IOT WITH ARDUINO IN A NUTSHELL
Lecturer:
Prof. Dr.
Michael Stal
ENGINEERS NEVER FAIL
I have not failed. I've
just found 10,000 ways
that won't work.
[Thomas A. Edison]
INTRO QUOTE
“The Internet of Things tells us that
a lot of computer-enabled
appliances and devices are going to
become part of this system, too:
appliances that you use around the
house, that you use in your office,
that you carry around with yourself
or in the car. That's the Internet of
Things that's coming”
Vint Cerf, one of the
fathers of the Internet
GOALS OF THIS TUTORIAL
Having Fun
Learning how to use Open Source
Hardware/Software for building IoT
devices
Getting to know microcontroller boards
Building your own IoT device using low
cost hardware such as Arduino with
sensors/actuators
Focusing on the embedded side assuming
most of you are rather familiar with
desktops, servers
WHY DO WE USE ARDUINO IN THIS TUTORIAL?
Arduino provides low-cost, open source hardware
arduino.cc and vendors (Intel, TI, ...) offer compatible
boards
Big product ecosystem available (shields, boards,
displays, ...)
Large community exists
Low level programming with C/C++ helps learn the
fundamental concepts
It is much easier to learn & use more powerful boards
such as Raspberry Pi after understanding Arduino
WHY DO WE USE ARDUINO IN THIS TUTORIAL?
Arduino provides low-cost, open source hardware
arduino.cc and vendors (Intel, TI, ...) offer compatible
boards
Big product ecosystem available (shields, boards,
displays, ...)
Large community exists
Low level programming with C/C++ helps learn the
fundamental concepts
It is much easier to learn & use more powerful boards
such as Raspberry Pi after understanding Arduino
AGENDA
PART I: Presentation
What the heck is IoT good for?
Introduction to IoT hardware/software
Fundamentals of electronics
Some best practices
PART II: DIY - Experiments
Learning Arduino
PART III: Hackathon- teams of 3-4
Develop an IoT device
Refine and extend it
Present it to the other participants and get feedback
What you will need
Notebook (Linux, MacOS, Windows)
WiFi - provided by the conference organization
Arduino Starter Kit and components
Open Source Software to be downloaded from the
Internet
A Book on Arduino Practice
OPEN SOURCE SOFTWARE DOWNLOADS
Arduino IDE Download
https://www.arduino.cc/en/Main/Software
Processing IDE Download
https://processing.org/download/
Twitter 4J Download
http://twitter4j.org
Tutorial Processing and Twitter
http://codasign.com/tutorials/processing-and-twitter/
Node.js: http://nodejs.org
Johnny-Five JS: http://johnny-five.io
Java mail https://java.net/projects/javamail/pages/Home
Java RXTX Serial Communication
http://rxtx.qbang.org/wiki/index.php/Download
Eclipse for Java Developers
http://www.eclipse.org/downloads/packages/eclipse-ide-
java-developers/mars2
Arduino library for Processing
http://playground.arduino.cc/Processing2-arduino/Zip
Fritzing Circuit Modeling: http://fritzing.org
IOT DEVICES
Basic Recipe
Take a microcontroller or CPU board
Add sensors and actuators
Connect device to the Internet or use
Internet-based protocols
Control and monitor device using a Web
Interface
Different form factors from wearables, mobile
devices up to workstations Sensors CPU+Microcontroller Board
& Actuators
CONSUMER USAGE SCENARIOS
Wearables (watches, classes) that connect
users with each other and and with their
digital environment
Robots (e.g., for mowing the lawn or cleaning
rooms)
Control of lighting using mobile devices and
geofencing
Myriads of toy stories such as coffee machines
or cat feeding devices that can be controlled
remotely
OPENHAB
Most products (Philips Hue, NEST, Osram
Lightify, …) use proprietary approach
openHAB* as alternative
Open Source integration solution for home
automation systems
Based on Event Driven Architecture
Only precondition: availability of a JVM runtime
*HAB = Home Automation Bus
INDUSTRIAL CHALLENGE
How (i.e., with which system
architecture) can we integrate
from 100s to millions of devices
into large systems?
Magic Number: 50 Billions
If you think that is not relevant: large
factories in Japan may use up to 2 million
nodes
CASE STUDY I - CONTAINERS
Containers for transport of goods can get damaged
or lost
It is surprising how many containers disappear
Scenario:
Container integrates IoT device
On loading device gets information such as items,
recipients
Container regularly tracks GPS position and sends it
to sender
On changes such of pressure, temperature, moisture
or forces, IoT device sends events
CASE STUDY II –TRAFFIC INFRASTRUCTURE
Additional Scenario:
Traffic signals use IoT to measure traffic flow
Measurements over longer time period are stored in
Cloud
Data Analytics application analyzes data for optimization
of traffic control (using goals such as less traffic jams, less
pollution, …)
Decision Support System derives tactical optimizations to
improve strategy
Traffic controls can also work autonomously interacting
with other local traffic controls
Process is continuously repeated
CASE STUDY III – DECENTRALIZED SOLUTIONS
Connected robots or drones may collaborate as a swarm
static or ad-hoc connection
Scenario
Swarm receives task such as controlling a pipeline or a plant
Swarm members are coordinating their work to achieve
their joint goal
If necessary, swarm member can ask other members for
assistance
If a member must be recharged, it leaves swarm and moves
to charging station
Mission accomplished => swarm returns
CASE STUDY IV: INTERACTIVE MAINTENANCE
For maintenance of large or complex systems,
IoT devices interact with maintenance/service
staff
Maintenance/service staff uses VR solution
System visualized as 3D object which can be
analyzed with respect to its parts, state,
defects
User can interact with system
For each component/area/part a dedicated
IoT device is in charge
COMMUNICATION PROTOCOLS
To connect heterogeneous hardware
standardized communication protocols
are necessary
In IoT two widely used standards are
MQTT
CoAP
MQTT
MQTT originally meant MQ Telemetry Transport. Today, it
defines an OASIS- resp. ISO Standard (ISO/IEC PRF 20922)
follows the Publisher/Subscriber Pattern
requires a MQTT Broker for storing and and managing
messages and topics
defines Quality of Service: fire‘n forget, at-least-once, exactly-
once
uses different ports depending on security requirements
(unsecured port: 1883)
does not care about message content
Tools: mosquito (free broker), MQTT.fx (test client)
RESTFUL WITH COAP
REST is an Architecture Style (used by HTTP)
Principles:
Ressources support verbs such as GET, PUT, POST,
DELETE
Client-Server Interaction using standardized
interfaces
Statelessness
Caching
Layered Architecture
Call-dependent code generation
COAP - SUCCESS & FAILURE SCENARIOS
COAP - BENEFITS AND LIABILITIES
CoAP feels more natural than MQTT due
to its close relationsship with REST
CoAP implementations need more
ressources (memory)
=> Does not fit well in small memory
devices such as wearables, Arduino
ELECTRONICS
Dealing with IoT/Digitalization involves
dealing with embedded hardware and
electronics
We software engineers hoped to get rid of
these bottom layers by abstraction
Unfortunately, we must go back to the
roots
CIRCUIT DIAGRAMS
Typical elements in a circuit diagram
Battery/Cell: produces voltage
Lamp: consumes voltage
Switch: opens or closes circuit
Cable: connects producers and consumers
Current only flows in closed circuits
Base assumption: we only use independent voltage
sources (that produce a constant voltage), but no
independent current sources
CIRCUIT DIAGRAMS
Typical elements in a circuit diagram
Battery/Cell: produces voltage
Lamp: consumes voltage
Switch: opens or closes circuit
Cable: connects producers and consumers
Current only flows in closed circuits
Base assumption: we only use independent voltage
sources (that produce a constant voltage), but no
independent current sources
CURRENT FLOW
• In contrast to intuition current flows from
• Cathode (+) to
• Anode (-)
e-
e-
e-
e-
Physical flow of
electrons
- +
Technical flow of current
e-
e-
e-
e-
e-
e-
e- e-
WATER METAPHOR
• Water Analogy is a good and intuitive model for
thinking about electricity
• Current => water flow
• Voltage => energy potential provided by the
pump
• Resistor => object resisting water flow
• Switch => valve
© signon.com
RESISTORS
• Problem: consumers are only able to
consume a maximum current
• Solution: Resistors consume energy (by
converting electricity into heat), thus
reducing overall current
• All parts in a circuit have resistance,
even cables (which can mostly be
neglected)
• An open switch has infinite resistance
OHM’S LAW
Ohm’s Law: U = R x I
• Serial Resistors: Rserial = R1 + R2 + ….
Hint: it is common practice to combine resistors for better
achieving a specific resistance value
• Parallel Resistors: 1/Rparallel = 1/R1 + 1/R2 + ....
R1 R2
Same Current
Different Voltages
R1
R2
Same Voltage
Different Currents
Voltage = Resistance x Current
RESISTOR COLOR CODE
• 3 Bands: Band 1,2 are digits, Band
3 is multiplier, Additional Band is
Tolerance
• 4 Bands: Band 1,2,3 are digits,
Band 4 is multiplier, Additional
Band is tolerance
Color Multiplier Tolerance
Brown x 10 +/- 1%
Red x 100 +/- 2%
Orange x 1 K
Yellow x 10 K
Green x 100 K +/- .5%
Blue x 1 M +/- .25%
Violet x 10 M +/- .1%
Grey +/- .05%
Gold x .1 +/- 5%
Silver X .01 +/- 10% Example 3-Band Resistor: 27 x 100 K = 2.7 M Ohm with Tolerance +/- 1%
KIRCHHOFF’S VOLTAGE LAW
The sum of all voltages of any loop within a circuit is always zero
(you may count clockwise or counterclockwise)
U1
U2
U3
U4
U1+U2+U3+U4 = 0
Kirchhoff’s Voltage Law:
the sum of all power
consumers in a closed
loop equals the sum of all
power producers
In direction of current (+ => -)
generators: negative voltage
consumers: positive voltage
In opposite direction
generators: positive voltage
consumers: negative voltage
KIRCHHOFF’S CURRENT LAW
The sum of all in-going/out-going currents at a node is
always zero
I1 - I2 - I3 - I4 = 0
I2
I1
I3
I4
Incoming
currents
Outgoing
currents
Kirchhoff’s Current Law:
the sum of all incoming
currents at a node equals
the sum of its outgoing
currents
APPLICATION OF OHM’S LAW
Lets connect a voltage source with a resistor and a LED
An Arduino Uno board operates at 5V and allows to
draw 40mA current from an I/O pin and 200mA from
Vcc/Ground
A red LED’s forward voltage is 2V and its current should
be ca. 20 mA
The resistor must “absorb” the remaining 3V
(Kirchhoff’s Voltage Law)
Ohm’s Law: U = R x I => R = U / I = 3V/20mA = 175 Ohm
=> Use next higher resistor with 220 Ohm
(red/red/brown)
Warning: There are no fuses in the I/O pins of an
Arduino!
Use the 3-band color code:
Red/Red/Brown = 220 Ohm
4-band resistor would be
Red/Red/Black/Black
MICROCONTROLLERS IN A NUTSHELL
Microcontrollers (aka µC, uC or MCU) are
not CPUs, but complete systems on a
chip (SoC) with
Processor
Buses
Memory
Input/Output Peripherals
More than half of all microcontrollers are
still 8 bit
Typically, embedded systems software is
written in Assembly Language or C/C++
Source: http://www.mikroe.com/chapters/view/16/chapter-3-pic16f887-microcontroller/
Universal Synchronous/Asynchronous Receiver/Transmitter
Serial Peripheral Interface
Inter-Integrated-Bus
Special Function Registers
WDT
PWM
Capture, Compare, and Pulse Width Modulation- PIC18 µC
Reference Voltage
Deciphering the secret language of µC
USART
SPI
I2C
SFR
WDT
PWM
CCP
Vref
COMMON CONSTRAINTS
 Limited Memory (Arduino Uno has 32k)
 Limited Number of I/O Ports (Raspberry Pi got only a
few out-off-the-box)
 Limited Energy if not connected to a power line
 Limited Connectivity: Only Arduino Yun has
communication on board
LET‘S GO ON BOARD
Increasing number of open
source microcontroller boards
Excellent and cheap tools for prototyping
Useful to learn software development
basics for embedded systems
Scope: systems w/o stringent real-
time/dependability requirements
ARDUINO BOARD DESIGN
Analog
Reference
Digital I/O Pins
2-13 (9, 10, 11
with PWM =
Pulse Width
Modulation)
Digital Ground
Pins 1 & 2: Digital
I/O. When used
for communication
then Serial In/Out,
TX/RX
Reset Button: on
reset the
bootloader
restarts
In-Circuit Serial
Programmer: if
you need to
upload a
bootloader
Analog In: 0-5
Jumpers:
Toggling
between USB
power and
external power
(jumpers)
Power Connectors
connected with your
board. Not all boards use
5V!
External Power
Supply
USB Used to load
programs
(=sketches) to the
board, to power the
board, and for serial
communicationBoards (i.e., their
pins) have a
maximum current
they can handle.
Most Arduino
boards define a
maximum of 40
mA. Higher values
will cause
damage.
CPU with
16MHz
SENSORS & ACTUATORS
Pressure
Sensor
Ultrasonic
Gyro
Hall Sensor
Temperature
Sensor
Developers needs to add
specific code for reading or
writing actuator/sensor values
Usually attached through an
analog port
Specification of
chip/component explains
mapping between sensor
values and physical units
PWM (Pulse Width Modulation)
often used in digital outputs
(actuators) to vary intensity of
speed, volume, brightness, ...
SENSORS
ACTUATORS
SENSORS & ACTUATORS
Pressure
Sensor
Ultrasonic
Gyro
Hall Sensor
Temperature
Sensor
Developers needs to add
specific code for reading or
writing actuator/sensor values
Usually attached through an
analog port
Specification of
chip/component explains
mapping between sensor
values and physical units
PWM (Pulse Width Modulation)
often used in digital outputs
(actuators) to vary intensity of
speed, volume, brightness, ...
SENSORS
ACTUATORS
SHIELDS & HATS
Arduino shields (incl. program libraries) add
advanced logic
Built to fit on top of an Arduino board
Typically, provide the same pins like the
Arduino on top (for stacking of boards)
Examples:
Motor Shield (Arduino)
LCD Shield (Sparkfun)
Proto Shield (Seeed Studio)
GPS Shield (Adafruit)
WiFi Shield (AsyncLabs)
See http://shieldlist.org/
Caveat: Some shields or
libraries may not work
together
ELEGOO ARDUINO STARTER KIT
5pcs White LED
5pcs Yellow LED
5pcs Blue LED
5pcs Green LED
5pcs Red LED
1pcs RGB LED
5pcs 22pf Ceramic Capacitor
5pcs 104 Ceramic Capacitor
2pcs Photoresistor
1pcs Thermistor
5pcs Diode Rectifier (1N4007)
2pcs Electrolytic Capacitor (10UF 50V)
2pcs Electrolytic Capacitor (100UF 50V)
5pcs NPN Transistor (PN2222)
5pcs NPN Transistor (S8050)
1pcs Tilt Switc
5pcs Button (small)
1pcs 1 digit 7-segment Display
1pcs 4 digit 7-segment Display
1pcs Sound Sensor Module
1pcs LCD1602 Module ( with pin header)
1pcs Active Buzzer
1pcs Passive Buzzer
1pcs RTC Module
1pcs DHT11 Temperature and Humidity
Module
2pcs Potentiometer
1pcs Rotary Encoder Module
1pcs Joystick Module
1pcs Keypad Module
1pcs 5V Relay
1pcs IR Receiver Module
1pcs UNO R3 Controller Board
1pcs Breadboard
1pcs Servo Motor (SG90)
1pcs Stepper Motor
1pcs ULN2003 Stepper Motor Driver Board
1pcs Prototype Expansion
1pcs Power Supply Module
1pcs HC-SR501 PIR Motion Sensor
1pcs Ultrasonic Sensor
1pcs ADXL335 Module
1pcs 3V Servo Motor
1pcs MAX7219 Module
1pcs Remote
1pcs 9V 1A Power Supply
1pcs 65 Jumper Wire
1pcs Water Lever Sensor
1pcs USB Cable
1pcs 9V Battery with DC
1pcs RC522 RFID Module
10pcs Resistor (10R)
10pcs Resistor (100R)
10pcs Resistor (220R)
10pcs Resistor (330R)
10pcs Resistor (1K)
10pcs Resistor (2K)
10pcs Resistor (5K1)
10pcs Resistor (10K)
10pcs Resistor (100K)
10pcs Resistor (1M)
20pcs Female-to-male Dupont Wire
UNO R3 Arduino compatible board plus USB cable
with Transport Box
Component List:
I2C* – THE LOW-SPEED BUS
Multi-master serial single-ended computer
bus invented by Philips Semiconductors
Used in most open source hardware boards
for attaching low-speed peripherals (speed 10
Kb/s-100Kb/s; newer versions even up to 3.6
Mb/s)
Two bidirectional open-drain lines: Serial Data
Line (SDA) und Serial Clock (SCL)
Pull-up resistors to prevent floating signals
Wire library available (for accessing I2C)
o Master generates the clock and
initiates communication
o Slave receives clock and
responds when addressed by
master
o Master sends only if it detects
no start or stop bit sent by
another master
o Single Message or Multi
Message
o License free; only slave
addresses must be bought
* I2C = Inter-Integrated Circuit, invented by Philips Semiconductor Division, now NXP
SOLDERLESS BREADBOARDS
Connecting the Arduino to a breadboard is very
useful for designing circuits without soldering
When finished you may use a PCB (Printed
Circuit Board) instead
Breadboards consist of pin holes to place
components (terminal strip) as well as bus strips:
Terminal strip: all vertical lines of pin holes
Notch in the middle (where mostly ICs such as DIPs are
placed)
Bus strips for power supply, blue = ground
red = voltage
NOTCH
DRAWING CIRCUITS WITH FRITZING
I use the Open Source
Fritzing editor to draw my
own circuits
Download available from
http://fritzing.org (Mac
OSX, Windows, Linux) – it is
free but you may provide a
small donation
THE ARDUINO IDE*
Available for MacOS X, Windows, Linux at no cost
Based on Processing, built with Java
Subset of C/C++, (implementation of Wiring)
Uses gcc & avr-gcc libraries in the build process
C/C++ Libraries import
You may use gcc directly or within Eclipse for C++
Other languages such as Java can remotely connect to Arduino
using a wrapper on top of a RxTx native library
* Free guide available at http://www.me.umn.edu/courses/me2011/arduino/arduinoGuide.pdf
PROGRAMMING MODEL
When coding a sketch (= program) for microcontroller
boards like Arduino, two steps are necessary:
Initialization and Controlling & Monitoring
1. Initialization phase executed once at start-up time:
definitions and initialization of ports, connections,
...
2. Control Loop: „Endless“ loop in which application
can monitor and control the board
Application may terminate itself on specific events
Initialization
Control Loop
start
final
INTERRUPTS IN ARDUINO
Interrupts enable Event-driven Processing
3 Types of Interrupts:
External: mapped to ports 2 and 3 (INT0 and INT1).
Triggered when input signal is RISING, FALLING,
CHANGING, ...
Pin-Change: can be enabled for all Arduino signal pins.
Triggered on all events. You must figure out what
happened on what pin.
Timer Interrupt: Three 16 bit Timers, originally
exclusively dedicated for timing PWM signals. On a 16
MHz machine timer clock period can be configured
from 0.0625 uS to 8388.608mS (more details on
http://playground.arduino.cc/Code/Timer1)
int pin = 2;
volatile int state = LOW;
void setup()
{
pinMode(pin, OUTPUT);
attachInterrupt(0, blink, CHANGE);
// there is also detachInterrupt
}
void loop()
{
digitalWrite(pin, state);
}
void blink()
{
state = !state;
}
BLINK IS THE NEW „HELLO WORLD“
„Hello, World“...
for Electronics
=>
Blinking LED
// Pin 13 has an LED connected on most boards
int led = 13;
// the setup routine - runs after each reset:
void setup() {
// initialize digital pin as an output pin
pinMode(led, OUTPUT);
Serial.begin(9600); // start serial port
}
// infinite loop; HIGH & LOW are voltage levels!
