The document discusses IPLook's vCore virtualization platform for network functions. It describes how the platform uses standard IT hardware and the Linux operating system to virtualize network functions using KVM virtualization. It supports both proprietary and standard virtualized network functions (VNFs) like virtualized Evolved Packet Core (vEPC) and virtualized IP Multimedia Subsystem (vIMS). Key features of the platform include enhanced packet forwarding using DPDK, flexible element management and orchestration with OpenStack, high availability of VNFs using redundancy, and resource pooling and load balancing of VNF instances.

1. WWW.IPLOOK.COM
Security Level:
IPLook vCore(vEPC)
2018/03 v1.03

2. WWW.IPLOOK.COM
Outline
1. NFV introduction
2. IPLOOK vCore Platform
3. Key features
4. vEPC & vIMS at a glance

3. WWW.IPLOOK.COM
NFV Introduction

4. WWW.IPLOOK.COM
NFV - Service Provider’s appeal
• OPEX and CAPEX saving.
• Reduce dependency on proprietary hardware .
• Expand service choice to include open-standard,
open-platform ingredients, solutions, and software.
• Rapid service deployment and monetization.

5. WWW.IPLOOK.COM
ETSI NFV Architecture Framework

6. WWW.IPLOOK.COM
IPLOOK Virtual Core Platform

7. WWW.IPLOOK.COM
IPLook vCore Cloud Platform
Network Functions Virtualization Infrastructure
 includes standard IT, high-volume hardware based on the Intel
architecture processors and 10G network interface cards (NICs).
 Red had Linux software execution environment, which includes KVM
(Kernel-based Virtual Machine) and Open vSwitch module, as well as
real-time extensions for virtualization.
Virtualized Network Functions
 IPLook proprietary VNF, covering vEPC and vIMS domain.
 Provide standard 3GPP network node function.
SDN Networking
 Openflow controller liked Open Daylight is used to manager open
vswitch, provides smart traffic steering policy control.
NFV Management and Orchestration
 manages overall VNF deployment and lifecycle.
 solution is provided by *Open Stack*, including compute(Nova),
storage(Swift), image(Glance), orchestration(Heat) and identity services
(Keystone).

8. WWW.IPLOOK.COM
10G physical NIC
X86 multi-core processors
Red had Linux + KVM + open vSwitch
VM
IPLOOK
EPC VNF
DPDK
VM
DPI VNF
DPDK
VM
APP
Server
Open Stack
keyston
e
Glance Nova Swift Heat
OpenDayLight
Openflow control
IPLOOK
Cloud
Manager
VM
IPLOOK
IMS VNF
DPDK
IPLook vCore Achitecture

9. WWW.IPLOOK.COM
Key Features

10. WWW.IPLOOK.COM
Enhanced Packet Forwarding
Enhanced Open vswitch
Linux*
Distribution
KVM SR-IOV
VM
Intel DPDK
Enterprise Linux
Buffer Management
Queue/Ring Functions
Packet flow classification
Poll-mode driver
IP stack
(route, forward, policy)
MME
Application
SGW
Application
PGW
Application
Middle ware
Reducelatency
Smartsteeringpolicycontrol

11. WWW.IPLOOK.COM
Flexible element M&O
Virtual
compute
Virtual
storage
Virtual
network
vMME vSGW vPGW vHSS
Nova
Hypervisor
Glance
Swift
Openstack
Service
monitor
Dashboard
Authentication
Redundancy
Manager
Orchestration
monitor
provisioning
orchestration
report
control
Provisioning
Agent
3rd Part
IPLOOK
proprietary
IPLOOK
enhanced

12. WWW.IPLOOK.COM
High availability
Enhanced vSwitch
Flow table, policy, packet steering
Active
VM
Standby
VM
Redundancy Manager
Spare strategy, VM registration, VM health check
Service
Orchestration
Provisioning
Agent
Sync up
 Support 2N VMs hot standby.
 Service Orchestration provides
interface to define VM roles,
active or standby.
 Redundancy Manager is key
component in HA, manages
spare strategy, maintains VNF
registration and monitor VMs
healthy.
 VNF will register to Red Mngr
when booting up. VMs pair-up
take place if they matches the
spare strategy.
 Only active VM provides
service, standby VM switch
over to active when active VM
failure occur.

13. WWW.IPLOOK.COM
vEPC & vIMS

14. WWW.IPLOOK.COM
IPLook proprietary EPC at a glance
 3GPP full compliance.
 Hardware independent..
 High available and throughput.
 NFV enhancement.
 Elastic deployment..
 Oversea LTE construction case.
 Provide industry area End-To-End
LTE solution.
ATCA
Blades
X86 HW/FW
Hypervisor
Carrier Grade Linux
Kernel, root file system, carrier grade extensions
IP Stack
Routing control
Forward table
Packet steering
Policy & filters HA Middle Ware
OAM & P
Fault, Performance,
CLI
Packet core common interface
MME SGW PGW HSS PCRF

15. WWW.IPLOOK.COM
EPC VNF resource pool
vMME vSGW vPGW
S6S11 S5/S8S1 SGI
SCTP NAS GTP DIAMDETER
OSPF RIP BGP VLAN
Enhanced Open-flow Switch
 vEPC VMs comprise a
resource pool, provide load
sharing to satisfy network
capability and HA requirement.
 A enhanced SDN open-flow
switch provide high throughput
and smart packet steering.
 Standard 3GPP, RFC protocol
support.
VMs
Pool

16. WWW.IPLOOK.COM
IPLook proprietary IMS at a glance
SGI
vP-CSCF
IPLOOK
proprietary
vI-CSCF
IPLOOK
proprietary
vS-CSCF
IPLOOK
proprietary
vEPC
IPLOOK
proprietary
vMGCF
IPLOOK
proprietary
vIM-MGW
IPLOOK
proprietary
Virtualization Layer
PCRF
IPLOOK
proprietary
Gx
Rx
HSS
IPLOOK
proprietary
Cx
S6a
IMS domain virtual
VoLTE Supported

17. WWW.IPLOOK.COM
THANK YOU!
广州爱浦路网络技术有限公司
Guangzhou iplook network technologies co.,ltd
地址(address)：广州市萝岗区科学城科学大道162号创意大厦b2-1103
B2-1103 Changyi Building ,162 science AVE, science city, Guangzhou, China
电话(tel)： +862028906963
邮箱(邮箱)： sales@iplooknetworks.com
网址(websit)： www.iplooknetworks.com
