Physics first spectrum of ball lightning
•
1 like•2,109 views
Researchers in China measured the first spectrum of ball lightning. They observed ball lightning form after a cloud-to-ground lightning strike about 900 meters away. The spectrum contained emission lines from silicon, iron, and calcium, elements common in soil. This supports the theory that ball lightning is formed when lightning vaporizes soil, producing glowing nanoparticles. It was about 2 meters wide and drifted horizontally for 30 meters before rising a few meters. This is the first direct observation of ball lightning forming from a lightning strike and the first measurement of its emission spectrum.
![Physics - First Spectrum of Ball Lightning
2 de 4
http://physics.aps.org.ez1.periodicos.capes.gov.br/articles/v7/5
J. Cen, P. Yuan, and S. Xue, Phys. Rev. Lett. (2014)
1.3 seconds of real-time video slowed down to show the ball lightning’s evolution in shape, color, and
brightness and its associated spectrum.
Ball lightning has been one of the most mysterious natural phenomena for centuries, partly because it is
so rare and transient and therefore hard to investigate. But a fortuitous observation during field
experiments in China to study ordinary lightning, reported in Physical Review Letters, has now provided
what seems to be the first measurement of the emission spectrum of ball lightning. The data suggest that
the glowing ball was composed of elements from soil, consistent with one popular theory.
Ball lightning typically appears during thunderstorms as a glow, ranging from the size of a golf ball to
several meters across, which floats in the air for between one second and tens of seconds. There are many
historical reports of such “fireballs” injuring or even killing people and setting buildings alight, and they
have sometimes been given supernatural explanations.
Scientific theories of ball lightning abound, with varying degrees of plausibility. Glowing plasma balls
have been created artificially by passing intense microwaves through air [1] or by underwater electrical
discharges [2]. But such laboratory experiments may not bear any relation to ball lightning formation in
the natural environment—about which very little is known, since there has been almost no solid data.
One popular theory is that ball lightning is caused when lightning striking the ground vaporizes some of
the silicate minerals in soil. Carbon in the soil strips the silicates of oxygen through chemical reactions,
creating a gas of energetic silicon atoms. These then recombine to form nanoparticles or filaments which,
while still floating in air, react with oxygen, releasing heat and emitting the glow [3]. If that’s so, one
should expect to see atomic emission lines of silicon and other soil elements in the spectrum.
That is what Ping Yuan and co-workers from Northwest Normal University in Lanzhou, China, now
report. They had set up spectrometers on the remote Qinghai Plateau of northwest China to investigate
ordinary lightning, which is frequent in this region. During one late-evening thunderstorm in July 2012,
they saw ball lightning appear just after a lightning strike about 900 meters from their apparatus and were
able to record a spectrum and high-speed video footage of the ball.
The recorded glow was about meters across—the actual size of the ball was much smaller—and it
changed from white to reddish during the second or so that it lasted. Although the darkness prevented the
researchers from estimating the ball’s altitude, they saw it drift horizontally for about
meters and
ascend about meters. Yuan says that this is the first time ball lightning has been seen to be created by a
cloud-to-ground lightning strike.
The researchers found that the spectrum contained several emission lines from silicon, iron, and
calcium—all elements expected to be abundant in soil. One would also expect aluminum to be present,
More Related Content
Viewers also liked
Viewers also liked (18)
Similar to Physics first spectrum of ball lightning
Similar to Physics first spectrum of ball lightning (20)
More from Carlos Bella
More from Carlos Bella (20)
Recently uploaded
Recently uploaded (20)
Physics first spectrum of ball lightning
- 1. Physics - First Spectrum of Ball Lightning 1 de 4 http://physics.aps.org.ez1.periodicos.capes.gov.br/articles/v7/5 American Physical Society Log in | Create Account (what's this?) Home About Browse APS Journals Focus: First Spectrum of Ball Lightning Published January 17, 2014 | Physics 7, 5 (2014) | DOI: 10.1103/Physics.7.5 Researchers measured a spectrum of light emitted by the rare and elusive ball lightning. Observation of the Optical and Spectral Characteristics of Ball Lightning Jianyong Cen, Ping Yuan, and Simin Xue Phys. Rev. Lett. 112, 035001 (2014) Published January 17, 2014 +Enlarge image J. Cen, P. Yuan, and S. Xue, Phys. Rev. Lett. (2014) Lucky strike. The spectrum of a cloud-to-ground lightning strike and of the ball lightning it generated. The ball lightning is the white dot at the far left, and its spectrum is the slightly brighter band of colors at the foot of the irregularly shaped main lightning spectrum. (See video below.) 18/01/2014 09:57