void loop() {
Serial.println(“Hello, World”); // send string
digitalWrite(led, HIGH); // shine a light
delay(1000); // wait for a second
digitalWrite(led, LOW); // switch off LED
delay(1000); // wait for a second
}
Language based on
C/C++
Serial stream received by
host and displayed on the
IDE‘s Serial Monitor if
available
SWITCH DEBOUNCING
Problem: when pressing a switch or button
the signal can bounce for a while
Solution: Debouncing pattern
DEBOUNCING– CODE (SETUP)
// constants won't change. They're used here to set pin numbers:
const int buttonPin = 2; // the number of the pushbutton pin
const int ledPin = 13; // the number of the LED pin
// Variables will change:
int ledState = HIGH; // the current state of the output pin
int buttonState; // the current reading from the input pin
int lastButtonState = LOW; // the previous reading from the input pin
long lastDebounceTime = 0; // the last time the output pin was toggled
long debounceDelay = 50; // the debounce time; increase if output flickers
void setup() {
pinMode(buttonPin, INPUT);
pinMode(ledPin, OUTPUT);
// set initial LED state
digitalWrite(ledPin, ledState);
}
DEBOUNCING – CODE (LOOP)
void loop() {
int reading = digitalRead(buttonPin); // read the state of the switch into a local variable
if (reading != lastButtonState) { // If the switch changed, due to noise or pressing
lastDebounceTime = millis(); // first time measure
}
if ((millis() - lastDebounceTime) > debounceDelay) {
// whatever the reading is at, it's been there for longer
// than the debounce delay, so take it as the actual current state:
// if the button state has changed:
if (reading != buttonState) {
buttonState = reading;
// only toggle the LED if the new button state is HIGH
if (buttonState == HIGH) {
ledState = !ledState;
}
}
}
digitalWrite(ledPin, ledState); // set the LED
lastButtonState = reading; // this will be the lastButtonState in the next loop
}
ALTERNATIVE SOLUTION
Using the Debounce
Library (DRY)
Available in the
Arduino IDE
Implements the same
functionality in an
elegant way
// This code turns a led on/off through a debounced switch
#include <Debounce.h>
#define SWITCH 5
#define LED 13
// Instantiate a Debounce object with a 20 millisecond debounce time
Debounce debouncer = Debounce( 20 , SWITCH );
void setup() {
pinMode(SWITCH,INPUT);
pinMode(LED,OUTPUT);
}
void loop() {
// Update the debouncer
debouncer.update ( );
// Get the update value
digitalWrite(LED, debouncer.read() );
}
YET ANOTHER ALTERNATIVE
Alternatively, you might use hardware for
debouncing.
A capacitor is smoothing the signal
If the button is not pressed, the capacitor will charge
=> LOW signal on Arduino digital input pin
If the button is pressed, capacitor discharges quickly
=> HIGH signal on input pin
Arduino Digital Pin
Using Hardware
PULL-UP RESISTORS
Problem: circuits are subject
to electrical fluctuations which
may lead to an undefined state
Solution: use a pull-up resistor
so that when unpressed, 5V
will be on pin 2, and when
pressed will be low due to
connection with ground
Arduino internally provides
Pull-Up resistors for digital pins
void setup(){
Serial.begin(9600); // start serial connection
pinMode(2, INPUT_PULLUP); // pin 2 is input and uses the pull-up resistor
pinMode(13, OUTPUT);
}
void loop(){
//read the pushbutton value into a variable
int sensorVal = digitalRead(2);
//print out the value of the pushbutton
Serial.println(sensorVal); // send current value via serial communication to host
// Keep in mind the pull-up means the push-button's
// logic is inverted. It goes HIGH when it's open,
// and LOW when it's pressed. Turn on pin 13 when the
// button's pressed, and off when it's not:
if (sensorVal == HIGH) {
digitalWrite(13, LOW);
}
else {
digitalWrite(13, HIGH);
}
}
PULL-UP RESISTORS – CODE
USING PWM
Problem: for dimming a led,
..., we need to change the
actual current continuously,
but how?
Solution: Use PWM (Pulse-
Width-Modulation) to
simulate an analog output
with variable current
Done by swítching the signal
on and off for specific time
intervals (duty cycles)
PWM is useful for fading a LED, changing DC Motor Speed, sending different tones to piezo buzzer
But it is not useful where non-discrete analog values are expected
PWM – CODE
int ledPin = 9; // LED connected to digital pin 9
void setup() {
// nothing happens in setup
}
void loop() {
// fade in from min to max in increments of 5 points:
for(int fadeValue = 0 ; fadeValue <= 255; fadeValue +=5) {
// sets the value (range from 0 to 255):
analogWrite(ledPin, fadeValue); // analog write on digital pin!
// wait for 30 milliseconds to see the dimming effect
delay(30);
}
// fade out from max to min in increments of 5 points:
for(int fadeValue = 255 ; fadeValue >= 0; fadeValue -=5) {
// sets the value (range from 0 to 255):
analogWrite(ledPin, fadeValue);
// wait for 30 milliseconds to see the dimming effect
delay(30);
}
}
LCD LIBRARY
Problem: How can we make
hardware such as the
LiquidChrystal display easily
usable
Solution: we need to provide a
library, e.g., the LiquidChrystal
library
to save wires use a 16x2 LCD Display
combined with an I2C circuit
16x2 LCD Display
Display connected to digital ports
Potentiometer used to control brightness of display
USING LIBRARIES – CODE
#include <LiquidCrystal.h> // the library for using LCDs
// initialize the library with the numbers of the interface pins
LiquidCrystal lcd(12, 11, 5, 4, 3, 2);
void setup() {
// set up the LCD's to 16 numbers and 2 rows
lcd.begin(16, 2);
// Print a message to the LCD.
lcd.print("hello, world!");
}
void loop() {
// set the cursor to column 0, line 1
// (note: line 1 is the second row, since counting begins with 0):
lcd.setCursor(0, 1);
// print the number of seconds since reset:
lcd.print(millis()/1000);
}
LCD DISPLAY OVER I2C
For using a standard 16x2 LCD display we had to use 6
pins on our Arduino plus Vcc plus Gnd
A better option is the I2C bus where we need 2(!!!)
pins plus Vcc plus Gnd
Fortunately, we have a I2C connected LCD Display in
our kit
Connect
LCD Vcc to Arduino 5V
LCD Gnd to Arduino Gnd
LCD SDA to Arduino Analog A4
LCD SCL to Arduino Analog A5
Potentiometer on back side of LCD to adjust
brightness
ADDING I2C LCD LIBRARY TO YOUR SKETCH
Create a new sketch
Download ZIP-Library from
http://github.com/marcoschwartz/LiquidCrystal_I2C
Add it to the Arduino Library
Create new sketch
Then
Select IDE menu Item Sketch
Select Include Library
Select Add .zip Library
Select downloaded file
CODE – PRINTING ON LCD
lcd.init(); // initialization of LCD
lcd.backlight(); // brighten backlight
lcd.setCursor(0,0); // move cursor to first line
lcd.print(”building iot"); // write to display
lcd.setCursor(0,1); // move cursor to second line
lcd.print(”Hackathon"); // write to display
CODE - DECLARATIONS
#include <Wire.h> // communication protocol library
#include <LiquidCrystal_I2C.h> // liquid crystal display library
LiquidCrystal_I2C lcd(0x27,16,2); // Define LCD device on I2C address 0x27
// with a 16 x 2 characters display
SCANNING FOR I2C DEVICES
#include <Wire.h> // communication library
int count = 0;
void setup() {
Serial.begin (9600);
Wire.begin(); // starting communication
}
void loop(){
count = 0;
for (int i = 1; i < 255; i++) { // scanning through all 256 IDs of I2C devices
Wire.beginTransmission (i); // attempt communication with device ID i
if (Wire.endTransmission () == 0) { // success => device found
Serial.print (”Device found on ");
Serial.print (" 0x");
Serial.println(i, HEX);
count++;
} // end if
delay (5);
} // end loop
Serial.print ("Found "); Serial.print (count); Serial.println (" devices");
}
TEMPERATURE SENSOR 18B20
Now, we are going to measure temperature with
the 18B20 chip
We only need one analog pin A2 for this purpose
The sensor supports the OneWire protocol
You’ll need two libraries
OneWire:
https://github.com/PaulStoffregen/OneWire
18B20 also known as Dallas:
https://github.com/milesburton/Arduino-
Temperature-Control-Library
SIDE NOTE
1-Wire is a protocol for communicating
with sensors over 1 single line
One Master (microcontroller), multiple
slaves
Only master can initiate communication
Every sensor has unique ID
Similar to I2C but with lower speed.
Benefit: longer range
CIRCUIT DIAGRAM
CODE – INITIALIZATION & SETUP
#include <OneWire.h>
#include <DallasTemperature.h>
#define ONE_WIRE_BUS 2 // Data wire => digital pin 2 on the Arduino
OneWire oneWire(ONE_WIRE_BUS); // init 1-Wire bus
DallasTemperature sensors(&oneWire); // passing 1-Wire reference to sensor
void setup(void)
{
// get serial data to PC
Serial.begin(9600);
// start sensor transmissions
sensors.begin();
}
CODE – CONTROL LOOP
void loop(void)
{
// start receiving temperatures
Serial.println(" Arduino as master starts retrieving temperatures");
sensors.requestTemperatures();
Serial.print(”Actual temperature: ");
Serial.println(sensors.getTempCByIndex(0));
// …ByIndex(0) => get first temperature sensor
}
TEMPERATURE SENSOR TMP36
We could also have used the analog TMP36
temperature sensor instead
This sensor is connected to an analog port
In the circuit A0 is connected with the analog signal
pin of the sensor
Calculating voltage at Pin A0 (5V Arduino):
milliVolts = (reading from ADC) * (5000.0 / 1024)
Temperature in C°:
temperature = (milliVolts – 500.0) / 10
Note: precision is 0.1°
STARTER KIT DHT11 TEMPERATURE AND HUMIDITY
SENSOR
DHT11
Ultra low cost
3 to 5V power and I/O
2.5mA max current use during conversion
(while requesting data)
Good for 20-80% humidity readings with
5% accuracy
Good for 0-50°C temperature readings
±2°C accuracy
No more than 1 Hz sampling rate (once
every second)
Body size 15.5mm x 12mm x 5.5mm
4 pins with 0.1" spacing
CIRCUIT
CODE – INITIALIZATION & SETUP
#include <DHT.h>
#define DHTPIN 2 // data pin
#define DHTTYPE DHT11 // DHT 11
dht(DHTPIN, DHTTYPE); // used to access sensor
int chk;
float hum; // humidity
float temp; // temperature
void setup(){
Serial.begin(9600); // Serial monitor output
dht.begin(); // start measuring
}
CODE – CONTROL LOOP
void loop(){
hum = dht.readHumidity(); // read humidity
temp= dht.readTemperature(); // read temperature
Serial.print("Humidity: "); // print it on serial monitor
Serial.print(hum);
Serial.print(" %, Temp: ");
Serial.print(temp);
Serial.println(" Celsius");
delay(1000); // wait for one second
}
ADDING DHT SENSOR LIBRARY
YET ANOTHER CHALLENGE
We want to connect eight LEDs
to our Arduino
Doing this, only a few digital
pins would be left for other
purposes
Moreover, what happens if we
need to connect more LEDs
than we got digital pins on the
Arduino?
SOLUTION: USE THE SHIFT REGISTER 74HC595
A Shift Register gets a byte where each bit
controls an output pin Q0.. Q7 (pins 15, 1..7)
Shift registers can combinable (daisy-chain) over
pin 9 (carry-over)
Pin 9 would be connected to Pin 14 of next
74HC595
Pin 14: send data to register
Pin 12: put new data on output pins
Pin 11: clock that triggers all activities
Other Shift Registers may even offer 16 bits and integrated
resistors
The 74HC595 converts an 8-Bit binary number to its bits. It
acts as a multiplexer/demultiplexer.
CIRCUIT
DIAGRAM
74HC595 Arduino Color of Wire
14: DS Digital 11 purple
11: SH_CP Digital 12 yellow
12: ST_CP Digital 8 green
08: GND GND
16: Vcc 5V
13: OE GND
10: MR 5V
1 µF Capacitor prevents signal
floating on latch pin ST_CP
CODE – CONTROL LOOP
void loop() {
for (int byteVal = 0; byteVal < 256; byteVal++) {
// latch pin ST_CP low => number not visible on the output of the shift register
digitalWrite(pinLatch, LOW);
// store the byte in the register:
shiftOut(pinData, pinClock, MSBFIRST, byteVal);
// latch pin set to high => byte value visible at 74HC595 output pins
digitalWrite(pinLatch, HIGH);
// take a break
delay(200);
}
}
CODE – INITIALIZATION & SETUP
int pinLatch = 8; // connection to ST_CP => latch
int pinClock = 12; // connection to SH_CP => clock
int pinData = 11; // connection to DS => data
void setup() {
pinMode(pinLatch, OUTPUT); // all three pins are output pins
pinMode(pinClock, OUTPUT);
pinMode(pinData, OUTPUT);
}
NEOPIXEL WS2812
LED built by adafruit - can be
controlled using a single data line
Controller + LED = WS2812
Often sold as LED strips
You may cut the strip in multiple strips
Simple Connection
Arduino Pin Dx -> WS2812 Data
Arduino 5V -> WS2812 5V
Arduino GND-> WS2812 GND
USING A WS2812 LIBRARY
adafruit Neopixel library:
https://github.com/adafruit/Adafruit_NeoPixel
Other option FastLED library (supports other
LED types as well):
https://github.com/FastLED/FastLED/releases
Lightweight library:
https://github.com/cpldcpu/light_ws2812
PARAMETERS FOR NEOPIXEL LIBRARY USAGE
Parameter 1 = number of pixels in strip
Parameter 2 = Arduino pin number (most are valid)
Parameter 3 = pixel type flags, add together as needed:
NEO_KHZ800 800 KHz bitstream (most NeoPixel
products w/WS2812 LEDs)
NEO_KHZ400 400 KHz (classic 'v1' (not v2) FLORA pixels,
WS2811 drivers)
NEO_GRB Pixels are wired for GRB bitstream (most
NeoPixel products)
NEO_RGB Pixels are wired for RGB bitstream (v1 FLORA
pixels, not v2)
• NEO_RGBW Pixels are wired for RGBW bitstream
(NeoPixel RGBW products)
• For non-Adafruit products you might need to
download and use proprietary library
CODE – SETUP
include <Adafruit_NeoPixel.h>
#ifdef __AVR__
#include <avr/power.h>
#endif
#define PIN 8 // Arduino pin connected to data-in of LED strip
#define NO_OF_LEDS 16 // length of strip
// for parameters see strandtest in adafruit examples
Adafruit_NeoPixel pixels
= Adafruit_NeoPixel(NO_OF_LEDS, PIN, NEO_GRB + NEO_KHZ800);
void setup() {
pixels.begin(); // Initializing library
}
CODE – LOOP
void loop() {
// first LED: 0, second: 1, third : 2, ...
for(int i = 0; i < NO_OF_LEDS; i++) {
pixels.setPixelColor(i, pixels.Color(255,0,0)); // set to red
pixels.show(); // Send pixel color to strip
delay(1000); // wait for a second
}
}
DC MOTORS
Problem: Connecting a
low current Arduino with
a high current consumer
Solution:
Transistor (npn) to separate
both circuits
Potentiometer to let user
vary the speed
Diode to prevent any
induced current from
damaging the circuit
Source: http://www.dummies.com/how-to/content/how-to-control-the-
speed-of-a-dc-motor-with-the-ar.html
DC MOTORS – CODE
int potPin = A0; // potentiometer on analog pin A0
int motorPin = 9; // motor on digital pin 9
int potValue = 0;
int motorValue = 0;
void setup() {
Serial.begin(9600);
}
void loop() {
potValue = analogRead(potPin);
// map maps from [0, 1023] to [0, 255]
motorValue = map(potValue, 0, 1023, 0, 255);
analogWrite(motorPin, motorValue); // set speed
Serial.print("potentiometer = " );
Serial.print(potValue);
Serial.print("t motor = ");
Serial.println(motorValue);
delay(2);
}
ALTERNATIVE SOLUTION
Use a motor shield (several available)
Can support multiple motors (brushed dc motor, stepper, servo)
Motor shields leverage the H-bridge L298P
ALTERNATIVE – CODE (SETUP)
const int
PWM_A = 3,
DIR_A = 12,
BRAKE_A = 9,
SNS_A = A0;
void setup() {
// Configure the A output
pinMode(BRAKE_A, OUTPUT); // Brake pin on channel A
pinMode(DIR_A, OUTPUT); // Direction pin on channel A
// Open Serial communication
Serial.begin(9600);
Serial.println("Motor shield DC motor Test:n");
}
ALTERNATIVE – CODE (LOOP)
void loop() {
// Set the outputs to run the motor forward
digitalWrite(BRAKE_A, LOW); // setting brake LOW disable motor brake
digitalWrite(DIR_A, HIGH); // setting direction to HIGH: motor will spin forward
analogWrite(PWM_A, 255); // Set the speed of the motor, 255 is the max value
delay(5000); // hold the motor at full speed for 5 seconds
Serial.print("current consumption at full speed: ");
Serial.println(analogRead(SNS_A));
// to be continued
ALTERNATIVE – LOOP CONT’D
// Brake the motor
Serial.println("Start brakingn");
// raising the brake pin the motor will stop faster than the stop by inertia
digitalWrite(BRAKE_A, HIGH); // raise the brake
delay(5000);
…
// to be continued
ALTERNATIVE – LOOP CONT’D
// Set the outputs to run the motor backward
Serial.println("Backward");
digitalWrite(BRAKE_A, LOW); // setting againg the brake LOW to disable motor brake
digitalWrite(DIR_A, LOW); // now change the direction to backw: LOW DIR_A pin
analogWrite(PWM_A, 255); // Set the speed of the motor
delay(5000);
Serial.print("current consumption backward: ");
Serial.println(analogRead(SNS_A));
…
ALTERNATIVE - END OF LOOP
// now stop the motor by inertia, motor will stop slower than with brake function
analogWrite(PWM_A, 0); // turn off power to the motor
Serial.print("current brake: ");
Serial.println(analogRead(A0));
Serial.println("End of the motor shield test with DC motors. Thank you!");
while(1);
}
SERVO CONTROLLED
BY POTENTIOMETER
Goal:
• Read potentiometer input, map value
to 0..180 degrees, and move servo
to that position
Parts:
• Genuino/Arduino Uno
• Potentiometer
• Servo Motor
• Jumper Wires
CODE
#include <Servo.h> // this library is provided in the Arduino IDE library folder
Servo hs53; // create servo object to control a servo
int potpin = 0; // analog pin A0 is connected to potentiometer
int val; // variable to read the value from the potentiometer
void setup() {
hs53.attach(9); // attaches the servo on pin 9 to the servo object
Serial.begin(9600); // starts serial data transfer to PC
}
void loop() {
val = analogRead(potpin); // reads value from potentiometer (value between 0 and 1023)
val = map(val, 0, 1023, 0, 180); // scale it to use it with the servo
//(position between 0 and 180)
hs53.write(val); // sets the servo position according to the scaled value
delay(15); // waits for the servo to get to new position
Serial.println(val); // send the new servo position
}
EXAMPLE PROJECT TRAFFIC LIGHT
Building a Traffic Light with
LEDs and a Piezo speaker that
signals red or green.
CIRCUIT LAYOUT
• Genuino/Arduino Uno
• Red, Green, Yellow LED
• 3 pcs 220 Ohm Resistors
• Piezo Speaker
• Jumper Wires
Goal:
• Get used to controlling LEDs and
piezo speakers
CODE - DECLARATIONS
// Simple Arduino sketch for a stand-alone traffic light by M. Stal, (c) 2016
int red = 9; // red LED on Pin 9
int yellow = 10; // yellow LED on Pin 10
int green = 11; // green LED on Pin 11
int loudspeaker = 6; // Loudspeaker on Pin 6
int REDPHASE = 5000; // Duration Red in msecs
int BEFOREGREEN = 2000; // Duration Before Green
int GREENPHASE = 10000; // Duration Green
int BEFORERED = 2000; // Duration Before Red
int IR = 0; // Interrupthandler IR called on CHANGE
int TONE_DELAY = 50; // Delay between tones
CODE - INITIALIZATION
// the setup routine runs once when you press reset:
void setup() {
// initialize the digital pins as output.
pinMode(red, OUTPUT);
pinMode(yellow, OUTPUT);
pinMode(green, OUTPUT);
pinMode(loudspeaker, OUTPUT);
Serial.begin(9600); // for talking to PC
}
CODE – UTILITY FUNCTIONS I
void redHigh() {
digitalWrite(red, HIGH);
Serial.println("Red on");
}
void redLow() {
digitalWrite(red, LOW);
Serial.println("Red off");
}
void toneSignalRed() {
for (int i = 0; i < 10; i++) {
tone(loudspeaker, 440);
