- JavaScript patterns like custom events, deferreds, and pub/sub can help manage asynchronous processes in the browser environment. Custom events allow defining and triggering custom events. Deferreds help manage callbacks and caching of asynchronous results. Pub/sub implements a publisher/subscriber pattern for loose coupling between modules. These patterns help modularize applications and decouple components.

1. JavaScript Essential Patterns
othree @ OSDC 2012

2. Who am I
• othree
• MozTW member
• F2E at HTC
• http://blog.othree.net

3. Evolution of the Web
WWW
Browser Wars
Web Standards
Web Applications
Web 2.0
Mobile
1990 1995 2003 2005 2006 2010

4. Web Applications

5. Text

10. Problem to F2E
• Large scale application never seen on Web

11. But
• The problem F2Es face today already exists

12. What is Pattern
• A general reusable solution to a commonly
occurring problem within a given context in
software design.
http://en.wikipedia.org/wiki/Software_design_pattern

13. GOF Book, 1994

14. Browser Environment
• Async
• Event Driven
• Async
• Source Code from Internet
• Async
• Business Logic on Server

15. Patterns to Talk Today
• Custom Event
• Deferred
• PubSub

16. Custom Event
http://www.flickr.com/photos/swehrmann/6009646752

17. Event
• Something happens to an element, to the
main document, or to the browser window
and that event triggers a reaction.
http://www.yuiblog.com/blog/2007/01/17/event-plan/

18. Native Events
• DOM Events • BOM Events
• UI • load
• UI logic • error
• mutation • history
• ... • ...

19. Problem of IE
• Didn’t follow the W3C DOM standard
• Memory leaks
• Not support bubbling/capturing
• ‘this’ is window, not element
• ‘event’ is different
http://www.quirksmode.org/blog/archives/2005/08/addevent_consid.html

20. Dean Edward’s Add Event
• Manage callback functions
• Fallback to elem.onevent = function () { ... }
• Only one function for each event
http://dean.edwards.name/weblog/2005/10/add-event2/

21. jQuery’s Event
• Normalize event object
• ‘trigger’ method to fire specific event

22. ‘trigger’ Method
• Can fire any event as you wish
• Even none native event name works

23. Custom Event
• An event name is defined by you, triggered
by you

24. When to Trigger
• State/Value change

25. Observer
• Define a one-to-many dependency between
objects so that when one object changes
state, all its dependents are notified and
updated automatically.
GoF Book

26. Example: Backbone
• A driver model
• A car model
• Driver’s tension will get higher when shift
gear

27. Driver
var Driver = Backbone.Model.extend(
defaults: {
tension: 0
},
tensionUp: function () {
this.set({
tension: this.get('tension') + 1
});
}
);

28. Car
var Car = Backbone.Model.extend(
defaults: {
gear: 'P'
}
);

29. Observer
var driver = new Driver(),
car = new Car();
car.on('change:gear', function () {
driver.tensionUp();
});
//GO
car.set({
gear: 1
});

30. Advantages
• Loose coupling
• Prevent nested codes

31. Deferred
http://www.flickr.com/photos/gozalewis/3256814461/

32. History
• a.k.a Promise
• Idea since 1976 (Call by future)
• Dojo 0.9 (2007), 1.5 (2010)
• jQuery 1.5 (2011)
• CommonJS Promises/A

33. What is Deferred
• In computer science, future, promise, and
delay refer to constructs used for
synchronization in some concurrent
programming languages.
http://en.wikipedia.org/wiki/Futures_and_promises

34. Example: Image Loader
function imgLoader(src) {
var _img = new Image(),
_def = $.Deferred();
_img.onload = _def.resolve; //success
_img.onerror = _def.reject; //fail
_img.src = src
return _def;
}

35. Use Image Loader
imgLoader('/images/logo.png').done(function () {
$('#logo').fadeIn();
}).fail(function () {
document.location = '/404.html';
});

36. jQuery Deferred
• Multiple callback functions
• Add callbacks at any time
• jQuery.when
http://api.jquery.com/category/deferred-object/

37. Image Loader with Cache
function imgLoader(src) {
if (imgLoader[src]) {
return imgLoader[src];
}
var _img = new Image(),
_def = $.Deferred();
imgLoader[src] = _def;
_img.onload = _def.resolve; //success
_img.onerror = _def.reject; //fail
_img.src = src
return _def;
}

38. Use Image Loader
imgLoader('/images/logo.png').done(function () {
$('#logo').fadeIn();
}).fail(function () {
document.location = '/404.html';
});
imgLoader('/images/logo.png').done(function () {
App.init();
});
imgLoader('/images/logo.png').fail(function () {
App.destroy();
});

39. jQuery.when
$.when(
$.getJSON('/api/jedis'),
$.getJSON('/api/siths'),
$.getJSON('/api/terminators')
).done(function (jedis, siths, terminators) {
// do something....
});

40. Advantages
• Manage callbacks
• Cache results
• $.when

41. PubSub
http://www.flickr.com/photos/birdfarm/519230710/

42. Case
• A module know when user signin
• X,Y modules need to know when user
signin
• A should not fail when X or Y fails

43. Without PubSub

44. X
signin
signin
A Y
B Z

45. X,Y depends on A

46. PubSub
Subscribe Event Only

47. X
PubSub
A Y
B Z

48. subscribe
‘signin’
X
PubSub
subscribe
A ‘signin’ Y
B Z

49. X
PubSub
publish
A ‘signin’ Y
B Z

50. signin X
PubSub
signin
A Y
B Z

51. Publish/Subscribe
• Mediator + Observer
• Easy to implement

52. $(document).trigger('eventName'); // Using .on()/.off() from jQuery 1.7.1
//equivalent to $.publish('eventName') (function($) {
$(document).on('eventName',...); var o = $({});
//equivalent to $.subscribe('eventName',...) $.subscribe = function() {
o.on.apply(o, arguments);
};
$.unsubscribe = function() {
o.off.apply(o, arguments);
};
$.publish = function() {
o.trigger.apply(o, arguments);
};
}(jQuery));
// Multi-purpose callbacks list object //Using Underscore and Backbone
// Pub/Sub implementation:
var myObject = {};
var topics = {};
_.extend( myObject, Backbone.Events );
jQuery.Topic = function( id ) {
var callbacks,
topic = id && topics[ id ]; //Example
if ( !topic ) {
callbacks = jQuery.Callbacks(); myObject.on('eventName', function( msg ) {
topic = { console.log( 'triggered:' + msg );
publish: callbacks.fire, });
subscribe: callbacks.add,
unsubscribe: callbacks.remove myObject.trigger('eventName', 'some event');
};
if ( id ) {
topics[ id ] = topic;
}
}
return topic;
};
http://addyosmani.com/blog/jqcon-largescalejs-2012/

53. When to Use
• Module and module have dependency but
not really depend on it.

54. Example: Error Handler
• An module to control the behavior when
error occurs
• All other module should call it when
something went wrong
• No module should fail because error
handler fails

55. Error Handler Code
//Error Handler
$.subscribe('AJAXfail', function () {
alert('Something wrong!!');
});
//Code
$.get('/api/siths').fail(function () {
$.publish('AJAXfail');
});

56. Advantages
• Loose coupling
• Scalability

57. Summary
• Control async process using deferred
• Modulize your application
• Decouple using custom event
• Decouple more using pubsub

58. Further Reading...

61. http://addyosmani.com/resources/essentialjsdesignpatterns/book/

62. http://shichuan.github.com/javascript-patterns/

63. http://leanpub.com/asyncjs

64. May the Patterns be with You

65. Questions?