- 2. Physics - First Spectrum of Ball Lightning 2 de 4 http://physics.aps.org.ez1.periodicos.capes.gov.br/articles/v7/5 J. Cen, P. Yuan, and S. Xue, Phys. Rev. Lett. (2014) 1.3 seconds of real-time video slowed down to show the ball lightning’s evolution in shape, color, and brightness and its associated spectrum. Ball lightning has been one of the most mysterious natural phenomena for centuries, partly because it is so rare and transient and therefore hard to investigate. But a fortuitous observation during field experiments in China to study ordinary lightning, reported in Physical Review Letters, has now provided what seems to be the first measurement of the emission spectrum of ball lightning. The data suggest that the glowing ball was composed of elements from soil, consistent with one popular theory. Ball lightning typically appears during thunderstorms as a glow, ranging from the size of a golf ball to several meters across, which floats in the air for between one second and tens of seconds. There are many historical reports of such “fireballs” injuring or even killing people and setting buildings alight, and they have sometimes been given supernatural explanations. Scientific theories of ball lightning abound, with varying degrees of plausibility. Glowing plasma balls have been created artificially by passing intense microwaves through air [1] or by underwater electrical discharges [2]. But such laboratory experiments may not bear any relation to ball lightning formation in the natural environment—about which very little is known, since there has been almost no solid data. One popular theory is that ball lightning is caused when lightning striking the ground vaporizes some of the silicate minerals in soil. Carbon in the soil strips the silicates of oxygen through chemical reactions, creating a gas of energetic silicon atoms. These then recombine to form nanoparticles or filaments which, while still floating in air, react with oxygen, releasing heat and emitting the glow [3]. If that’s so, one should expect to see atomic emission lines of silicon and other soil elements in the spectrum. That is what Ping Yuan and co-workers from Northwest Normal University in Lanzhou, China, now report. They had set up spectrometers on the remote Qinghai Plateau of northwest China to investigate ordinary lightning, which is frequent in this region. During one late-evening thunderstorm in July 2012, they saw ball lightning appear just after a lightning strike about 900 meters from their apparatus and were able to record a spectrum and high-speed video footage of the ball. The recorded glow was about meters across—the actual size of the ball was much smaller—and it changed from white to reddish during the second or so that it lasted. Although the darkness prevented the researchers from estimating the ball’s altitude, they saw it drift horizontally for about meters and ascend about meters. Yuan says that this is the first time ball lightning has been seen to be created by a cloud-to-ground lightning strike. The researchers found that the spectrum contained several emission lines from silicon, iron, and calcium—all elements expected to be abundant in soil. One would also expect aluminum to be present, 18/01/2014 09:57
- 3. Physics - First Spectrum of Ball Lightning 3 de 4 http://physics.aps.org.ez1.periodicos.capes.gov.br/articles/v7/5 given its abundance in soil minerals. But the researchers couldn’t confirm that, as there are no emission lines of neutral aluminum atoms within the spectral range of their instrument (wavelengths of 400–1000 nanometers). The team also used their video data to plot the ball lightning’s intensity and apparent diameter as they varied in time, down to the millisecond time-scale. “I think that this is a unique observation that is probably of ball lightning, or one type of ball lightning,” says lightning specialist Martin Uman of the University of Florida in Gainesville. “There have been many research programs that routinely video or photograph natural and triggered lightning,” he says, “but none, as far as I am aware, has stumbled on a ball lightning.” “This one certainly seems to be made of dirt,” says Uman, but he says the data don’t reveal any hints as to which ball lightning theory is correct. Such observations might ultimately suggest how to create ball lightning artificially, says Uman, and Yuan agrees. “We are planning to simulate the observational conditions and reproduce it in the laboratory,” says Yuan. –Philip Ball Philip Ball is a freelance science writer in London and author of Curiosity: How Science Became Interested in Everything (2012). References 1. Y. H. Ohtsuki and H. Ofuruton, “Plasma Fireballs Formed by Microwave Interference in Air,” Nature 350, 139 (1991). 2. Y. Sakawa, K. Sugiyama, T. Tanabe, and R. More, “Fireball Generation in a Water Discharge,” J. Plasma Fusion Res. 1, 039 (2006). 3. J. Abrahamson and J. Dinniss, “Ball Lightning Caused by Oxidation of Nanoparticle Networks from Normal Lightning Strikes on Soil,” Nature 403, 519 (2000). Previous Focus | Next Focus Article Options Printable Version Share/Email This Export Citation (BibTeX) Export Citation (RIS) Subject Areas Plasma Physics Geophysics Related Articles More Plasma Physics A Particle Accelerator in the Radiation Belts Viewpoint | Dec 2, 2013 18/01/2014 09:57
- 4. Physics - First Spectrum of Ball Lightning 4 de 4 http://physics.aps.org.ez1.periodicos.capes.gov.br/articles/v7/5 The Seeds of a Magnetic Universe Viewpoint | Jul 29, 2013 All Plasma Physics » More Geophysics Riding Planetary Waves Synopsis | Sep 24, 2013 Simulations Strengthen Earth’s Magnetic-Field/Climate Connection Focus | Sep 20, 2013 All Geophysics » New in Physics Tossing and Turning Synopsis | Jan 15, 2014 Catching ’s in Particle Colliders Synopsis | Jan 15, 2014 Chemical Synthesis in Small Spaces Viewpoint | Jan 13, 2014 Herding Particles to Make a Mirror Synopsis | Jan 13, 2014 Bleaching Cleans Up Cell Images Focus | Jan 10, 2014 Contact Us FAQ Privacy Policies For Contributors APS Journals RSS Feeds APS ISSN 1943-2879. Use of the American Physical Society websites and journals implies that the user has read and agrees to our Terms and Conditions and any applicable Subscription Agreement. 18/01/2014 09:57