delay(100);
tone(loudspeaker, 360);
delay(100);
}
noTone(loudspeaker);
}
…
Functions for setting signals (=
LEDs)
CODE – UTILITY FUNCTIONS II
void redPhase() {
Serial.println("Red Phase");
redHigh();
toneSignalRed();
yellowLow();
greenLow();
delay(REDPHASE);
beforeGreen();
}
void beforeGreen() {
Serial.println("Before Green Phase");
redHigh();
yellowHigh();
greenLow();
delay(BEFOREGREEN);
greenPhase();
}
…
Applying the State pattern with
“functions for states”
Red Phase
Green Phase
Yellow before
Green
Yellow before Red
CODE – HANDLING INTERRUPTS
void emergencyHandler() {
for (int i = 0; i < 10; i++) {
tone(loudspeaker, 240);
delay(TONE_DELAY);
tone(loudspeaker, 160);
delay(TONE_DELAY);
tone(loudspeaker, 440);
delay(TONE_DELAY);
}
}
Reminder:
Interrupt 0 is associated with Pin 2
Interrupt 1 is associated with Pin 3
Interrupt handlers called on defined
events at these pins
Example: Interrupt handler is called
when switch is pressed
CODE – MAIN LOOP
// the loop routine runs over and over again forever:
void loop() {
noTone(loudspeaker);
attachInterrupt(IR, emergencyHandler, CHANGE);
redPhase(); // state machine starts with red
}
ARDUINO + ESP8266
ESP8266:
Chip from Espressif for under
5 € that supports Wifi
With 3.3V logic
Maybe used standalone as an
Arduino compatible MCU
Or as a peer of the Arduino
board for handling
communication
Different versions: we’ll use
the ESP-01
CHALLENGE 2: 2 SERIAL PORTS OF ARDUINO
NECESSARY
Arduino communicates with ESP8266 and
host computer
Solution 1 (rich man‘s approach): Use
Arduino Mega
Solution 2: Use software serial
#include <SoftwareSerial.h> // Simulierter serieller Port
#define ESP_RX 2
#define ESP_TX 3
SoftwareSerial Serial1(ESP_RX, ESP_TX);
CHALLENGE 1: DEALING WITH DIFFERENT LOGIC
LEVELS
We cannot directly connect the 3.3V
ESP8266 to the 5V-Arduino
Solution 1 (poor man‘s approach): Voltage
divider using resistors
Solution 2: Logic Level Converter
CODE
void setup()
{
Serial.begin(9600);
Serial1.begin(115200);
}
void loop()
{ // read messages from ESP-01
while (Serial1.available()) {
Serial.write(Serial1.read());
}
// write messages to ESP-01
while (Serial.available()) {
Serial1.write(Serial.read());
}
}
Use Serial Monitor with 9600 Baud. Select
Both NL & CR.
AT => OK
AT+GMR => Version
AT+RST => Reset
AT+CWLAP => List of WLAN APs
Connect:
AT+CWJAP_DEF=“SSID”,”PASSWORD”
AT+CIFSR => IP/MAC
SAMPLE CIRCUIT
Arduino Uno as Bridge + Breadboard Power
Component
Install boardmanager in Arduino IDE:
http://arduino.esp8266.com/stable/package_esp8266com_index.json is
added in Arduino>Preferences >Add Additional
Board Managers URLs
Go to Tools>Board>Boards Manager and select
ESP board: Tools>Board>Generic ESP8266
Module
Restart IDE
Select right port in Tools>Port
To check it use File>Examples>ESP8266/Blink
USING ESP8266 AS WIFI SHIELD
On Uno we will use
Pin 2 as RX Port
Pin 3 as TX Port
In Arduino IDE search for
WiFiEsp Library and include it
For example, see articles 23a
and 23b in archive
COMMUNICATION BETWEEN TWO ARDUINOS
Connect two Arduinos over serial
line: Tx to Rx and Rx to Tx (yellow
and green wire)
Don’t forget to also connect Gnd to
Gnd (blue wire)
One Arduino is sending numbers to
the second Arduino, …
… second Arduino blinks (LED on
digital pin 8) <received number> + 1
times
SERIAL COMMUNICATION
TX
RX
RX
TX
ArduinoOther
System
e.g. USB
of PC or
other
Arduino
2 lines: one for
sending (TX) on pin 1,
one for receiving (RX)
on pin 0
Arduino MEGA has
several serial
communication lines,
UNO and NANO have
only one
10100011 10110100 01111111 11010101 11011011
01100111 00000000 10110101 11001111 00010101
RX/TX COMMUNICATION
Arduino to Arduino
Arduino to PC
PC to Arduino
Server to Arduino
Arduino to Server
CODE – SKETCHES SENDER & RECEIVER
void setup(){ // init. serial communication line
Serial.begin(9600);
}
void loop(){ // send numbers 1 to 10 all the time
for (int count = 1; count <= 10; count++) {
Serial.println(i); //Send to receiver
delay(7000); // let the other board work
}
}
int val;
const int led = 8;
void setup(){
Serial.begin(9600); // init. serial comm.
pinMode(led, OUTPUT); // pin with LED
}
void loop(){ // recv. value n and blink LED n times
int incoming = Serial.available(); // get data
if (incoming > 0) blink(Serial.parseInt());
}
void blink(int howOften) { // blink LED
for (int j = 0; j < howOften; j++) {
digitalWrite(led, HIGH); // LED on
delay(300);
digitalWrite(led, LOW); // LED off
delay(300);
}
delay(1000); // break to better separate events
}
SENDING ARDUINO RECEIVING ARDUINO
DESKTOP TO ARDUINO - CODING OPTIONS
• This presentation introduces three choices
for communicating with an Arduino over
serial comm. (USB)
• We could have also used Arduino + WiFi-
shield or Bluetooth-shield
• Or nodemcu which can also be
programmed using the Arduino IDE
• Processing:
• Implemented in Java
• IDE was base for Arduino IDE
• For developers, artists, …
• Java:
• RXTX library
• JavaScript:
• Server-side JS using node.js
• Johnny-five library
INTERFACE TO PROCESSING
• Problem: How can we
access Arduino from
Processing?
• Solution: use the
Processing library
• Based on Firmata:
generic protocol for
communicating with
microcontrollers like the
Arduino from software on a
host computer. Arduino IDE based on Processing. Processing language was developed as a
subset of Java to support visual artists, designers, young programmers, .... It
provides stunning Animation, Simulation, Graphics.
SERIAL COMMUNICATION BETWEEN ARDUINO AND
PROCESSING
Processing IDE written in Java for artists, electric engineers, SW developers
Arduino IDE is based on processing
Processing IDE Arduino IDE
CODE – ARDUINO SKETCH
void setup(){
Serial.begin(9600);
}
void loop(){
// map analog value from (0,1023) to (0,255)
// will be used as a RGB value
int val = map(analogRead(A0), 0, 1023, 0, 255);
// write result to serial line
Serial.println(val);
// time to relax
delay(70);
}
Task:
• Read potentiometer
• send value over serial line
CODE – PROCESSING SKETCH
import processing.serial.*; // use serial library
Serial port; // communication port
float potiVal = 0; // variable to hold read values from potentiometer
void setup(){ // used for initialization same as in Arduino
size(150,150); // draw colored rectangle with size 150 x 150
port = new Serial(this, Serial.list()[1], 9600); // access USB for serial communication
port.bufferUntil('n'); // read data from Arduino until NEWLINE
}
void draw(){ // In Processing there is draw() instead of loop()
background(potiVal,0, 0); // draw red rectangle with brightness depending on received value
}
void serialEvent (Serial port){ // called whenever serial data is available
potiVal = float(port.readStringUntil('n')); // read data until NEWLINE; value is in [0, 255]
}
In your case Serial.list()[0] might
be the right port. You may also
directly specify the port such as
“COM3” (Windows) or “/dev/<tty-
usb>” in (Linux, Mac OS)
Task:
• Obtain value from port
• Draw rectangle with Red = value received
import processing.serial.*;
import cc.arduino.*;
Arduino arduino;
int ledPin = 13; // standard led on board
void setup()
{
println(Arduino.list()); // all detected Arduinos
// we use the first one
arduino = new Arduino(this, Arduino.list()[0], 57600);
arduino.pinMode(ledPin, Arduino.OUTPUT);
}
void draw() // draw instead of loop
{
arduino.digitalWrite(ledPin, Arduino.HIGH);
delay(1000);
arduino.digitalWrite(ledPin, Arduino.LOW);
delay(1000);
}
DIRECT ACCESS TO ARDUINO FROM PROCESSING - CODE
EXAMPLE
Include libraries
Arduino(Firmata) in your
sketch (Menu Item Sketch)
Sketchbook is a subfolder in
in your Documents folder.
The link to the library is in
the download slide of this
presentation.
USING JAVASCRIPT
• What we need
• Node.js http://nodejs.org (JavaScript Server
Framework)
• Johnny-Five http://johnny-five.io (JavaScript
Library for accessing Arduinos, BeagleBone,
Raspberry Pi, …)
• Installation:
• Install node.js
• Use the Node Package Manager to install
Johnny-Five: > npm install johnny-
five
• In the Arduino IDE select
File/Examples/Firmata/StandardFirmata and
upload it to your Arduino boards
var five = require("johnny-five");
var board = new five.Board();
board.on("ready", function() {
var led = new five.Led(13);
led.blink(500);
});
+
JOHNNY-FIVE EXAMPLE
var five = require("johnny-five");
var board = new five.Board();
board.on("ready", function() {
// Create a standard `led` component
// on a valid pwm pin
var led = new five.Led(11);
led.pulse();
// Stop and turn off the led pulse loop after 10 seconds (shown in ms)
this.wait(10000, function() {
// stop() terminates the interval, off() shuts the led off
led.stop().off();
});
});
USING JAVA
• We need the RXTX libraries
• Get RXTX libs from http://rxtx.qbang.org/wiki/index.php/Download
• Install libraries:
• RXTXcomm.jar (for all OS)
• librxtxSerial.{jnilib | dll | so} for your OS
• Make sure, Firmata is installed on your Arduino (see Johnny-Five slides)
• Make sure, that there is no lock (such as /var/lock on Unix). If it is there, unlock using
sudo chmod go+rxw /var/lock)
EXAMPLE
Example taken from:
http://stackoverflow.com/questions/90447
58/gnu-io-portinuseexception-unknown-
application
Read the DrDobbs tutorial on:
http://www.drdobbs.com/jvm/control-an-
arduino-from-java/240163864
ARDULINK
• To make it even easier, add Ardulink see:
http://www.ardulink.org
ONLINE SCENARIOS
• Retrieve e-mail and initiate an action on
Arduino whenever special
subject/header was found in mail
• I have written an example how to
access mail from Java:
https://dl.dropboxusercontent.com/u/2
228034/JavaMailTest.java
• You’ll need to obtain javax.mail
(JavaMail) and include it in your build
path:
https://java.net/projects/javamail/page
s/Home#Download_JavaMail_Release
• You may use Twitter4J to access tweets:
http://twitter4j.org/en/index.html
• You may also provide a Web Server with
JavaScript accessing the Arduino, i.e., a
Dashboard
EVEN MORE OPTIONS FOR WRITING ARDUINO
PROGRAMS
• For this list of development tools
including links visit
http://playground.arduino.cc/Main/DevelopmentTools
ARDUINO SIMULATORS
• Simulator for
those with
limited tinkering
capabilities or
without interest
• Virtronics not
perfect, but so
far the best
solution I found
for small budget
Running my
Traffic Lighht
example
HACKATHON COMPETITION
Invent a cool IoT device in groups of two or three
Use hardware components you got (which is pretty
obvious)
Examples:
Traffic lights on two Arduinos, one is the master, the other
one the slave. Master is configurable via Internet.
Thermometer with temperature being displayed as binary
code on 8 LEDs or as text on LCD display and obtained via
serial communication
Safe locked and unlocked by Arduino when pressing the
right keys. Alarm is send to user when safe is opened
Clock with temperature display: values can be retrieved
over Internet access
LAST WORDS: THE PAIN OF ENGINEERING
The major difference between a
thing that might go wrong and a
thing that cannot possibly go
wrong is that when a thing that
cannot possibly go wrong goes
wrong, it usually turns out to be
impossible to get at and repair.
[Douglas Adams]
ADDENDUM A: USEFUL TOOLS & INSTRUMENTS
MVP - MOST VALUABLE POWERTOOLS
Multimeters: 20-40€
current, voltage (AC/DC and DC),
resistance, diode testing, capacitance,
inductance
Oscilloscope: ca. 300€
high bandwidth, frequency counter, high
sampling rate, 2 channels plus one
external channel
Variable Power Supply: 50-80€
variable setting of DC output voltage &
current (e.g., 0-30V, 0-5A)
ADDENDUM B: BUILD YOUR OWN ARDUINO
BUILDING YOUR OWN ARDUINO
Bill of Material
• 1 x Processor ATMEGA328P DIP
• Optional: 1 x 28 Pin Socket Holder
• 1 x Breadboard (840)
• 1 x Pushbutton
•16 MHZ Oscillator
• 2 x Ceramic Capacitors 22pF
• 1 x Green Led
• 1 x Red Led
• 1 x1N4001 Diode
• 1 x LM8705 Voltage Regulator
• 1 x Electrolyt Capacitor 100yF
• 1 x Electrolyt Capacitor 10yF
• 1 x 10 KOhm Resistor
• 1 x 220 Ohm Resistor
• Wire
• 1 x Battery/Power Supply or
• FTDI breakout board
See also http://www.arduino.cc/en/Main/Standalone
USING ARDUINO UNO BOARD AS PROGRAMMER
• You may also buy a programmer or use an
original Arduino Board to program your
atmega and then move the chip to your DiY
board
• But you may also use an Arduino Uno as a
programmer
• Based on SPI (Serial Peripheral Interface):
allows to upload programs to Microcontroller
• Select Uno as board i the tools menu and your
USB port in the Arduino IDE
• Select ArduinoISP (ISP = In-System Program) in
examples menu
• Run it
• If successful, upload Blink example to your DiY
board
Connect Arduino Board 5V, Gnd
to 5V/Gnd terminal of your
breadboard (red and black
wire)
(for larger boards with many
components use separate
power source instead)
Connect digital pin 10 of Uno
board to reset pin of your
atmega (green wire)
Connect digital pins 13, 12, 11
of Arduino Uno to pins 19, 18,
17 of your Arduino on the
breadboard (yellow wires)
BURNING A NEW BOOTLOADER
• Bootloader is functionality that communicates over serial line
for uploading your sketches
• Not used when connecting Arduino directly over SPI
• We overwrite boot loader whenever we upload a sketch over
SPI
• However, the original bootloader configures fuses (memory
chunks) to behave as an Arduino Board
• It makes sense to burn the bootloader once whenever you
use a new Arduino Microcontroller
• In Tools menu configure the board
type of your Arduino and the serial
port of your computer
• As programmer choose„Arduino as
ISP“
• Select Burn bootloader in Tools menu
• Select Blink example from IDE
• Hold shift key while pressing the run
button in IDE
• => Will upload sketch via Arduino Uno
board to your Arduino on a
breadboard
ADDENDUM C: OFTEN USED COMPONENTS IN
CIRCUITS
CAPACITORS, INDUCTORS, AND MORE
• Capacitors store power and smooth signals: available in
different materials (ceramic => poles do not matter ,
electrolyt. => poles do matter). ingredient for High-
Pass/Low-Pass/Band-Pass filters
• Inductors are coils that produce a magnetic field when
current flows, and induce current when moved through a
magnetic field: ingredient of transformators and motors
• Diodes (LEDs are diodes as well) let pass current through
in only one direction)
• Transistors used to build logical gates (like flip-flops) and
switches (to control and separate a high current circuit
from a low power circuit)
Capacitors
and
Inductors
have
dynamic
resistance
(impedance)
ICS
Examples
• 555 Timer IC: used as timer, pulse generator, ocsillator
• Half-Bridge (E.g., a SN754410 offers four half bridges) lets you change in
which direction current flows (e.g., motor movement clock- or anti-clock-
wise). It can control high-voltage circuits.
• Operational Amplifiers (e.g., 741, LM 358, LM386) : amplify input100s or
1000s of times => useful as comparators. In feedback mode different
transfer functions can be implemented
• Shift Registers (HC74HC595): take a byte, convert it to a bit-array with
each bit being an output signal. Example application: reduce number of
required pins of a microcontroller
• Opto couplers (e.g., PC817): let a circuit control another circuit without
being wire-connected (light used insteads)
• Darlington transistor (e.g., ULN2003) chains two transistors tofurther
increase the amplification: used to control motors
Visit http://arduino-
info.wikispaces.com/Popular-
ICs to see more details
ADDENDUM D: BRIEF DETOUR - IMPLEMENTING
YOUR OWN LIBRARIES
• If you want to provide a library you need to program in C/C++
• Interface defined in header file, implementation in c++ file
/* Header file specifies public contract */
#ifndef Loudspeaker_h
#define Loudspeaker_h
class Loudspeaker {
Loudspeaker();
~Loudspeaker();
public:
void playTone(int freq);
void shutUp();
}
#endif
/* The Implementation File */
#include <Loudspeaker.h>
const byte SPEAKER_PIN = 0x8;
// constructor
Loudspeaker::Loudspeaker() {
pinMode(SPEAKER_PIN, OUTPUT);
}
Loudspeaker::~Loudspeaker() {/* NOP */}
void Loudspeaker::playTone(int freq) {/* ... */}
void Loudspeaker::shutUp() {/* ... */}
Compile with gcc-avr
ADDENDUM E: LINKS
ONE MORE THING?
• Experiments/Projects
• http://playground.arduino.cc/
• http://www.electroschematics.com/arduino/
• http://www.instructables.com/id/Arduino-Projects/
• http://www.makeuseof.com/tag/10-great-arduino-
projects-for-beginners/
• http://practicalarduino.com/projects
• https://learn.adafruit.com/category/learn-arduino
• https://sainsmart.wordpress.com/tag/arduino-projects/
• https://arduinoprojects.xyz/
• https://learn.sparkfun.com/
• Learning/Tutorials
• http://www.jeremyblum.com/category/arduino-
tutorials/
• http://www.arduino.cc/en/Tutorial/HomePage
• http://tronixstuff.com/tutorials/
• http://www.ladyada.net/learn/arduino/
• http://www.arduino-tutorials.com/
ADDENDUM F: USING ESP-01 WITH ADAPTER
USB to PC: View
from above
CH340G Driver required:
Windows: http://www.wch.cn/download/CH341SER_ZIP.html
Mac: http://www.wch.cn/download/CH341SER_MAC_ZIP.html
Linux:
http://www.wch.cn/download/CH341SER_LINUX_ZIP.html
For Flash Upload: set orange cable to ground, switch pink cable
(RESET) from voltage to ground and back to voltage. You may
just take away ESP-01 from ground and then put it to voltage
again => now ESP-01 is in update mode
FLASHING THE FIRMWARE
Example Flasher Tool for Windows:
https://www.espressif.com/sites/default/files
/tools/flash_download_tools_v3.6.3_0.rar
Current AT-Firmware Version:
https://www.espressif.com/sites/default/files
/ap/esp8266_at_bin_v1.5.1.zip
Visit
https://www.espressif.com/en/support/down
load/documents to obtain AT-
Command/Instruction-Set and -Examples
Documentation for ESP8266
Python tools (esptool) are also available
INSTALLING ESP8266/ESP-01 IN THE ARDUINO IDE
With special firmware we can use Arduino sketches on our ESP8266/ESP32 board. Our board then
behaves like an Arduino from a coding perspective
Under the hood the Arduino DIE is using other compilers & tools, however
Steps:
• In Preferences>Settings menu specify a new boardsmanager:
http://arduino.esp8266.com/stable/package_esp8266com_index.json
• In menu Tools>ESP8266>Boardsmanager search for „esp8266“ and install component found
• When adapter is connected with the ESP01, choose Generic ESP8266 Module as board and
select the right port
• In serial monitor set mode „Both NL & CR“ and speed 115200 Baud. Type in AT <return> => ESP-
01 should return OK
• Note: If you upload one of the example sketches, its firmware will be overwritten (if we have
previously put GPIO0 to Low legen and then resetted the ESP-01, which brings the ESP-01 in
update mode)
AT COMMANDS (USING SERIAL MONITOR)
Eingabe
AT <cr> // Funktion prüfen
OK
AT+CWMODE=3 <cr> // Chip kann als Station oder AP arbeiten
OK
AT+CWJAP=“SSID“,“PASSWORD“ <cr> // Mit WLAN verbinden
WIFI COMPLETED
WIFI GOT IP
AT+UART? <cr> // UART Konfiguration abfragen
<baudrate>,<databits>,<stopbits>,<flowcontrol>
AT+UART_DEF=9600,<databits>,<stopbits>,<flow control> <cr> // UART auf 9600 Baud setzen

