Perofrmance testing and apache jmeter

1. Performance Testing
Apache JMeter
&
Mai Duy1

2. Agenda
➱ Performance Testing
➱ Apache JMeter
➱ JMeter Plugins
➱ Example JMeter
1. Web app
2. Mobile app
2

3. Performance Testing
3

4. Performance Testing
Performance Testing is a type of testing to ensure software applications
will perform well under their expected workload.
The focus:
● Speed
● Scalability
● Stability
What is Performance testing ?
4

5. Performance
Testing
Why Performance testing ?
Loss of revenue
If your application doesn't perform, what could be the damage:
Loss of customers
Loss of productivity
Backlog of work
Damage to your brand
5

6. Performance Testing
Performance
Testing
Endurance
Testing
Load
Testing
Volume
Testing
Scalability
Testing
Spike
Testing
Stress
Testing
How many types of Performance testing ?
6

7. Performance Testing
Difference between Load & Stress test
Load test:
To verify application behavior under normal and
peak load conditions
Stress Test:
To determine or validate an application’s behavior
when it is pushed beyond normal or peak load
conditions
7

8. Performance Testing
Free/Open source Commercial
Performance Testing tools
8

9. Performance Testing
User Satisfaction
At https://comparisons.financesonline.com/ 9

10. Performance Testing
Performance Testing Process
10

11. Performance Testing
Application Server
Database Problems
Web Server
Network Server
● Memory leaks
● High CPU usage
● Database deadlocks
● Insufficient Indexing
● Fragmented Database.
● Poor server design
● Memory problems
● Firewall throughput
● Load balancers
Performance Symptoms and Issues
11

12. Install JMeter tool
Create a scenario & run script
Get result & Analysis report
Overview Apache JMeter
12

13. Performance Testing
➔ JMeter is a software that can perform load test,performance-oriented
business (functional) test, regression test, etc., on different protocols
or technologies.
➔ JMeter is a Java desktop application with a graphical interface that
uses the Swing graphical API
What is the Apache JMeter ?
13

14. Performance Testing
Why JMeter ?
14

15. Performance Testing
❖ It is an Open source tool
❖ Perform automated and functional testing for your application
❖ Can load and performance test server types: Web(HTTP, HTTPS),
Web Services (SOAP/XML-RPC), Database via JDBC, FTP Service,...
❖ Test results format like report, Graph, Aggregate report, Results in
tree and Results in Table
Why JMeter ?
15

16. Performance Testing
How does JMeter Works ?
16

17. Performance Testing
1. Install the latest JRE or JDK (Java 8)
2. Download JMeter at http://jmeter.apache.org/download_jmeter.cgi
(Apache JMeter 3.3)
3. Unzip the zip/tar file & open command prompt
4. Run the file /bin/jmeter.bat (Window) or jmeter.sh (Linux, OS)
Installing & Running JMeter
17

18. Performance Testing
Installing & Running JMeter
Interface of JMeter
18

19. Performance Testing
Test Plan
➢ Used for containing the test
➢ Describe series of steps JMeter will execute
➢ A test plan must have at least one Thread Group
JMeter basic elements
19

20. Performance Testing
Workbench
➢ Provide a place to temporarily store test elements while not in use
➢ To copy/paste purposes or any other purpose you desire
➢ Your WorkBench can be saves independently
JMeter basic elements
20

21. Performance Testing
JMeter basic elements
Thread Group
- Setup number of thread
- Setup ramp up period
- No. of times test executes
Timer
- Delay next request for
certain amount of time
Listener
- Graph Result
- View Results Tree and
many more
Controllers
- Sampler (Send Request to
Server)
- Logical Controller
21

22. Performance Testing
JMeter basic elements
Assertions
- To assert fact about
responses received from
HTTP request
Pre-Processor
- Execute prior to sample
request
Post-Processor
- Execute some action after
sampler request
Configuration Elements
- To configure setting
22

23. Performance Testing
How to create & build a small JMeter script ?
23

24. Performance Testing
Get & Analyse result/report of JMeter
Zing News(http://news.zing.vn/) Genk (http://genk.vn/)
24

25. JMeter Plugins
Selenium Webdriver
25

26. JMeter Plugins
A plugin of JMeter, lots of great features (https://jmeter-plugins.org)
● PerfMon Metrics collector
● Response Times Over Time
● Stepping Thread Group
● Non-GUI console Status Logger
● Webdriver Sampler
● ...
JMeter Plugins
26

27. JMeter Plugins
Use selenium for performance testing
● Use real Browsers : Firefox, Chrome, Internet Explorer (IE)
● Write your WebDriver script as usual: Java, JavaScript, BeanShell, ...
JMeter Real Browser
8 GB, 4 core machine = 1000 users 8 GB, 4 core machine = 4-12 users
27

28. JMeter Plugins
Use selenium for performance testing
DEMO
28

29. A
Q
29

30. 30
