PET Technologies is European manufacture of PET stretch blow molding equipment and blow molds with 18 years of experience. Head office is in Austria, plant is in Ukraine.

1. Company
presentation

2. 2
Our Mission
by means of:
individual approach to customers’ needs
full-cycle production – total quality and production terms control
European modern developments
efficient worldwide service support
blow molds manufacturing for PET Technologies equipment as
well as for all European blow molders producers
original and technological PET bottles design development
long-term beneficial cooperation and partnership
PET Technologies is the European company for development and manufacturing of
professional turnkey solutions for PET-market producers at optimal price.

3. 3
Company
PET Technologies headquarter is in Austria and plant is located in
Ukraine. This combination allows to produce European quality
equipment for reasonable price. All the equipment range is developed
by Austrian engineers, meets all the norms and directives of European
quality standard CE and HACCP requirements for food industry.
more than 18
years of
operational
experience;
full
production
cycle
500 projects
for blow
molders
installation,
10000 blow
mold cavities
supplied
270
employees
total
production
area more
than 9000 m2
sales and
service
centers in 15
countries
certificates
for all range
of equipment:
CE, HACCP,
CIS countries
quality
certificates

4. 4
PET Technologies customers map

5. 5
Main business activities
Blow molding
equipment
Blow molds Complete
filling lines
Service

6. Stretch blow molding equipment
6
• Output – 6000, 10000, 14000 bph
• Bottle volume: 0.2 – 2.0 l (3.0 l for
6-cavity modification)
• Modular system – possibility to install
4, 6, 8 cavities
• High pressure air demand – 40 bar
• overall dimensions, mm –
6700х2400х3100
Automatic blower,
up to 14.000 bph
APF-Max 8APF-Max 8

7. 7
• installed power:
for 6000 bph – 70 kW
for 10000 bph – 100 kW
for 14000 bph – 130 kW
• Minimum preform neck diameter – 18 mm
• Maximum preform neck diameter – 48 mm
Stretch blow molding equipment
Automatic blow molding machine
Output 6000 – 14000 bph
APF-Max 8

8. 8
Automatic blow molding machine
for 0.2-2.0l bottles
APF-6004
• output, bottles/h – 6000
• bottle volume, l – 0.2 – 2.0
• number of cavities – 4
• installed power, kW – 62
• overall dimensions, mm –
8660х3240х2540
Stretch blow molding equipment

9. Stretch blow molding equipment
9
Automatic blow molding machine
for 0.2-2.0l bottles
APF-3002
• output, bottles/h – 3000
• bottle volume, l – 0.2 – 2.0
• number of cavities – 2
• installed power, kW – 38
• overall dimensions, mm –
6400х2800х2300

10. Stretch blow molding equipment
10
APF-5
• output:
- for 3-5 l, bottles/h – 1 600
- for 10 l, bottles/h – 700
• bottle capacity, l – 3.0 – 10.0
• number of cavities – 2/1
• installed power, kW– 46
• overall dimensions, mm -
9200х2200х2740
Automatic blow molding machine
for 3.0-10.0l bottles

11. Stretch blow molding equipment
11
APF-10
• output:
- for 3-5 l, bottles/h – 2 500
- for 10 l, bottles/h – up to 1 800
• bottle capacity, l – 3,0 – 10,0
• number of cavities – 2
• installed power, kW – 62
• overall dimensions, mm –
8200х3400х2600
Automatic blow molding machine
for 3.0-10.0l bottles

12. 12
• output: bottles/h – 120; 250
• bottle capacity, l – 15.0 – 30.0
• number of cavities – 1
• installed power, kW – 87
• overall dimensions, mm –
6700х2400х3100
APF-30
Stretch blow molding equipment
Automatic blow molding machine
for PET kegs and cooler bottles

13. 13
Universal semi-automatic blower
UPF-5
• output:
- for 0.2 – 2 l, bottles/h – 600-800
- for 5 – 6 l, bottles/h – 300-350
• bottle volume, l – 0.2 – 6.0
• number of cavities – 2/1
• installed power, kW – 7,5
• overall dimensions, mm – 1600х600х2200
– 1200х600х1100
Stretch blow molding equipment

14. 14
• output:
- for 5.0 –6.0 l, bottles/h – 600-800
- for 7.0 –10.0 l, bottles/h – 250-300
• bottle volume, l – 1,0 – 10,0
• number of cavities – 1
• installed power, kW – 12
• overall dimensions, mm - 1300х800х2200
- 1200х600х1200
UPF-10
Stretch blow molding equipment
Semi-automatic blower
for bottles 0.5-10.0l

