This document provides instructions for making a simple electrical extension cord. It lists the necessary materials, which include an extension cord, male plug, and 3-gang convenience outlet. It also lists the required tools: screwdrivers, pliers, knife, and multi-tester. The procedure has 9 steps that include stripping and twisting the cord wires, connecting them to the male plug and outlet, and testing the completed extension cord.

3. Long Nose Pliers
Rake
Multi-meter
Side cutter pliersCrosscut Saw
Philips
Screwdriver
Monkey
Wrench
Welding
Machine
Flat
Screwdriver

4. Making Simple Electrical
Gadgets
Extension Cord

6. Pictures of Materials Needed
Heavy Duty Male Plug Flat cord no. 16 (stranded) 3 gang Convenience Outlet

7. Tools and Equipment Needed
Standard/Flat Screw Driver
Philips Screw Driver
Long Nose Pliers
Side Cutting Pliers
Electrician’s knife/ Pocket knife
Continuity Tester or Multi-tester

8. Procedure
1. Gather all necessary materials, tools and equipment
needed.
2. Insert cord into the male plug, split the cord wires about 8
centimetres long.
3. Remove insulation of both wires 1 centimetre long with a
pocket knife as if sharpening a pencil. Be careful not to cut
any strand.
4. Scrape bare wire with the back of the knife until shiny. Twist
the wire stands.

9. Procedure
5. Make a loop on terminal wires and connect the wires to the
screw of the male plug. The loop should go with the thread
clockwise direction.
6. Split the cord wires at the other end about 4 centimetres
long, then follow procedure no. 4.
7. Open the convenience outlet then remove the screw.
8. Make a loop on terminal screws, tighten it and return the
cover. The loop should go with the thread clockwise
direction.
9. Check the continuity and test the extension cord.

11. Write the number corresponding to the
sequence of instructions in making an
Extension Cord.
 ________ Gather all necessary materials, tools and equipment needed.
 ________ Make a loop on terminal screws, tighten it and return the cover. The
loop should go with the thread clockwise direction.
 ________ Check the continuity and test the extension cord.
 ________ Open the convenience outlet then remove the screw.
 ________ Insert cord into the male plug, split the cord wires about 8 centimetres
long. Remove insulation of both wires 1 centimetre long with a pocket knife as if
sharpening a pencil. Be careful not to cut any strand.