More Related Content

What's hot

Automatic Room Lights Controller Using Arduino & PIR Sensor
Automatic Room Lights Controller Using Arduino & PIR SensorAutomatic Room Lights Controller Using Arduino & PIR Sensor
Automatic Room Lights Controller Using Arduino & PIR Sensor
Ankit Chaudhary

Smart home using andriod application
Smart home using andriod applicationSmart home using andriod application
Smart home using andriod application
eSAT Publishing House

Io t
Io tIo t
smart sensor
smart sensorsmart sensor
smart sensor
Yasir Hashmi

Smart sensors
Smart sensorsSmart sensors
Smart sensors
Supriya Gorai

Smart sensor architecture 2006
Smart sensor architecture 2006Smart sensor architecture 2006
Smart sensor architecture 2006
Iiro Jantunen

Arduino Based Home Automation System with Android and
Arduino Based Home Automation System with Android andArduino Based Home Automation System with Android and
Arduino Based Home Automation System with Android and
Anish Basu

Smart sensors
Smart sensorsSmart sensors
Smart sensors
Hari Shiyam Prakash T

PIR sensing with arduino
PIR sensing  with  arduinoPIR sensing  with  arduino
PIR sensing with arduino
chetan kadiwal

T-Mobile - Internet of Things
T-Mobile - Internet of ThingsT-Mobile - Internet of Things
T-Mobile - Internet of Things
Eddie Voluntad

Final Presentation - Edan&Itzik
Final Presentation - Edan&ItzikFinal Presentation - Edan&Itzik
Final Presentation - Edan&Itzik
itzik cohen

Smart sensors -Sukanta Bhattacharyya
Smart sensors -Sukanta BhattacharyyaSmart sensors -Sukanta Bhattacharyya
Smart sensors -Sukanta Bhattacharyya
Sukanta Bhattacharyya

IRJET- IoT based System for Smart and Secured Home
IRJET- IoT based System for Smart and Secured HomeIRJET- IoT based System for Smart and Secured Home
IRJET- IoT based System for Smart and Secured Home
IRJET Journal

IR BASED HOME AUTOMATION USING ARDUINO UNO
IR BASED HOME AUTOMATION USING ARDUINO UNOIR BASED HOME AUTOMATION USING ARDUINO UNO
IR BASED HOME AUTOMATION USING ARDUINO UNO
Mln Phaneendra

IRJET- Voice Based Home Automation System using Raspberry Pi
IRJET-  	  Voice Based Home Automation System using Raspberry PiIRJET-  	  Voice Based Home Automation System using Raspberry Pi
IRJET- Voice Based Home Automation System using Raspberry Pi
IRJET Journal

Smart Sensor
Smart SensorSmart Sensor
Smart Sensor
Pawan Bahuguna

Pxc3891504
Pxc3891504Pxc3891504
Pxc3891504
avasodekar2010

M44096368
M44096368M44096368
M44096368
IJERA Editor

Voice Control Home Automation
Voice Control Home AutomationVoice Control Home Automation
Voice Control Home Automation
Abhishek Neb

Arduino interfacing with bluetooth.
Arduino interfacing with bluetooth.Arduino interfacing with bluetooth.
Arduino interfacing with bluetooth.
Nitish Kumar


What's hot (20)

Automatic Room Lights Controller Using Arduino & PIR Sensor
Automatic Room Lights Controller Using Arduino & PIR SensorAutomatic Room Lights Controller Using Arduino & PIR Sensor
Automatic Room Lights Controller Using Arduino & PIR Sensor

Smart home using andriod application
Smart home using andriod applicationSmart home using andriod application
Smart home using andriod application

Io t
Io tIo t
Io t

smart sensor
smart sensorsmart sensor
smart sensor

Smart sensors
Smart sensorsSmart sensors
Smart sensors

Smart sensor architecture 2006
Smart sensor architecture 2006Smart sensor architecture 2006
Smart sensor architecture 2006

Arduino Based Home Automation System with Android and
Arduino Based Home Automation System with Android andArduino Based Home Automation System with Android and
Arduino Based Home Automation System with Android and

Smart sensors
Smart sensorsSmart sensors
Smart sensors

PIR sensing with arduino
PIR sensing  with  arduinoPIR sensing  with  arduino
PIR sensing with arduino

T-Mobile - Internet of Things
T-Mobile - Internet of ThingsT-Mobile - Internet of Things
T-Mobile - Internet of Things

Final Presentation - Edan&Itzik
Final Presentation - Edan&ItzikFinal Presentation - Edan&Itzik
Final Presentation - Edan&Itzik

Smart sensors -Sukanta Bhattacharyya
Smart sensors -Sukanta BhattacharyyaSmart sensors -Sukanta Bhattacharyya
Smart sensors -Sukanta Bhattacharyya

IRJET- IoT based System for Smart and Secured Home
IRJET- IoT based System for Smart and Secured HomeIRJET- IoT based System for Smart and Secured Home
IRJET- IoT based System for Smart and Secured Home

IR BASED HOME AUTOMATION USING ARDUINO UNO
IR BASED HOME AUTOMATION USING ARDUINO UNOIR BASED HOME AUTOMATION USING ARDUINO UNO
IR BASED HOME AUTOMATION USING ARDUINO UNO

IRJET- Voice Based Home Automation System using Raspberry Pi
IRJET-  	  Voice Based Home Automation System using Raspberry PiIRJET-  	  Voice Based Home Automation System using Raspberry Pi
IRJET- Voice Based Home Automation System using Raspberry Pi

Smart Sensor
Smart SensorSmart Sensor
Smart Sensor

Pxc3891504
Pxc3891504Pxc3891504
Pxc3891504

M44096368
M44096368M44096368
M44096368

Voice Control Home Automation
Voice Control Home AutomationVoice Control Home Automation
Voice Control Home Automation

Arduino interfacing with bluetooth.
Arduino interfacing with bluetooth.Arduino interfacing with bluetooth.
Arduino interfacing with bluetooth.


Similar to Oop2018 tutorial-stal-mo2-io t-arduino-en

Resume for Embedded Engineer_1
Resume for Embedded Engineer_1Resume for Embedded Engineer_1
Resume for Embedded Engineer_1
gajendra parmar

SIGFOX Makers Tour - Dublin
SIGFOX Makers Tour - DublinSIGFOX Makers Tour - Dublin
SIGFOX Makers Tour - Dublin
Nicolas Lesconnec

Report on automatic door
Report on automatic doorReport on automatic door
Report on automatic door
Indira Kundu

EMBEDDED_SYSTEM_INTRODUCTION.pdf
EMBEDDED_SYSTEM_INTRODUCTION.pdfEMBEDDED_SYSTEM_INTRODUCTION.pdf
EMBEDDED_SYSTEM_INTRODUCTION.pdf
NadiSarj2

Industrial Pioneers Days - Machine Learning
Industrial Pioneers Days - Machine LearningIndustrial Pioneers Days - Machine Learning
Industrial Pioneers Days - Machine Learning
VEDLIoT Project

SIGFOX Makers Tour - Porto
SIGFOX Makers Tour - PortoSIGFOX Makers Tour - Porto
SIGFOX Makers Tour - Porto
Nicolas Lesconnec

TLE-TVL_ICT(CSS)9_Q1_CLAS1_Assessing-Quality-of-Received-Materials - RHEA ROM...
TLE-TVL_ICT(CSS)9_Q1_CLAS1_Assessing-Quality-of-Received-Materials - RHEA ROM...TLE-TVL_ICT(CSS)9_Q1_CLAS1_Assessing-Quality-of-Received-Materials - RHEA ROM...
TLE-TVL_ICT(CSS)9_Q1_CLAS1_Assessing-Quality-of-Received-Materials - RHEA ROM...
JayPaulTBadenas

Arduino Workshop Day 1 - Basic Arduino
Arduino Workshop Day 1 - Basic ArduinoArduino Workshop Day 1 - Basic Arduino
Arduino Workshop Day 1 - Basic Arduino
Vishnu

Best HW for IoT project-1.pdf
Best HW for IoT project-1.pdfBest HW for IoT project-1.pdf
Best HW for IoT project-1.pdf
Kunal Pandhram

02/2017 Santa Clara, California: Networks of autonomous devices and their imp...
02/2017 Santa Clara, California: Networks of autonomous devices and their imp...02/2017 Santa Clara, California: Networks of autonomous devices and their imp...
02/2017 Santa Clara, California: Networks of autonomous devices and their imp...
Frank Alexander Reusch

Oop 2014 embedded systems with open source hardware v2
Oop 2014 embedded systems with open source hardware v2Oop 2014 embedded systems with open source hardware v2
Oop 2014 embedded systems with open source hardware v2
Michael Stal

Control of Industrial Pneumatic & Hydraulic Systems using Serial Communicatio...
Control of Industrial Pneumatic & Hydraulic Systems using Serial Communicatio...Control of Industrial Pneumatic & Hydraulic Systems using Serial Communicatio...
Control of Industrial Pneumatic & Hydraulic Systems using Serial Communicatio...
IJSRD

Control of Industrial Pneumatic & Hydraulic Systems using Serial Communicatio...
Control of Industrial Pneumatic & Hydraulic Systems using Serial Communicatio...Control of Industrial Pneumatic & Hydraulic Systems using Serial Communicatio...
Control of Industrial Pneumatic & Hydraulic Systems using Serial Communicatio...
IJSRD

N414 Documentation Data.docx
N414 Documentation Data.docxN414 Documentation Data.docx
N414 Documentation Data.docx
RAGU83

training report on embedded system and AVR
training report on embedded system and AVRtraining report on embedded system and AVR
training report on embedded system and AVR
Urvashi Khandelwal

Jprofessionals co create the future of your city
Jprofessionals co create the future of your cityJprofessionals co create the future of your city
Jprofessionals co create the future of your city
Pance Cavkovski

IRJET - Smart Washroom Cleaning System using Hub Technology
IRJET -  	  Smart Washroom Cleaning System using Hub Technology IRJET -  	  Smart Washroom Cleaning System using Hub Technology
IRJET - Smart Washroom Cleaning System using Hub Technology
IRJET Journal

E044081720
E044081720E044081720
E044081720
IJERA Editor

Getting Started with the NodeMCU- Getting started with Internet of Things (Io...
Getting Started with the NodeMCU- Getting started with Internet of Things (Io...Getting Started with the NodeMCU- Getting started with Internet of Things (Io...
Getting Started with the NodeMCU- Getting started with Internet of Things (Io...
AkshetPatel

"Black Box for a Car" report
"Black Box for a Car" report"Black Box for a Car" report
"Black Box for a Car" report
subrat manna


Similar to Oop2018 tutorial-stal-mo2-io t-arduino-en (20)

Resume for Embedded Engineer_1
Resume for Embedded Engineer_1Resume for Embedded Engineer_1
Resume for Embedded Engineer_1

SIGFOX Makers Tour - Dublin
SIGFOX Makers Tour - DublinSIGFOX Makers Tour - Dublin
SIGFOX Makers Tour - Dublin

Report on automatic door
Report on automatic doorReport on automatic door
Report on automatic door

EMBEDDED_SYSTEM_INTRODUCTION.pdf
EMBEDDED_SYSTEM_INTRODUCTION.pdfEMBEDDED_SYSTEM_INTRODUCTION.pdf
EMBEDDED_SYSTEM_INTRODUCTION.pdf

Industrial Pioneers Days - Machine Learning
Industrial Pioneers Days - Machine LearningIndustrial Pioneers Days - Machine Learning
Industrial Pioneers Days - Machine Learning

SIGFOX Makers Tour - Porto
SIGFOX Makers Tour - PortoSIGFOX Makers Tour - Porto
SIGFOX Makers Tour - Porto

TLE-TVL_ICT(CSS)9_Q1_CLAS1_Assessing-Quality-of-Received-Materials - RHEA ROM...
TLE-TVL_ICT(CSS)9_Q1_CLAS1_Assessing-Quality-of-Received-Materials - RHEA ROM...TLE-TVL_ICT(CSS)9_Q1_CLAS1_Assessing-Quality-of-Received-Materials - RHEA ROM...
TLE-TVL_ICT(CSS)9_Q1_CLAS1_Assessing-Quality-of-Received-Materials - RHEA ROM...

Arduino Workshop Day 1 - Basic Arduino
Arduino Workshop Day 1 - Basic ArduinoArduino Workshop Day 1 - Basic Arduino
Arduino Workshop Day 1 - Basic Arduino

Best HW for IoT project-1.pdf
Best HW for IoT project-1.pdfBest HW for IoT project-1.pdf
Best HW for IoT project-1.pdf

02/2017 Santa Clara, California: Networks of autonomous devices and their imp...
02/2017 Santa Clara, California: Networks of autonomous devices and their imp...02/2017 Santa Clara, California: Networks of autonomous devices and their imp...
02/2017 Santa Clara, California: Networks of autonomous devices and their imp...

Oop 2014 embedded systems with open source hardware v2
Oop 2014 embedded systems with open source hardware v2Oop 2014 embedded systems with open source hardware v2
Oop 2014 embedded systems with open source hardware v2

Control of Industrial Pneumatic & Hydraulic Systems using Serial Communicatio...
Control of Industrial Pneumatic & Hydraulic Systems using Serial Communicatio...Control of Industrial Pneumatic & Hydraulic Systems using Serial Communicatio...
Control of Industrial Pneumatic & Hydraulic Systems using Serial Communicatio...

Control of Industrial Pneumatic & Hydraulic Systems using Serial Communicatio...
Control of Industrial Pneumatic & Hydraulic Systems using Serial Communicatio...Control of Industrial Pneumatic & Hydraulic Systems using Serial Communicatio...
Control of Industrial Pneumatic & Hydraulic Systems using Serial Communicatio...

N414 Documentation Data.docx
N414 Documentation Data.docxN414 Documentation Data.docx
N414 Documentation Data.docx

training report on embedded system and AVR
training report on embedded system and AVRtraining report on embedded system and AVR
training report on embedded system and AVR

Jprofessionals co create the future of your city
Jprofessionals co create the future of your cityJprofessionals co create the future of your city
Jprofessionals co create the future of your city

IRJET - Smart Washroom Cleaning System using Hub Technology
IRJET -  	  Smart Washroom Cleaning System using Hub Technology IRJET -  	  Smart Washroom Cleaning System using Hub Technology
IRJET - Smart Washroom Cleaning System using Hub Technology

E044081720
E044081720E044081720
E044081720

Getting Started with the NodeMCU- Getting started with Internet of Things (Io...
Getting Started with the NodeMCU- Getting started with Internet of Things (Io...Getting Started with the NodeMCU- Getting started with Internet of Things (Io...
Getting Started with the NodeMCU- Getting started with Internet of Things (Io...

