The document discusses performance improvements in Neo4j 3.2 including faster native label indexing, composite indexes for multi-property queries, orders of magnitude speed increases for reachability queries through pruning, and up to 300% faster query performance from the new compiled Cypher runtime. It provides details on these improvements such as the new GBPTree index design for native labels and conditions for using composite indexes.

1. Craig Taverner
Cypher Team Lead
Performance Improvements
in Neo4j 3.2

2. Craig Taverner
craig@neo4j.com
@craigtaverner
Craig Taverner
craig@neo4j.com
@craigtaverner

3. Native Graph Performance Improvements
• Native Label index: Writes now 30-300% faster
• Composite indexes: Faster multi-property queries
• Reachability Queries: Can improve by orders of magnitude
• Compiled Cypher runtime: Speeds queries up to 300%
• Neo4j Browser: Ground-up rewrite yields snappier
performance

4. Cypher Parser
Performance Improvements in Neo4j 3.2
• Native Label Index
• Composite Indexes
• Compiled Runtime
• Reachability (Pruning Var Expand)
• Solving OR Using Indexes
Cypher Planner
Cypher Runtime
Neo4j Kernel
Storage
CompositeIndexes
Compiled
Native
Label
Index
PruningVXOr

5. Native Label Index
• New GBPTree Index
• Designed for
concurrent read and
write load
• Performance
• Similar for reads
• Faster for writes

6. Composite Indexes
Full-stack generalisation of schema indexes to multiple properties
• Cypher:
CREATE INDEX ON :Person(firstname,lastname)
MATCH (n:Person)
WHERE n.firstname = 'Joe' AND n.lastname = 'Soap' RETURN n;
• Core API:
gds.schema().indexFor(Label.label("Person"))
.on("firstname")
.on("lastname")
.create();

7. Composite Indexes
Cypher queries will use the composite index if the following conditions exist:
• Predicates must exist for all properties in the index and be equality
predicates for the index to be used.
• Predicates for existence, range, starts-with, ends-with and contains will not
be able to use the index (yet).
CREATE INDEX ON :Person(firstname, lastname);
// Direct composite index search on multiple property equality
MATCH (n:Person) WHERE n.firstname = 'Joe' AND n.lastname = 'Soap' RETURN n;
// No use of composite index (yet)
MATCH (n:Person) WHERE n.firstname = 'Joe' AND exists(n.lastname) RETURN n;
MATCH (n:Person) WHERE n.firstname = 'Joe' AND n.lastname STARTS WITH 'Soap' RETURN n;
MATCH (n:Person) WHERE n.firstname = 'Joe' RETURN n;

8. Composite Indexes

9. Reachability Queries - Pruning Var Expand
MATCH (kevin {name:'Kevin Bacon'})-[*1..5]-(actor)
RETURN DISTINCT actor

10. Compiled Runtime
• Coverage
• 50% of Cypher Operators supported
• Cypher Benchmarks Suite 15% supported
• LDBC suite 18% supported
• Does this mean many simple and few complex?
• Performance
• Operators 2x to 20x faster
• Queries … well it depends… let’s say 2x for supported queries

11. Compiled Runtime - Operators

12. Compiled Runtime - Operators

13. Compiled Runtime - LDBC Benchmarks

14. Compiled Runtime

15. Solving OR using Indexes
• Consider AND
MATCH (n:X)
WHERE n.firstName = $first AND n.lastName = $last
RETURN n
• Solved with Index and Filter - FAST
• But what happens with OR
MATCH (n:X)
WHERE n.firstName = $first OR n.lastName = $last
RETURN n
• 3.1: Solved with LabelScan and Filter - SLOW
• 3.2: Solved with two IndexSeeks - FAST

16. Solving OR using indexes

17. Resources
• Compiled Runtime Coverage
Performance Improvements
in Neo4j 3.2