15. 15
• output, bottles/h – up to 80
• bottle volume, l – 10.0 – 40.0
• number of cavities – 1
• installed power, kW – 20
• overall dimensions, mm - 2485х810х2440
- 1980х760х2190
Semi-automatic blower
for bottles 10-40l
UPF-30
Stretch blow molding equipment

16. 16
PET Technologies
blow molding equipment
automatic
0,2-2,0 L
APF-6004
PCO,
30/25,
38/33, oil
4 cavities
6000
bph
beverages,
beer
milk, dairy
oil &
vinegar
non food
detergents
APF-Max
18-48mm
4-6-8
cavities
6000-14000
bph
beverages,
beer milk,
dairy, oil &
vinegar
non food
detergents
APF-3002
PCO,
30/25,
38/33, oil
2 cavities
3000
bph
beverages,
beer
milk, dairy
oil &
vinegar
non food
detergents
3,0-10,0
L
APF-5
38-48 mm
2 cavities
1600
bph
non
carbonate
d water
oil &
vinegar
non food
detergents
APF-10
38-48
mm
2 cavities
2500
bph
non
carbonated
water
oil &
vinegar
non food
detergents
15,0-30,0 L
APF-30
1 cavity
120; 250
bph
non
carbona
ted
water,
beer
semi-automatic
0,2-10,0 L
UPF-5
28-48 mm
2 cavities
600-800 bph
(0,2-3,0 L)
300-350 bph
(5,0-6,0 L)
beverages,
beer
milk & dairy
oil &
vinegar
non food
detergents
UPF-10
28-48 mm
2 cavities
600-800 bph
(1,0-5,0 L)
300-350 bph
(5,0-10,0 L)
beverages, beer
milk & dairy
oil & vinegar
non food
detergents
10,0-40,0 L
UPF-30
48-120mm
1 cavity
80 kegs/h
300
jars/hour
non
carbonated
water,
beer, dry
products

17. 17
Blow molds
for automatic
rotary blowers
Sidel, KHS, Krupp,
SIPA, SMI, Krones
for automatic
linear blowers
Kosme, Siapi, SIPA,
Mag Plastic, ADS,
Lonza
for semi-
automatic
blowers of
various types

18. 18
Exclusive bottle
design
development
concept
development
blowers
parameters and
PET material
technological
features
calculation
recommendations
to the customer
from the
economic point of
view
correspondence
with all the
requirements
for filling lines
bottle
theoretical 2D
drawings and
computer 3D
models
Blow molds

19. 19
Bottles design
creation of new
bottle concepts
design development
based on excising
bottle shape
scaling into other
volumes and
formats
adaptation to the
restrictions of
existing filling line

20. 20
Prototyping
Test mold
production
Bottle samples
production
Bottle forming
control:
- fill level,
- brimful
- bottle dimensions
Bottle testing and
material distribution
control
Trials on the
customer’s filling
line
Final tests report
for the customer

21. 21
Laboratory
Preform weight
reduction
Custom PET
bottle design
Detailed PET
bottle test report
Project feasibility
analysis
Top load test
Burst test
Material distribution
Brimful test
Fill point test
Dimensions test

22. 22
Complete filling lines
PET Technologies provides turn-key complete filling
lines. We guarantee exact project correspondence to
all PET market producers requirements in terms of
output, product quality and cost effectiveness.
Equipment
blow molding equipment compressor
carbonator labeling equipment filler
chiller group packing equipment daters
conveyor systems supplementary machinery

23. 23
Service
PET Technologies will help you at all
stages of cooperation: from molds design
to provision of technical and consulting
services after equipment start up.
We constantly monitor our equipment
operation at customer plant.
PET Technologies global service network
provides:
- after-sales support & spare parts
delivery,
- repair and modernization of equipment,
- customers technitians training

24. 24
PET Technologies equipment :
• has certificates of conformity and
correspondence to the norms and
directives of the European quality
standard CE.
• meets HACCP requirements for
food industry
All our products are
marked with the sign
Quality

25. 25
They trust us

26. PET Technologies GmbH
Grünlandgasse 5/1/12,
2620 Neunkirchen, Austria
+43 720 775 196
office@pet-eu.com
60V Liubetska Str.,
14021 Chernihiv, Ukraine
+38 0462 677 628, 678 125
office.ua@pet-eu.com
PET Technologies Ukraine Ltd.
— Thank you
