Objectives: 1. using indirect addressing 2. passing parameters 3. generating “random” numbers 4. working with arrays Description: Write and test a MASM (assembly language) program to perform the following tasks: 1. Introduce the program. 2. Get a user request in the range [min = 10 .. max = 200]. 3. Generate request random integers in the range [lo = 100 .. hi = 999], storing them in consecutive elements of an array. 4. Display the list of integers before sorting, 10 numbers per line. 5. Sort the list in descending order (i.e., largest first). 6. Calculate and display the median value, rounded to the nearest integer. 7. Display the sorted list, 10 numbers per line. Requirements: 1. The title, programmer\'s name, and brief instructions must be displayed on the screen. 2. The program must validate the user’s request. 3. min, max, lo, and hi must be declared and used as global constants. Strings may be declared as global variables or constants. 4. The program must be constructed using procedures. At least the following procedures are required: A. main B. introduction C. get data {parameters: request (reference)} D. fill array {parameters: request (value), array (reference)} E. sort list {parameters: array (reference), request (value)} i. exchange elements (for most sorting algorithms): {parameters: array[i] (reference), array[j] (reference), where i and j are the indexes of elements to be exchanged} F. display median {parameters: array (reference), request (value)} G. display list {parameters: array (reference), request (value), title (reference)} 5. Parameters must be passed by value or by reference on the system stack as noted above. 6. There must be just one procedure to display the list. This procedure must be called twice: once to display the unsorted list, and once to display the sorted list. 7. Procedures (except main) should not reference .data segment variables by name. request, array, and titles for the sorted/unsorted lists should be declared in the .data segment, but procedures must use them as parameters. Procedures may use local variables when appropriate. Global constants are OK. 8. The program must use appropriate addressing modes for array elements. 9. The two lists must be identified when they are displayed (use the title parameter for the display procedure). 10. The program must be fully documented. This includes a complete header block for the program and for each procedure, and a comment outline to explain each section of code. 11. The code and the output must be well-formatted. 12. Submit your text code file (.asm) to Canvas by the due date. Notes: 1. The Irvine library provides procedures for generating random numbers. Call Randomize once at the beginning of the program (to set up so you don\'t get the same sequence every time), and call RandomRange to get a pseudo-random number. (See the documentation in Lecture slides.) 2. The Selection Sort is probably the easiest sorting algorithm to implement. Here is a version of the.

1. Objectives:
1. using indirect addressing
2. passing parameters
3. generating “random” numbers
4. working with arrays
Description:
Write and test a MASM (assembly language) program to perform the following tasks:
1. Introduce the program.
2. Get a user request in the range [min = 10 .. max = 200].
3. Generate request random integers in the range [lo = 100 .. hi = 999], storing them in
consecutive elements of an array.
4. Display the list of integers before sorting, 10 numbers per line.
5. Sort the list in descending order (i.e., largest first).
6. Calculate and display the median value, rounded to the nearest integer.
7. Display the sorted list, 10 numbers per line.
Requirements:
1. The title, programmer's name, and brief instructions must be displayed on the screen.
2. The program must validate the user’s request.
3. min, max, lo, and hi must be declared and used as global constants. Strings may be declared
as global variables or constants.
4. The program must be constructed using procedures. At least the following procedures are
required:
A. main
B. introduction
C. get data {parameters: request (reference)}
D. fill array {parameters: request (value), array (reference)}
E. sort list {parameters: array (reference), request (value)}
i. exchange elements (for most sorting algorithms): {parameters: array[i] (reference), array[j]
(reference), where i and j are the indexes of elements to be exchanged}
F. display median {parameters: array (reference), request (value)}
G. display list {parameters: array (reference), request (value), title (reference)}
5. Parameters must be passed by value or by reference on the system stack as noted above.
6. There must be just one procedure to display the list. This procedure must be called twice:

2. once to display the unsorted list, and once to display the sorted list.
7. Procedures (except main) should not reference .data segment variables by name. request,
array, and titles for the sorted/unsorted lists should be declared in the .data segment, but
procedures must use them as parameters. Procedures may use local variables when appropriate.
Global constants are OK.
8. The program must use appropriate addressing modes for array elements.
9. The two lists must be identified when they are displayed (use the title parameter for the
display procedure).
10. The program must be fully documented. This includes a complete header block for the
program and for each procedure, and a comment outline to explain each section of code.
11. The code and the output must be well-formatted.
12. Submit your text code file (.asm) to Canvas by the due date.
Notes:
1. The Irvine library provides procedures for generating random numbers. Call Randomize once
at the beginning of the program (to set up so you don't get the same sequence every time), and
call RandomRange to get a pseudo-random number. (See the documentation in Lecture slides.)
2. The Selection Sort is probably the easiest sorting algorithm to implement. Here is a version of
the descending order algorithm, where request is the number of array elements being sorted, and
exchange is the code to exchange two elements of array:
for(k=0; k array[i])
i = j;
}
exchange(array[k], array[i]);
}
3. The median is calculated after the array is sorted. It is the "middle" element of the sorted list.
If the number of elements is even, the median is the average of the middle two elements (may be
rounded).
Example (user input is in italics):
Sorting Random Integers Programmed by Road Runner
This program generates random numbers in the range [100 .. 999],
displays the original list, sorts the list, and calculates the
median value. Finally, it displays the list sorted in descending order.
How many numbers should be generated? [10 .. 200]: 9
Invalid input
How many numbers should be generated? [10 .. 200]: 16

