit for 1" Port, includes (1) cable port, 8003407 X X X (1) plug and (1) clamp Future cable port kit for 1-1/4" Port includes (1) cable 8003409 X X port, (1) plug and (1) clamp Future cable installation kit, includes LOCK-TAPE 8003291 X X X X X X sealant, bead sealant and l-bracket Future cable port for 7/8" port plus installation kit 8003289 X X (8003291) Future cable port for 1" port plus installation kit 8003408 X X (8003291) Future cable port for 1-1/4" port plus installation kit 8003410 X X (8003291) COYOTE Closure End Plate Grommets End Plate Installation Material Kits Catalog Number Description 6 Port end plate kit, includes 80805105 (1) end plate assembly, (1) full set of plugs and LOCK-TAPE sealant End Plate Grommets 4 Port end plate kit, includes expand the capacity of 80805739 (1) end plate assembly, the COYOTE Closure (1) full set of plugs and LOCK-TAPE sealant T h re e - S e c t i o n E n d 80806037 Plug Kit for 3/4" ports (2 per kit) Plates for applications 80806180 Plug Kit for 7/8" ports (2 per kit) with smaller diameter 80806038 Plug Kit for 1.0" ports (2 per kit) cables or insulated 80806181 Plug Kit for 1-1/4" ports (2 per kit) ground wires. The grommets are manufactured from a weather-resistant urethane material that is designed to ensure a tight and permanent seal. A Silicone Sealant is provided to lubricate the grommet and cables for easy installation. The entry holes in the multi-entry grommets are covered with a thin layer of urethane material to provide a choice of which entries are to be used for future cable entries. See Grommet charts on pages 1-29 and 1-30. 1-32
  • 33.
    PREVIOUS SECTION CONTENTS SEARCH NEXT COYOTE® Closure Series: Section 1 COYOTE ® Cross-Connect and Cross-Connect/Express Closures Cross-Connect/Express Closures COYOTE Cross-Connect & Refinement of the Breed… ® The COYOTE Cross-Connect Closure provides long-term peace of mind. The COYOTE Cross-Connect and Cross-Connect/Express- Closures allow you to splice up to 96 single fiber splices PATENTED and cross connect up to 48 pigtails on both the office and distribution side. Consult PLP support for details on ribbon fiber splices. By redirecting fiber for outside plant, the COYOTE Cross-Connect Closure saves time and money: because you splice only once. The COYOTE Cross-Connect and Cross-Connect/Express- Closures are made from the same durable UV stabilized material as the COYOTE Closure. The internal bulkhead is designed to accept a variety of connector styles. Place your order as soon as you have chosen the connector for your application and determined your pigtail requirements. This customization process saves time and money by limiting the order to only the parts required. Each end plate allows for multiple entries. Isolated ground studs simplify troubleshooting, and provide additional support for strength member tie-off. The family of COYOTE Cross Connect/Express Closures The COYOTE Cross-Connect Closure is waterproof and is configured to conveniently and safely store uncut buffer uses the revolutionary LOCK-TAPE™ Sealant System, tubes of the feeder cable, while providing individual providing field-proven durability. The neoprene gasket also connectivity to the fibers of the drop cables. aids in keeping the closure’s contents accessible again and again without a costly re-entry kit. The COYOTE Closure is tested in accordance with Bellcore GR-771-CORE. COYOTE Cross-Connect Closure components Bulkhead 8.5" (216 mm) COYOTE® Closure Shell Blank End Plate Transition Compartment Kit with Pigtail Guides Three-Section End Plate 8.5" (216 mm) COYOTE® COYOTE® Closure Shell Splice Trays (4) 1-33
  • 34.
