Natural Ventilation & Lighting brochure »
Our Natural Ventilation & Lighting brochure is an introduction to the various systems we offer, detailing the health benefits, suitable applications, sectors, product information and technical specifications for each of the various systems and any complementary products available. It also includes a selection of case studies.
AN INTELLIGENT BUILDING IS THE ONE WHICH PROVIDES A PRODUCTIVE AND
COST-EFFECTIVE ENVIRONMENT THROUGH OPTIMIZATION OF FOUR BASIC
ELEMENTS: STRUCTURE, SYSTEMS, SERVICES AND MANAGEMENT, AND THE
INTERRELATIONSHIP BETWEEN THEM.
IT IS A TYPE OF BUILDING THAT USES BOTH TECHNOLOGY AND PROCESS TO
CREATE AN ENVIRONMENT THAT IS SAFE, HEALTHY, AND COMFORTABLE TO
EVERYONE.
WHAT IS AN INTELLIGENT BUILDING?
A BUILDING…
•
WHO’S SYSTEMS ARE SELF RELIANT
WITH SENSORS RELAYING DATA
THAT USES THE LATEST TECHNOLOGY
THAT IS THE FUTURE OF BUILDINGS
INTELLIGENT BUILDING
: INTELLIGENT BUILDING ADJUSTS THE INSIDE
FUNCTIONAL ASPECTS SUCH AS LIGHTING, VENTILATION, FIRE FIGHTING, AIR
CONDITIONING, ETC. AUTOMATICALLY WITH THE CHANGES IN ENVIRONMENTAL
CONDITIONS CONTROLLED BY COMPUTER.
THE SECURITY SYSTEM, COMMUNICATION SYSTEM, ETC. ARE COORDINATED AND
AUTOMATICALLY CONTROLLED BY COMPUTER WORK STATION.
ORDINARY BUILDING
: ORDINARY BUILDING THERE WILL BE DIFFERENT ROOM
CONDITIONS DEPENDING ON THE CHANGES IN THE ENVIRONMENTAL
CONDITIONS.
THE SECURITY SYSTEM, COMMUNICATION SYSTEM, ETC. ARE NOT
COORDINATED AND AUTOMATICALLY CONTROLLED BY COMPUTER WORK
STATION.