3. The unsorted random numbers:
680 329 279 846 123 101 427 913 255 736
431 545 984 391 626 803
The median is 488.
The sorted list:
984 913 846 803 736 680 626 545 431 427
391 329 279 255 123 101
Solution
TITLE Sorting Random Integers (ass_5.asm)
INCLUDE Irvine32.inc
;min and max range of the number of random integers to generate
MIN = 10
MAX = 200
;low and high range of random integers to generate
LO = 100
HI = 999
.data
intro1 BYTE "Welcome to Sorting Random Integers! My name is Frank Eslami.", 0
intro2 BYTE "This program generates random numbers in the range [100 .. 999],
displays the original list,"
BYTE " sorts the list, and calculates the median value. Finally, it displays the list
sorted in descending order.", 0
promptUser BYTE "How many numbers should be generated? ", 0
invalidInt BYTE "Invalid input", 0
arrTitle1 BYTE "The unsorted random numbers:", 0
arrTitle2 BYTE "The sorted list:", 0
arrForm1 BYTE " ", 0 ;5 spacing between elements
arrForm2 DWORD 1 ;elements per line counter
unsortedMess BYTE "The unsorted random numbers:", 0
medianMess BYTE "The median is: ", 0
userGenInput DWORD ? ;stores random numbers to be generated
randArr DWORD MAX DUP(?) ;reserve space for random numbers generated up to
the max allowed

4. randArrSize DWORD ? ;size of array (filled elements)
range DWORD ? ;range of random numbers to generate
.code
;********************* START Procedure Definitions *********************
;Title: intro
;Description: introduce the program and programmer
;Receives: none
;Returns: none
;Precondition:none
;Registers changed: none
intro PROC
mov edx, OFFSET intro1 ;introduce programmer and program title.
call WriteString
call CrLf
call CrLf
mov edx, OFFSET intro2 ;introduce program
call WriteString
call CrLf
call CrLf
ret
intro ENDP
;---------------------------------------------------------------------------------------------------------
;numsToGen
;Description: obtain & validate user's input for the number of random numbers to generate
;Receives: @userGenInput, @promptUser, @invalidInt
;Returns: [userGenInput] = int in range of [10, 200]
;Precondition: global userGenInput declared, promptUser & invalidInt initialized
;Registers changed: none
numsToGen PROC
push ebp ;save old ebp
mov ebp, esp
ObtainInput:
;Prompt user for the number of random numbers to be generated
mov edx, [ebp+16] ;prompt user for input
call WriteString
call ReadInt ;obtain integer from user

5. mov [ebp+8], eax ;store input in global userGenInput
call CrLf
;Validate user's input to be in the range [10, 200]
cmp eax, min ;compare user's input to min range allowed
jl InvalidInput ;if user's input < min input is invalid
cmp eax, max ;compare user's input to max range allowed
jg InvalidInput ;if user's input > max input is invalid
jmp Valid ;input is valid
InvalidInput:
mov edx, [ebp+12] ;warn user of invalid input
call WriteString
call CrLF
jmp ObtainInput ;obtain new input
Valid:
mov userGenInput, eax ;store user's input
pop ebp ;restore old ebp
ret 12 ;pop EBP+8
numsToGen ENDP
;---------------------------------------------------------------------------------------------------------
;GenRandNums
;Description: generate random integers and store them in an array
;Receives: global userGenInput
;Returns: randArray of size userGenInput of random integers in range [100, 999]
;Precondition: int userGenInput in range of [10, 200]
;Precondition2: randArray declared to MAX capacity
;Registers changed: none
GenRandNums PROC
push ebp ;save old ebp
mov ebp, esp
;Calculate range [LO, HI]
mov eax, HI ;high range
sub eax, LO ;HI - LO
inc eax ;eax + 1
mov ebx, [ebp+20] ;address of range
mov [ebx], eax ;store range
;Generate random numbers and store them in array