    PREVIOUS SECTION CONTENTS SEARCH NEXT COYOTE ® Cross-Connect and Cross-Connect/Express Closures Refinement of the Breed… Ordering Information Included in all COYOTE Cross-Connect Closure Kits is one Three-Section End Plate, one Blank End Plate, Transition Compartment Kit with Pigtail Guides, Bulkhead, and four COYOTE Splice Trays (single fiber). ST, SC and FC Half- Loaded and Fully-Loaded Kits contain additional items which are described in the table below. COYOTE Cross-Connect Closure Catalog Number Description COYOTE Cross Connect-Closure (Standard Unit) includes one three-section End Plate, one blank End Plate, transition 8006572 compartment kit with pigtail guides, bulkhead, and four COYOTE Splice Trays (single fiber) COYOTE Cross-Connect Closure – ST half loaded (24 count) includes standard unit, plus four (Bulkhead) coupler 8006576 panels with six singlemode ST couplers, four field pigtail kits with ST connector (6) and transport tube, and four service pigtail kits with ST connector (6) and transport tube COYOTE Cross-Connect Closure – ST fully loaded (48 count) includes standard unit, plus eight (Bulkhead) coupler 8006577 panels with six singlemode ST couplers, eight field pigtail kits with ST connector (6) and transport tube, and eight service pigtail kits with ST connector (6) and transport tube COYOTE Cross-Connect Closure – SC half loaded (24 count) includes standard unit, plus four (Bulkhead) coupler 8006591 panels with six singlemode SC couplers, four field pigtail kits with SC connector (6) and transport tube, and four service pigtail kits with SC connector (6) and transport tube COYOTE Cross-Connect Closure – SC fully loaded (48 count) includes standard unit, plus eight (Bulkhead) coupler 8006592 panels with six singlemode SC couplers, eight field pigtail kits with SC connector (6) and transport tube, and eight service pigtail kits with SC connector (6) and transport tube COYOTE Cross-Connect Closure – FC half loaded (24 count) includes standard unit, plus four (Bulkhead) coupler 8006593 panels with six singlemode FC couplers, four field pigtail kits with FC connector (6) and transport tube, and four service pigtail kits with FC connector (6) and transport tube COYOTE Cross-Connect Closure – FC fully loaded (48 count) includes standard unit, plus eight (Bulkhead) coupler 8006594 panels with six singlemode FC couplers, eight field pigtail kits with FC connector (6) and transport tube, and eight service pigtail kits with FC connector (6) and transport tube COYOTE Cross-Connect Closure – AP/SC fully loaded (48 count) includes standard unit, plus eight (Bulkhead) coupler 8006670 panels with six singlemode AP/SC couplers, eight field pigtail kits with AP/SC connector (6) and transport tube, and eight service pigtail kits with AP/SC connector (6) and transport tube 1-34
  • 35.
    PREVIOUS SECTION CONTENTS SEARCH NEXT COYOTE® Closure Series: Section 1 COYOTE ® Cross-Connect and Cross-Connect/Express Closures Cross-Connect/Express Closures COYOTE Cross-Connect & Refinement of the Breed… ® Cross connect and store expressed fibers in the same closure The family of COYOTE Cross-Connect Express Closures are configured to conveniently and safely store uncut buffer tubes of the feeder cable, while providing individual connectivity to the fibers of the drop cables. COYOTE Cross-Connect/Express Closure Catalog Number Description Expanded COYOTE RUNT Cross-Connect/Express 8006916 Closure, Includes one 12 count splice tray COYOTE PUP Cross-Connect/Express Closure, with 8006920 PATENTED 6-port end plate, includes two 12 count splice trays COYOTE PUP Cross-Connect/Express