Pcdvpcu en ex9200-customer-presentation-1
The document provides an overview of the Juniper EX9200 programmable switch, highlighting its scalability, programmability, and flexibility for enterprise networking. It features high density, extensive protocol support, and automation capabilities, making it suitable for campus and data center deployments. The presentation emphasizes Juniper's commitment to innovation and investment protection, as well as the switch's ability to enhance business agility.
More Related Content
Similar to Pcdvpcu en ex9200-customer-presentation-1
Pcdvpcu en ex9200-customer-presentation-1
- 1.
- 2. 2 Copyright ©2013 Juniper Networks, Inc. www.juniper.net LEGAL DISCLAIMER This statement of direction sets forth Juniper Networks’ current intention and is subject to change at any time without notice. No purchases are contingent upon Juniper Networks delivering any feature or functionality depicted in this presentation.
- 3. 3 Copyright ©2013 Juniper Networks, Inc. www.juniper.net ENTERPRISE CORE SWITCHING Campus 1 Data Center 1 Data Center 2 Campus N Campus 2 Wired Devices Wireless Devices BYOD Virtual Desktop Desktop Backups Virtualization Automation Orchestration Network Overlays Multi-tenancy Campus Data Center CORE
- 4. 4 Copyright ©2013 Juniper Networks, Inc. www.juniper.net TAKING INFRASTRUCTURE FORWARD Handle growth North-south in campus East-west in data center Simplify infrastructure No Spanning Tree Scale up/down Enable network functions MPLS/VPLS Overlay networks Campus 1 Data Center 1 Data Center 2 Campus N Campus 2
- 5. 5 Copyright ©2013 Juniper Networks, Inc. www.juniper.net EX9204 EX9208 EX9214 INTRODUCING THE EX9200 PROGRAMMABLE SWITCH DELIVERING ENTERPRISE INNOVATION The “most programmable” enterprise core switch Programmable Flexible Scalable
- 6. 6 Copyright ©2013 Juniper Networks, Inc. www.juniper.net Scalable Logical scale High density Up to 13.2 Tbps chassis capacity 100GbE ready Programmable Programmable ASIC (Junos) Programmable control and management planes via open APIs Automation Flexible Campus- and data center-optimized Extensive protocol support Feature rich Future ready EX9200 OVERVIEW Juniper One Custom Silicon EX9204 EX9208 EX9214
- 7. 7 Copyright ©2013 Juniper Networks, Inc. www.juniper.net EX9200 PROGRAMMABILITY SoftwareSystemSilicon Junos Automation Junos SDK Native interfaces Custom Juniper ASIC Programmable packet forwarding engine Integration with leading orchestration applications VXLAN NVGRE MPLS over IP Business agility demands programmability SDN
- 8. 8 Copyright ©2013 Juniper Networks, Inc. www.juniper.net JUNIPER ONE CUSTOM SILICON Silicon ready for the next 10 years Packet Forwarding Engine Capability Current Merchant Silicon Future Merchant Silicon Competitive Custom ASIC Juniper One Programmable ASIC Investment Protection ✓ Overlay Gateway Routing ✓ Advanced MPLS ✓ Deep Buffers ✓ ✓ Advanced L3 ✓ ✓ Overlay Gateway ✓ ✓ ✓ MPLS ✓ ✓ ✓ ✓ L3 ✓ ✓ ✓ ✓ Advanced L2 ✓ ✓ ✓ ✓ L2 ✓ ✓ ✓ ✓ Logical Scale Across All Capabilities
- 9. 9 Copyright ©2013 Juniper Networks, Inc. www.juniper.net EX9200 DEPLOYMENT FLEXIBILITY COLLAPSING NETWORK TIERS = EX Series Virtual Chassis Access Aggregation Core Access Core / Aggregation Data Center EX9200 Access Core / Distribution Access Distribution Core Wireless Controller Campus EX9200 w/ Integrated Wireless Controller Combined Campus & Data Center Access Aggregation Core Wireless Controller Access Core / Aggregation EX9200 w/ Integrated Wireless Controller Simple, secure, virtualized networks
- 10. 10 Copyright ©2013 Juniper Networks, Inc. www.juniper.net EX9200 PROTOCOL FLEXIBILITY Combined Campus & Data Center Campus Data Center Extensive protocol support for campus and data center VPLS IP VXLAN NVGRE GRE MPLSIS-IS CAPWAP Investment Protection Representative of future capabilities
- 11. 11 Copyright ©2013 Juniper Networks, Inc. www.juniper.net EX9200 SYSTEMS 40 x 10/100/1000BASE-T 40 x 100FX/1000BASE-X SFP EX9204 Chassis EX9208 Chassis EX9214 Chassis 4 slots Switch Fabric, Routing Engine, power supply and fan tray resiliency Up to 1.6 Tbps chassis capacity 8 slots Switch Fabric, Routing Engine, power supply and fan tray resiliency Up to 4.8 Tbps chassis capacity 14 slots Switch Fabric, Routing Engine, power supply and fan tray resiliency Up to 13.2 Tbps chassis capacity Scalable switching & routing MPLS (VPLS, L3VPN, P2MP) Sub 50 msec convergence 1M MAC addresses 256K ACLs 256K IPv4/IPv6 routes 32K VLANs
- 12. 12 Copyright ©2013 Juniper Networks, Inc. www.juniper.net EX9200 LINE CARDS 40 x 10/100/1000BASE-T 40 x 100FX/1000BASE-X SFP Roadmap 1GbE Line Cards 10GbE Line Card 40GbE Line Card 100GbE Line Card 32 x 10GbE SFP+ Up to 240G throughput 4 x 40GbE QSFP+ Up to 120G throughput 2 x 100G CFP + 8 x 10GbE SFP+ Up to 240G throughput
- 13. 13 Copyright ©2013 Juniper Networks, Inc. www.juniper.net Deployed Extensively Why We Win JUNIPER ETHERNET SWITCHING Technology flexibility Performance Carrier-class reliability Over 22,000 customers, 15M+ ports Data center, campus, branch, SP Financials, healthcare, education #3 LAN switching vendor Delivering operational simplicity