6. mov ecx, [ebp+16] ;set loop counter to user's input
mov esi, [ebp+12] ;1st element of global array
Generate:
mov ebx, [ebp+20] ;global range variable address
mov eax, [ebx] ;global range variable value
call RandomRange ;generate random number based on global range
add eax, LO ;adjust random generator for min value
;Store random number in array
mov [esi], eax ;store random integer in current array index
add esi, 4 ;add 4 bytes to current array index for next index
;Increment array size by 1
mov ebx, [ebp+8] ;size of array
mov eax, 1
add [ebx], eax ;increment array size by 1
loop Generate ;obtain & store more random numbers
pop ebp ;restore old ebp
ret 16
GenRandNums ENDP
;---------------------------------------------------------------------------------------------------------
;DisplayArr
;Description: display array elements
;Receives: @arrTitle, @randArr, randArrSize
;Returns: displays array's title with its elements, 10 per line
;Precondition: @arrTitle, @randArr, randArrSize have been inititalized
;Registers changed: none
DisplayArr PROC
push ebp ;save old ebp
mov ebp, esp
;Display array's title
mov edx, [ebp+16] ;array's title
call WriteString
call CrLf
;Display array
mov ecx, [ebp+8] ;number of elements in array
mov esi, [ebp+12] ;array
More:

7. mov eax, [esi] ;current array element
call WriteDec
;Format array output
mov edx, OFFSET arrForm1 ;5 spaces between elements
call WriteString
mov eax, arrForm2 ;number of elements per line counter
mov ebx, 10
mov edx, 0
div ebx
cmp edx, 0
jne SameLine
call CrLf
SameLine:
add esi, 4 ;add 4 bytes to current array element for next element
inc arrForm2 ;increment line counter by 1
loop More ;display more elements
call CrLF
pop ebp ;restore old ebp
ret 12
DisplayArr ENDP
;---------------------------------------------------------------------------------------------------------
;Sort
;Description: sort array
;Receives: @arrTitle, @randArr, randArrSize
;Returns: displays sorted array
;Precondition: the parameters received must be initialized
;Registers changed: none
Sort PROC
push ebp
mov ebp, esp
mov ecx, [ebp+8] ;size of array (filled elements)
L1:
mov esi, [ebp+12] ;array's current element
mov edx, ecx
L2:
mov eax, [esi]

8. mov ebx, [esi+4]
cmp ebx, eax
jle L3 ;if current element <= next element
mov [esi], ebx ;swap elements since current element > next element
mov [esi+4], eax
L3:
add esi, 4
loop L2
mov ecx, edx
loop L1
pop ebp
ret 8
Sort ENDP
;---------------------------------------------------------------------------------------------------------
;Median
;Description: calculate the median
;Receives: @medianMess, @randArr, randArrsize
;Returns: median
;Precondition: @randArr must be sorted. Remaining parameters must be initialized
;Registers changed: none
Median PROC
push ebp ;save old ebp
mov ebp, esp
;Determine whether the number of elements are even or odd
mov eax, [ebp + 8] ;array size
mov edx, 0 ;set to 0 for remainder
mov ebx, 2
div ebx
cmp edx, 0
je IsEven ;array size is even
;Array size is odd
inc eax ;add 1 to quatient to get median
jmp Display
IsEven:
mov ebx, eax
inc ebx ;ebx = eax + 1

9. add eax, ebx
mov ebx, 2
div ebx ;note that the instructions said this "may be rounded." I
assumed it was optional.
jmp Display
Display:
mov edx, OFFSET medianMess ;median message
call WriteString
call WriteDec
call CrLf
pop ebp ;restore old ebp
ret 12
Median ENDP
;---------------------------------------------------------------------------------------------------------
;********************* END Procedure Definitions *********************
main PROC
call Randomize ;create seed for RandomRange procedure
call intro ;introduce program and obtain user's input
;Obtain & validate user's input for the number of random numbers to generate
push OFFSET promptUser ;pass string argument to prompt user for input
push OFFSET invalidInt ;pass string argument to warn for invalid input
push OFFSET userGenInput ;pass argument to store user's input
call numsToGen ;procedure to validate & store user's input
;Generate random numbers and store them in an array
push OFFSET range ;pass argument for range of random numbers to generate
push userGenInput ;pass argument for random numbers to generate
push OFFSET randArr ;pass argument for array to store random numbers
push OFFSET randArrSize ;pass argument for array's size (number of filled elements)
call GenRandNums ;procedure to generate & store random numbers in an array
;Display unsorted random numbers to user
push OFFSET arrTitle1 ;title of array
push OFFSET randArr ;1st element of array
push randArrSize ;array size (filled elements)
call DisplayArr ;call procedure to display array elements

10. ;Sort unsorted array
push OFFSET randArr ;1st element of array
push randArrSize ;array size (filled elements)
call Sort ;call procedure to sort array
;Display sorted random numbers to user
push OFFSET arrTitle2 ;title of array
push OFFSET randArr ;1st element of array
push randArrSize ;array size (filled elements)
call DisplayArr ;call procedure to display array elements
;Display Median
push OFFSET medianMess ;median message
push OFFSET randArr ;1st element of array
push randArrSize ;array size (filled elements)
call Median ;call procedure to display median
exit ; exit to operating system
main ENDP
; (insert additional procedures here)
END main