Closure, with Adaptor Plates 8006921 4-port end plate, includes two 12 count splice trays Catalog 6" x 22" COYOTE Cross-Connect/Express Closure, Number Connector Adaptor 8006911 with 6-port end plate, includes two 36 count splice trays 6SMSC SC 6 6" x 22" Cross-Connect/Express Closure, with 6SCAPC SC/APC 6 8006912 12SMDSC SC 6 Duplex 4-port end plate, includes two 36 count splice trays 8.5" x 22" COYOTE Cross-Connect/Express 8SMSC SC 8 8006612 Closure with 6-port end plate, includes two 36 6SMST ST 6 count splice trays 8SMST ST 8 8.5" x 22" COYOTE Cross-Connect/ Express 6SMFC FC 6 8006915 Closure, with 4-port end plate, includes two 36 count splice trays 8SMFC FC 8 6.5" x 22" COYOTE Dome Cross-Connect/Express 6FCAPC FC/APC 6 800012184 Closure, (Empty) 6SMLC LC 6 6.5" x 17" COYOTE Dome Cross-Connect/Express 12SMLC LC 12 800012185 Closure, (Empty) 600 Blank – Catalog Capacities Adapter Number Description Max. No. of No. of (Bulkhead) Coupler Panel with six holes for ST 80805605 Feeder Adapter Splice Splices Feed-Thru Adapters Closure Cable Plates Trays per Tray (Bulkhead) Coupler Panel with six holes for SC 80805606 Expanded Feed-Thru Adapters 48-fiber 1 1 12 RUNT (Bulkhead) Coupler Panel with six holes for FC 80805607 PUP 144-fiber 2 2 12 Feed-Thru Adapters 6" x 22" 144-fiber 3 2 36 8.5" x 22" 288-fiber 3 4 36 Pigtail Kits and Accessories 17" Dome 48-fiber 1 1 12 Catalog 22" Dome 144-fiber 2 2 12 Number Description Pigtail Kit with ST Singlemode Connector (6) and 8003292 Transport Tube, FIELD Pigtail Kit with SC Singlemode Connector (6) and 8003314 Transport Tube, FIELD Pigtail Kit with FC Singlemode Connector (6) and 8003316 Transport Tube, FIELD Pigtail Kit with ST Singlemode Connector (6) and 8003293 Transport Tube, SERVICE Pigtail Kit with SC Singlemode Connector (6) and 8003315 Transport Tube, SERVICE Pigtail Kit with FC Singlemode Connector (6) and 8003317 Transport Tube, SERVICE Pigtail Transition Tube Kit, includes one Transport 8003368 Tube with Transition and Reducing Tubes 1-35
  • 36.
    PREVIOUS SECTION CONTENTS SEARCH NEXT COYOTE Drop Cable Closure ® Refinement of the Breed… The perfect solution to the splicing or repair of low fiber count drop cables The COYOTE Drop Cable Closure is a re-enterable (not re-usable), encapsulant filled closure for splicing buried fiber optic drop cables (up to 6-fiber). The COYOTE Drop Cable Closure will accept either dielec- tric or shielded fiber optic drop cables with an outside diameter of up to 0.5" (13 mm). Each Closure body is factory filled with field proven (over 14 years) POLY-BEE™ Sealant to provide a protective Catalog barrier around the sealed splice tray assembly. Number Description COYOTE Drop Cable Closure, includes sealed The sealed splice tray assembly has an integral bond clamp 8006876 splice tray assembly and six (6) heat shrink which provides both conductivity between the cable shields splice protectors. and cable restraint. COYOTE Drop Cable Closure unfilled includes 8006914 splice tray assembly & six (6) heat shrink splice protectors. The splice block on the splice tray assembly holds up to six heat-shrink fusion splice protectors. Six 40 mm long protectors are provided. Assembly is simple: • Prepare & secure cables to splice tray • Splice fibers • Seal splice tray • Place splice tray in encapsulated closure • Secure closure with closing clamp Unfilled version for aerial fiber optic drop cables (up to 6-fiber) are available. Cable entries and closure seams are still sealed to prevent the ingress of wind-driven rain and dust. Length (mm) Height (mm) Width (mm) 12" (305) 3" (76) 3.5" (89) 1-36
  • 37.
