Bol.com uses the Elastic (ELK) stack to make sense of logs from over 1,600 servers and 500-600 million events per day. Key aspects of their system include: 1. Shipping JSON-formatted log events from sources like Apache, databases, and applications to Redis queues to allow multiple Logstash instances to process events in real-time without data loss. 2. Enriching log events with information like request IDs to correlate requests across services, and IP-to-role mappings to identify client roles. 3. Using Elasticsearch aggregations and transformations to generate a directed graph of service dependencies based on logs, to help understand their distributed architecture.

1. Renzo Tomà, bol.com
1
How bol.com makes sense of its logs,
using the Elastic technology stack.

2. How bol.com makes sense of its logs,
using the Elastic technology stack.
2
Renzo Tomà, Oct. 29 2015

3. • Renzo Tomà
• IT Operations engineer at bol.com, large webshop in the Netherlands and Belgium
• Product owner & tech lead for 2 platforms: metrics & logsearch
• Opensource user + contributor
• Husband and dad of 2 cool kids!
3
Please to meet you

4. ELK powers a Logsearch platform (“grep on steroids”).
Log events from many layers of our infrastructure.
Central user interface for querying: Kibana.
For software developers, system engineers & our security team (~300 potential users).
Supports development & operations co-op (sharing Kibana dashboards = 1 truth).
Bottomline: faster incident resolution = less revenue loss.
4
bol.com & ELK

5. ELK is a 1st class citizen, since datacenter rebuild go-live in 2014.
Getting feeds from:
• 3 datacenters
• 5 frontend apps, 80+ services
• lots of databases
Log types: Apache and Tomcat access logging, Log4j, PostgreSQL, Oracle, syslog, …
Numbers:
• 1600+ servers emitting log events
• 500-600 million events per day, indexing peaks at 25k/sec
• 23 billion events stored, 14TB * 2 on disk
• We keep 90 days available for search.
5
ELK as 1st class citizen

6. 6
Our high level design

7. 7
Great, but how do those events get into Redis?

8. In 2013: tail files & ship lines to Logstash over UDP. Lots of grokking.
Logstash (1 instance) unable to process feed in real time => data loss, incomplete events.
Need for speed & simplicity!
• Scale Logstash instances. Use Redis as message bus, to feed multiple Logstash instances.
• Reduce need for complex grok. Format events in a structured format.
In 2015: events get converted into JSON docs at the source. Our shippers run inside JVMs and DBs.
Logstash reads from Redis and decodes events. No more grokking.
Logstash out of work? No. Cleanup, enrichment (IP geo location) and metrics generations (lag, throughput).
8
Struggles in log shipping

9. Application server access logging (Tomcat):
Inside Tomcat: convert ‘hits’ into JSON doc and send to Redis: https://github.com/bolcom/redis-log-valve
Java application logging (Log4j):
Inside JVM: convert events into JSON doc and send to Redis:
https://github.com/bolcom/log4j-jsonevent-layout + https://github.com/bolcom/log4j-redis-appender
Webserver access logging (Apache):
• Custom LogFormat to output ‘hit’ as JSON: http://untergeek.com/2013/09/11/getting-apache-to-output-json-for-logstash-1-2-x/
• Apache sends JSON docs to external process, which sends to Redis.
Docker logging:
Shipper container: subscribes to logs for all running containers, convert events into JSON doc and send to
Redis:https://github.com/bolcom/logspout-redis-logstash
Oracle logging:
Inside database: custom PL/SQL package with API, creates JSON docs and send to Redis.
PostgreSQL logging:
Inside database: hooks into logging, convert events into JSON doc and send to Redis: https://github.com/2ndquadrant-it/redislog
9
The logshippers we use

10. Each Webshop request gets tagged with Request ID.
Webshop is connected to 25 services. Request ID gets attached to all service calls.
It gets logged in many places.
Correlation time!
Search for a Request ID and see:
• initial Webshop request
• all service calls made
Including: order, parameters,
status codes and responsetimes.
10
Special sauce 1/2: the call stack

11. We have 5 frontend application and 80+ services. Services calling services.
New services get introduced. New connections are made. Canary releases. A/B testing…
Its a living distributed architecture.
We need a map, we can trust!
Let’s build a directed graph.
• Use the Tomcat access logging
• Add “A called B” information
• Elasticsearch aggregation query
• Transform the result and draw graph
11
Special sauce 2/2: the service map

12. Event emitted for every request a Tomcat Java application processes:
12
Tomcat access log events
{
"@message": ”/v1/get-product/987654321”,
"@source_host": ”pro-catalog-001",
"@fields": {
"agent": "curl/7.43.0",
"role": ”catalog",
"verb": "GET",
"time_in_msec": 2,
"response": 200,
"bytes": 75,
"client": ”10.0.0.1",
"httpversion": "HTTP/1.1",
"time_in_sec": 0,
"timestamp": 1443101965498
}
}

13. We create a lookup table for our whole datacenter IP space:
“10.0.0.1”: “webshop”
“10.0.0.2”: “catalog”
…
Add new field, using Logstash ‘translate’ filter:
translate {
dictionary_path => ‘ip-to-role-mapping.yaml’
field => ‘client’
destination => ‘client_role’
}
That’s all we need.
13
Enrich events with external data
{
"@message": ”/v1/get-product/987654321”,
"@source_host": ”pro-catalog-001",
"@fields": {
"agent": "curl/7.43.0",
"role": ”catalog",
"verb": "GET",
"time_in_msec": 2,
"response": 200,
"bytes": 75,
"client": ”10.0.0.1",
”client_role": ”webshop",
"httpversion": "HTTP/1.1",
"time_in_sec": 0,
"timestamp": 1443101965498
}
}

14. 14
Searching & transforming
# search query
{
"size": 0,
"query": { … },
"aggs": {
"_apps_": {
"terms": {"field": "role"},
"aggs": {
"_clients_": {
"terms": {"field": "client_role"},
}
}
}
}
}
# search result
{
"hits": { … },
"aggregations": {
"_apps_": {
"buckets": [
{
"_clients_": {
"buckets": [
{
"key": ”catalog",
"doc_count": 1234,
},
…
],
"key": “webshop",
…
}
}
],
}
}
}
# dot file
digraph {
node [shape=box];
“webshop" -> “catalog" [label=1234];
"abc" -> "foo" [label=42];
"foo" -> "bar" [label=13];
…
}

15. 15
That makes sense! (Sort of …)
Names have been obfuscated. Sorry.

16. 16
That makes sense!

17. Renzo Tomà
rtoma@bol.com
Thanks!