"Black Box for a Car" report
"Black Box for a Car" report"Black Box for a Car" report
"Black Box for a Car" report


More from Michael Stal

Oop 2014 sw architekt v3
Oop 2014 sw architekt v3Oop 2014 sw architekt v3
Oop 2014 sw architekt v3
Michael Stal

Qcon2011 functions rockpresentation_f_sharp
Qcon2011 functions rockpresentation_f_sharpQcon2011 functions rockpresentation_f_sharp
Qcon2011 functions rockpresentation_f_sharp
Michael Stal

Qcon2011 functions rockpresentation_f_sharp
Qcon2011 functions rockpresentation_f_sharpQcon2011 functions rockpresentation_f_sharp
Qcon2011 functions rockpresentation_f_sharp
Michael Stal

Qcon2011 functions rockpresentation_scala
Qcon2011 functions rockpresentation_scalaQcon2011 functions rockpresentation_scala
Qcon2011 functions rockpresentation_scala
Michael Stal

Oop2011 actor presentation_stal
Oop2011 actor presentation_stalOop2011 actor presentation_stal
Oop2011 actor presentation_stal
Michael Stal

Accu2010 archrefactoring
Accu2010 archrefactoringAccu2010 archrefactoring
Accu2010 archrefactoring
Michael Stal

Oop2010 Scala Presentation Stal
Oop2010 Scala Presentation StalOop2010 Scala Presentation Stal
Oop2010 Scala Presentation Stal
Michael Stal


More from Michael Stal (7)

Oop 2014 sw architekt v3
Oop 2014 sw architekt v3Oop 2014 sw architekt v3
Oop 2014 sw architekt v3

Qcon2011 functions rockpresentation_f_sharp
Qcon2011 functions rockpresentation_f_sharpQcon2011 functions rockpresentation_f_sharp
Qcon2011 functions rockpresentation_f_sharp

Qcon2011 functions rockpresentation_f_sharp
Qcon2011 functions rockpresentation_f_sharpQcon2011 functions rockpresentation_f_sharp
Qcon2011 functions rockpresentation_f_sharp

Qcon2011 functions rockpresentation_scala
Qcon2011 functions rockpresentation_scalaQcon2011 functions rockpresentation_scala
Qcon2011 functions rockpresentation_scala

Oop2011 actor presentation_stal
Oop2011 actor presentation_stalOop2011 actor presentation_stal
Oop2011 actor presentation_stal

Accu2010 archrefactoring
Accu2010 archrefactoringAccu2010 archrefactoring
Accu2010 archrefactoring

Oop2010 Scala Presentation Stal
Oop2010 Scala Presentation StalOop2010 Scala Presentation Stal
Oop2010 Scala Presentation Stal


Recently uploaded

Building a Raspberry Pi Robot with Dot NET 8, Blazor and SignalR
Building a Raspberry Pi Robot with Dot NET 8, Blazor and SignalRBuilding a Raspberry Pi Robot with Dot NET 8, Blazor and SignalR
Building a Raspberry Pi Robot with Dot NET 8, Blazor and SignalR
Peter Gallagher

按照学校原版(UOL文凭证书)利物浦大学毕业证快速办理
按照学校原版(UOL文凭证书)利物浦大学毕业证快速办理按照学校原版(UOL文凭证书)利物浦大学毕业证快速办理
按照学校原版(UOL文凭证书)利物浦大学毕业证快速办理
terpt4iu

按照学校原版(QU文凭证书)皇后大学毕业证快速办理
按照学校原版(QU文凭证书)皇后大学毕业证快速办理按照学校原版(QU文凭证书)皇后大学毕业证快速办理
按照学校原版(QU文凭证书)皇后大学毕业证快速办理
8db3cz8x

按照学校原版(UST文凭证书)圣托马斯大学毕业证快速办理
按照学校原版(UST文凭证书)圣托马斯大学毕业证快速办理按照学校原版(UST文凭证书)圣托马斯大学毕业证快速办理
按照学校原版(UST文凭证书)圣托马斯大学毕业证快速办理
zpc0z12

1比1复刻澳洲皇家墨尔本理工大学毕业证本科学位原版一模一样
1比1复刻澳洲皇家墨尔本理工大学毕业证本科学位原版一模一样1比1复刻澳洲皇家墨尔本理工大学毕业证本科学位原版一模一样
1比1复刻澳洲皇家墨尔本理工大学毕业证本科学位原版一模一样
2g3om49r

买(usyd毕业证书)澳洲悉尼大学毕业证研究生文凭证书原版一模一样
买(usyd毕业证书)澳洲悉尼大学毕业证研究生文凭证书原版一模一样买(usyd毕业证书)澳洲悉尼大学毕业证研究生文凭证书原版一模一样
买(usyd毕业证书)澳洲悉尼大学毕业证研究生文凭证书原版一模一样
nvoyobt

一比一原版(TheAuckland毕业证书)新西兰奥克兰大学毕业证如何办理
一比一原版(TheAuckland毕业证书)新西兰奥克兰大学毕业证如何办理一比一原版(TheAuckland毕业证书)新西兰奥克兰大学毕业证如何办理
一比一原版(TheAuckland毕业证书)新西兰奥克兰大学毕业证如何办理
xuqdabu

SOLIDWORKS 2024 Enhancements eBook.pdf for beginners
SOLIDWORKS 2024 Enhancements eBook.pdf for beginnersSOLIDWORKS 2024 Enhancements eBook.pdf for beginners
SOLIDWORKS 2024 Enhancements eBook.pdf for beginners
SethiLilu

一比一原版(UOL文凭证书)利物浦大学毕业证如何办理
一比一原版(UOL文凭证书)利物浦大学毕业证如何办理一比一原版(UOL文凭证书)利物浦大学毕业证如何办理
一比一原版(UOL文凭证书)利物浦大学毕业证如何办理
eydeofo

按照学校原版(USD文凭证书)圣地亚哥大学毕业证快速办理
按照学校原版(USD文凭证书)圣地亚哥大学毕业证快速办理按照学校原版(USD文凭证书)圣地亚哥大学毕业证快速办理
按照学校原版(USD文凭证书)圣地亚哥大学毕业证快速办理
snfdnzl7

按照学校原版(UVic文凭证书)维多利亚大学毕业证快速办理
按照学校原版(UVic文凭证书)维多利亚大学毕业证快速办理按照学校原版(UVic文凭证书)维多利亚大学毕业证快速办理
按照学校原版(UVic文凭证书)维多利亚大学毕业证快速办理
1jtj7yul

按照学校原版(Columbia文凭证书)哥伦比亚大学毕业证快速办理
按照学校原版(Columbia文凭证书)哥伦比亚大学毕业证快速办理按照学校原版(Columbia文凭证书)哥伦比亚大学毕业证快速办理
按照学校原版(Columbia文凭证书)哥伦比亚大学毕业证快速办理
uyesp1a

一比一原版(Greenwich文凭证书)格林威治大学毕业证如何办理
一比一原版(Greenwich文凭证书)格林威治大学毕业证如何办理一比一原版(Greenwich文凭证书)格林威治大学毕业证如何办理
一比一原版(Greenwich文凭证书)格林威治大学毕业证如何办理
byfazef

一比一原版(UQ文凭证书)昆士兰大学毕业证如何办理
一比一原版(UQ文凭证书)昆士兰大学毕业证如何办理一比一原版(UQ文凭证书)昆士兰大学毕业证如何办理
一比一原版(UQ文凭证书)昆士兰大学毕业证如何办理
xuqdabu

按照学校原版(Adelaide文凭证书)阿德莱德大学毕业证快速办理
按照学校原版(Adelaide文凭证书)阿德莱德大学毕业证快速办理按照学校原版(Adelaide文凭证书)阿德莱德大学毕业证快速办理
按照学校原版(Adelaide文凭证书)阿德莱德大学毕业证快速办理
terpt4iu

按照学校原版(AU文凭证书)英国阿伯丁大学毕业证快速办理
按照学校原版(AU文凭证书)英国阿伯丁大学毕业证快速办理按照学校原版(AU文凭证书)英国阿伯丁大学毕业证快速办理
按照学校原版(AU文凭证书)英国阿伯丁大学毕业证快速办理
ei8c4cba

按照学校原版(UPenn文凭证书)宾夕法尼亚大学毕业证快速办理
按照学校原版(UPenn文凭证书)宾夕法尼亚大学毕业证快速办理按照学校原版(UPenn文凭证书)宾夕法尼亚大学毕业证快速办理
按照学校原版(UPenn文凭证书)宾夕法尼亚大学毕业证快速办理
uwoso

按照学校原版(SUT文凭证书)斯威本科技大学毕业证快速办理
按照学校原版(SUT文凭证书)斯威本科技大学毕业证快速办理按照学校原版(SUT文凭证书)斯威本科技大学毕业证快速办理
按照学校原版(SUT文凭证书)斯威本科技大学毕业证快速办理
1jtj7yul

一比一原版(ANU文凭证书)澳大利亚国立大学毕业证如何办理
一比一原版(ANU文凭证书)澳大利亚国立大学毕业证如何办理一比一原版(ANU文凭证书)澳大利亚国立大学毕业证如何办理
一比一原版(ANU文凭证书)澳大利亚国立大学毕业证如何办理
nudduv

按照学校原版(UAL文凭证书)伦敦艺术大学毕业证快速办理
按照学校原版(UAL文凭证书)伦敦艺术大学毕业证快速办理按照学校原版(UAL文凭证书)伦敦艺术大学毕业证快速办理
按照学校原版(UAL文凭证书)伦敦艺术大学毕业证快速办理
yizxn4sx


Recently uploaded (20)

Building a Raspberry Pi Robot with Dot NET 8, Blazor and SignalR
Building a Raspberry Pi Robot with Dot NET 8, Blazor and SignalRBuilding a Raspberry Pi Robot with Dot NET 8, Blazor and SignalR
Building a Raspberry Pi Robot with Dot NET 8, Blazor and SignalR

按照学校原版(UOL文凭证书)利物浦大学毕业证快速办理
按照学校原版(UOL文凭证书)利物浦大学毕业证快速办理按照学校原版(UOL文凭证书)利物浦大学毕业证快速办理
按照学校原版(UOL文凭证书)利物浦大学毕业证快速办理

按照学校原版(QU文凭证书)皇后大学毕业证快速办理
按照学校原版(QU文凭证书)皇后大学毕业证快速办理按照学校原版(QU文凭证书)皇后大学毕业证快速办理
按照学校原版(QU文凭证书)皇后大学毕业证快速办理

按照学校原版(UST文凭证书)圣托马斯大学毕业证快速办理
按照学校原版(UST文凭证书)圣托马斯大学毕业证快速办理按照学校原版(UST文凭证书)圣托马斯大学毕业证快速办理
按照学校原版(UST文凭证书)圣托马斯大学毕业证快速办理

1比1复刻澳洲皇家墨尔本理工大学毕业证本科学位原版一模一样
1比1复刻澳洲皇家墨尔本理工大学毕业证本科学位原版一模一样1比1复刻澳洲皇家墨尔本理工大学毕业证本科学位原版一模一样
1比1复刻澳洲皇家墨尔本理工大学毕业证本科学位原版一模一样

买(usyd毕业证书)澳洲悉尼大学毕业证研究生文凭证书原版一模一样
买(usyd毕业证书)澳洲悉尼大学毕业证研究生文凭证书原版一模一样买(usyd毕业证书)澳洲悉尼大学毕业证研究生文凭证书原版一模一样
买(usyd毕业证书)澳洲悉尼大学毕业证研究生文凭证书原版一模一样

一比一原版(TheAuckland毕业证书)新西兰奥克兰大学毕业证如何办理
一比一原版(TheAuckland毕业证书)新西兰奥克兰大学毕业证如何办理一比一原版(TheAuckland毕业证书)新西兰奥克兰大学毕业证如何办理
一比一原版(TheAuckland毕业证书)新西兰奥克兰大学毕业证如何办理

SOLIDWORKS 2024 Enhancements eBook.pdf for beginners
SOLIDWORKS 2024 Enhancements eBook.pdf for beginnersSOLIDWORKS 2024 Enhancements eBook.pdf for beginners
SOLIDWORKS 2024 Enhancements eBook.pdf for beginners

一比一原版(UOL文凭证书)利物浦大学毕业证如何办理
一比一原版(UOL文凭证书)利物浦大学毕业证如何办理一比一原版(UOL文凭证书)利物浦大学毕业证如何办理
一比一原版(UOL文凭证书)利物浦大学毕业证如何办理

按照学校原版(USD文凭证书)圣地亚哥大学毕业证快速办理
按照学校原版(USD文凭证书)圣地亚哥大学毕业证快速办理按照学校原版(USD文凭证书)圣地亚哥大学毕业证快速办理
按照学校原版(USD文凭证书)圣地亚哥大学毕业证快速办理

按照学校原版(UVic文凭证书)维多利亚大学毕业证快速办理
按照学校原版(UVic文凭证书)维多利亚大学毕业证快速办理按照学校原版(UVic文凭证书)维多利亚大学毕业证快速办理
按照学校原版(UVic文凭证书)维多利亚大学毕业证快速办理

按照学校原版(Columbia文凭证书)哥伦比亚大学毕业证快速办理
按照学校原版(Columbia文凭证书)哥伦比亚大学毕业证快速办理按照学校原版(Columbia文凭证书)哥伦比亚大学毕业证快速办理
按照学校原版(Columbia文凭证书)哥伦比亚大学毕业证快速办理

一比一原版(Greenwich文凭证书)格林威治大学毕业证如何办理
一比一原版(Greenwich文凭证书)格林威治大学毕业证如何办理一比一原版(Greenwich文凭证书)格林威治大学毕业证如何办理
一比一原版(Greenwich文凭证书)格林威治大学毕业证如何办理

一比一原版(UQ文凭证书)昆士兰大学毕业证如何办理
一比一原版(UQ文凭证书)昆士兰大学毕业证如何办理一比一原版(UQ文凭证书)昆士兰大学毕业证如何办理
一比一原版(UQ文凭证书)昆士兰大学毕业证如何办理

按照学校原版(Adelaide文凭证书)阿德莱德大学毕业证快速办理
按照学校原版(Adelaide文凭证书)阿德莱德大学毕业证快速办理按照学校原版(Adelaide文凭证书)阿德莱德大学毕业证快速办理
按照学校原版(Adelaide文凭证书)阿德莱德大学毕业证快速办理

按照学校原版(AU文凭证书)英国阿伯丁大学毕业证快速办理
按照学校原版(AU文凭证书)英国阿伯丁大学毕业证快速办理按照学校原版(AU文凭证书)英国阿伯丁大学毕业证快速办理
按照学校原版(AU文凭证书)英国阿伯丁大学毕业证快速办理

按照学校原版(UPenn文凭证书)宾夕法尼亚大学毕业证快速办理
按照学校原版(UPenn文凭证书)宾夕法尼亚大学毕业证快速办理按照学校原版(UPenn文凭证书)宾夕法尼亚大学毕业证快速办理
按照学校原版(UPenn文凭证书)宾夕法尼亚大学毕业证快速办理

按照学校原版(SUT文凭证书)斯威本科技大学毕业证快速办理
按照学校原版(SUT文凭证书)斯威本科技大学毕业证快速办理按照学校原版(SUT文凭证书)斯威本科技大学毕业证快速办理
按照学校原版(SUT文凭证书)斯威本科技大学毕业证快速办理

一比一原版(ANU文凭证书)澳大利亚国立大学毕业证如何办理
一比一原版(ANU文凭证书)澳大利亚国立大学毕业证如何办理一比一原版(ANU文凭证书)澳大利亚国立大学毕业证如何办理
一比一原版(ANU文凭证书)澳大利亚国立大学毕业证如何办理

按照学校原版(UAL文凭证书)伦敦艺术大学毕业证快速办理
按照学校原版(UAL文凭证书)伦敦艺术大学毕业证快速办理按照学校原版(UAL文凭证书)伦敦艺术大学毕业证快速办理
按照学校原版(UAL文凭证书)伦敦艺术大学毕业证快速办理


