Compliance, validation, and QA/QC in the real world

1. Data Validation

2. F M E
&
D a t a
Validation

3. A spectrum of data compliance tools
• Schema / Data Model
• Attributes
• CAD / GIS 2D Geometry
• 3D Geometry
• Topology
• Networks
• …
Single Item Validation
GeometryValidator
Comparative Validation
SpatialRelator

4. Compliance Validation QA/QC
- Trust & Verify -

5. Improving Data Compliancy Using
FME
• City or Kitchener, near Toronto.
• Centralized GIS in ESRI SDE
environment.
• Maintain ~400 GIS layers
• User of FME for last ~8 years.
David van Riel
- GIS Technologist -
Full Presentation

6. Digital Submission Compliancy
• CAD Standards Checker
• Attribute Checker*
o Complete attribute data
o Correct attribute data
• Topology Checker*
*Relative Checks
CAD Standards checkers
developed by
• FME reads submitted
AutoCAD Map 3D files
plus Excel files
containing validation
settings.
• Requirements :
1. GIS or AutoCAD, and
text or Excel outputs.
2. Easily customizable
settings for changing
needs.

7. CAD Standards Checker
Key transformer:
• FeatureMerger
CAD Standard

8. CAD Standards Checker
Key transformer:
• StatisticsCalculator
Error Reports

9. Attribute Checker

10. Attribute Checker
Key transformer:
• Joiner

11. Attribute Checker

12. Topology Checker
12 rules:
• node edge snap
• node end snap
• floating node
• duplicate node
• line end snap
• line edge snap
• crossed line
• line end node
• duplicate line
• floating service
• one line two nodes
• both line ends snap

13. Topology Checker
Key transformers:
• Joiner
• NeighbourFinder

14. Loading Data into CoK Database
• After drawing has passed all checkers the
data is ready to be exported from
AutoCAD and loaded into the GIS
database.

15. DigitalSubmission/ DataCompliancy
BENEFITS
• Time saving.
• Accuracy/completeness of data
• Defined deliverables based on
standards
• Everyone is happy!
vs.

16. Validation Workflows on
FME Server
FMEpedia:
Upload & Validate
FME Server

17. Useful links & resources
• Safe blog
The Ultimate Geospatial Data
Validation Checklist
• More great data validation
customer stories at:
safe.com/events
– FME User Conference
– FME World Tours

18. Questions?