    PREVIOUS SECTION CONTENTS SEARCH NEXT COYOTE® Closure Series: Section 1 COYOTE Closures for High Fiber COYOTE Closures for High Fiber Count Applications ® Count Applications ® Refinement of the Breed… Larger sizes for High Fiber Count Metropolitan Networks. COYOTE Closures are now available in 9.5" x 28" (241 mm x 711 mm) and 9.5" x 38" (241 mm x 965 mm) for high fiber count applications. These larger COYOTE Closures use the same drillable end plates and fiber management systems as the COYOTE Splice Case (see section 2), but incorporate a new light- weight, durable non-metallic shell. COYOTE Hi-Count Closure Catalog Number 800010810 COYOTE Closure Kits Catalog Number Description (mm) Closure Kits 9.5" x 28" (241 x 711) COYOTE Hi-Count Closure for buffer tube applications, up to 432 single fiber splices, holds up to 800010810 eighteen 24-count splice trays 8003469 24-count Splice Tray for COYOTE Hi-Count Closure (heat shrink protector only) 9.5" x 28" (241 x 711) COYOTE Closure, unitube version, holds up to six 144-fiber ribbon splice trays (mass fusion), 800010897 864-fiber capacity or ten 36 fiber single fiber splice trays, 360-fiber capacity, for use with central core ribbon fiber cables 9.5" x 28" (241 x 711) COYOTE Closure, buffer tube version, holds up to six 144-fiber ribbon splice trays (mass fusion), 800010884 864-fiber capacity or ten 36 fiber single fiber splice trays, 360-fiber capacity, for use with flexible buffered ribbon fiber cables 9.5" x 38" (241 x 965) COYOTE Closure, unitube version, holds up to nine 144-fiber ribbon splice trays (mass fusion), 8006765 1296-fiber capacity or sixteen 36-fiber single fiber splice trays, 576-fiber capacity, for use with central core ribbon fiber cables Splice Tray Kits 80805146 144 Count Ribbon Tray w/fixed rigid slots 80805515 144 Count Ribbon Tray w/2 elastomeric splice blocks 80805514 36 Count Standard Tray w/elastomeric splice blocks – fusion & mechanical splices 8001127 36 Count Low Profile Tray w/plastic splice block – single fusion splices Installation Accessories 8006792 9.5" x 28" (241 x 711) COYOTE Closure Shell Kit 8006793 9.5" x 38" (241 x 965) COYOTE Closure Shell Kit 1-37
  • 38.
    PREVIOUS SECTION CONTENTS SEARCH NEXT COYOTE Retrofit Closure ® Refinement of the Breed… The ideal Closure for replacement or expansion The COYOTE Retrofit Closure contains a versatile Fiber Management System which makes simple work out of retrofitting existing fiber optic closures for either closure replacement or closure capacity expansion. Specifically, the COYOTE Retrofit Closure will accommodate the existing fiber management systems (slack buffer tubes or fiber and splice trays) from closures manufactured by Lucent Technologies (UCB Series), 3M (2178 Series) and other suppliers. In addition to accommodating the existing splice trays and fiber storage, the COYOTE Retrofit Closure will hold up to Closure Kits four single fiber splice trays, six low-profile trays or up to two Catalog ribbon fiber trays. The total added capacity of the COYOTE Number Description Splice Trays is 216 single fiber, or 288 mass fusion. Closure Kit 8.5" x 22.0" (216 x 559 mm) COYOTE Retrofit As part of the family of COYOTE Closures, the COYOTE Closure. Includes two (2) Three-Section Six Port Retrofit Closure uses the permanent neoprene gasket in 8006638 End Plates, hybrid Fiber Management System, the shell halves and the proven LOCK-TAPE™ Sealing Ten (10) End Plate Plugs and four (4) L-Brackets System for the End Plate and cable seals. These features Splice Tray Kits mean that the COYOTE Retro-fit Closure will meet the same 36 Count Standard Tray w/elastomeric splice 80805514 performance standards as the COYOTE Closure in aerial, blocks – Fusion & mechanical splices underground and buried applications.The COYOTE Closure 80805146 144 Count Ribbon Tray w/fixed rigid slots has been tested in accordance with the requirements of 36 Count Low Profile Tray w/plastic splice block Telcordia GR-771-CORE. 8001127 – single fusion splices In addition, the COYOTE Retrofit Closure uses the same accessories as available for the COYOTE Closure, including Future Cable Ports, End Plate Grommets, Aerial or Manhole Brackets and Splice Trays. See COYOTE Accessories section for catalog numbers for accessories. 1-38
  • 39.