Oop2018 tutorial-stal-mo2-io t-arduino-en

  • 1. IOT WITH ARDUINO IN A NUTSHELL Lecturer: Prof. Dr. Michael Stal
  • 2. ENGINEERS NEVER FAIL I have not failed. I've just found 10,000 ways that won't work. [Thomas A. Edison]
  • 3. INTRO QUOTE “The Internet of Things tells us that a lot of computer-enabled appliances and devices are going to become part of this system, too: appliances that you use around the house, that you use in your office, that you carry around with yourself or in the car. That's the Internet of Things that's coming” Vint Cerf, one of the fathers of the Internet
  • 4. GOALS OF THIS TUTORIAL Having Fun Learning how to use Open Source Hardware/Software for building IoT devices Getting to know microcontroller boards Building your own IoT device using low cost hardware such as Arduino with sensors/actuators Focusing on the embedded side assuming most of you are rather familiar with desktops, servers
  • 5. WHY DO WE USE ARDUINO IN THIS TUTORIAL? Arduino provides low-cost, open source hardware arduino.cc and vendors (Intel, TI, ...) offer compatible boards Big product ecosystem available (shields, boards, displays, ...) Large community exists Low level programming with C/C++ helps learn the fundamental concepts It is much easier to learn & use more powerful boards such as Raspberry Pi after understanding Arduino WHY DO WE USE ARDUINO IN THIS TUTORIAL? Arduino provides low-cost, open source hardware arduino.cc and vendors (Intel, TI, ...) offer compatible boards Big product ecosystem available (shields, boards, displays, ...) Large community exists Low level programming with C/C++ helps learn the fundamental concepts It is much easier to learn & use more powerful boards such as Raspberry Pi after understanding Arduino
  • 6. AGENDA PART I: Presentation What the heck is IoT good for? Introduction to IoT hardware/software Fundamentals of electronics Some best practices PART II: DIY - Experiments Learning Arduino PART III: Hackathon- teams of 3-4 Develop an IoT device Refine and extend it Present it to the other participants and get feedback What you will need Notebook (Linux, MacOS, Windows) WiFi - provided by the conference organization Arduino Starter Kit and components Open Source Software to be downloaded from the Internet A Book on Arduino Practice
  • 7. OPEN SOURCE SOFTWARE DOWNLOADS Arduino IDE Download https://www.arduino.cc/en/Main/Software Processing IDE Download https://processing.org/download/ Twitter 4J Download http://twitter4j.org Tutorial Processing and Twitter http://codasign.com/tutorials/processing-and-twitter/ Node.js: http://nodejs.org Johnny-Five JS: http://johnny-five.io Java mail https://java.net/projects/javamail/pages/Home Java RXTX Serial Communication http://rxtx.qbang.org/wiki/index.php/Download Eclipse for Java Developers http://www.eclipse.org/downloads/packages/eclipse-ide- java-developers/mars2 Arduino library for Processing http://playground.arduino.cc/Processing2-arduino/Zip Fritzing Circuit Modeling: http://fritzing.org
  • 8. IOT DEVICES Basic Recipe Take a microcontroller or CPU board Add sensors and actuators Connect device to the Internet or use Internet-based protocols Control and monitor device using a Web Interface Different form factors from wearables, mobile devices up to workstations Sensors CPU+Microcontroller Board & Actuators
  • 9. CONSUMER USAGE SCENARIOS Wearables (watches, classes) that connect users with each other and and with their digital environment Robots (e.g., for mowing the lawn or cleaning rooms) Control of lighting using mobile devices and geofencing Myriads of toy stories such as coffee machines or cat feeding devices that can be controlled remotely
  • 10. OPENHAB Most products (Philips Hue, NEST, Osram Lightify, …) use proprietary approach openHAB* as alternative Open Source integration solution for home automation systems Based on Event Driven Architecture Only precondition: availability of a JVM runtime *HAB = Home Automation Bus
  • 11. INDUSTRIAL CHALLENGE How (i.e., with which system architecture) can we integrate from 100s to millions of devices into large systems? Magic Number: 50 Billions If you think that is not relevant: large factories in Japan may use up to 2 million nodes
  • 12. CASE STUDY I - CONTAINERS Containers for transport of goods can get damaged or lost It is surprising how many containers disappear Scenario: Container integrates IoT device On loading device gets information such as items, recipients Container regularly tracks GPS position and sends it to sender On changes such of pressure, temperature, moisture or forces, IoT device sends events
  • 13. CASE STUDY II –TRAFFIC INFRASTRUCTURE Additional Scenario: Traffic signals use IoT to measure traffic flow Measurements over longer time period are stored in Cloud Data Analytics application analyzes data for optimization of traffic control (using goals such as less traffic jams, less pollution, …) Decision Support System derives tactical optimizations to improve strategy Traffic controls can also work autonomously interacting with other local traffic controls Process is continuously repeated
  • 14. CASE STUDY III – DECENTRALIZED SOLUTIONS Connected robots or drones may collaborate as a swarm static or ad-hoc connection Scenario Swarm receives task such as controlling a pipeline or a plant Swarm members are coordinating their work to achieve their joint goal If necessary, swarm member can ask other members for assistance If a member must be recharged, it leaves swarm and moves to charging station Mission accomplished => swarm returns
  • 15. CASE STUDY IV: INTERACTIVE MAINTENANCE For maintenance of large or complex systems, IoT devices interact with maintenance/service staff Maintenance/service staff uses VR solution System visualized as 3D object which can be analyzed with respect to its parts, state, defects User can interact with system For each component/area/part a dedicated IoT device is in charge
  • 16. COMMUNICATION PROTOCOLS To connect heterogeneous hardware standardized communication protocols are necessary In IoT two widely used standards are MQTT CoAP
  • 17. MQTT MQTT originally meant MQ Telemetry Transport. Today, it defines an OASIS- resp. ISO Standard (ISO/IEC PRF 20922) follows the Publisher/Subscriber Pattern requires a MQTT Broker for storing and and managing messages and topics defines Quality of Service: fire‘n forget, at-least-once, exactly- once uses different ports depending on security requirements (unsecured port: 1883) does not care about message content Tools: mosquito (free broker), MQTT.fx (test client)
  • 18. RESTFUL WITH COAP REST is an Architecture Style (used by HTTP) Principles: Ressources support verbs such as GET, PUT, POST, DELETE Client-Server Interaction using standardized interfaces Statelessness Caching Layered Architecture Call-dependent code generation
  • 19. COAP - SUCCESS & FAILURE SCENARIOS
  • 20. COAP - BENEFITS AND LIABILITIES CoAP feels more natural than MQTT due to its close relationsship with REST CoAP implementations need more ressources (memory) => Does not fit well in small memory devices such as wearables, Arduino
  • 21. ELECTRONICS Dealing with IoT/Digitalization involves dealing with embedded hardware and electronics We software engineers hoped to get rid of these bottom layers by abstraction Unfortunately, we must go back to the roots
  • 22. CIRCUIT DIAGRAMS Typical elements in a circuit diagram Battery/Cell: produces voltage Lamp: consumes voltage Switch: opens or closes circuit Cable: connects producers and consumers Current only flows in closed circuits Base assumption: we only use independent voltage sources (that produce a constant voltage), but no independent current sources CIRCUIT DIAGRAMS Typical elements in a circuit diagram Battery/Cell: produces voltage Lamp: consumes voltage Switch: opens or closes circuit Cable: connects producers and consumers Current only flows in closed circuits Base assumption: we only use independent voltage sources (that produce a constant voltage), but no independent current sources
  • 23. CURRENT FLOW • In contrast to intuition current flows from • Cathode (+) to • Anode (-) e- e- e- e- Physical flow of electrons - + Technical flow of current e- e- e- e- e- e- e- e-
  • 24. WATER METAPHOR • Water Analogy is a good and intuitive model for thinking about electricity • Current => water flow • Voltage => energy potential provided by the pump • Resistor => object resisting water flow • Switch => valve © signon.com
  • 25. RESISTORS • Problem: consumers are only able to consume a maximum current • Solution: Resistors consume energy (by converting electricity into heat), thus reducing overall current • All parts in a circuit have resistance, even cables (which can mostly be neglected) • An open switch has infinite resistance
  • 26. OHM’S LAW Ohm’s Law: U = R x I • Serial Resistors: Rserial = R1 + R2 + …. Hint: it is common practice to combine resistors for better achieving a specific resistance value • Parallel Resistors: 1/Rparallel = 1/R1 + 1/R2 + .... R1 R2 Same Current Different Voltages R1 R2 Same Voltage Different Currents Voltage = Resistance x Current
  • 27. RESISTOR COLOR CODE • 3 Bands: Band 1,2 are digits, Band 3 is multiplier, Additional Band is Tolerance • 4 Bands: Band 1,2,3 are digits, Band 4 is multiplier, Additional Band is tolerance Color Multiplier Tolerance Brown x 10 +/- 1% Red x 100 +/- 2% Orange x 1 K Yellow x 10 K Green x 100 K +/- .5% Blue x 1 M +/- .25% Violet x 10 M +/- .1% Grey +/- .05% Gold x .1 +/- 5% Silver X .01 +/- 10% Example 3-Band Resistor: 27 x 100 K = 2.7 M Ohm with Tolerance +/- 1%
  • 28. KIRCHHOFF’S VOLTAGE LAW The sum of all voltages of any loop within a circuit is always zero (you may count clockwise or counterclockwise) U1 U2 U3 U4 U1+U2+U3+U4 = 0 Kirchhoff’s Voltage Law: the sum of all power consumers in a closed loop equals the sum of all power producers In direction of current (+ => -) generators: negative voltage consumers: positive voltage In opposite direction generators: positive voltage consumers: negative voltage
  • 29. KIRCHHOFF’S CURRENT LAW The sum of all in-going/out-going currents at a node is always zero I1 - I2 - I3 - I4 = 0 I2 I1 I3 I4 Incoming currents Outgoing currents Kirchhoff’s Current Law: the sum of all incoming currents at a node equals the sum of its outgoing currents
  • 30. APPLICATION OF OHM’S LAW Lets connect a voltage source with a resistor and a LED An Arduino Uno board operates at 5V and allows to draw 40mA current from an I/O pin and 200mA from Vcc/Ground A red LED’s forward voltage is 2V and its current should be ca. 20 mA The resistor must “absorb” the remaining 3V (Kirchhoff’s Voltage Law) Ohm’s Law: U = R x I => R = U / I = 3V/20mA = 175 Ohm => Use next higher resistor with 220 Ohm (red/red/brown) Warning: There are no fuses in the I/O pins of an Arduino! Use the 3-band color code: Red/Red/Brown = 220 Ohm 4-band resistor would be Red/Red/Black/Black
  • 31. MICROCONTROLLERS IN A NUTSHELL Microcontrollers (aka µC, uC or MCU) are not CPUs, but complete systems on a chip (SoC) with Processor Buses Memory Input/Output Peripherals More than half of all microcontrollers are still 8 bit Typically, embedded systems software is written in Assembly Language or C/C++ Source: http://www.mikroe.com/chapters/view/16/chapter-3-pic16f887-microcontroller/ Universal Synchronous/Asynchronous Receiver/Transmitter Serial Peripheral Interface Inter-Integrated-Bus Special Function Registers WDT PWM Capture, Compare, and Pulse Width Modulation- PIC18 µC Reference Voltage Deciphering the secret language of µC USART SPI I2C SFR WDT PWM CCP Vref
  • 32. COMMON CONSTRAINTS  Limited Memory (Arduino Uno has 32k)  Limited Number of I/O Ports (Raspberry Pi got only a few out-off-the-box)  Limited Energy if not connected to a power line  Limited Connectivity: Only Arduino Yun has communication on board
  • 33. LET‘S GO ON BOARD Increasing number of open source microcontroller boards Excellent and cheap tools for prototyping Useful to learn software development basics for embedded systems Scope: systems w/o stringent real- time/dependability requirements
  • 34. ARDUINO BOARD DESIGN Analog Reference Digital I/O Pins 2-13 (9, 10, 11 with PWM = Pulse Width Modulation) Digital Ground Pins 1 & 2: Digital I/O. When used for communication then Serial In/Out, TX/RX Reset Button: on reset the bootloader restarts In-Circuit Serial Programmer: if you need to upload a bootloader Analog In: 0-5 Jumpers: Toggling between USB power and external power (jumpers) Power Connectors connected with your board. Not all boards use 5V! External Power Supply USB Used to load programs (=sketches) to the board, to power the board, and for serial communicationBoards (i.e., their pins) have a maximum current they can handle. Most Arduino boards define a maximum of 40 mA. Higher values will cause damage. CPU with 16MHz
  • 35. SENSORS & ACTUATORS Pressure Sensor Ultrasonic Gyro Hall Sensor Temperature Sensor Developers needs to add specific code for reading or writing actuator/sensor values Usually attached through an analog port Specification of chip/component explains mapping between sensor values and physical units PWM (Pulse Width Modulation) often used in digital outputs (actuators) to vary intensity of speed, volume, brightness, ... SENSORS ACTUATORS SENSORS & ACTUATORS Pressure Sensor Ultrasonic Gyro Hall Sensor Temperature Sensor Developers needs to add specific code for reading or writing actuator/sensor values Usually attached through an analog port Specification of chip/component explains mapping between sensor values and physical units PWM (Pulse Width Modulation) often used in digital outputs (actuators) to vary intensity of speed, volume, brightness, ... SENSORS ACTUATORS
  • 36. SHIELDS & HATS Arduino shields (incl. program libraries) add advanced logic Built to fit on top of an Arduino board Typically, provide the same pins like the Arduino on top (for stacking of boards) Examples: Motor Shield (Arduino) LCD Shield (Sparkfun) Proto Shield (Seeed Studio) GPS Shield (Adafruit) WiFi Shield (AsyncLabs) See http://shieldlist.org/ Caveat: Some shields or libraries may not work together
  • 37. ELEGOO ARDUINO STARTER KIT 5pcs White LED 5pcs Yellow LED 5pcs Blue LED 5pcs Green LED 5pcs Red LED 1pcs RGB LED 5pcs 22pf Ceramic Capacitor 5pcs 104 Ceramic Capacitor 2pcs Photoresistor 1pcs Thermistor 5pcs Diode Rectifier (1N4007) 2pcs Electrolytic Capacitor (10UF 50V) 2pcs Electrolytic Capacitor (100UF 50V) 5pcs NPN Transistor (PN2222) 5pcs NPN Transistor (S8050) 1pcs Tilt Switc 5pcs Button (small) 1pcs 1 digit 7-segment Display 1pcs 4 digit 7-segment Display 1pcs Sound Sensor Module 1pcs LCD1602 Module ( with pin header) 1pcs Active Buzzer 1pcs Passive Buzzer 1pcs RTC Module 1pcs DHT11 Temperature and Humidity Module 2pcs Potentiometer 1pcs Rotary Encoder Module 1pcs Joystick Module 1pcs Keypad Module 1pcs 5V Relay 1pcs IR Receiver Module 1pcs UNO R3 Controller Board 1pcs Breadboard 1pcs Servo Motor (SG90) 1pcs Stepper Motor 1pcs ULN2003 Stepper Motor Driver Board 1pcs Prototype Expansion 1pcs Power Supply Module 1pcs HC-SR501 PIR Motion Sensor 1pcs Ultrasonic Sensor 1pcs ADXL335 Module 1pcs 3V Servo Motor 1pcs MAX7219 Module 1pcs Remote 1pcs 9V 1A Power Supply 1pcs 65 Jumper Wire 1pcs Water Lever Sensor 1pcs USB Cable 1pcs 9V Battery with DC 1pcs RC522 RFID Module 10pcs Resistor (10R) 10pcs Resistor (100R) 10pcs Resistor (220R) 10pcs Resistor (330R) 10pcs Resistor (1K) 10pcs Resistor (2K) 10pcs Resistor (5K1) 10pcs Resistor (10K) 10pcs Resistor (100K) 10pcs Resistor (1M) 20pcs Female-to-male Dupont Wire UNO R3 Arduino compatible board plus USB cable with Transport Box Component List:
  • 38. I2C* – THE LOW-SPEED BUS Multi-master serial single-ended computer bus invented by Philips Semiconductors Used in most open source hardware boards for attaching low-speed peripherals (speed 10 Kb/s-100Kb/s; newer versions even up to 3.6 Mb/s) Two bidirectional open-drain lines: Serial Data Line (SDA) und Serial Clock (SCL) Pull-up resistors to prevent floating signals Wire library available (for accessing I2C) o Master generates the clock and initiates communication o Slave receives clock and responds when addressed by master o Master sends only if it detects no start or stop bit sent by another master o Single Message or Multi Message o License free; only slave addresses must be bought * I2C = Inter-Integrated Circuit, invented by Philips Semiconductor Division, now NXP
  • 39. SOLDERLESS BREADBOARDS Connecting the Arduino to a breadboard is very useful for designing circuits without soldering When finished you may use a PCB (Printed Circuit Board) instead Breadboards consist of pin holes to place components (terminal strip) as well as bus strips: Terminal strip: all vertical lines of pin holes Notch in the middle (where mostly ICs such as DIPs are placed) Bus strips for power supply, blue = ground red = voltage NOTCH
  • 40. DRAWING CIRCUITS WITH FRITZING I use the Open Source Fritzing editor to draw my own circuits Download available from http://fritzing.org (Mac OSX, Windows, Linux) – it is free but you may provide a small donation
  • 41. THE ARDUINO IDE* Available for MacOS X, Windows, Linux at no cost Based on Processing, built with Java Subset of C/C++, (implementation of Wiring) Uses gcc & avr-gcc libraries in the build process C/C++ Libraries import You may use gcc directly or within Eclipse for C++ Other languages such as Java can remotely connect to Arduino using a wrapper on top of a RxTx native library * Free guide available at http://www.me.umn.edu/courses/me2011/arduino/arduinoGuide.pdf
  • 42. PROGRAMMING MODEL When coding a sketch (= program) for microcontroller boards like Arduino, two steps are necessary: Initialization and Controlling & Monitoring 1. Initialization phase executed once at start-up time: definitions and initialization of ports, connections, ... 2. Control Loop: „Endless“ loop in which application can monitor and control the board Application may terminate itself on specific events Initialization Control Loop start final
  • 43. INTERRUPTS IN ARDUINO Interrupts enable Event-driven Processing 3 Types of Interrupts: External: mapped to ports 2 and 3 (INT0 and INT1). Triggered when input signal is RISING, FALLING, CHANGING, ... Pin-Change: can be enabled for all Arduino signal pins. Triggered on all events. You must figure out what happened on what pin. Timer Interrupt: Three 16 bit Timers, originally exclusively dedicated for timing PWM signals. On a 16 MHz machine timer clock period can be configured from 0.0625 uS to 8388.608mS (more details on http://playground.arduino.cc/Code/Timer1) int pin = 2; volatile int state = LOW; void setup() { pinMode(pin, OUTPUT); attachInterrupt(0, blink, CHANGE); // there is also detachInterrupt } void loop() { digitalWrite(pin, state); } void blink() { state = !state; }
  • 44. BLINK IS THE NEW „HELLO WORLD“ „Hello, World“... for Electronics => Blinking LED // Pin 13 has an LED connected on most boards int led = 13; // the setup routine - runs after each reset: void setup() { // initialize digital pin as an output pin pinMode(led, OUTPUT); Serial.begin(9600); // start serial port } // infinite loop; HIGH & LOW are voltage levels! void loop() { Serial.println(“Hello, World”); // send string digitalWrite(led, HIGH); // shine a light delay(1000); // wait for a second digitalWrite(led, LOW); // switch off LED delay(1000); // wait for a second } Language based on C/C++ Serial stream received by host and displayed on the IDE‘s Serial Monitor if available