- 14. 14 Copyright ©2013 Juniper Networks, Inc. www.juniper.net JUNIPER CORE SWITCH PORTFOLIO Campus Data Center QFabric EX8200 Performance Programmability EX9200 EX9204 EX9208 EX9214
- 15. 15 Copyright ©2013 Juniper Networks, Inc. www.juniper.net EX9204 EX9208 EX9214 WHY THE EX9200? Programmable Flexible Scalable EX9200 increases business agility!
- 16. 16 Copyright ©2013 Juniper Networks, Inc. www.juniper.net NEXT STEPS Let us build the best network for your business. Let us help solve your most challenging network problems. Let us show you how the EX9200 would fit into your network environment.
Editor's Notes
- #4 The core switch is literally the core of your network – switching all traffic in you key campus and data center facilities.[Click]However your campus networks are facing the tremendous challenge of supporting;the tremendous growth in the number of wired and wireless devices connected to the network,managing the employee owned and applications running on the network,new enterprise applications like virtual desktop, unified communications and HD video, orhandling desktop backups without disrupting the flow of business[click]Similarly in the data center, your core switch needs to be capable of supporting;server virtualizationdata center automation and orchestration,hypervisor network overlays such as VxLAN, andmulti-tenancy to give you better control of how you deliver applications to various parts of your business[Click]
- #5 To have your network provide the agility your business demands you a network core that will:Handle growth:North-South data traffic in campus driven by the increasing number of wired and wireless devices being in campus environments along with the growth in video and other rich media toolsEast-West in data center driven by the increases in server virtualization and application to application trafficSimplify yourinfrastructureEliminateSpanning Tree Protocol from your in the infrastructureAllow you to Scale up and scale down as your business needs dictateEliminate network tiers Reduce the number of physical devices in your network, and Reduce the number of managed devices in your network Enable network functionsSupport interoperation of multiple network protocols without additional hardware (ieMPLS/VPLS, Overlay networks and EVPN)Foster innovation
- #6 To address these challenges, Juniper isintroducing the EX9200 line of modular Ethernet core switches for campus and data center environments. The EX9200 addresses the challenges of supporting cloud applications, server virtualization, rich media collaboration tools, and of coping with the explosive growth of mobile devices by dramatically simplifying the network architecture and network operations.The EX9200 is programmable, flexible and scalable, making it well suited for both campus and data center core and aggregation environments. In fact, the EX9200 provides programmability at the silicon, system and networking layers.The EX9200’s programmability, coupled with its flexibility, scalability and carrier-class availability, allow it to dramatically simplify network architectures and operations, making it the best core and aggregation switch for the next decade.[click]
- #7 Three EX9200 switch models are available:The 4-slot EX9204The 8-slot EX9208 The 14-slot EX9214All EX9200 chassis are built on Juniper One custom silicon, the same silicon used in our industry-leading routers. All EX9200 switches also run Juniper’s Junos OS operating system. 1GbE (copper and fiber), 10GbE and 40GbE interface cards are available today; a 100GbE interface card is in development. Any combination of interface cards can be used in each of the EX9200 chassis.The key values of the EX9200 include programmability, flexibility and scalability.Programmability: The EX9200 is built on Juniper One custom silicon, a programmable ASIC featuring programmable control and management planes that allow Juniper to support new networking protocols such as VxLAN through a simple software update. Programmability extends beyond the silicon to the entire system, which supports automation capabilities to make it ready for SDN.Flexibility: The EX9200 has been optimized for both campus and data center core and aggregation environments, making it extremely flexible. The EX9200 can collapse network layers to simplify network architectures and operations. Future ready protocol support can be extended to include new protocols through simple software updates. The EX9200’s rich feature set includes:Network segmentation using MPLS, where one network can offer multiple segregated servicesConfiguration roll-backIn-service software updates In addition – the EX9200 is capable of hosting Juniper’s Virtual Wireless controller to integrate the abstracts the underlying hardware that runs wireless control servicesScalability: The system also provides the logical scale required to support any enterprise environment, including multi-tenancy and high volume VM and VDI deployments. The EX9200 scales to support more than 1 million MAC addresses, 256,000 IPv4 routes, 256,000 IPv6 routes, and 32,000 VLANs. The chassis capacity is up to 13.2 Tbps. The EX9200 lines provides five 9s of carrier-class platform availability and resiliency, plus sub-50 msec convergence to protect mission-critical data, voice and video experience following link failures. [click]
