Lecture 3
Statistical Process
Control (SPC)
Data collection for Six SigmaData are simply facts and figures without context or interpretation.Information refers to useful or meaningful patterns found in the data.Knowledge represents information of sufficient quality and/or quantity that actions can be taken based on the information.If data are not collected and used wisely, their vary existence can lead to activities that are ineffective and possibly even counterproductive.An organization collects data & reacts whenever an out-of-specification condition occurs.
“Common cause” & “ special cause” variation
There are two causes of process variations:
1) Common cause variation: This variation is due to the process only. It may not tell you whether the process meets the needs of the customer unless it is compared with the specification. This can be improved by focusing on the process.
2) Special cause variation: This variation is due the individual employee, if the point is beyond specification limits. In this case the focus should be about what happened relative to the individual employee as though it were a “special” condition.
Attribute versus Variable Data
Attribute data: It is a data with yes or no decision such as:whether an iten passed or failed a testpass/fail, go/no go gaging, true/false, accept/reject. There are no quantifiable values
Variable data: are related to measurements with quantifiable values such as:Diameter of a part which has been machinedlength or thickness of the machined part
The success of Six SigmaThe success of Six Sigma depends upon knowing the difference between special & common cause variations and how the organization reacts to the data.If the management focuses on wrong cause of variation, it can lead to waste of time (firefighting).It can also effect employee motivation & morale.Reacting to one data point that do not meet the specification limit can be counterproductive and very expensive.Do not use “firefighting” actions just because the data point is out of specification limits. It must first be determined whether the condition is common or special cause.
Example of variability due to common causeControl limits are calculated from the sample data.There are no data points outside the control limits therefore there are no special causes within the data.The source of variation in this case is “common cause” due to process.
Type of firefighting done by management before evaluating the cause of variabilityProduction supervisors might constantly review production output by employee, machine, product line, work shift etc.An administrative assistant’s daily output & memo’s may be monitored.The average time per call may be monitored in a call center.The efficiency of computer programmers may be monitored by tracking “lines of code produced per day”.
All of these actions would be a waste of time if the cause of variability is “common cause” and due to the process rather than individu ...