  • 45. SWITCH DEBOUNCING Problem: when pressing a switch or button the signal can bounce for a while Solution: Debouncing pattern
  • 46. DEBOUNCING– CODE (SETUP) // constants won't change. They're used here to set pin numbers: const int buttonPin = 2; // the number of the pushbutton pin const int ledPin = 13; // the number of the LED pin // Variables will change: int ledState = HIGH; // the current state of the output pin int buttonState; // the current reading from the input pin int lastButtonState = LOW; // the previous reading from the input pin long lastDebounceTime = 0; // the last time the output pin was toggled long debounceDelay = 50; // the debounce time; increase if output flickers void setup() { pinMode(buttonPin, INPUT); pinMode(ledPin, OUTPUT); // set initial LED state digitalWrite(ledPin, ledState); }
  • 47. DEBOUNCING – CODE (LOOP) void loop() { int reading = digitalRead(buttonPin); // read the state of the switch into a local variable if (reading != lastButtonState) { // If the switch changed, due to noise or pressing lastDebounceTime = millis(); // first time measure } if ((millis() - lastDebounceTime) > debounceDelay) { // whatever the reading is at, it's been there for longer // than the debounce delay, so take it as the actual current state: // if the button state has changed: if (reading != buttonState) { buttonState = reading; // only toggle the LED if the new button state is HIGH if (buttonState == HIGH) { ledState = !ledState; } } } digitalWrite(ledPin, ledState); // set the LED lastButtonState = reading; // this will be the lastButtonState in the next loop }
  • 48. ALTERNATIVE SOLUTION Using the Debounce Library (DRY) Available in the Arduino IDE Implements the same functionality in an elegant way // This code turns a led on/off through a debounced switch #include <Debounce.h> #define SWITCH 5 #define LED 13 // Instantiate a Debounce object with a 20 millisecond debounce time Debounce debouncer = Debounce( 20 , SWITCH ); void setup() { pinMode(SWITCH,INPUT); pinMode(LED,OUTPUT); } void loop() { // Update the debouncer debouncer.update ( ); // Get the update value digitalWrite(LED, debouncer.read() ); }
  • 49. YET ANOTHER ALTERNATIVE Alternatively, you might use hardware for debouncing. A capacitor is smoothing the signal If the button is not pressed, the capacitor will charge => LOW signal on Arduino digital input pin If the button is pressed, capacitor discharges quickly => HIGH signal on input pin Arduino Digital Pin Using Hardware
  • 50. PULL-UP RESISTORS Problem: circuits are subject to electrical fluctuations which may lead to an undefined state Solution: use a pull-up resistor so that when unpressed, 5V will be on pin 2, and when pressed will be low due to connection with ground Arduino internally provides Pull-Up resistors for digital pins
  • 51. void setup(){ Serial.begin(9600); // start serial connection pinMode(2, INPUT_PULLUP); // pin 2 is input and uses the pull-up resistor pinMode(13, OUTPUT); } void loop(){ //read the pushbutton value into a variable int sensorVal = digitalRead(2); //print out the value of the pushbutton Serial.println(sensorVal); // send current value via serial communication to host // Keep in mind the pull-up means the push-button's // logic is inverted. It goes HIGH when it's open, // and LOW when it's pressed. Turn on pin 13 when the // button's pressed, and off when it's not: if (sensorVal == HIGH) { digitalWrite(13, LOW); } else { digitalWrite(13, HIGH); } } PULL-UP RESISTORS – CODE
  • 52. USING PWM Problem: for dimming a led, ..., we need to change the actual current continuously, but how? Solution: Use PWM (Pulse- Width-Modulation) to simulate an analog output with variable current Done by swítching the signal on and off for specific time intervals (duty cycles) PWM is useful for fading a LED, changing DC Motor Speed, sending different tones to piezo buzzer But it is not useful where non-discrete analog values are expected
  • 53. PWM – CODE int ledPin = 9; // LED connected to digital pin 9 void setup() { // nothing happens in setup } void loop() { // fade in from min to max in increments of 5 points: for(int fadeValue = 0 ; fadeValue <= 255; fadeValue +=5) { // sets the value (range from 0 to 255): analogWrite(ledPin, fadeValue); // analog write on digital pin! // wait for 30 milliseconds to see the dimming effect delay(30); } // fade out from max to min in increments of 5 points: for(int fadeValue = 255 ; fadeValue >= 0; fadeValue -=5) { // sets the value (range from 0 to 255): analogWrite(ledPin, fadeValue); // wait for 30 milliseconds to see the dimming effect delay(30); } }
  • 54. LCD LIBRARY Problem: How can we make hardware such as the LiquidChrystal display easily usable Solution: we need to provide a library, e.g., the LiquidChrystal library to save wires use a 16x2 LCD Display combined with an I2C circuit 16x2 LCD Display Display connected to digital ports Potentiometer used to control brightness of display
  • 55. USING LIBRARIES – CODE #include <LiquidCrystal.h> // the library for using LCDs // initialize the library with the numbers of the interface pins LiquidCrystal lcd(12, 11, 5, 4, 3, 2); void setup() { // set up the LCD's to 16 numbers and 2 rows lcd.begin(16, 2); // Print a message to the LCD. lcd.print("hello, world!"); } void loop() { // set the cursor to column 0, line 1 // (note: line 1 is the second row, since counting begins with 0): lcd.setCursor(0, 1); // print the number of seconds since reset: lcd.print(millis()/1000); }
  • 56. LCD DISPLAY OVER I2C For using a standard 16x2 LCD display we had to use 6 pins on our Arduino plus Vcc plus Gnd A better option is the I2C bus where we need 2(!!!) pins plus Vcc plus Gnd Fortunately, we have a I2C connected LCD Display in our kit Connect LCD Vcc to Arduino 5V LCD Gnd to Arduino Gnd LCD SDA to Arduino Analog A4 LCD SCL to Arduino Analog A5 Potentiometer on back side of LCD to adjust brightness
  • 57. ADDING I2C LCD LIBRARY TO YOUR SKETCH Create a new sketch Download ZIP-Library from http://github.com/marcoschwartz/LiquidCrystal_I2C Add it to the Arduino Library Create new sketch Then Select IDE menu Item Sketch Select Include Library Select Add .zip Library Select downloaded file
  • 58. CODE – PRINTING ON LCD lcd.init(); // initialization of LCD lcd.backlight(); // brighten backlight lcd.setCursor(0,0); // move cursor to first line lcd.print(”building iot"); // write to display lcd.setCursor(0,1); // move cursor to second line lcd.print(”Hackathon"); // write to display
  • 59. CODE - DECLARATIONS #include <Wire.h> // communication protocol library #include <LiquidCrystal_I2C.h> // liquid crystal display library LiquidCrystal_I2C lcd(0x27,16,2); // Define LCD device on I2C address 0x27 // with a 16 x 2 characters display
  • 60. SCANNING FOR I2C DEVICES #include <Wire.h> // communication library int count = 0; void setup() { Serial.begin (9600); Wire.begin(); // starting communication } void loop(){ count = 0; for (int i = 1; i < 255; i++) { // scanning through all 256 IDs of I2C devices Wire.beginTransmission (i); // attempt communication with device ID i if (Wire.endTransmission () == 0) { // success => device found Serial.print (”Device found on "); Serial.print (" 0x"); Serial.println(i, HEX); count++; } // end if delay (5); } // end loop Serial.print ("Found "); Serial.print (count); Serial.println (" devices"); }
  • 61. TEMPERATURE SENSOR 18B20 Now, we are going to measure temperature with the 18B20 chip We only need one analog pin A2 for this purpose The sensor supports the OneWire protocol You’ll need two libraries OneWire: https://github.com/PaulStoffregen/OneWire 18B20 also known as Dallas: https://github.com/milesburton/Arduino- Temperature-Control-Library
  • 62. SIDE NOTE 1-Wire is a protocol for communicating with sensors over 1 single line One Master (microcontroller), multiple slaves Only master can initiate communication Every sensor has unique ID Similar to I2C but with lower speed. Benefit: longer range
  • 64. CODE – INITIALIZATION & SETUP #include <OneWire.h> #include <DallasTemperature.h> #define ONE_WIRE_BUS 2 // Data wire => digital pin 2 on the Arduino OneWire oneWire(ONE_WIRE_BUS); // init 1-Wire bus DallasTemperature sensors(&oneWire); // passing 1-Wire reference to sensor void setup(void) { // get serial data to PC Serial.begin(9600); // start sensor transmissions sensors.begin(); }
  • 65. CODE – CONTROL LOOP void loop(void) { // start receiving temperatures Serial.println(" Arduino as master starts retrieving temperatures"); sensors.requestTemperatures(); Serial.print(”Actual temperature: "); Serial.println(sensors.getTempCByIndex(0)); // …ByIndex(0) => get first temperature sensor }
  • 66. TEMPERATURE SENSOR TMP36 We could also have used the analog TMP36 temperature sensor instead This sensor is connected to an analog port In the circuit A0 is connected with the analog signal pin of the sensor Calculating voltage at Pin A0 (5V Arduino): milliVolts = (reading from ADC) * (5000.0 / 1024) Temperature in C°: temperature = (milliVolts – 500.0) / 10 Note: precision is 0.1°
  • 67. STARTER KIT DHT11 TEMPERATURE AND HUMIDITY SENSOR DHT11 Ultra low cost 3 to 5V power and I/O 2.5mA max current use during conversion (while requesting data) Good for 20-80% humidity readings with 5% accuracy Good for 0-50°C temperature readings ±2°C accuracy No more than 1 Hz sampling rate (once every second) Body size 15.5mm x 12mm x 5.5mm 4 pins with 0.1" spacing
  • 69. CODE – INITIALIZATION & SETUP #include <DHT.h> #define DHTPIN 2 // data pin #define DHTTYPE DHT11 // DHT 11 dht(DHTPIN, DHTTYPE); // used to access sensor int chk; float hum; // humidity float temp; // temperature void setup(){ Serial.begin(9600); // Serial monitor output dht.begin(); // start measuring }
  • 70. CODE – CONTROL LOOP void loop(){ hum = dht.readHumidity(); // read humidity temp= dht.readTemperature(); // read temperature Serial.print("Humidity: "); // print it on serial monitor Serial.print(hum); Serial.print(" %, Temp: "); Serial.print(temp); Serial.println(" Celsius"); delay(1000); // wait for one second }
  • 71. ADDING DHT SENSOR LIBRARY
  • 72. YET ANOTHER CHALLENGE We want to connect eight LEDs to our Arduino Doing this, only a few digital pins would be left for other purposes Moreover, what happens if we need to connect more LEDs than we got digital pins on the Arduino?
  • 73. SOLUTION: USE THE SHIFT REGISTER 74HC595 A Shift Register gets a byte where each bit controls an output pin Q0.. Q7 (pins 15, 1..7) Shift registers can combinable (daisy-chain) over pin 9 (carry-over) Pin 9 would be connected to Pin 14 of next 74HC595 Pin 14: send data to register Pin 12: put new data on output pins Pin 11: clock that triggers all activities Other Shift Registers may even offer 16 bits and integrated resistors The 74HC595 converts an 8-Bit binary number to its bits. It acts as a multiplexer/demultiplexer.
  • 74. CIRCUIT DIAGRAM 74HC595 Arduino Color of Wire 14: DS Digital 11 purple 11: SH_CP Digital 12 yellow 12: ST_CP Digital 8 green 08: GND GND 16: Vcc 5V 13: OE GND 10: MR 5V 1 µF Capacitor prevents signal floating on latch pin ST_CP
  • 75. CODE – CONTROL LOOP void loop() { for (int byteVal = 0; byteVal < 256; byteVal++) { // latch pin ST_CP low => number not visible on the output of the shift register digitalWrite(pinLatch, LOW); // store the byte in the register: shiftOut(pinData, pinClock, MSBFIRST, byteVal); // latch pin set to high => byte value visible at 74HC595 output pins digitalWrite(pinLatch, HIGH); // take a break delay(200); } }
  • 76. CODE – INITIALIZATION & SETUP int pinLatch = 8; // connection to ST_CP => latch int pinClock = 12; // connection to SH_CP => clock int pinData = 11; // connection to DS => data void setup() { pinMode(pinLatch, OUTPUT); // all three pins are output pins pinMode(pinClock, OUTPUT); pinMode(pinData, OUTPUT); }
  • 77. NEOPIXEL WS2812 LED built by adafruit - can be controlled using a single data line Controller + LED = WS2812 Often sold as LED strips You may cut the strip in multiple strips Simple Connection Arduino Pin Dx -> WS2812 Data Arduino 5V -> WS2812 5V Arduino GND-> WS2812 GND
  • 78. USING A WS2812 LIBRARY adafruit Neopixel library: https://github.com/adafruit/Adafruit_NeoPixel Other option FastLED library (supports other LED types as well): https://github.com/FastLED/FastLED/releases Lightweight library: https://github.com/cpldcpu/light_ws2812
  • 79. PARAMETERS FOR NEOPIXEL LIBRARY USAGE Parameter 1 = number of pixels in strip Parameter 2 = Arduino pin number (most are valid) Parameter 3 = pixel type flags, add together as needed: NEO_KHZ800 800 KHz bitstream (most NeoPixel products w/WS2812 LEDs) NEO_KHZ400 400 KHz (classic 'v1' (not v2) FLORA pixels, WS2811 drivers) NEO_GRB Pixels are wired for GRB bitstream (most NeoPixel products) NEO_RGB Pixels are wired for RGB bitstream (v1 FLORA pixels, not v2) • NEO_RGBW Pixels are wired for RGBW bitstream (NeoPixel RGBW products) • For non-Adafruit products you might need to download and use proprietary library
  • 80. CODE – SETUP include <Adafruit_NeoPixel.h> #ifdef __AVR__ #include <avr/power.h> #endif #define PIN 8 // Arduino pin connected to data-in of LED strip #define NO_OF_LEDS 16 // length of strip // for parameters see strandtest in adafruit examples Adafruit_NeoPixel pixels = Adafruit_NeoPixel(NO_OF_LEDS, PIN, NEO_GRB + NEO_KHZ800); void setup() { pixels.begin(); // Initializing library }
  • 81. CODE – LOOP void loop() { // first LED: 0, second: 1, third : 2, ... for(int i = 0; i < NO_OF_LEDS; i++) { pixels.setPixelColor(i, pixels.Color(255,0,0)); // set to red pixels.show(); // Send pixel color to strip delay(1000); // wait for a second } }
  • 82. DC MOTORS Problem: Connecting a low current Arduino with a high current consumer Solution: Transistor (npn) to separate both circuits Potentiometer to let user vary the speed Diode to prevent any induced current from damaging the circuit Source: http://www.dummies.com/how-to/content/how-to-control-the- speed-of-a-dc-motor-with-the-ar.html
  • 83. DC MOTORS – CODE int potPin = A0; // potentiometer on analog pin A0 int motorPin = 9; // motor on digital pin 9 int potValue = 0; int motorValue = 0; void setup() { Serial.begin(9600); } void loop() { potValue = analogRead(potPin); // map maps from [0, 1023] to [0, 255] motorValue = map(potValue, 0, 1023, 0, 255); analogWrite(motorPin, motorValue); // set speed Serial.print("potentiometer = " ); Serial.print(potValue); Serial.print("t motor = "); Serial.println(motorValue); delay(2); }
  • 84. ALTERNATIVE SOLUTION Use a motor shield (several available) Can support multiple motors (brushed dc motor, stepper, servo) Motor shields leverage the H-bridge L298P
  • 85. ALTERNATIVE – CODE (SETUP) const int PWM_A = 3, DIR_A = 12, BRAKE_A = 9, SNS_A = A0; void setup() { // Configure the A output pinMode(BRAKE_A, OUTPUT); // Brake pin on channel A pinMode(DIR_A, OUTPUT); // Direction pin on channel A // Open Serial communication Serial.begin(9600); Serial.println("Motor shield DC motor Test:n"); }
  • 86. ALTERNATIVE – CODE (LOOP) void loop() { // Set the outputs to run the motor forward digitalWrite(BRAKE_A, LOW); // setting brake LOW disable motor brake digitalWrite(DIR_A, HIGH); // setting direction to HIGH: motor will spin forward analogWrite(PWM_A, 255); // Set the speed of the motor, 255 is the max value delay(5000); // hold the motor at full speed for 5 seconds Serial.print("current consumption at full speed: "); Serial.println(analogRead(SNS_A)); // to be continued
  • 87. ALTERNATIVE – LOOP CONT’D // Brake the motor Serial.println("Start brakingn"); // raising the brake pin the motor will stop faster than the stop by inertia digitalWrite(BRAKE_A, HIGH); // raise the brake delay(5000); … // to be continued
  • 88. ALTERNATIVE – LOOP CONT’D // Set the outputs to run the motor backward Serial.println("Backward"); digitalWrite(BRAKE_A, LOW); // setting againg the brake LOW to disable motor brake digitalWrite(DIR_A, LOW); // now change the direction to backw: LOW DIR_A pin analogWrite(PWM_A, 255); // Set the speed of the motor delay(5000); Serial.print("current consumption backward: "); Serial.println(analogRead(SNS_A)); …
  • 89. ALTERNATIVE - END OF LOOP // now stop the motor by inertia, motor will stop slower than with brake function analogWrite(PWM_A, 0); // turn off power to the motor Serial.print("current brake: "); Serial.println(analogRead(A0)); Serial.println("End of the motor shield test with DC motors. Thank you!"); while(1); }
  • 90. SERVO CONTROLLED BY POTENTIOMETER Goal: • Read potentiometer input, map value to 0..180 degrees, and move servo to that position Parts: • Genuino/Arduino Uno • Potentiometer • Servo Motor • Jumper Wires
  • 91. CODE #include <Servo.h> // this library is provided in the Arduino IDE library folder Servo hs53; // create servo object to control a servo int potpin = 0; // analog pin A0 is connected to potentiometer int val; // variable to read the value from the potentiometer void setup() { hs53.attach(9); // attaches the servo on pin 9 to the servo object Serial.begin(9600); // starts serial data transfer to PC } void loop() { val = analogRead(potpin); // reads value from potentiometer (value between 0 and 1023) val = map(val, 0, 1023, 0, 180); // scale it to use it with the servo //(position between 0 and 180) hs53.write(val); // sets the servo position according to the scaled value delay(15); // waits for the servo to get to new position Serial.println(val); // send the new servo position }
  • 92. EXAMPLE PROJECT TRAFFIC LIGHT Building a Traffic Light with LEDs and a Piezo speaker that signals red or green.
  • 93. CIRCUIT LAYOUT • Genuino/Arduino Uno • Red, Green, Yellow LED • 3 pcs 220 Ohm Resistors • Piezo Speaker • Jumper Wires Goal: • Get used to controlling LEDs and piezo speakers
  • 94. CODE - DECLARATIONS // Simple Arduino sketch for a stand-alone traffic light by M. Stal, (c) 2016 int red = 9; // red LED on Pin 9 int yellow = 10; // yellow LED on Pin 10 int green = 11; // green LED on Pin 11 int loudspeaker = 6; // Loudspeaker on Pin 6 int REDPHASE = 5000; // Duration Red in msecs int BEFOREGREEN = 2000; // Duration Before Green int GREENPHASE = 10000; // Duration Green int BEFORERED = 2000; // Duration Before Red int IR = 0; // Interrupthandler IR called on CHANGE int TONE_DELAY = 50; // Delay between tones
  • 95. CODE - INITIALIZATION // the setup routine runs once when you press reset: void setup() { // initialize the digital pins as output. pinMode(red, OUTPUT); pinMode(yellow, OUTPUT); pinMode(green, OUTPUT); pinMode(loudspeaker, OUTPUT); Serial.begin(9600); // for talking to PC }
  • 96. CODE – UTILITY FUNCTIONS I void redHigh() { digitalWrite(red, HIGH); Serial.println("Red on"); } void redLow() { digitalWrite(red, LOW); Serial.println("Red off"); } void toneSignalRed() { for (int i = 0; i < 10; i++) { tone(loudspeaker, 440); delay(100); tone(loudspeaker, 360); delay(100); } noTone(loudspeaker); } … Functions for setting signals (= LEDs)
