Power hacksaw machine
development of pedal power hacksaw machine
Aim : this project manly used for cutting wood and plastics, it is manually pedal operated
circular motion lo linear motion system.
Abstract
In this project Pedal Operation convert Energy Input given by Operator to Circular
motion of the wheel. Pedaling also useful as an exercise. Pedal Power is converted into
mechanical work. This Circular motion of the pedal crank is converted into reciprocating or
sometime oscillatory motion to drive Hacksaw blade. Generally Hacksaw is operated by
manually, hydraulically, electrically motor or pulley commonly used in industries and workshop.
'To and pro motion of the hacksaw blade should cut the required material.
Block diagram

2. 1000KV TECHNOLOGIES 9030 844 866 / 9030 844 877
ECE / EEE / EIE / MECHAICAL / MECHATRANIC MAIN & MINI PROJECTS
1000KV TECHNOLOGIES
FLAT NO:#A2 ; EurekaCourt Complex ;OPPLine of R.S Brothers; near Image Hospital ;Ameerpet
9030 844 866 / 9030 844 877
Project demo view
Block diagram using modules
 Cycle pedal
 Wheels
 Connecting rod
 Hacksaw blade
Advantages
 Power saving as it is manually operated
 Easy mechanism and simple construction
 As it is pedal operated so good for health
 Comfortable then ordinary hacksaw
Application
 This project can be applicable to cut small round, square bars.
 Hacksaw blade as well RPM required , type of material, type of jobs and total hardness of
the material which is to be cut.
Declaration of Project Interest to Project Guide:
 Respected Sir/Madam,
 We are happy to work this project under your guidance, and we are interested to
develop this idea, kindly accept to allow us to this project
 THANK YOU!