- #8 Enterprise networks are often viewed as impediments to business agility. It takes time to re-provision networks to support new virtual machines and applications. Changes are inherently risky and are vulnerable to human errors that can take your business down. The EX9200 addresses these challenges through programmability. In fact, the EX9200 is the most programmable core switch on the market.Programmability is implemented at the silicon, system and network levels. The EX9200 is built on the Juniper One custom silicon, or ASIC—the same ASIC used in Juniper’s proven and field-tested routing platforms. The EX9200 is the first product in its class to be built on a programmable ASIC, enabling Juniper to modify the ASIC’s behavior down to the Packet Forwarding Engine (PFE) and allowing support for new networking protocols such as VxLAN to be implemented via a simple software upgrade rather than a cumbersome hardware replacement. At the system level, EX9200 platforms support Junos Automation and the Junos SDK. The switches also provide the ability to support native interfaces for SDN automation tools such as Juniper’s Contrail , Puppet, OpenFlow and others. This level of programmability and automation reduces the time it takes to re-provision the network to support new applications from days or weeks to seconds while virtually eliminating “human risk.” At a softwarelevel, the EX9200 supports integration with leading orchestration applications such as VMWare and OpenStack, eliminating delays and errors caused by re-provisioning the network to support virtual machine or application mobility.[click]
- #9 Most switches use “Merchant Silicon” composed of off-the-shelf chip components for their Packet Forwarding Engines—the chipset that switches and routes individual packets. Built for the masses, Merchant Silicon restricts network product manufacturers’ ability innovate since they are limited by the capabilities of the chip. Delivering basic and advanced Layer 2 switching capabilities and some basic Layer 3 switching / routing capabilities such as MPLS, Merchant Silicon has its place in the market, supporting higher volume / lower cost platforms such as access switches.A core switch based on Merchant Silicon, however, cannot deliver business agility. Today’s core switches require advanced Layer 3 and deep buffering capabilities. Furthermore, business agility requires advanced MPLS and Overlay Gateway Routing capabilities, as well as the ability to support future, still evolving capabilities without requiring hardware replacements.[Click]Most important, Packet Forwarding Engines need to deliver all capabilities “at scale,” whether to one device or to hundreds of thousands. Capabilities cannot be sacrificed at the expense of scale.Juniper’s programmable ASIC is ready to support any network for at least the next 10 years.[Click]NOTE: Examples of vendors using Merchant vs Custom SiliconMerchant Silicon: Arista, HuwaiiCustom Silicon: Brocade, CiscoProgrammable Custom Silicon: Juniper
- #10 The EX9200 is ideal for simplifying campus, data center, and combined campus and data center network environments by collapsing network layers.In the campus, the EX9200 collapses the core and distribution layers; when used with Juniper access layer switches deployed in a Virtual Chassis configuration, the EX9200 also reduces the number of managed devices by more than 50% while eliminating Spanning Tree Protocol, dramatically simplifying the network architecture and network operations.[Click]Similarly, in the data center the EX9200 can be used to collapse core and aggregation layers; again, when used with Juniper access switches in a Virtual Chassis configuration, the EX9200 helps reduce the number of managed devices by more than 50% and eliminating STP from the network. [Click]In combined campus and data center environments, the EX9200 consolidates network layers to simplify the network architecture and operations.In all scenarios, the EX9200 delivers a simple, secure, virtualized network environment that increases enterprise business agility. [Click]
- #11 To further simplify network operations across campus and data center environments, the EX9200 has the ability to support for protocols such as GRE and CAPWAP for campus wireless deployments; and protocols like VXLAN and NVGRE in data center environments. Support for new protocols is provided via Junos Software updates—no hardware replacement required—providing extensive investment protection.