  • 97. CODE – UTILITY FUNCTIONS II void redPhase() { Serial.println("Red Phase"); redHigh(); toneSignalRed(); yellowLow(); greenLow(); delay(REDPHASE); beforeGreen(); } void beforeGreen() { Serial.println("Before Green Phase"); redHigh(); yellowHigh(); greenLow(); delay(BEFOREGREEN); greenPhase(); } … Applying the State pattern with “functions for states” Red Phase Green Phase Yellow before Green Yellow before Red
  • 98. CODE – HANDLING INTERRUPTS void emergencyHandler() { for (int i = 0; i < 10; i++) { tone(loudspeaker, 240); delay(TONE_DELAY); tone(loudspeaker, 160); delay(TONE_DELAY); tone(loudspeaker, 440); delay(TONE_DELAY); } } Reminder: Interrupt 0 is associated with Pin 2 Interrupt 1 is associated with Pin 3 Interrupt handlers called on defined events at these pins Example: Interrupt handler is called when switch is pressed
  • 99. CODE – MAIN LOOP // the loop routine runs over and over again forever: void loop() { noTone(loudspeaker); attachInterrupt(IR, emergencyHandler, CHANGE); redPhase(); // state machine starts with red }
  • 100. ARDUINO + ESP8266 ESP8266: Chip from Espressif for under 5 € that supports Wifi With 3.3V logic Maybe used standalone as an Arduino compatible MCU Or as a peer of the Arduino board for handling communication Different versions: we’ll use the ESP-01
  • 101. CHALLENGE 2: 2 SERIAL PORTS OF ARDUINO NECESSARY Arduino communicates with ESP8266 and host computer Solution 1 (rich man‘s approach): Use Arduino Mega Solution 2: Use software serial #include <SoftwareSerial.h> // Simulierter serieller Port #define ESP_RX 2 #define ESP_TX 3 SoftwareSerial Serial1(ESP_RX, ESP_TX);
  • 102. CHALLENGE 1: DEALING WITH DIFFERENT LOGIC LEVELS We cannot directly connect the 3.3V ESP8266 to the 5V-Arduino Solution 1 (poor man‘s approach): Voltage divider using resistors Solution 2: Logic Level Converter
  • 103. CODE void setup() { Serial.begin(9600); Serial1.begin(115200); } void loop() { // read messages from ESP-01 while (Serial1.available()) { Serial.write(Serial1.read()); } // write messages to ESP-01 while (Serial.available()) { Serial1.write(Serial.read()); } } Use Serial Monitor with 9600 Baud. Select Both NL & CR. AT => OK AT+GMR => Version AT+RST => Reset AT+CWLAP => List of WLAN APs Connect: AT+CWJAP_DEF=“SSID”,”PASSWORD” AT+CIFSR => IP/MAC
  • 104. SAMPLE CIRCUIT Arduino Uno as Bridge + Breadboard Power Component Install boardmanager in Arduino IDE: http://arduino.esp8266.com/stable/package_esp8266com_index.json is added in Arduino>Preferences >Add Additional Board Managers URLs Go to Tools>Board>Boards Manager and select ESP board: Tools>Board>Generic ESP8266 Module Restart IDE Select right port in Tools>Port To check it use File>Examples>ESP8266/Blink
  • 105. USING ESP8266 AS WIFI SHIELD On Uno we will use Pin 2 as RX Port Pin 3 as TX Port In Arduino IDE search for WiFiEsp Library and include it For example, see articles 23a and 23b in archive
  • 106. COMMUNICATION BETWEEN TWO ARDUINOS Connect two Arduinos over serial line: Tx to Rx and Rx to Tx (yellow and green wire) Don’t forget to also connect Gnd to Gnd (blue wire) One Arduino is sending numbers to the second Arduino, … … second Arduino blinks (LED on digital pin 8) <received number> + 1 times
  • 107. SERIAL COMMUNICATION TX RX RX TX ArduinoOther System e.g. USB of PC or other Arduino 2 lines: one for sending (TX) on pin 1, one for receiving (RX) on pin 0 Arduino MEGA has several serial communication lines, UNO and NANO have only one 10100011 10110100 01111111 11010101 11011011 01100111 00000000 10110101 11001111 00010101
  • 108. RX/TX COMMUNICATION Arduino to Arduino Arduino to PC PC to Arduino Server to Arduino Arduino to Server
  • 109. CODE – SKETCHES SENDER & RECEIVER void setup(){ // init. serial communication line Serial.begin(9600); } void loop(){ // send numbers 1 to 10 all the time for (int count = 1; count <= 10; count++) { Serial.println(i); //Send to receiver delay(7000); // let the other board work } } int val; const int led = 8; void setup(){ Serial.begin(9600); // init. serial comm. pinMode(led, OUTPUT); // pin with LED } void loop(){ // recv. value n and blink LED n times int incoming = Serial.available(); // get data if (incoming > 0) blink(Serial.parseInt()); } void blink(int howOften) { // blink LED for (int j = 0; j < howOften; j++) { digitalWrite(led, HIGH); // LED on delay(300); digitalWrite(led, LOW); // LED off delay(300); } delay(1000); // break to better separate events } SENDING ARDUINO RECEIVING ARDUINO
  • 110. DESKTOP TO ARDUINO - CODING OPTIONS • This presentation introduces three choices for communicating with an Arduino over serial comm. (USB) • We could have also used Arduino + WiFi- shield or Bluetooth-shield • Or nodemcu which can also be programmed using the Arduino IDE • Processing: • Implemented in Java • IDE was base for Arduino IDE • For developers, artists, … • Java: • RXTX library • JavaScript: • Server-side JS using node.js • Johnny-five library
  • 111. INTERFACE TO PROCESSING • Problem: How can we access Arduino from Processing? • Solution: use the Processing library • Based on Firmata: generic protocol for communicating with microcontrollers like the Arduino from software on a host computer. Arduino IDE based on Processing. Processing language was developed as a subset of Java to support visual artists, designers, young programmers, .... It provides stunning Animation, Simulation, Graphics.
  • 112. SERIAL COMMUNICATION BETWEEN ARDUINO AND PROCESSING Processing IDE written in Java for artists, electric engineers, SW developers Arduino IDE is based on processing Processing IDE Arduino IDE
  • 113. CODE – ARDUINO SKETCH void setup(){ Serial.begin(9600); } void loop(){ // map analog value from (0,1023) to (0,255) // will be used as a RGB value int val = map(analogRead(A0), 0, 1023, 0, 255); // write result to serial line Serial.println(val); // time to relax delay(70); } Task: • Read potentiometer • send value over serial line
  • 114. CODE – PROCESSING SKETCH import processing.serial.*; // use serial library Serial port; // communication port float potiVal = 0; // variable to hold read values from potentiometer void setup(){ // used for initialization same as in Arduino size(150,150); // draw colored rectangle with size 150 x 150 port = new Serial(this, Serial.list()[1], 9600); // access USB for serial communication port.bufferUntil('n'); // read data from Arduino until NEWLINE } void draw(){ // In Processing there is draw() instead of loop() background(potiVal,0, 0); // draw red rectangle with brightness depending on received value } void serialEvent (Serial port){ // called whenever serial data is available potiVal = float(port.readStringUntil('n')); // read data until NEWLINE; value is in [0, 255] } In your case Serial.list()[0] might be the right port. You may also directly specify the port such as “COM3” (Windows) or “/dev/<tty- usb>” in (Linux, Mac OS) Task: • Obtain value from port • Draw rectangle with Red = value received
  • 115. import processing.serial.*; import cc.arduino.*; Arduino arduino; int ledPin = 13; // standard led on board void setup() { println(Arduino.list()); // all detected Arduinos // we use the first one arduino = new Arduino(this, Arduino.list()[0], 57600); arduino.pinMode(ledPin, Arduino.OUTPUT); } void draw() // draw instead of loop { arduino.digitalWrite(ledPin, Arduino.HIGH); delay(1000); arduino.digitalWrite(ledPin, Arduino.LOW); delay(1000); } DIRECT ACCESS TO ARDUINO FROM PROCESSING - CODE EXAMPLE Include libraries Arduino(Firmata) in your sketch (Menu Item Sketch) Sketchbook is a subfolder in in your Documents folder. The link to the library is in the download slide of this presentation.
  • 116. USING JAVASCRIPT • What we need • Node.js http://nodejs.org (JavaScript Server Framework) • Johnny-Five http://johnny-five.io (JavaScript Library for accessing Arduinos, BeagleBone, Raspberry Pi, …) • Installation: • Install node.js • Use the Node Package Manager to install Johnny-Five: > npm install johnny- five • In the Arduino IDE select File/Examples/Firmata/StandardFirmata and upload it to your Arduino boards var five = require("johnny-five"); var board = new five.Board(); board.on("ready", function() { var led = new five.Led(13); led.blink(500); }); +
  • 117. JOHNNY-FIVE EXAMPLE var five = require("johnny-five"); var board = new five.Board(); board.on("ready", function() { // Create a standard `led` component // on a valid pwm pin var led = new five.Led(11); led.pulse(); // Stop and turn off the led pulse loop after 10 seconds (shown in ms) this.wait(10000, function() { // stop() terminates the interval, off() shuts the led off led.stop().off(); }); });
  • 118. USING JAVA • We need the RXTX libraries • Get RXTX libs from http://rxtx.qbang.org/wiki/index.php/Download • Install libraries: • RXTXcomm.jar (for all OS) • librxtxSerial.{jnilib | dll | so} for your OS • Make sure, Firmata is installed on your Arduino (see Johnny-Five slides) • Make sure, that there is no lock (such as /var/lock on Unix). If it is there, unlock using sudo chmod go+rxw /var/lock)
  • 119. EXAMPLE Example taken from: http://stackoverflow.com/questions/90447 58/gnu-io-portinuseexception-unknown- application Read the DrDobbs tutorial on: http://www.drdobbs.com/jvm/control-an- arduino-from-java/240163864
  • 120. ARDULINK • To make it even easier, add Ardulink see: http://www.ardulink.org
  • 121. ONLINE SCENARIOS • Retrieve e-mail and initiate an action on Arduino whenever special subject/header was found in mail • I have written an example how to access mail from Java: https://dl.dropboxusercontent.com/u/2 228034/JavaMailTest.java • You’ll need to obtain javax.mail (JavaMail) and include it in your build path: https://java.net/projects/javamail/page s/Home#Download_JavaMail_Release • You may use Twitter4J to access tweets: http://twitter4j.org/en/index.html • You may also provide a Web Server with JavaScript accessing the Arduino, i.e., a Dashboard
  • 122. EVEN MORE OPTIONS FOR WRITING ARDUINO PROGRAMS • For this list of development tools including links visit http://playground.arduino.cc/Main/DevelopmentTools
  • 123. ARDUINO SIMULATORS • Simulator for those with limited tinkering capabilities or without interest • Virtronics not perfect, but so far the best solution I found for small budget Running my Traffic Lighht example
  • 124. HACKATHON COMPETITION Invent a cool IoT device in groups of two or three Use hardware components you got (which is pretty obvious) Examples: Traffic lights on two Arduinos, one is the master, the other one the slave. Master is configurable via Internet. Thermometer with temperature being displayed as binary code on 8 LEDs or as text on LCD display and obtained via serial communication Safe locked and unlocked by Arduino when pressing the right keys. Alarm is send to user when safe is opened Clock with temperature display: values can be retrieved over Internet access
  • 125. LAST WORDS: THE PAIN OF ENGINEERING The major difference between a thing that might go wrong and a thing that cannot possibly go wrong is that when a thing that cannot possibly go wrong goes wrong, it usually turns out to be impossible to get at and repair. [Douglas Adams]
  • 126. ADDENDUM A: USEFUL TOOLS & INSTRUMENTS
  • 127. MVP - MOST VALUABLE POWERTOOLS Multimeters: 20-40€ current, voltage (AC/DC and DC), resistance, diode testing, capacitance, inductance Oscilloscope: ca. 300€ high bandwidth, frequency counter, high sampling rate, 2 channels plus one external channel Variable Power Supply: 50-80€ variable setting of DC output voltage & current (e.g., 0-30V, 0-5A)
  • 128. ADDENDUM B: BUILD YOUR OWN ARDUINO
  • 129. BUILDING YOUR OWN ARDUINO Bill of Material • 1 x Processor ATMEGA328P DIP • Optional: 1 x 28 Pin Socket Holder • 1 x Breadboard (840) • 1 x Pushbutton •16 MHZ Oscillator • 2 x Ceramic Capacitors 22pF • 1 x Green Led • 1 x Red Led • 1 x1N4001 Diode • 1 x LM8705 Voltage Regulator • 1 x Electrolyt Capacitor 100yF • 1 x Electrolyt Capacitor 10yF • 1 x 10 KOhm Resistor • 1 x 220 Ohm Resistor • Wire • 1 x Battery/Power Supply or • FTDI breakout board See also http://www.arduino.cc/en/Main/Standalone
  • 130. USING ARDUINO UNO BOARD AS PROGRAMMER • You may also buy a programmer or use an original Arduino Board to program your atmega and then move the chip to your DiY board • But you may also use an Arduino Uno as a programmer • Based on SPI (Serial Peripheral Interface): allows to upload programs to Microcontroller • Select Uno as board i the tools menu and your USB port in the Arduino IDE • Select ArduinoISP (ISP = In-System Program) in examples menu • Run it • If successful, upload Blink example to your DiY board Connect Arduino Board 5V, Gnd to 5V/Gnd terminal of your breadboard (red and black wire) (for larger boards with many components use separate power source instead) Connect digital pin 10 of Uno board to reset pin of your atmega (green wire) Connect digital pins 13, 12, 11 of Arduino Uno to pins 19, 18, 17 of your Arduino on the breadboard (yellow wires)
  • 131. BURNING A NEW BOOTLOADER • Bootloader is functionality that communicates over serial line for uploading your sketches • Not used when connecting Arduino directly over SPI • We overwrite boot loader whenever we upload a sketch over SPI • However, the original bootloader configures fuses (memory chunks) to behave as an Arduino Board • It makes sense to burn the bootloader once whenever you use a new Arduino Microcontroller • In Tools menu configure the board type of your Arduino and the serial port of your computer • As programmer choose„Arduino as ISP“ • Select Burn bootloader in Tools menu • Select Blink example from IDE • Hold shift key while pressing the run button in IDE • => Will upload sketch via Arduino Uno board to your Arduino on a breadboard
  • 132. ADDENDUM C: OFTEN USED COMPONENTS IN CIRCUITS
  • 133. CAPACITORS, INDUCTORS, AND MORE • Capacitors store power and smooth signals: available in different materials (ceramic => poles do not matter , electrolyt. => poles do matter). ingredient for High- Pass/Low-Pass/Band-Pass filters • Inductors are coils that produce a magnetic field when current flows, and induce current when moved through a magnetic field: ingredient of transformators and motors • Diodes (LEDs are diodes as well) let pass current through in only one direction) • Transistors used to build logical gates (like flip-flops) and switches (to control and separate a high current circuit from a low power circuit) Capacitors and Inductors have dynamic resistance (impedance)
  • 134. ICS Examples • 555 Timer IC: used as timer, pulse generator, ocsillator • Half-Bridge (E.g., a SN754410 offers four half bridges) lets you change in which direction current flows (e.g., motor movement clock- or anti-clock- wise). It can control high-voltage circuits. • Operational Amplifiers (e.g., 741, LM 358, LM386) : amplify input100s or 1000s of times => useful as comparators. In feedback mode different transfer functions can be implemented • Shift Registers (HC74HC595): take a byte, convert it to a bit-array with each bit being an output signal. Example application: reduce number of required pins of a microcontroller • Opto couplers (e.g., PC817): let a circuit control another circuit without being wire-connected (light used insteads) • Darlington transistor (e.g., ULN2003) chains two transistors tofurther increase the amplification: used to control motors Visit http://arduino- info.wikispaces.com/Popular- ICs to see more details
  • 135. ADDENDUM D: BRIEF DETOUR - IMPLEMENTING YOUR OWN LIBRARIES • If you want to provide a library you need to program in C/C++ • Interface defined in header file, implementation in c++ file /* Header file specifies public contract */ #ifndef Loudspeaker_h #define Loudspeaker_h class Loudspeaker { Loudspeaker(); ~Loudspeaker(); public: void playTone(int freq); void shutUp(); } #endif /* The Implementation File */ #include <Loudspeaker.h> const byte SPEAKER_PIN = 0x8; // constructor Loudspeaker::Loudspeaker() { pinMode(SPEAKER_PIN, OUTPUT); } Loudspeaker::~Loudspeaker() {/* NOP */} void Loudspeaker::playTone(int freq) {/* ... */} void Loudspeaker::shutUp() {/* ... */} Compile with gcc-avr
  • 137. ONE MORE THING? • Experiments/Projects • http://playground.arduino.cc/ • http://www.electroschematics.com/arduino/ • http://www.instructables.com/id/Arduino-Projects/ • http://www.makeuseof.com/tag/10-great-arduino- projects-for-beginners/ • http://practicalarduino.com/projects • https://learn.adafruit.com/category/learn-arduino • https://sainsmart.wordpress.com/tag/arduino-projects/ • https://arduinoprojects.xyz/ • https://learn.sparkfun.com/ • Learning/Tutorials • http://www.jeremyblum.com/category/arduino- tutorials/ • http://www.arduino.cc/en/Tutorial/HomePage • http://tronixstuff.com/tutorials/ • http://www.ladyada.net/learn/arduino/ • http://www.arduino-tutorials.com/
  • 138. ADDENDUM F: USING ESP-01 WITH ADAPTER USB to PC: View from above CH340G Driver required: Windows: http://www.wch.cn/download/CH341SER_ZIP.html Mac: http://www.wch.cn/download/CH341SER_MAC_ZIP.html Linux: http://www.wch.cn/download/CH341SER_LINUX_ZIP.html For Flash Upload: set orange cable to ground, switch pink cable (RESET) from voltage to ground and back to voltage. You may just take away ESP-01 from ground and then put it to voltage again => now ESP-01 is in update mode
  • 139. FLASHING THE FIRMWARE Example Flasher Tool for Windows: https://www.espressif.com/sites/default/files /tools/flash_download_tools_v3.6.3_0.rar Current AT-Firmware Version: https://www.espressif.com/sites/default/files /ap/esp8266_at_bin_v1.5.1.zip Visit https://www.espressif.com/en/support/down load/documents to obtain AT- Command/Instruction-Set and -Examples Documentation for ESP8266 Python tools (esptool) are also available
  • 140. INSTALLING ESP8266/ESP-01 IN THE ARDUINO IDE With special firmware we can use Arduino sketches on our ESP8266/ESP32 board. Our board then behaves like an Arduino from a coding perspective Under the hood the Arduino DIE is using other compilers & tools, however Steps: • In Preferences>Settings menu specify a new boardsmanager: http://arduino.esp8266.com/stable/package_esp8266com_index.json • In menu Tools>ESP8266>Boardsmanager search for „esp8266“ and install component found • When adapter is connected with the ESP01, choose Generic ESP8266 Module as board and select the right port • In serial monitor set mode „Both NL & CR“ and speed 115200 Baud. Type in AT <return> => ESP- 01 should return OK • Note: If you upload one of the example sketches, its firmware will be overwritten (if we have previously put GPIO0 to Low legen and then resetted the ESP-01, which brings the ESP-01 in update mode)
  • 141. AT COMMANDS (USING SERIAL MONITOR) Eingabe AT <cr> // Funktion prüfen OK AT+CWMODE=3 <cr> // Chip kann als Station oder AP arbeiten OK AT+CWJAP=“SSID“,“PASSWORD“ <cr> // Mit WLAN verbinden WIFI COMPLETED WIFI GOT IP AT+UART? <cr> // UART Konfiguration abfragen <baudrate>,<databits>,<stopbits>,<flowcontrol> AT+UART_DEF=9600,<databits>,<stopbits>,<flow control> <cr> // UART auf 9600 Baud setzen

Editor's Notes

  1. 7
  2. 11
