OAuth: A Question of Trust
About Me

 • Lorna Jane Mitchell

 • Twitter: @lornajane

 • Web: http://lornajane.net




                               2
If OAuth is the answer, what was the
              question?
OAuth




        username: lornajane
         password: qwerty




                              4
OAuth




        Hi, I’m lornajane




                            5
Two Kinds of OAuth

 •   OAuth 1
      • in use on many systems
      • many steps: ’the oauth dance’
      • encryption overhead (so use a lib)

 • OAuth 2
      • requires SSL
      • fewer steps
      • recognises trust
      • recommended for new systems

                                             6
OAuth 2: Performance over Paranoia
OAuth2 Relationships




                       8
OAuth2 Relationships




                       9
Before We Begin

Register for an API key and capture:

  • application name

  • callback URL(s) to use

  • description


e.g. http://joind.in/user/apikey




                                       10
OAuth2 Endpoints


    Application Website        API                 Client
    api key registration       auth endpoint       callback URL
    user grant/revoke access   resource endpoint
    resources




                                                                  11
Establishing Trust

We need an authorisation grant for the assistant to be able to access
user data




                                                                        12
Authorisation Grants
Authorisation Grant: Many Choices

How we authorise a third party:

  • authorisation code

  • implicit

  • resource owner credentials

  • client credentials

  • ... potentially further extensions




                                         14
Authorisation Code

Use for: server-side apps

Flow: we send user to application to grant access, recieve a code in
return. Then exchange code for access token

Features: user never sees access token




                                                                       15
Authorisation Code Process




                  client_id
                  redirect_url
                  type
                  scope
                  state


                                 16
Authorisation Code Process




User must be able to visit the site and revoke later
                                                       17
Authorisation Code Process




                         code




                     code
                     state



                                18
Authorisation Code Process


                  client_key
                  client_secret
                  code


                       code

                    access token




                  access_token



                                   19
Implicit Grant

Use for: client-side apps

Flow: we send user to application to grant access, recieve an access
token in return

Features: super-simple




                                                                       20
Implicit Process




                   client_id
                   redirect_url
                   type
                   scope
                   state


                                  21
Implicit Process




User must be able to visit the site and revoke later
                                                       22
Implicit Process




                       access token




                   access_token
                   state



                                      23
Resource Owner Credentials

Use for: trusted consumers, such as same-provider apps or a script the
user writes themselves

Flow: user gives username and password to app, app exchanges for
access token and does not store

Features: saves sending user to the main site and back




                                                                         24
Resource Owner Credentials Process




        username,          username,
         password           password




                                       25
Resource Owner Credentials Process




                       access token




                                      26
Client Credentials

Use for: privileged consumers

Flow: client credentials act as an authorsation grant, access token is
returned

Features: ideal for applications with more than per-user-data access
rights




                                                                         27
Client Credentials Process




                        hai

                   access token




                                  28
How to Choose Grant Type

What will be consuming this data?

It isn’t unusual for applications to support some or all of these grant types




                                                                                29
You have an access token, now what?
Using Access Tokens

With the access token, include it in an Authorization header:

Authorization:        OAuth db141c50adb74b22




                                                                31
Using Access Tokens

With the access token, include it in an Authorization header:

Authorization:                       OAuth db141c50adb74b22



Everything you already knew about web APIs now applies as normal




                                                                   31
Refresh Tokens

Some applications will give you two tokens

   • access token (shorter expiry)

   • refresh token (longer expiry)


The refresh token is an authorisation grant in its own right, to be used
when the access token has expired




                                                                           32
What about access control?
Scope

Consumers will request a given set of permissions, usually called scope

Users usually only get to accept, or not




                                                                          34
HTTPS (a vital OAuth2 ingredient)
HTTPS

HTTPS is HTTP over SSL/TLS (Secure Socket Layer/Transport Layer
Security)

Basically, we encrypt the pipe!




                                                                  36
OAuth 1
About OAuth 1

In a nutshell:

   • Had its own encryption: needed a library/extension

   • Involved many steps, therefore many request/response roundtrips

        • leading to the phrase ’oauth dance’

   • Solved exactly the same problem

   • Had a single oauth endpoint




                                                                       38
OAuth 1 Process

 • Step 0: Register as a consumer

 • Step 1: Get a request token

 • Step 2: Send the user to authenticate

 • Step 3: Swap their verification for an access token

 • Step 4: Consume data




                                                        39
OAuth Today
OAuth Today

 • New project? Use OAuth 2

 • OAuth 1 is complicated and needs PECL extension

 • OAuth 2 requires SSL, and decision-making




                                                     41
Resources and Further Reading

 • OAuth2 Spec:
   http://tools.ietf.org/html/draft-ietf-oauth-v2

 • Great introductory article:
   http://hueniverse.com/2010/05/introducing-oauth-2-0/

 • Images from http://thenounproject.org




                                                          42
Thanks!
Thanks




         https://joind.in/6232

              @lornajane

         http://lornajane.net