- #12 Three EX9200 chassis options provide full deployment flexibility:The EX9204 is a 4-slot, 6 U chassis that supports up to three line cards (two line cards with Switch Fabric and Routing Engine resiliency). The EX9204 also offers fan tray resiliency and supports up to four power supplies (110 or 220 VAC, or -48 VDC power input) for 1+1 or 2+2 redundancy configurations. Chassis capacity on the EX9204 is up to 1.6 Tbps.The EX9208 is an 8-slot, 8 U chassis that supports up to six line cards with Switch Fabric, Routing Engine and fan tray resiliency. The EX9208 supports up to four power supplies (110 or 220 VAC, or -48 VDC power input) for 2+2 or 3+1 redundancy. Chassis capacity on the EX9208 is up to 4.8 Tbps.The EX9214 is a 14-slot, 16 U chassis that supports up to 12 line cards (11 line cards with full Switch Fabric and Routing Engine resiliency and maximum throughput). The EX9214 offers fan tray resiliency and supports up to four power supplies (220 VAC or -48 VDC power input) divided into two power zones, each of which support 1+1 redundancy. Chassis capacity on the EX9214 is up to 13.2 Tbps.All EX9200 chassis provide a rich array of scalable switching and routing features, including:Extensive MPLS capabilities such as Virtual Private LAN Services (VPLS), Layer 3 VPN (L3VPN) and Point to Multipoint (PP2MP) capabilitiesSub 50 milli-second convergence time Significant logical scale such as support for 1 million MAC addresses, 256,000 access control lists (ACLs), 256,000 IPv4 or IPv6 routes, and 32,000 Virtual LANs (VLANs)
- #14 The EX9200 is the latest addition to Juniper Networks switching portfolio. Over 15 million EX Series and QFX Series switch ports have been deployed around the globe in more 22,000 unique customer networks, ranging from enterprise campus and branch environments to enterprise and service provider data centers. These networks are often found in the most demanding environments, including:Financials, where low latency is a critical requirementHealthcare, where network availability is crucial to patient safetyEducation, where mobile device usage by students pushes the network to the breaking pointJuniper’s EX Series and QFX Series platforms are selected by customers for their:Technology flexibilityPrice / performanceCarrier-class reliabilityMost importantly, Juniper is known for “delivering operational simplicity.”
- #15 Currently our core switch portfolio consists of the EX8200 and QFabricEX8200 is positioned in highly distributed campus or collapsed campus/data center deployments with four-member Virtual Chassis capabilities.QFabricremains our flagship architecture for the most demanding, high-performance data center environments looking for the greatest scale and ease of management. [Click]And now we are adding the EX9200 to the mix.EX9200 is positioned in campus and data center environments for customers who need a high degree of programmability and automation.EX9204 and EX9208 are positioned primarily in campus environments and will feature support for the Juniper Virtual Wireless Controller. EX9208 and EX9214 are positioned primarily in the data center for customers who need a high degree of programmability and automationBoth the EX8200 / EX9200 with Virtual Chassis technology and QFabric deliver the agility to change the network to keep pace with your business. [Click]
- #16 The EX9200 core Ethernet switch eases the challenges of supporting cloud applications, server virtualization, rich media collaboration tools, and of coping with the explosive growth of mobile devices by dramatically simplifying the network architecture and network operations.It’s programmable in silicon, as a system and within the network to support current and future networking protocols, automation tools and orchestration applications.It’s flexible enough to be used in both campus and data center environments. Its extensive protocol support allows it to operate in any environment using a single, common, portfolio of interface cards. It provides a rich set of switching and routing features investment protection well into the future.Lastly, the EX9200’s logical and physical scale, along with its 13.2 Tbps chassis capacity throughput and 100GbE capabilities, allow it to support the most demanding campus and virtualized data center environments.
- #17 [NOTE: Modify this slide as required for your specific customer engagement. Use it to leave the meeting with tangible next steps.]
