2. Need for microneedles
From child to elder everyone hates needles
and “ PAIN” caused by them. Various systems are
adopted to avoid needles. Among them is the
“Micro needle mediate transdermal drug delivery system”
3. What is Microniddle
The concept of micro needles was first
proposed in the 1970s
Combines the benefits of hypodermic needle
injections and transdermal patches
Micro needles are typically hundreds of
microns long, 1 to 50 μm wide at the tip, and
approximately 50 - 300 μm at the base.
They can be solid/hollow and can be
fabricated as single needles or multi-needle arrays
6. Solid microneedles
Solid microneedles create holes in SC and are applied before application of medicine and
removed there after
Or the drug may be coated onto the needle
Increase the permeability by pocking the holes in skin, rub drug over area or coat needle
with drug.
They are fabricated in 750-1000μm in length
Materials used:
Silicon: Fabrication by microneedle is costly.
Silicon is brittle and may break in the skin.
Metal: They have good mechanical strength, cost is low Eg: stainless steel, titanium,
nickel, iron.
7. Dissolving microneedles
It involves encapsulating the drug within the
biodegradable, polymeric microneedles , followed
by the insertion into the skin for drug release
Materials used:
Polymers used : PLA, PGA, PLGA,PVP,
Polycarbonate
8. Hollow microneedles
Lumen diameter30μm and height 250μm.
Carry drug continuously into the body by diffusion
Large amount of drug are delivered
Remove fluid from the body for analysis
9. Advantages of micro needles
Large molecules can be administered.
Painless administration of the active pharmaceuticalingredient.
First-pass metabolism is avoided.
Faster healing at injection site than with a hypodermic needle, No fear of needle.
Ease of administration.
Decreased microbial penetration as compared with a hypodermic needle, the microneedle
punctures only the epidermis.
Specific skin area can be targeted for desired drug delivery enhanced drug efficacy may result in
dose reduction
Good tolerability without long-term edema or erythema
Rapid drug delivery can be achieved by coupling the microneedles with other technologies
10. Disadvantages of microneedles
Careful use of the device may be needed to avoid particles
‘bouncing off’ the skin surface.
The thickness of the stratum corneum and other skin layers
varies between individuals and so penetration depth of particles
could vary too.
The external environment, like hydration of the skin, could affect
delivery.
Repetitive injection may collapse the veins.
The tip of the microneedle may break off and remain within the
skin on removal of the patch.
11. Application of microneedles
Immunobiologicals :
Microneedles have an edge over the other
methods due to lack of pain.Eg: influenza vaccine, hepatitis B vaccine,
flavivirus vaccine etc.
Biopharmaceuticals:
Insulin, heparin, and growth hormones,
parathyroid hormone, human growth hormone, desmopressin
can be delivered by microneedles.
Drugs:
Diclofenac, lidocaine, naltrexone, doxetaxel etc can be
administered via microneedles
12. Application of microneedles
Ibuprofen patchPatch for diabetes Vaccine paches
Anti-Wrinkle Retinol PatchesSkin patch fights fat localized cancer immunotherapy
