JAVA PLATFORMS

•J2SE – Java 2 Standard Edition    Java for the desktop / workstation
     •
•J2ME – Java 2 Micro Edition       Java for the consumer device

•J2EE - Java 2 Enterprise Edition  Java for the server
J2ee   J2se   J2me
J2EE Supports

• Extensible Markup Language

• Web Applications

• Web Services Support / WSDL Standard Format

• UDDI and ebXML Standard Formats

• HTTP-SOAP Transport Protocol
•J2EE comes with a built in application server

•J2EE defines Java API for XML Processing (JAXP)
API for processing XML

•Uses SAX and DOM standards
•J2EE does not specify the nature and structure of
the runtime.

•J2EE Container – capability of the runtime to
manage application components.

•J2EE APIs specifies the contract between the
applications and the container.
Data

                                                                                                                         JDBC

                                                                                                                                    RDBMS

Client                                    Application Logic
                                                                                                                        JavaMail

                         Web Container                                                                                             Mail Server
HTML/
 XML                                                                                                                      RMI
           Servlets                        JSPs
                                                                                       J2EE
           RMI/IIOP




                                                JavaMail                            Application
                                   JDBC
                      JNDI




                                                                                      Server
                                          JMS

                                                                                                                         IIOP
                             JTA




                                                           JAF
 Applet
                                                                                EJB Container                                        CORBA
                                                                 Session Beans                   Entity Beans
                                                                                                                        JNDI
 Client
Applica-
  tion
                                                                  RMI/IIOP
                                                                                                                               Directory Services




                                                                                                       JavaMail
                                                                                          JDBC
                                                                             JNDI
                                                                                                                         JMS



                                                                                                 JMS
                                                                                    JTA




                                                                                                                  JAF
•The Component technologies – to hold the business logic. (JSP, Servlets and EJB)

•The Service technologies – to provide supported services to application
components (JDBC, JTA, JNDI)

•The Communication technologies – transparent to appln programmer, provide
the mechanism for communication among different parts of the appln.
(JMS, JavaMail, RMI-IIOP)

•They are re-usable software units containing business logic.

• An EJB is just a collection of Java classes and an XML file, bundled into a single
unit.
• They are re-usable software units containing business logic.

• An EJB is just a collection of Java classes and an XML file, bundled into a
  single unit.

• Java classes must follow certain rules and provide certain callback
   methods.
• Session Beans

• Entity Beans

• Message-driven Beans
• Intended for the use of a single client.

• Lifespan is limited to that of its client.

• When the client leaves the web site or the application is shut down, the
  session bean disappears.
Can keep information on behalf of its client across method calls.


For example,

     Full information of the client is stored in every transactions
example , credit card
• This bean implements a particular business logic, though its
created for a particular client, it doesn’t have to remember anything
about the client.


• Can be considered as a remote procedure that gets executed on
behalf of the client, taking some parameters and returns the result
(of calculation in a particular business rule context).
•Persistence is its basic property.

•It stays around even after the program is terminated until it is deleted.

•When the program is restarted, it can gain access to this bean again.

•It can be used by any program on the network.

•It is executed remotely.

•It is identified by a primary key.

•Its nothing but the object representation of records in RDBMS tables.
Advantages

• J2EE provides a complete architecture for developing

       - Distributed systems including object persistence, session tracking,
         transaction management, …

•Separation of technical and application-specific code

       - Deployment descriptors
       - Container Managed Persistence
Disadvantages

• Very complex technology
     Even simple examples require many interfaces, bean classes, deployment
     descriptors.
• Many errors occur only at runtime (several steps required until the application is
                                                                              running)
- Compilation
- Packaging
- Deployment
- Running the application
A Web Application Framework (WAF) is a
reusable, skeletal, semi-complete modular platform
that can be specialized to produce custom web
applications , which commonly serve the web browsers
via the Http's protocol.


WAF usually implements the Model-View-Controller
(MVC) design pattern, typically in the Model 2
architecture to develop request-response web-based
applications on the Java EE and .NET models.
Request-based Framework :
          Struts
          WebWork
          Beehive , Stripes

Component-based Framework
        Jave Server Faces (JSF)
        Tapestry
        Wicket

Hybrid – Meta Framework
          RIFE
          Spring Framework

RIA-based Framework
          DWR
          Echo2
          JSON-RPC-Java