    PREVIOUS SECTION CONTENTS SEARCH NEXT COYOTE® Closure Series: Section 1 COYOTE Closures (ADOBE Series) ® ™ COYOTE® Closures (ADOBE™ Series) Refinement of the Breed… Low profile ADOBE™ Series Trays allow more splices to be stored in groups of 12 or 24 For applications which require a limited number of splices per splice tray, the COYOTE® Closure configured for 12-count or 24-count ADOBE Splice Trays provides the answer. The low profile ADOBE Splice Trays combined with the versatile buffer tube management system of the COYOTE Closure organize and protect the buffer tubes and fibers while maintaining maximum overall storage capacity. See the COYOTE Closure End Plates, End Plate Grommets, Future Cable Port Kits, Mounting Brackets and other common COYOTE Closure accessories. See page 1-25 for COYOTE Closure dimensions. COYOTE Closure (ADOBE Series) Kit Catalog Numbers 6-Port 4-Port End Plate End Plate Description (mm) 6.0" x 22" (152 x 559) COYOTE Closure Kit configured for ADOBE-12 or ADOBE-24 splice trays. 8006684 8006688 Includes: 1 Three-Section End Plate, 1 Blank End Plate, and Buffer Tube Storage Compartment 8.5" x 22" (216 x 559) COYOTE Closure Kit configured for ADOBE-12 or ADOBE-24 splice trays. 8006685 8006686 Includes: 1 Three-Section End Plate, 1 Blank End Plate, and Buffer Tube Storage Compartment 6.0" x 22" (152 x 559) COYOTE Express Closure Kit configured for ADOBE-12 or ADOBE-24 splice trays. 8006806 8006820 Includes: 1 Three-Section End Plate, 1 Blank End Plate, and Express Buffer Tube Storage Compartment 8.5" x 22" (216 x 559) COYOTE Express Closure Kit configured for ADOBE-12 or ADOBE-24 splice trays. 8006807 8006819 Includes: 1 Three-Section End Plate, 1 Blank End Plate, and Express Buffer Tube Storage Compartment ADOBE Series Splice Trays Catalog Number Description 8001122 ADOBE-12 Splice Tray (12 Count) with Heat Shrink Splice Block. Includes: Tray, Cover, Tie Wraps and Felt Strips 8001096 ADOBE-12 Splice Tray (12 Count) with Molded-in Splice Block. Includes: Tray, Cover, Tie Wraps and Felt Strips 8001120 ADOBE-12 Splice Tray Blank. Includes: Tray, Cover, Tie Wraps and Felt Strips 8001121 ADOBE-24 Splice Tray (24 Count) with 2 Heat Shrink Splice Blocks. Includes: Tray, Cover, Tie Wraps and Felt Strips 8001119 ADOBE-24 Splice Tray Blank. Includes: Tray, Cover, Tie Wraps and Felt Strips ADOBE-12 Splice Trays are 13" L x 315⁄16" W x 11⁄32" H (330 x 100 x 9 mm) ADOBE-24 Splice Trays are 13" L x 4¾" W x 11⁄32" H (330 x 121 x 9 mm) Capacities Splice Tray Usable Splice Splice Capacity Max. Number of Max. Closure Closure (mm) Catalog No Protectors Per Tray Trays Per Closure Splice Capacity 8001122 Heat Shrink Only 12 12 144 6.0" x 22" (152 x 559 ) 8001096 Protected Fusion 12 12 144 8001121 Heat Shrink Only 24 6 144 8001122 Heat Shrink Only 12 18 216 8.5" x 22" (216 x 559 ) 8001096 Protected Fusion 12 18 216 8001121 Heat Shrink Only 24 12 288 Note: Maximum number of trays per closure and closure capacity for COYOTE Express Closure Kits (8006806, 8006807, 8006819 and 8006820) are reduced by 50%. 1-39
