1. Networks
Network Adapter
1

2. Objective of this presentation
2

3. Network Adapter (NIC)
 Also known as a Network interface card.
 Integrated circuit board that plugs into the
internal circuitry of the computer.
 Allows the members of a local-area network
to communicate with each other.
3

4.  NIC is the physical interface from
the computer or peripheral to the
medium.
 The Medium may be physical cable,
such as twisted pair wiring, coaxial
cable, fiber optic or even wireless.
4

5. Role of NIC In networking
5

6. This old ‘combo’ NIC accepts both BNC
(coaxial) and RJ45 (UTP) connectors.

7. Network Cards Convert Data from
Parallel to Serial, and vice versa
 Most computers use parallel data lines
internally to send data between the CPU and
the adapter cards. This is called a Bus.
 Most networking media transmit data in a
single line, called serial transmission.
7

8.  The NIC translates parallel into
serial for outgoing messages and
serial into parallel for incoming
messages.
 Prior to the invention of NICs, data
was sent via serial ports on the
computer.
8

9. Serial port
9

10. Need Of NICs
 Most computer networks transfer data across a
medium at a fixed rate, often faster than the
speed at which computers can process
individual bits.
 To accommodate the mismatch in speed, each
computer attached to a network contain special
purpose hardware known as a network interface
card (NIC).

11.  The NIC functions like an I/O
device: it is built for a specific
network technology.
 It handles the details of frame
transmission or reception without
requiring the CPU to process each
bit
11

12. Types of Network Interface Cards
 Fiber-Optic Network Interface Cards work on
a Fiber-Optic cabled network.
 Infrared networking uses infrared light to
transmit data from one device to another.
 Wireless network cards with antennas
operate on a wireless network with a
wireless hub.
 Copper wired Network Interface Cards work
on coaxial cable or twisted-pair wire.
12

13. ETHERNET AND WIFI NICs
 Some NIC cards work with wired connections while
others are wireless.
 Most NICs support either wired Ethernet or WiFi wireless
standards.
 Ethernet NICs plug into the system bus of the PC and
include jacks for network cables.
 while WiFi NICs contain built-in transmitters / receivers
(transceivers).

14. The MAC Address
 NICs have a unique identifier, called a Media Access
Control (MAC) address.
 It is programmed into a ROM chip on the NIC.
 It’s a 48-bit number, written as six two-digit
hexadecimal numbers separated by colons.
 The first part identifies the manufacturer.
 The second part is unique to each NIC.
14

15. IP Address
 Network Cards can have a second address
called an IP address.
 IP Address is software configurable.
 IP currently uses 32 bits split into four sections
separated by dots.
 i.e. 165.255.110.133 – These are decimal values.
 Only used in certain network protocols such as
TCP/IP.
15

16. WORKING
 A computer or device on a network can be reached by
its MAC (media access control)
address through the NIC card.
 Every Ethernet network card has a unique 48-bit serial
number called a MAC address, which is stored in ROM
carried on the card.
 The MACs on the network are used to direct traffic
between the computers.

17. Cont..
 An example of a MAC address: A1B2C3D4E5F6
 The first 6 hex digits in the MAC address is the OUI
(organizationally unique identifier), assigned by the
IEEE to each manufacturer (e.g. Cisco, Intel etc).
 The rest of the MAC address can be assigned in any way
by the manufacturer to the individual networking
devices that it manufactures

18. Installation of NICs
 The most common language or protocol for LANs is Ethernet, sometimes
referred to as IEEE 802.3.
 A lesser-used protocol is Token Ring.
 When building a LAN, a network interface card must be installed in each
computer on the network and all NICs in the network must be of the same
architecture.
 For example, all must either be Ethernet cards, Token Ring cards, or an
alternate technology.

19. Cont..
 An Ethernet network interface card is installed in an available slot inside
the computer.
 Most newer computers have a network interface built into the
motherboard.
 A separate network card is not required unless multiple interfaces are
needed or some other type of network is used.
 Newer motherboards may even have dual network (Ethernet) interfaces
built-in.

20. Network Interface Card for connection of a
computer to an Ethernet Network

21. 4. Driver Software
4.1. NIC Driver Configuration
4.2. Wireless NIC Configuration
21

22.  Device driver: small, specialized program that
22
represents a device to an OS and manages
communications between the OS and NIC
 Incorrect/poorly written drivers can have negative
impact on performance or prevent PC from booting
 Major vendor standards for drivers
 Network Device Interface Specification (NDIS)
 Win32 Driver Model (WDM)
 Open Data-link Interface (ODI)
 Installing a driver for a NIC is usually easy

23. 23

24. 4.1. NIC Driver Configuration
24

25. 25

26. 4.2. Wireless NIC Configuration
Guide to
Networki
ng
Essentials
, Fifth
Edition
26

27. 27

28. NICs on network
 The card implements the electronic circuitry required
to communicate using a specific physical layer and data
link layer standard such as Ethernet or token ring.
 This provides a base for a full network protocol stack,
allowing communication among small groups of
computers on the same LAN and large-scale network
communications through routable protocols, such as IP.

29. Configuring a Network Interface Card
 This involves three settings:
 Interrupt Request line (IRQ)
 Base Input/Output (I/O) port
 Base memory address
 In older computers, the user needed to
supply the IRQ and base I/O port. Currently
Plug and Play operating systems have
automated this task and default values are
normally assigned.
29

30. 10Mbs Ethernet Card with an ISA Slot
30
Mounting
bracket
10baseT RJ45
Socket
Status LEDs
10Base2 BNC
Connector
Each network card
has a unique 48 bit identifier
known as the Media Access Control
(MAC) number.

31. Network interface card
Network cards are
typically available in
10/100/1000 Mbit/s
varieties. This means
they can support a
notional maximum
transfer rate of 10,
100 or 1000 Megabits
per second.

32. Electronic Components on the
Network Interface Card
 Resistors
 Diodes
 Capacitors
 Coils
 Crystals
32

33. Features of the Ethernet Controller
 Scrambling: All the encoded data is passed to the data
scrambler to reduce EMI by spreading the power
spectrum using a 10-bit scrambler seed loaded at the
beginning.
33

34. Summary of the Network
Interface Card
 Allows connectivity of one computer to another.
 Controls the communication that takes place
between computers.
 Utilizes an ethernet controller chip to encode,
scramble, send and receive data.
34

35. Conti
 Converts data from parallel to serial for transmission to
another Network Interface Card.
 Comes in a variety of forms depending on the
application or network medium.
35

36. Question
 1. A bridge makes forwarding decision based on what
information .
 Ip Address
 Mac Address
 Binary Address
 Irq Address
 2. On window 2000 System ,ifconfig/all command would
you use to view the Mac Address
 Yes /no
36

37. Thank You
37
